RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

PLP ID	SFI	Modulation	Code Rate	Layer	TI Mode	LLS	Lock	Required SNR	Bitrate
0	0	qpsk	6/15	core	cti	Yes	Yes	AWGN: (-0.54) dB Rayleigh: 0.86 dB	N/A
1	0	qam64	6/15	enhanced	cti	No	Yes	AWGN: 7.66 dB Rayleigh: 9.72 dB	N/A

L1 Signaling Details (From Text File)


--- L1-Basic Signaling ---

L1B_version: 0

L1B_mimo_scattered_pilot_encoding: Walsh-Hadamard

L1B_lls_flag: LLS present

L1B_time_info_flag: ns precision

L1B_return_channel_flag: 0

L1B_papr_reduction: None

L1B_frame_length_mode: Symbol-aligned

  L1B_time_offset: 512

  L1B_additional_samples: 0

L1B_num_subframes: 1

L1B_preamble_num_symbols: 2

L1B_preamble_reduced_carriers: 0

L1B_L1_Detail_content_tag: 0

L1B_L1_Detail_size_bytes: 42

L1B_L1_Detail_fec_type: Mode 1

L1B_L1_additional_parity_mode: K=0

L1B_L1_Detail_total_cells: 3611

L1B_first_sub_mimo: No MIMO

L1B_first_sub_miso: 0

L1B_first_sub_fft_size: 8K

L1B_first_sub_reduced_carriers: 0

L1B_first_sub_guard_interval: GI_6_1536

L1B_first_sub_num_ofdm_symbols: 174

L1B_first_sub_scattered_pilot_pattern: 2

L1B_first_sub_scattered_pilot_boost: 1

L1B_first_sub_sbs_first: 1

L1B_first_sub_sbs_last: 1

L1B_crc: 0x00000000

--- L1-Detail Signaling ---

L1D_version: 0

L1D_num_rf: 0

L1D_time_sec: 1758108497

L1D_time_msec: 322

L1D_time_usec: 48

L1D_time_nsec: 481

Subframe #0:

  L1D_frequency_interleaver: Preamble Only

  L1D_sbs_null_cells: 127

  L1D_num_plp: 2

    PLP #0:

      L1D_plp_id: 0

      L1D_plp_lls_flag: 1

      L1D_plp_layer: Core

      L1D_plp_start: 0

      L1D_plp_size: 1044402

      L1D_plp_scrambler_type: PRBS

      L1D_plp_fec_type: BCH + 64K LDPC

      L1D_plp_mod: QPSK

      L1D_plp_cod: 6/15

      L1D_plp_TI_mode: CTI

      L1D_plp_CTI_fec_block_start: 796404

      L1D_plp_type: non-dispersed

      L1D_plp_TI_extended_interleaving: 0

      L1D_plp_CTI_depth: 3

      L1D_plp_CTI_start_row: 12

      -> PLP Bitrate: 3.321 Mbps

    PLP #1:

      L1D_plp_id: 1

      L1D_plp_lls_flag: 0

      L1D_plp_layer: Enhanced

      L1D_plp_start: 0

      L1D_plp_size: 1044402

      L1D_plp_scrambler_type: PRBS

      L1D_plp_fec_type: BCH + 64K LDPC

      L1D_plp_mod: 64QAM

      L1D_plp_cod: 6/15

      L1D_plp_TI_mode: CTI

      L1D_plp_CTI_fec_block_start: 796404

      L1D_plp_ldm_injection_level: 8

      -> PLP Bitrate: 9.964 Mbps

L1D_crc: 0x55458a85

Link Mapping Table Data Not Available

Service Summary (SLT BSID: 9100)

Service Name	ID	Channel	Protocol / Category	SLS Destination
WIAV	5001	58.1	ROUTE / Linear A/V Service	239.255.58.1:5001
ESG	5002		ROUTE / ESG Service	239.255.58.1:5100
24/7MMT	5006	58.5	MMT / Linear A/V Service	239.255.58.5:5006
DDAAS	5008		ROUTE / App-Based Service	239.255.58.100:6000

