RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

PLP ID	SFI	Modulation	Code Rate	Layer	TI Mode	LLS	Lock	Required SNR	Bitrate
0	0	qam16	9/15	core	hti	Yes	Yes	AWGN: 7.32-7.58 dB Rayleigh: 9.94-10.28 dB	N/A
1	0	qam256	11/15	core	hti	Yes	Yes	AWGN: 18.76-19.08 dB Rayleigh: 21.94-22.40 dB	N/A

L1 Detail Information Not Available

Link Mapping Table Data Not Available

Service Summary (SLT BSID: 9234)

Service Name	ID	Channel	Protocol / Category	SLS Destination
WWHB-CD	5001	48.1	ROUTE / Linear A/V Service	239.255.48.1:5001
ESG	5002		ROUTE / ESG Service	239.255.48.1:5100
WPEC	5003	12.1	ROUTE / Linear A/V Service	239.255.12.1:5001
WPTV	5004	5.1	ROUTE / Linear A/V Service	239.255.5.1:5001
WFLX	5005	29.1	ROUTE / Linear A/V Service	239.255.29.1:5001
WPBF	5006	25.1	ROUTE / Linear A/V Service	239.255.25.1:5001
T2	5007	12.10	ROUTE / Linear A/V Service	239.255.12.10:5000
DDAAS	5008		ROUTE / App-Based Service	239.255.48.100:6000
PBTV	5009	12.11	ROUTE / Linear A/V Service	239.255.12.11:5000
GMLOOP	5010	12.20	ROUTE / App-Based Service	239.255.12.20:5000

Capability Descriptor Table (CDT) - 3 Certificate(s)

Attribute	Value
OCSP Refresh	P7DT0H
Certificate Count	3

Certificate Details

Certificate 1 - WWHB-CD Signaling Signing SMT 0001 (Valid Until: Oct 12 2025)

Field	Value
Subject	/C=US/ST=FL/L=West Palm Beach/O=Sinclair Broadcast Group, Inc./CN=WWHB-CD Signaling Signing SMT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	2BFCB234C03199A1B930DA5560EB94EED2A34CB8
Valid From	Oct 12 19:50:43 2023 GMT
Valid Until	Oct 12 19:50:43 2025 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	EA:02:B7:DD:60:19:24:41:5E:B1:E7:AA:F8:DF:64:78:B8:34:FF:84
SHA-256 Fingerprint	7B:D0:CB:E0:D5:E7:9E:F8:7D:27:A7:CD:9D:FB:B2:0B:E2:C0:0E:D1:64:BE:70:71:93:EB:8B:0D:F5:60:6B:
Certificate Authority	No
Self-Signed	No

Certificate 2 - ATSC 3.0 Signing CA-2 (Valid Until: Sep 8 2030)

Field	Value
Subject	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Issuer	/C=US/O=Pearl TV/OU=Root CA-1/CN=ATSC3 Root-CA
Serial Number	1D81C0A269A03D9AAF128428593DB6B8
Valid From	Sep 8 00:00:00 2021 GMT
Valid Until	Sep 8 23:59:59 2030 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	06:63:9A:0C:E9:C0:E7:2C:44:05:1C:8A:91:B6:68:FB:25:C4:38:75
SHA-256 Fingerprint	23:42:5B:1C:CA:CB:F3:31:7C:8B:03:59:DA:E0:A3:98:C4:84:05:DB:1B:6B:92:15:58:69:F7:89:30:9A:65:
Certificate Authority	Yes
Self-Signed	No

Certificate 3 - WWHB-CD Signaling Signing CDT 0001 (Valid Until: Oct 12 2025)

Field	Value
Subject	/C=US/ST=FL/L=West Palm Beach/O=Sinclair Broadcast Group, Inc./CN=WWHB-CD Signaling Signing CDT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	1AE9322D53F4DBCE75F26D253C7385B2166D962B
Valid From	Oct 12 19:49:47 2023 GMT
Valid Until	Oct 12 19:49:47 2025 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	2E:82:81:63:57:80:6B:DF:F4:49:BD:40:2F:9E:65:24:A9:10:A0:B9
SHA-256 Fingerprint	90:EE:56:DF:86:FE:F5:92:50:B2:F5:93:A9:7E:6E:1F:EF:14:7B:37:1C:71:2F:D4:3D:EB:56:F4:F0:74:6D:
Certificate Authority	No
Self-Signed	No

Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<CertificationData xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/CDT-1.0-20180706.xsd">
<ToBeSignedData OCSPRefresh="P7DT0H"><Certificates>MIIFwTCCBCmgAwIBAgIUK/yyNMAxmaG5MNpVYOuU7tKjTLgwDQYJKoZIhvcNAQENBQAwcDELMAkGA1UEBhMCVVMxKDAmBgNVBAoTH0FUU0MgMy4wIFNlY3VyaXR5IEF1dGhvcml0eSBMTEMxFzAVBgNVBAsTDlNpZ25pbmcgQ0EtREMxMR4wHAYDVQQDExVBVFNDIDMuMCBTaWduaW5nIENBLTIwHhcNMjMxMDEyMTk1MDQzWhcNMjUxMDEyMTk1MDQzWjCBijELMAkGA1UEBhMCVVMxCzAJBgNVBAgTAkZMMRgwFgYDVQQHEw9XZXN0IFBhbG0gQmVhY2gxJzAlBgNVBAoTHlNpbmNsYWlyIEJyb2FkY2FzdCBHcm91cCwgSW5jLjErMCkGA1UEAxMiV1dIQi1DRCBTaWduYWxpbmcgU2lnbmluZyBTTVQgMDAwMTCCAaIwDQYJKoZIhvcNAQEBBQADggGPADCCAYoCggGBANUIFysp3MKVl8ol/hmtRp1/deREmVi0N9wHwWFajhLAfg2jPEmhGHpMxTHoBcGZ79UEZbcWB2CNH2tGIPnHt1xUBgBctVEjVjOI9ijwxou8VJnDgsVkqnteW+qPCRRRUXR3NbOJlhJEIsMgLxEkPszhbktBrnYyUty/W+qRXwmU/S7uZU0sBzznl+noJ3AD0PmAt5yHO5o+3z+SFxuG5d0NJ+JB0cCWfDoVCGsv2jl4HjxxQmNoO+SJHheq5cslMAZ/cM5USj0MK2pQnsxh9GI2rQECk3aoxYaAIHMqDw95F5lvqHZDwiPHnXcaJbC/BeeNO93T2w+54I0a+Q5WfrWNh9AD9N5yucZp+UjXdufs8k12OqjvinjEv2fNENVZVaNiWFb8BOYKx8YF7pI1a+QtIWjc6KJZ/8ADbnW823X8ocSkK6ku5LJWo0TfCi4XPKU4fEUGI7le3luP+0XENdCoNwzlVz3V6COiyfyU6AlgE3NmzzuPh6nN8d/+/RotrQIDAQABo4IBNjCCATIwDAYDVR0TAQH/BAIwADAdBgNVHQ4EFgQUQLbTi8H/VeKu/MgUPoMgykRgRwQwHwYDVR0jBBgwFoAUoN79JJBZSAIhlyd/4ZY74oFoxrYwDgYDVR0PAQH/BAQDAgeAMBgGA1UdJQEB/wQOMAwGCisGAQQBg5JgJQMwOAYIKwYBBQUHAQEELDAqMCgGCCsGAQUFBzABhhxodHRwOi8vb2NzcC5vbmUuZGlnaWNlcnQuY29tMEMGA1UdHwQ8MDowOKA2oDSGMmh0dHA6Ly9jcmwub25lLmRpZ2ljZXJ0LmNvbS9BVFNDMy4wU2lnbmluZ0NBLTIuY3JsMBoGA1UdIAEB/wQQMA4wDAYKKwYBBAGDlGMCATAdBgNVHQkEFjAUMBIGCisGAQQBg5JgCQExBAICJBIwDQYJKoZIhvcNAQENBQADggGBAFchQF9dJNceb6nPVdilguvjAydbvHSFrhOyDMVBsrNVhA2qDXuhWwkzK2G3AaxvgKU3U6M7L3lZg7Vru4kzytppJ8mZvL4tRpiNCqNWHw90YE0TXOoM7v3B7yS06HEkds3/dRZ6NAC9MHQKOtu2IVc1cug1Fz6iuUOe+2eA5P03E+byYEQwYvN3+UyKXlmCTumMdUqJeeKT9RA2S2RVcPero7vDc1teChLXaFrs/PtCLIJYSK+4xydiwKSuT96ZZmQK9CvWqlHFAoCwDB1ETg2JuN93nC15UXrXX7Wc+naU2SG2YTKeiJITDOLHIAlr4iaY4ANzFsatjoCDZ5cOECb0KHsa3/1fyre1E7ZAbdN7W39lnf5YtfA598aE+mjsIKidumkXC8eAitrOPHbFMTqpJPDO1CE4e8j6DobF65dK1a9hWnBsC9Gn5JKGcRpSMyH2Y0RlmlKsGLZdPmqilnznTkudc4u/V/faOLFqrIc/3x/A9BvuFgGLHrPNmlrHug==</Certificates><Certificates>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</Certificates><Certificates>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</Certificates><CurrentCert>QLbTi8H/VeKu/MgUPoMgykRgRwQ=</CurrentCert></ToBeSignedData>
<CMSSignedData>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</CMSSignedData>
<OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse>
</CertificationData>

