RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

PLP/L1 Information Not Available
Link Mapping Table Data Not Available

Service Summary (SLT BSID: 918)

Service NameIDChannelProtocol / CategorySLS Destination
FOX500117.1ROUTE / Linear A/V Service239.255.17.1:5001
WHO Encrypted500213.1ROUTE / Linear A/V Service239.255.13.1:5002
KDIN500311.1ROUTE / Linear A/V Service239.255.11.1:5003
KCCI Encrypted50048.1ROUTE / Linear A/V Service239.255.8.1:5004
ESG5005ROUTE / ESG Service239.255.17.1:5100
T2 Internet Required500617.10ROUTE / Linear A/V Service239.255.17.10:5000
DDAAS Hidden5007ROUTE / App-Based Service239.255.17.100:6000
PBTV Internet Required500817.11ROUTE / Linear A/V Service239.255.17.11:5000
GMLOOP500917.20ROUTE / App-Based Service239.255.17.20:5000
ROXi501017.21ROUTE / App-Based Service239.255.17.21:5000
Capability Descriptor Table (CDT) - 3 Certificate(s)
AttributeValue
OCSP RefreshP7DT0H
Certificate Count3

Certificate Details

Certificate 1 - KDSM-TV Signalling Signing SMT 0001 (Valid Until: Aug 14 2026)
FieldValue
Subject/C=US/ST=Iowa/L=Des Moines/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=KDSM-TV Signalling Signing SMT 0001
Issuer/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number2A638680A621D26B47DBF15BE5A7B56B757EBF64
Valid FromAug 14 17:55:39 2025 GMT
Valid UntilAug 14 17:55:39 2026 GMT
Signature Algorithmsha256WithRSAEncryption
Public KeyRSA (3072 bits)
SHA-1 FingerprintAF:77:12:95:A0:1C:C7:C5:91:9E:0C:64:FF:1B:5A:B8:48:09:FF:01
SHA-256 Fingerprint30:22:B2:3C:8B:ED:55:BA:F7:EC:D5:3E:5B:21:1C:D4:6F:27:83:A7:4C:C7:D3:32:C2:1B:D5:94:A1:E0:1B:
Certificate AuthorityNo
Self-SignedNo
Certificate 2 - KDSM-TV Signalling Signing CDT 0001 (Valid Until: Aug 14 2026)
FieldValue
Subject/C=US/ST=Iowa/L=Des Moines/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=KDSM-TV Signalling Signing CDT 0001
Issuer/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number247C26595B5F0FA447997A88E5B581BDBED9C2CA
Valid FromAug 14 17:55:38 2025 GMT
Valid UntilAug 14 17:55:38 2026 GMT
Signature Algorithmsha256WithRSAEncryption
Public KeyRSA (3072 bits)
SHA-1 Fingerprint9F:F6:DD:24:4D:06:65:B4:54:04:1F:74:34:BA:2A:0F:B8:C3:86:72
SHA-256 Fingerprint87:DC:EC:79:6B:BE:41:09:B0:E4:56:38:B9:86:64:B7:89:A6:B4:7C:EF:A5:81:BF:FF:A8:00:8B:EC:1A:4D:
Certificate AuthorityNo
Self-SignedNo