Capability Descriptor Table (CDT) - 5 Certificate(s)

Attribute	Value
OCSP Refresh	P7DT0H
Certificate Count	5

Certificate Details

Certificate 1 - WIAV-CD Signaling Signing CDT 0001 (Valid Until: Sep 28 2025)

Field	Value
Subject	/C=US/ST=DC/L=Washington/O=Sinclair Broadcast Group, Inc./CN=WIAV-CD Signaling Signing CDT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	527300F563DD77A4FE99162C2BE20E58EDEF473B
Valid From	Sep 28 16:11:33 2023 GMT
Valid Until	Sep 28 16:11:33 2025 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	05:F6:C8:EB:A2:1A:CD:FB:72:DC:15:DB:5F:57:BF:A6:50:B1:56:1C
SHA-256 Fingerprint	22:40:13:B2:A5:EC:A3:5B:78:29:F8:68:04:23:76:59:1A:4D:95:97:F3:85:14:5E:0C:71:4C:89:4A:07:92:
Certificate Authority	No
Self-Signed	No

Certificate 2 - WIAV-TV Signalling Signing SMT 0001 (Valid Until: Sep 2 2026)

Field	Value
Subject	/C=US/ST=DC/L=Washington/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=WIAV-TV Signalling Signing SMT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	18E519EE704AC89C8EC2FEDC81A985F197DB5839
Valid From	Sep 2 16:54:55 2025 GMT
Valid Until	Sep 2 16:54:55 2026 GMT
Signature Algorithm	sha256WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	BA:4D:03:3C:27:C7:3C:16:23:F6:51:6E:21:B3:1B:30:B2:D9:C4:35
SHA-256 Fingerprint	38:32:A2:AF:CB:D8:98:FC:94:52:99:9E:84:CC:EB:5C:44:54:21:92:97:F5:DA:1E:D9:2B:13:95:74:44:95:
Certificate Authority	No
Self-Signed	No

Certificate 3 - WIAV-CD Signaling Signing SMT 0001 (Valid Until: Sep 28 2025)

Field	Value
Subject	/C=US/ST=DC/L=Washington/O=Sinclair Broadcast Group, Inc./CN=WIAV-CD Signaling Signing SMT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	3B1055E91D1D8891005F1B20AD72399AFDCDC093
Valid From	Sep 28 16:12:33 2023 GMT
Valid Until	Sep 28 16:12:33 2025 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	96:39:9B:01:64:59:F8:67:5A:C9:1B:2D:B5:4E:23:67:18:7F:73:6A
SHA-256 Fingerprint	D4:62:09:3E:12:FA:8D:70:BF:EC:74:24:0E:9B:07:1F:44:19:98:54:C4:F8:1B:91:E0:97:A9:50:31:05:29:
Certificate Authority	No
Self-Signed	No

Certificate 4 - ATSC 3.0 Signing CA-2 (Valid Until: Sep 8 2030)

Field	Value
Subject	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Issuer	/C=US/O=Pearl TV/OU=Root CA-1/CN=ATSC3 Root-CA
Serial Number	1D81C0A269A03D9AAF128428593DB6B8
Valid From	Sep 8 00:00:00 2021 GMT
Valid Until	Sep 8 23:59:59 2030 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	06:63:9A:0C:E9:C0:E7:2C:44:05:1C:8A:91:B6:68:FB:25:C4:38:75
SHA-256 Fingerprint	23:42:5B:1C:CA:CB:F3:31:7C:8B:03:59:DA:E0:A3:98:C4:84:05:DB:1B:6B:92:15:58:69:F7:89:30:9A:65:
Certificate Authority	Yes
Self-Signed	No

Certificate 5 - WIAV-TV Signalling Signing CDT 0001 (Valid Until: Sep 2 2026)