Service List Table (SLT) Instance 1 - Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<SLT bsid="9234" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SLT/1.0/ SLT-1.0-20211209.xsd">
    <Service globalServiceID="tag:sinclairplatform.com,2022:WWHB-CD:9235" majorChannelNo="48" minorChannelNo="1" serviceCategory="1" serviceId="5001" shortServiceName="WWHB-CD" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.48.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service serviceCategory="4" serviceId="5002" shortServiceName="ESG" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.48.1" slsDestinationUdpPort="5100" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2022:WPEC:725" majorChannelNo="12" minorChannelNo="1" serviceCategory="1" serviceId="5003" shortServiceName="WPEC" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.12.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/B601-BA85" majorChannelNo="5" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5004" shortServiceName="WPTV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.5.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/8C1E-06E2" majorChannelNo="29" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5005" shortServiceName="WFLX" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.29.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/A88E-612C" majorChannelNo="25" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5006" shortServiceName="WPBF" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.25.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:T2:WPEC" majorChannelNo="12" minorChannelNo="10" serviceCategory="1" serviceId="5007" shortServiceName="T2" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.12.10" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:broadspanwireless.com,2023:9234:WWHB-CD:9235" serviceCategory="3" serviceId="5008" shortServiceName="DDAAS" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.48.100" slsDestinationUdpPort="6000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:PBTV:WPEC" majorChannelNo="12" minorChannelNo="11" serviceCategory="1" serviceId="5009" shortServiceName="PBTV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.12.11" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:sinclairplatform.com,2020:Gameloop:WPEC" majorChannelNo="12" minorChannelNo="20" serviceCategory="3" serviceId="5010" shortServiceName="GMLOOP" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.12.20" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
</SLT>

Service 5001: WWHB-CD (48.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.48.1:5001

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 16 ch @ 192 kbps
Codec: ac-4.02.01.02

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2022:WWHB-CD:9235
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.48.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5001"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>d3_3-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	1,'TV-PG',{0 'TV-PG'}
200	a02_2	audio	N/A
300	d3_3	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4000000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-PG',{0 'TV-PG'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="192000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d3_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d3_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="23"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="75"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="215"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="2"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-02-22T19:18:49Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4000000 (4.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 192000 (192 kbps)
Codecs: ac-4.02.01.02
Audio Sample Rate: 48000 Hz
Audio Channels: 16
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d3_3

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT20.02S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-02-22T19:18:49Z" timeShiftBufferDepth="PT12.012S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="4000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>               <Representation audioSamplingRate="48000" bandwidth="192000" codecs="ac-4.02.01.02" id="a02_2"/></AdaptationSet><AdaptationSet contentType="text" id="2" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d3_3"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html" appContextId="tag:sinclairplatform.com,2022:WWHB-CD:9235" />
</HELD>

Service 5002: ESG

Protocol: ROUTE
Category: ESG Service

Source: 172.16.200.1
Destination: 239.255.48.1:5100

Hidden: No
App: No

Service Details (from SLT)

Global Service ID:
Category: 4 (ESG Service)
SLS Destination: 239.255.48.1:5100
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5002"></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: 239.255.48.1:5100

TSI	Representation ID	Content Type	Content Ratings
50			N/A
60			N/A
80			N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1" dIpAddr="239.255.48.1" dPort="5100"><LS tsi="50"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="1005" Content-Location="sgdd_1005" Content-Length="60763" Transfer-Length="6058" Content-Type="application/vnd.oma.bcast.sgdd+xml" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="60"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="3508" Content-Location="sgdu_content_3508" Content-Length="416676" Transfer-Length="41792" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File><fdt:File TOI="4319" Content-Location="sgdu_service_schedule_4319" Content-Length="82513" Transfer-Length="7097" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="80"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="5776" Content-Location="s102116_ll_h15_ab.png" Content-Length="4217" Transfer-Length="3393" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5777" Content-Location="s28711_h3_ba.png" Content-Length="9147" Transfer-Length="8388" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5778" Content-Location="s28717_h3_ba.png" Content-Length="12443" Transfer-Length="11419" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5779" Content-Location="s28719_ll_h15_ac.png" Content-Length="8623" Transfer-Length="8259" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5780" Content-Location="s28708_h3_aa.png" Content-Length="15267" Transfer-Length="15136" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="3"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="4312"></item></metadataEnvelope>

Electronic Service Guide (ESG) - 5 Service(s), 451 Program(s) (from 461 fragments)

Service : WPBF (25.1)

Field	Value
ID	urn:digicap:svc:5006:1740208812921
Status	https://doi.org
Description	WPBF

Raw XML (0 fragments)

Service : WFLX (29.1)

Field	Value
ID	urn:digicap:svc:5005:1740208812921
Status	https://doi.org
Description	WFLX

Raw XML (0 fragments)

Service : WPTV (5.1)

Field	Value
ID	urn:digicap:svc:5004:1740208812921
Status	https://doi.org
Description	WPTV

Raw XML (0 fragments)

Service : WPEC (12.1)

Field	Value
ID	urn:digicap:svc:5003:1740208812921
Status	tag:sinclairpla
Description	WPEC

Raw XML (0 fragments)

Service : WWHB-CD (48.1)

Field	Value
ID	urn:digicap:svc:5001:1740208812921
Status	tag:sinclairpla
Description	WWHB-CD

Raw XML (0 fragments)

Service 5003: WPEC (12.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.12.1:5001

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 16 ch @ 192 kbps
Codec: ac-4.02.01.02

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2022:WPEC:725
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.12.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5003"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4700000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="192000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="21"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="50"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="99"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="2"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-02-22T19:19:01Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4700000 (4.7 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 192000 (192 kbps)
Codecs: ac-4.02.01.02
Audio Sample Rate: 48000 Hz
Audio Channels: 16
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT20.02S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-02-22T19:19:01Z" timeShiftBufferDepth="PT12.012S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="4700000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>               <Representation audioSamplingRate="48000" bandwidth="192000" codecs="ac-4.02.01.02" id="a02_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <SegmentTemplate duration="480480" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html" appContextId="tag:sinclairplatform.com,2022:WPEC:725" />
</HELD>

Service 5004: WPTV (5.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.5.1:5001