Field	Value
Subject	/C=US/ST=DC/L=Washington/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=WIAV-TV Signalling Signing CDT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	7FD4AB49602157A3FD3265628096F6860E50C121
Valid From	Sep 2 16:54:54 2025 GMT
Valid Until	Sep 2 16:54:54 2026 GMT
Signature Algorithm	sha256WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	62:A0:51:63:67:9D:B9:62:BC:3D:2B:34:16:CD:74:AA:88:B2:2D:D0
SHA-256 Fingerprint	BD:39:38:4C:5D:F1:99:85:DD:86:4C:9A:8B:F1:EF:F9:F2:C0:68:66:55:06:49:6C:BE:22:DF:44:D7:05:35:
Certificate Authority	No
Self-Signed	No

Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<CertificationData xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/CDT-1.0-20180706.xsd">
<ToBeSignedData OCSPRefresh="P7DT0H"><Certificates>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</Certificates><Certificates>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</Certificates><Certificates>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</Certificates><Certificates>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</Certificates><Certificates>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</Certificates><CurrentCert>bjUDaxhkZHfHrHTkPBbB54tBxIo=</CurrentCert></ToBeSignedData>
<CMSSignedData>MIICXgYJKoZIhvcNAQcCoIICTzCCAksCAQMxDTALBglghkgBZQMEAgEwCwYJKoZIhvcNAQcBMYICKDCCAiQCAQOAFBjZZU10Ia1XkKMedJPsjlTKjZ41MAsGCWCGSAFlAwQCAaBpMBgGCSqGSIb3DQEJAzELBgkqhkiG9w0BBwEwHAYJKoZIhvcNAQkFMQ8XDTI1MDkwNzA4MTMyMlowLwYJKoZIhvcNAQkEMSIEILuWNmkKm+RfEnXdJllV42GBTfT3/Ot/ep8nQxD3XjinMA0GCSqGSIb3DQEBAQUABIIBgBPeA4FjhQdrhf2FSgUcphK3U0Ayg+gl36x+C9O/BVmdmyzLRNwSvGgUKbpBnt4jU9/r54vB6rg/B1+Pc69EsYjQjF+gPPOT66YFFOtxGK9Ew1lwOfmoIrQ63nv3bw/th7rsDFMhn3NAzT1oxhGOmnV66PBdP9EKZOMpUxIUCgu4FL5bO1taDgGcH5gUIXT+b8cTtRWs0laylrO3M0+zAeK71unuVp7OFf2M+MvxdLQzcPEw51vwAtj9+KoQv7gl0jmFEVr53b0EITlpNIHakzLd1WXI0CaSbv71Y3lve52VTlKqtOrNnRo4/gUPx8eBEoQykZLQNIf5ahXJj4S7+iMp/opDdp85qNVA1g4PeMyJbs1nxZMUCzDQ0cTyxRWJtZv0yT1wiYxq649x+gT2BpwFeZuR0mcdRpNefI/hFE2kOT8gdJZNz9+8mkhbG6aUpCqVo45YyA5/plwhClP2x6FMvQmwrCqS212ciekVr0k/k3oRP0wsVWDo9Jp34t3ORQ==</CMSSignedData>
<OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse>
</CertificationData>

Service List Table (SLT) Instance 1 - Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<SLT bsid="9100" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SLT/1.0/ SLT-1.0-20211209.xsd">
    <Service globalServiceID="tag:sinclairplatform.com,2021:WIAV:9101" majorChannelNo="58" minorChannelNo="1" serviceCategory="1" serviceId="5001" shortServiceName="WIAV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.58.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="10.252.36.2"/>
    </Service>
    <Service serviceCategory="4" serviceId="5002" shortServiceName="ESG" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.58.1" slsDestinationUdpPort="5100" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="10.252.36.2"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020,247MMT:9109" majorChannelNo="58" minorChannelNo="5" serviceCategory="1" serviceId="5006" shortServiceName="24/7MMT" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.58.5" slsDestinationUdpPort="5006" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="2" slsSourceIpAddress="10.252.36.2"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:broadspanwireless.com,2023:9100:WIAV-CD:9101" hidden="true" hideInGuide="true" serviceCategory="3" serviceId="5008" shortServiceName="DDAAS" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.58.100" slsDestinationUdpPort="6000" slsProtocol="1" slsSourceIpAddress="10.252.36.2"/>
    </Service>
</SLT>

Service 5001: WIAV (58.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 10.252.36.2
Destination: 239.255.58.1:5001

Video: 1920x1080p (29.97 fps)
Codec: hev1.2.4.L120.B0

Audio: 2 ch @ 96 kbps
Codec: ac-4.02.01.00

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2021:WIAV:9101
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.58.1:5001
SLS Source: 10.252.36.2
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5001"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>d3_3-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	1,'TV-14',{0 'TV-14'}
200	a02_2	audio	N/A
300	d3_3	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="2000000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-14',{0 'TV-14'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d3_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d3_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="54"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="229"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="174"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="5"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-07T22:58:03Z)

Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-live:2011

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 2000000 (2.0 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 30000/1001 (29.97 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: d3_3

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT10S" profiles="urn:mpeg:dash:profile:isoff-live:2011" publishTime="2025-09-07T22:58:03Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="30000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="30000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>               <Representation bandwidth="2000000" codecs="hev1.2.4.L120.B0" frameRate="30000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920">            <SegmentTemplate duration="240240" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="a02_2">            <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>            <SegmentTemplate duration="240240" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="subtitle"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d3_3">            <SegmentTemplate duration="240240" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html"   appContextId="tag:sinclairplatform.com,2021:WIAV:9101" ></HTMLEntryPackage>
</HELD>

Service 5002: ESG

Protocol: ROUTE
Category: ESG Service

Source: 10.252.36.2
Destination: 239.255.58.1:5100

Hidden: No
App: No

Service Details (from SLT)

Global Service ID:
Category: 4 (ESG Service)
SLS Destination: 239.255.58.1:5100
SLS Source: 10.252.36.2
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5002"></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: 239.255.58.1:5100

TSI	Representation ID	Content Type	Content Ratings
50			N/A
60			N/A
80			N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="10.252.36.2" dIpAddr="239.255.58.1" dPort="5100"><LS tsi="50"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="1721" Content-Location="sgdd_1721" Content-Length="14222" Transfer-Length="1485" Content-Type="application/vnd.oma.bcast.sgdd+xml" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="60"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="3865" Content-Location="sgdu_content_3865" Content-Length="106156" Transfer-Length="7691" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File><fdt:File TOI="4792" Content-Location="sgdu_service_schedule_4792" Content-Length="18729" Transfer-Length="2031" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="80"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="5966" Content-Location="s102116_ll_h15_ac.png" Content-Length="9117" Transfer-Length="8676" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="11"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="694"></item></metadataEnvelope>

Electronic Service Guide (ESG) - 1 Service(s), 95 Program(s) (from 97 fragments)

Service : WIAV (58.1)

Field	Value
ID	urn:digicap:svc:5001:1757217764920
Status	tag:sinclairpla
Description	WIAV

Raw XML (0 fragments)

Service 5006: 24/7MMT (58.5)

Protocol: MMT
Category: Linear A/V Service

Source: 10.252.36.2
Destination: 239.255.58.5:5006

Video:
Codec: hev1.2.X.L123.X

Audio: 6 ch
Codec: ac-4.02.01.00

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020,247MMT:9109
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.58.5:5006
SLS Source: 10.252.36.2
SLS Protocol Version: 0.0 (MMT)

User Service Bundle Description (USBD) Instance 1

ID	Content Type	Version
5006	UserServiceDescription	1.0

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionMMT xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/MMTUSD/1.0/" xmlns:sa="tag:atsc.org,2016:XMLSchemas/ATSC3/SA/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/MMTUSD/1.0/ MMTUSD-1.0-20210401.xsd"><UserServiceDescription serviceId="5006"><Channel serviceIcon="service_icon"><ServiceDescription serviceDescrText="TBD" serviceDescrLang="en"></ServiceDescription></Channel><MPUComponent mmtPackageId="mmt"></MPUComponent><ComponentInfo componentType="1" componentRole="0" componentProtectedFlag="false" componentId="videoasset01"></ComponentInfo><ComponentInfo componentType="0" componentRole="0" componentProtectedFlag="false" componentId="audioasset02"></ComponentInfo><ComponentInfo componentType="2" componentRole="0" componentProtectedFlag="false" componentId="subtitleasset03"></ComponentInfo></UserServiceDescription></BundleDescriptionMMT>