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: https://doi.org/10.5239/B601-BA85
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.5.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Protected: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5004"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4800000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="25"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="30"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="215"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="2"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-02-22T19:18:45Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4800000 (4.8 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wptv_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wptv_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wptv_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT20.02S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-02-22T19:18:45Z" timeShiftBufferDepth="PT12.012S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="0c450114-4db7-5d20-8f0f-d0a3000d52e6" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="0c450114-4db7-5d20-8f0f-d0a3000d52e6" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>AAAASnBzc2gAAAAA7e+LqXnWSs6jyCfc1R0h7QAAACoiDHdwdHZfZzJfcDJfMUjj3JWbBmoUYXRzY19ncm91cDJfcHJvZmlsZTIAAAJocHNzaAAAAADt74upedZKzqPIJ9zVHSHtAAACSCIMd3B0dl9nMl9wMl8xSOPclZsGWAJqFGF0c2NfZ3JvdXAyX3Byb2ZpbGUyclgKEFD0qTWm5FqUqgDEtdurTYYSEAxFARRNt10gjw/QowANUuYaIBTMxPpVFDEcSJdsbANCJgg5eP6r4OpNKTF8+bM/3p6jIhBy+IVmdGPKB6QTD+F3ifINclgKEMtonnMvM1NbiAzYoZigpGUSEAxFARRNt10gjw/QowANUuYaIGwPz7sZTIpJi5xe73JzsFQ2fB+7e0tmDgVX2iboP90TIhA+QsRAv1CsxfcqGHJfGmp+clgKEBAOUqas8V3VvG2INzH5cpwSEGCPzUVeYVw4sWDempzGHg4aICQJ/+iG+PHwr4DikyEaPMJPjw5kcXkYv/EnwMDaANjoIhDmzEv4Ydk1PC0YaYqb+Vb4clgKEAqxnRcP+VBvjQwDq2QUA5QSEGCPzUVeYVw4sWDempzGHg4aIKctOrDmCYdY/s89aUEhhd0jCch3sYuWdk6ouyAqU3pPIhDTDtSNvvbAn1Oy0Hat2lGIclgKEPIL+VfLKFo8lLCE610LMAwSEANomyrO5lvOsBU2u+9WfB0aIHHX3jP1JyGy0uqnu+POpOddxxfBRh8P7c48x5tkd2oGIhACRaSkG0RWhjizvn7vJen9clgKEHg5LB43JVKIjuApVhHyY3wSEANomyrO5lvOsBU2u+9WfB0aIH6NbMIr1a2cbU/qBRoToF3oq8GY838WyhAOjHm7uaBXIhAfg8t3lxcH2e5VHioQXlT9</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wptv_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <Supplemental schemeIdUri="http://dashif.org/metadata/hdr" value="SMPTE2094-10"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="4800000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" segmentProfiles="cdm1" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="0c450114-4db7-5d20-8f0f-d0a3000d52e6" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="0c450114-4db7-5d20-8f0f-d0a3000d52e6" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wptv_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a02_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="0c450114-4db7-5d20-8f0f-d0a3000d52e6" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="0c450114-4db7-5d20-8f0f-d0a3000d52e6" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wptv_g2_p2_1</dashif:Laurl>         </ContentProtection>         <SegmentTemplate duration="480480" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://wptv-atsc3.scrippscloud.com/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage
      appContextId="tv:ota-wptv.ewscloud.com"
      bbandEntryPageUrl="https://wptv-atsc3.scrippscloud.com/run3tv-common/index.html" >
  </HTMLEntryPackage>
</HELD>

Service 5005: WFLX (29.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.29.1:5001

Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: https://doi.org/10.5239/8C1E-06E2
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.29.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Protected: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5005"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-4800000-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4800000" afdt:fileTemplate="video-4800000-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-4800000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="26"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="148"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="159"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-02-22T19:18:49Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-live:2011

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4800000 (4.8 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-$Bandwidth$-init.mp4
- Media URL: video-$Bandwidth$-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wflx_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wflx_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wflx_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT20.02S" profiles="urn:mpeg:dash:profile:isoff-live:2011" publishTime="2025-02-22T19:18:49Z" timeShiftBufferDepth="PT12.012S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="b852a8b6-e02a-589c-8c50-2001ef2a6085" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="b852a8b6-e02a-589c-8c50-2001ef2a6085" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wflx_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-$Bandwidth$-init.mp4" media="video-$Bandwidth$-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="4800000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="b852a8b6-e02a-589c-8c50-2001ef2a6085" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="b852a8b6-e02a-589c-8c50-2001ef2a6085" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wflx_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a02_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="b852a8b6-e02a-589c-8c50-2001ef2a6085" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="b852a8b6-e02a-589c-8c50-2001ef2a6085" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wflx_g2_p2_1</dashif:Laurl>         </ContentProtection>         <SegmentTemplate duration="480480" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://atsc-v2.gdm-connect.com/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tv:wflx.gray.tv" bbandEntryPageUrl="https://atsc-v2.gdm-connect.com/run3tv-common/index.html"></HTMLEntryPackage>
</HELD>

Service 5006: WPBF (25.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.25.1:5001