User Service Description (USD) -

Field	Value
Service ID	5006
MMT Package ID	mmt

Components:

Component ID	Type	Description
videoasset01	1	Main Video
audioasset02	0	Main Audio
subtitleasset03	2	Main Data/Captions

Raw XML

<?xml version="1.0" encoding="UTF-8"?><UserServiceDescription serviceId="5006">
  <Channel serviceIcon="service_icon">
    <ServiceDescription serviceDescrText="TBD" serviceDescrLang="en"/>
  </Channel>
  <MPUComponent mmtPackageId="mmt"/>
  <ComponentInfo componentType="1" componentRole="0" componentProtectedFlag="false" componentId="videoasset01"/>
  <ComponentInfo componentType="0" componentRole="0" componentProtectedFlag="false" componentId="audioasset02"/>
  <ComponentInfo componentType="2" componentRole="0" componentProtectedFlag="false" componentId="subtitleasset03"/>
</UserServiceDescription>

MMT Signaling (MP Table - Binary)

Binary MMT Package Table

Asset ID	Asset Type	Codec	Packet ID
videoasset01	hev1	HEVC/H.265	100
audioasset02	ac-4	AC-4 Audio	200
subtitleasset03	stpp	TTML Subtitles	300

MMT Stream Descriptors Instance 1

Video Stream Properties Descriptor (VSPD)

Codec: hev1.2.2.L123.B (HEVC/H.265)
HEVC Profile: Main 10 (supports 10-bit color depth for HDR content)
HEVC Level: 4.1 (defines maximum resolution, frame rate, and bitrate capabilities)
Tier: Main (Main tier: standard bitrates, High tier: allows higher bitrates)
Scan Type: Progressive (full frames, better quality)

Audio Stream Properties Descriptor (ASPD)

Codec: ac-4 (Dolby AC-4 - next-generation audio codec)
Language: en
Presentations: 1 (separate audio mixes, e.g., main, commentary, descriptive)
Sample Rate: 48000 Hz

Caption Asset Descriptor (CAD)

Caption Track 1:
- Language: en
- Role: main (primary captions)
- Aspect Ratio: 16:9
- Profile: text (text-based captions)

Service 5008: DDAAS

Protocol: ROUTE
Category: App-Based Service

Source: 10.252.36.2
Destination: 239.255.58.100:6000

Hidden: Service & Guide
App: No

Service Details (from SLT)

Global Service ID: tag:broadspanwireless.com,2023:9100:WIAV-CD:9101
Category: 3 (App-Based Service)
SLS Destination: 239.255.58.100:6000
SLS Source: 10.252.36.2
SLS Protocol Version: . (ROUTE)
Hidden: Yes
Hide in Guide: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5008"></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
1000			N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="10.252.36.2"><LS tsi="1000"><SrcFlow><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="8"></item><item metadataURI="dwd.dwd" contentType="application/atsc-dwd+xml" version="1"></item></metadataEnvelope>

Dynamic Window Description (DWD) Instance 1

Raw XML

<?xml version="1.0" encoding="UTF-8"?><DWD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/DWD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/DWD/1.0/ DWD-1.0-20180830.xsd"><DistributionWindow startTime="2025-08-24T14:43:19Z" endTime="2025-08-24T14:49:26Z" lctTSIRef="1001" contentLabel="2"><AppContextId>http://ddaas.broadspan.com</AppContextId></DistributionWindow></DWD>

Other Global LLS Tables

System Time Details - Actual Timestamp in L1Detail

Attribute	Value
currentUtcOffset	37
utcLocalOffset	-PT4H
dsStatus	false

Raw XML

<?xml version="1.0" encoding="utf-8"?>
<SystemTime xmlns="http://www.atsc.org/XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/ SYSTIME-1.0-20211208.xsd" currentUtcOffset="37" utcLocalOffset="-PT4H" dsStatus="false"/>

Unlinked User Defined Service Table (UDST)