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: https://doi.org/10.5239/A88E-612C
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.25.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Protected: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5006"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4800000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="23"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="243"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="101"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="2"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-02-22T19:18:55Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4800000 (4.8 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wpbf_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wpbf_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wpbf_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT20.02S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-02-22T19:18:55Z" timeShiftBufferDepth="PT12.012S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="831e08e3-9f46-5101-9c68-e22ebfba5a87" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="831e08e3-9f46-5101-9c68-e22ebfba5a87" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>AAAASnBzc2gAAAAA7e+LqXnWSs6jyCfc1R0h7QAAACoiDHdwYmZfZzJfcDJfMUjj3JWbBmoUYXRzY19ncm91cDJfcHJvZmlsZTIAAAJocHNzaAAAAADt74upedZKzqPIJ9zVHSHtAAACSCIMd3BiZl9nMl9wMl8xSOPclZsGWAJqFGF0c2NfZ3JvdXAyX3Byb2ZpbGUyclgKEMDrbQHxglPjheJ0siR40MwSEIMeCOOfRlEBnGjiLr+6WocaICyDO6r5QhLetwuLsedjVWIsohkKmiELKxjWCFXwi5WKIhCZpDGvDrYIpJcLbiu1BqsyclgKEMtonnMvM1NbiAzYoZigpGUSEIMeCOOfRlEBnGjiLr+6WocaIHwl3CzbqN/H+UI1jHyhL2OxuP35qtT6UqZ2Nx7iy62MIhDYbZack9IYR/bUbEGFK/EfclgKEKySZjVWHVdeht1aboFxzsMSEFXS80zCAFGMrAuM4ojGpfMaILnKwe+F1DEv+Jm7HgD1/378s5G85qIyBafaHXJfahTKIhBF04/2s0LYwHaPVNX5VRVeclgKEAqxnRcP+VBvjQwDq2QUA5QSEFXS80zCAFGMrAuM4ojGpfMaIGKq2b4qPFlaUXRf7MyZlrUlpkqiwxpBezNO47jApnuCIhDekygsZYoVCriBfuKzlDI1clgKEHRSSNLRu1S2h4Xf3E1JhRkSEN+3EajdCFDnonJI/RCAyPgaIOSdVKJ6iWJZ40elYoLuBi6hsqmgvaEH7MWnPEsobI/vIhDRBze6eWtXOAWgl/TQabY+clgKEHg5LB43JVKIjuApVhHyY3wSEN+3EajdCFDnonJI/RCAyPgaIP3ORuSNRAwq75ZThGL2iOXQcPGtZ06OjZaAMtXlRvkBIhCFgT+IoziPaA6XiPZBmuce</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wpbf_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="4800000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="831e08e3-9f46-5101-9c68-e22ebfba5a87" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="831e08e3-9f46-5101-9c68-e22ebfba5a87" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wpbf_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a02_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="831e08e3-9f46-5101-9c68-e22ebfba5a87" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="831e08e3-9f46-5101-9c68-e22ebfba5a87" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wpbf_g2_p2_1</dashif:Laurl>         </ContentProtection>         <SegmentTemplate duration="480480" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://atsc-ec2.htvapps.net/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage
      appContextId="tv:atsc3-app.wpbf.hearst.com"
      bbandEntryPageUrl="https://atsc-ec2.htvapps.net/run3tv-common/index.html" ></HTMLEntryPackage>
</HELD>

Service 5007: T2 (12.10)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.12.10:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 2 ch @ 192 kbps
Codec: ac-4.02.01.00

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:T2:WPEC
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.12.10:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5007"><DeliveryMethod><UnicastAppService><BasePattern>a0-22-</BasePattern><BasePattern>d0-Data3_3-</BasePattern><BasePattern>video-Video1_1-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="6"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="11"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-02-22T19:19:00Z)

Type: dynamic
Min Buffer Time: PT10S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 7000000 (7.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=417660450567360, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 192000 (192 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 240000
- S: t=417660450567360, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_3

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 240000
- S: t=417660450567360, d=480480, r=29

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-02-22T19:19:00Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://ipc.atsc3.com/T2/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="417660450567360"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="7000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="417660450567360"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="192000" codecs="ac-4.02.01.00" id="22"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="417660450567360"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_3"/></AdaptationSet>   </Period></MPD>

Service 5008: DDAAS

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.48.100:6000

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:broadspanwireless.com,2023:9234:WWHB-CD:9235
Category: 3 (App-Based Service)
SLS Destination: 239.255.48.100:6000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5008"></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item></metadataEnvelope>

Service 5009: PBTV (12.11)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.12.11:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 2 ch @ 384 kbps
Codec: ac-4.02.01.00

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:PBTV:WPEC
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.12.11:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5009"><DeliveryMethod><UnicastAppService><BasePattern>a0-24-</BasePattern><BasePattern>d0-Data3_5-</BasePattern><BasePattern>video-Video1_1-</BasePattern><BasePattern>video-Video1_2-</BasePattern><BasePattern>video-Video1_3-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="2"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="130"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-02-22T19:19:00Z)

Type: dynamic
Min Buffer Time: PT10S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_3

Bandwidth: 1000000 (1000 kbps)
Codecs: hev1.2.4.L93.B0
Resolution: 960x540 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=417660450567360, d=480480, r=29

Representation ID: Video1_2

Bandwidth: 4000000 (4.0 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=417660450567360, d=480480, r=29

Representation ID: Video1_1

Bandwidth: 8000000 (8.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=417660450567360, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 24

Bandwidth: 384000 (384 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 240000
- S: t=417660450567360, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_5

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 240000
- S: t=417660450567360, d=480480, r=29

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-02-22T19:19:00Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://wpec-sbgtv.atsc.stream/pickleball/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="540" minWidth="960" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="417660450567360"/>            </SegmentTimeline>         </SegmentTemplate>                                 <Representation bandwidth="1000000" codecs="hev1.2.4.L93.B0" frameRate="60000/1001" height="540" id="Video1_3" sar="1:1" scanType="progressive" width="960"/><Representation bandwidth="4000000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_2" sar="1:1" scanType="progressive" width="1280"/><Representation bandwidth="8000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="417660450567360"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.00" id="24"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="417660450567360"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_5"/></AdaptationSet>   </Period></MPD>

Service 5010: GMLOOP (12.20)

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.12.20:5000

Hidden: No
App: GameLoop

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:Gameloop:WPEC
Category: 3 (App-Based Service)
SLS Destination: 239.255.12.20:5000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5010"></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://nextgen.gameloop.tv/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tag:sinclairplatform.com,2020:Gameloop:WPEC" bbandEntryPageUrl="https://nextgen.gameloop.tv/run3tv-common/index.html"></HTMLEntryPackage>
</HELD>

Other Global LLS Tables

System Time Details - Actual Timestamp in L1Detail

Attribute	Value
currentUtcOffset	37
utcLocalOffset	-PT5H
dsStatus	false

Raw XML

<?xml version="1.0" encoding="utf-8"?>
<SystemTime xmlns="http://www.atsc.org/XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/ SYSTIME-1.0-20211208.xsd" currentUtcOffset="37" utcLocalOffset="-PT5H" dsStatus="false"/>

Input Info

Attribute	Value
Input Type	PCAP File
File Name	63557-0-20250222-141903-p0p1-ipv4.pcap
Total Packets Processed	97478
Capture Duration	42.2 seconds
File Last Modified	2025-02-22 14:19:03 EST
Analysis Run Time	2025-11-23 16:15:27 EST