BroadSpan Service: DDAAS

Reservation Name: RTK
Service ID in UDST: 5004
Destination: 239.255.58.103:6123
Order ID: 2025-08-20-RTK-Route-4

Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<UDST version="0.1">
    <UDS>
        <broadSpanServices>
            <broadSpanService name="DDAAS">
                <rsrv apiKey="" callbackUrl="" destIP="239.255.58.103" destPort="6123" mktid="" name="RTK" orderId="2025-08-20-RTK-Route-4" srvid="5004"/>
            </broadSpanService>
        </broadSpanServices>
    </UDS>
</UDST>

Input Info

Attribute	Value
Input Type	PCAP File
File Name	168063-0-20250907-185804-p0p1-ipv4.pcap
Total Packets Processed	2301
Capture Duration	2.9 seconds
File Last Modified	2025-09-07 18:58:08 EDT
Analysis Run Time	2025-11-23 16:15:16 EST

ATSC 3.0 Data Usage Analysis

IP:Port (ID)	Usage ↓	Service	Type	Total Data	Bitrate
239.255.58.4:5004	24.75%	Unknown Service	Other UDP	923.0 KB	2.54 Mbps
239.255.58.5:5006 (PID 32515)	21.70%	24/7MMT	Data/Captions	808.9 KB	2.23 Mbps
239.255.58.5:5006 (PID 100)	20.29%	24/7MMT	Video	756.5 KB	2.08 Mbps
239.255.58.1:5001 (TSI 100)	16.40%	WIAV	Video	611.6 KB	1.68 Mbps
239.255.58.1:5001 (TSI 0)	4.52%	WIAV	Service Signaling	168.6 KB	463.9 Kbps
239.255.58.5:5006 (PID 0)	4.22%	24/7MMT	Service Signaling	157.4 KB	433.1 Kbps
224.0.23.60:4937 (LLS)	1.83%	LLS Signaling	LLS Signaling	68.1 KB	187.5 Kbps
239.255.58.1:5100 (TSI 80)	1.22%	ESG	ROUTE Media	45.7 KB	125.7 Kbps
239.255.58.5:5006 (PID 200)	1.07%	24/7MMT	Audio	39.8 KB	109.6 Kbps
239.255.58.1:5100 (TSI 0)	0.92%	ESG	Service Signaling	34.5 KB	94.9 Kbps
239.255.58.1:5001 (TSI 200)	0.92%	WIAV	Audio	34.1 KB	93.9 Kbps
239.255.58.103:6123	0.51%	Unknown Service	Other UDP	19.0 KB	52.4 Kbps
239.255.58.100:6000 (TSI 0)	0.50%	DDAAS	Service Signaling	18.5 KB	51.0 Kbps
239.255.58.1:5100 (TSI 50)	0.41%	ESG	ROUTE Media	15.3 KB	42.2 Kbps
239.255.58.1:5100 (TSI 60)	0.38%	ESG	ROUTE Media	14.3 KB	39.3 Kbps
239.255.58.5:5006 (PID 300)	0.22%	24/7MMT	stpp	8.3 KB	23.0 Kbps
239.255.58.1:5001 (TSI 300)	0.13%	WIAV	Captions	4.8 KB	13.2 Kbps

Total: 3.73 MB | Signaling: 11.99% | Media: 62.74% | Other: 25.26%

RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

Service Summary (SLT BSID: 9100)

Certificate Details

Service 5001: WIAV (58.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: d3_3

Raw XML

Raw XML

Service 5002: ESG

Raw XML

ROUTE Stream: 239.255.58.1:5100

Raw XML

Raw XML

Service 5006: 24/7MMT (58.5)

Raw XML

Components:

Raw XML

Binary MMT Package Table

Video Stream Properties Descriptor (VSPD)

Audio Stream Properties Descriptor (ASPD)

Caption Asset Descriptor (CAD)

Service 5008: DDAAS Hidden

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Raw XML

Other Global LLS Tables

BroadSpan Service: DDAAS

Input Info

ATSC 3.0 Data Usage Analysis

Service 5008: DDAAS