ATSC 3.0 Data Usage Analysis

IP:Port (ID)	Usage ↓	Service	Type	Total Data	Bitrate
239.255.5.1:5001 (TSI 100)	18.76%	WPTV	Video	25.86 MB	4.91 Mbps
239.255.29.1:5001 (TSI 100)	18.70%	WFLX	Video	25.79 MB	4.89 Mbps
239.255.25.1:5001 (TSI 100)	18.62%	WPBF	Video	25.67 MB	4.87 Mbps
239.255.12.1:5001 (TSI 100)	18.21%	WPEC	Video	25.11 MB	4.76 Mbps
239.255.48.1:5001 (TSI 100)	15.50%	WWHB-CD	Video	21.37 MB	4.06 Mbps
224.0.23.60:4937 (LLS)	1.10%	LLS Signaling	LLS Signaling	1.52 MB	287.6 Kbps
239.255.5.1:5001 (TSI 0)	0.88%	WPTV	Service Signaling	1.21 MB	229.8 Kbps
239.255.29.1:5001 (TSI 0)	0.87%	WFLX	Service Signaling	1.20 MB	228.2 Kbps
239.255.25.1:5001 (TSI 0)	0.87%	WPBF	Service Signaling	1.20 MB	227.9 Kbps
239.255.12.1:5001 (TSI 200)	0.77%	WPEC	Audio	1.06 MB	201.2 Kbps
239.255.48.1:5001 (TSI 200)	0.77%	WWHB-CD	Audio	1.06 MB	201.0 Kbps
239.255.12.1:5001 (TSI 0)	0.58%	WPEC	Service Signaling	795.6 KB	151.0 Kbps
239.255.48.1:5001 (TSI 0)	0.55%	WWHB-CD	Service Signaling	751.8 KB	142.7 Kbps
239.255.25.1:5001 (TSI 200)	0.42%	WPBF	Audio	572.9 KB	108.7 Kbps
239.255.29.1:5001 (TSI 200)	0.42%	WFLX	Audio	572.7 KB	108.7 Kbps
239.255.5.1:5001 (TSI 200)	0.42%	WPTV	Audio	572.6 KB	108.7 Kbps
239.255.12.10:5000 (TSI 0)	0.37%	T2	Service Signaling	506.5 KB	96.1 Kbps
239.255.48.1:5100 (TSI 0)	0.26%	ESG	Service Signaling	355.2 KB	67.4 Kbps
239.255.25.1:5001 (TSI 201)	0.23%	WPBF	Audio	317.4 KB	60.2 Kbps
239.255.29.1:5001 (TSI 201)	0.23%	WFLX	Audio	316.9 KB	60.1 Kbps
239.255.5.1:5001 (TSI 201)	0.23%	WPTV	Audio	315.4 KB	59.9 Kbps
239.255.12.1:5001 (TSI 201)	0.21%	WPEC	Audio	289.6 KB	55.0 Kbps
239.255.12.11:5000 (TSI 0)	0.20%	PBTV	Service Signaling	279.2 KB	53.0 Kbps
239.255.48.1:5100 (TSI 80)	0.19%	ESG	ROUTE Media	255.6 KB	48.5 Kbps
239.255.12.20:5000 (TSI 0)	0.10%	GMLOOP	Service Signaling	137.8 KB	26.2 Kbps
239.255.48.100:6000 (TSI 0)	0.09%	DDAAS	Service Signaling	118.7 KB	22.5 Kbps
239.255.25.1:5001 (TSI 300)	0.08%	WPBF	Captions	115.2 KB	21.9 Kbps
239.255.48.1:5100 (TSI 50)	0.07%	ESG	ROUTE Media	103.2 KB	19.6 Kbps
239.255.48.1:5100 (TSI 60)	0.07%	ESG	ROUTE Media	102.4 KB	19.4 Kbps
239.255.5.1:5001 (TSI 300)	0.07%	WPTV	Captions	100.9 KB	19.1 Kbps
239.255.29.1:5001 (TSI 300)	0.07%	WFLX	Captions	95.1 KB	18.0 Kbps
239.255.12.1:5001 (TSI 300)	0.07%	WPEC	Captions	89.7 KB	17.0 Kbps
239.255.48.1:5001 (TSI 300)	0.05%	WWHB-CD	Captions	74.9 KB	14.2 Kbps

Total: 137.89 MB | Signaling: 5.86% | Media: 94.14% | Other: 0.00%

RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

Service Summary (SLT BSID: 9234)

Certificate Details

Service 5001: WWHB-CD (48.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d3_3

Raw XML

Raw XML

Service 5002: ESG

Raw XML

ROUTE Stream: 239.255.48.1:5100

Raw XML

Raw XML

Service 5003: WPEC (12.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4

Raw XML

Raw XML

Service 5004: WPTV (5.1) Encrypted

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4

Raw XML

Raw XML

Service 5005: WFLX (29.1) Encrypted

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4

Raw XML

Raw XML

Service 5006: WPBF (25.1) Encrypted

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4

Service 5004: WPTV (5.1)

Service 5005: WFLX (29.1)

Service 5006: WPBF (25.1)

Service 5007: T2 (12.10)

Service 5009: PBTV (12.11)