Certificate 3 - ATSC 3.0 Signing CA-2 (Valid Until: Sep 8 2030)
FieldValue
Subject/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Issuer/C=US/O=Pearl TV/OU=Root CA-1/CN=ATSC3 Root-CA
Serial Number1D81C0A269A03D9AAF128428593DB6B8
Valid FromSep 8 00:00:00 2021 GMT
Valid UntilSep 8 23:59:59 2030 GMT
Signature Algorithmsha512WithRSAEncryption
Public KeyRSA (3072 bits)
SHA-1 Fingerprint06:63:9A:0C:E9:C0:E7:2C:44:05:1C:8A:91:B6:68:FB:25:C4:38:75
SHA-256 Fingerprint23:42:5B:1C:CA:CB:F3:31:7C:8B:03:59:DA:E0:A3:98:C4:84:05:DB:1B:6B:92:15:58:69:F7:89:30:9A:65:
Certificate AuthorityYes
Self-SignedNo
Raw XML
<?xml version="1.0" encoding="UTF-8"?>
<CertificationData xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/CDT-1.0-20180706.xsd">
<ToBeSignedData OCSPRefresh="P7DT0H"><Certificates>MIIF5zCCBE+gAwIBAgIUKmOGgKYh0mtH2/Fb5ae1a3V+v2QwDQYJKoZIhvcNAQELBQAwcDELMAkGA1UEBhMCVVMxKDAmBgNVBAoTH0FUU0MgMy4wIFNlY3VyaXR5IEF1dGhvcml0eSBMTEMxFzAVBgNVBAsTDlNpZ25pbmcgQ0EtREMxMR4wHAYDVQQDExVBVFNDIDMuMCBTaWduaW5nIENBLTIwHhcNMjUwODE0MTc1NTM5WhcNMjYwODE0MTc1NTM5WjCBsDELMAkGA1UEBhMCVVMxDTALBgNVBAgTBElvd2ExEzARBgNVBAcTCkRlcyBNb2luZXMxJzAlBgNVBAoTHlNpbmNsYWlyIEJyb2FkY2FzdCBHcm91cCwgSW5jLjEmMCQGA1UECxMdU2luY2xhaXIgQnJvYWRjYXN0IEdyb3VwLCBJbmMxLDAqBgNVBAMTI0tEU00tVFYgU2lnbmFsbGluZyBTaWduaW5nIFNNVCAwMDAxMIIBojANBgkqhkiG9w0BAQEFAAOCAY8AMIIBigKCAYEAoCJ4pEUUg+UTJc9IeGHymU9+q3RpvANfhFyJjJ7bWiaXF1LjGKsE8gnP5NRylUQkRitJ9DcPrYCDATR5HPcq29GHfrpo6UxenolIVK6nqgpz7jo0RpI/f8Crp+WSw2wNuQEpE40lcpaUmuGVsEAnUk1xLRXXfxOyrkC7fL0VabfpoELWtcbtwckokQDWJUaEJbEWEBEYh0OpFvrgRzB/mpYscVFQ+zrcg3trKbtAzKVTht6NDzJF0VZN67td3O/zhUIeeN5BJj2mJb+EShJu7FEScJneYmYG8yU0TEVexRlirdSnJgAonTdoRaAC2/sF1QP/syhpMrqwUUIhfPM20RswDfSIMLrJv9QiG0yf42j+foKi5gbw6VFpNkGoKLBnE9fJMrzfhUAeJM+04EHt8rT3Wwl3/XEwKulRJx2Ho4A/k6iKhcg9vf3Z59zc5nOvUWkFTbiS/TE8v7cPqkKpvp5VUsQNv0wdE1d+7M/5ZsflSZD1Zxeue7JQ4IhytORdAgMBAAGjggE2MIIBMjAMBgNVHRMBAf8EAjAAMB0GA1UdDgQWBBRk5zaAgAQCUv2cmoqEJCZrllRc1DAfBgNVHSMEGDAWgBSg3v0kkFlIAiGXJ3/hljvigWjGtjAOBgNVHQ8BAf8EBAMCB4AwGAYDVR0lAQH/BA4wDAYKKwYBBAGDkmAlAzA4BggrBgEFBQcBAQQsMCowKAYIKwYBBQUHMAGGHGh0dHA6Ly9vY3NwLm9uZS5kaWdpY2VydC5jb20wQwYDVR0fBDwwOjA4oDagNIYyaHR0cDovL2NybC5vbmUuZGlnaWNlcnQuY29tL0FUU0MzLjBTaWduaW5nQ0EtMi5jcmwwGgYDVR0gAQH/BBAwDjAMBgorBgEEAYOUYwIBMB0GA1UdCQQWMBQwEgYKKwYBBAGDkmAJATEEAgIDljANBgkqhkiG9w0BAQsFAAOCAYEAgER11MjBLhwF5VdsbNO5rTOpzqbPP3BY2Kpm6Vc8Uv6sKPGwU97bFuIW11SScSSw2ARsvO283jEek1Vc2U3m3H6UJrRKJB1Y0lWQcROLDZ885tBBPRm9GWJwJHTzvRobkmdX3HYXlaVXPm+WSHBQ/5Vpx4j2oJaOzLPd7CAyBbymvJlRgM5sZJ+OZ6hoo0f8R0l5ojb5X8aOmJAJsXUWzeU6V0zWcEa0NRxYZ0lhMb0+REgJ8l+Auo4JNJ0Cn4ElpmPascKMvpXXkWQYo3Pl/3yyBFXqJ7g2NOXLj32MfZjPCtFmWQAx0hCRUoqNaE7AwmtBU0Oaz8zvYLpFQHs1Gb7nKRiAoaeWpwRP5Na/dmMvG61wO7Awa8IU7rI+tmMfOQtTMGb6Sz38Z2mHP3+IrtjaD1Z9SvFjSh6QlseIgWbvzxvqfxwbCpgNEIxXK9c6Q9Ryl59CkyOpwfjDSQHZ6x2yDW4gVnExdveusCLFIpLqQRWh21U+69yS1DM1x7s0</Certificates><Certificates>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</Certificates><Certificates>MIIF7zCCA9egAwIBAgIQHYHAommgPZqvEoQoWT22uDANBgkqhkiG9w0BAQ0FADBMMQswCQYDVQQGEwJVUzERMA8GA1UEChMIUGVhcmwgVFYxEjAQBgNVBAsTCVJvb3QgQ0EtMTEWMBQGA1UEAxMNQVRTQzMgUm9vdC1DQTAeFw0yMTA5MDgwMDAwMDBaFw0zMDA5MDgyMzU5NTlaMHAxCzAJBgNVBAYTAlVTMSgwJgYDVQQKEx9BVFNDIDMuMCBTZWN1cml0eSBBdXRob3JpdHkgTExDMRcwFQYDVQQLEw5TaWduaW5nIENBLURDMTEeMBwGA1UEAxMVQVRTQyAzLjAgU2lnbmluZyBDQS0yMIIBojANBgkqhkiG9w0BAQEFAAOCAY8AMIIBigKCAYEAu7US2OxGzCtEMQZ7FR0fNv6d6hd+x3hV7Uu0H8wso+rXbr4+WhHmenMLLSS5VT0qchH9Bs8ntS15Ijxvgj8rj1ZzeHY7p9enLp9LnbmC4/VtiRM9W5w4oqCt7rHYG2soYweyoedjyhvXQSZzZPi3gSX5wgjwAINLbPc+1KwL61nPFqwuy8QeEitV9dhR+V5HS3kt7jkIru+aHFvmDhEKRxrZTZ1c1ayEC8AKnwABhTodRpvq14yNuAppStJ71DIIsqZk7H4YcUDSLhbgbGxN6UMWPb+U7zzTIGQBCp297vFCOUHjvJvSM5QU3tfZM1QDNkftyIqDohKKBJKQGSODGPOHCkXPPisv9itKaM4gPMh/GcZZRwiwt0i+nQwndmleViUGD9LMiDeNnm5z6qIO+YwaV4G+/HKUJ0SpVmA3vH/UPu0Zc0nvk8wvcVZtjdsu6m/ncSMQBjslZ6spgt01OQNGas4ODHyeqt46vdL2MxB8bjv0zOa3DwOx2FvbJQnhAgMBAAGjggEnMIIBIzASBgNVHRMBAf8ECDAGAQH/AgEAMDUGA1UdIAEB/wQrMCkwCwYJKwYBBAGDlGMCMAwGCisGAQQBg5RjAgEwDAYKKwYBBAGDlGMCAjBMBgNVHR8ERTBDMEGgP6A9hjtodHRwOi8vcGtpLWNybC5zeW1hdXRoLmNvbS9vZmZsaW5lY2EvUGVhcmxUVkFUU0MzUm9vdENBLmNybDAOBgNVHQ8BAf8EBAMCAcYwHQYDVR0OBBYEFKDe/SSQWUgCIZcnf+GWO+KBaMa2MB8GA1UdIwQYMBaAFAVpwvy6iPDgHPhycVgAuJ4KgHGmMDgGCCsGAQUFBwEBBCwwKjAoBggrBgEFBQcwAYYcaHR0cDovL3BraS1vY3NwLmRpZ2ljZXJ0LmNvbTANBgkqhkiG9w0BAQ0FAAOCAgEAEtmDPuS023t4GSaMMtMkPyh8IG5B2HOPtnwjXzf418ar2XCMcaRI7jGk12+VPOg5S6baCKin+QSgbGonU6mH9eLEhl2fCpRMnM6XhzdplCCj7xMZAHf5AhuCz+M5tqaQelVv4WJrWHvMK1Jdw4q6GDtEKxF0cIYXyrinMqR65P2qvjEaJZUNdRSo/yuxu0UrkbNtuJ9TzQABnY5y7pTgcJOBbGes6bC/VrWurUXDFpeNfybm5PRZE9rlsIIeT4J+3i7BGpUdnrPWQrk6NNa6M36XKxe1dh1HptyNXwOPamS5qpw7ewQARlP495uORvAM3p50TN2vtXKLgDQENi+Kmo/E+ORKaLJtgbet0jllhR9L7Gau8DdykvnTHkm2/yxB0tDZTbrTRJciPjFHsRXmYQAyQYaod729shWngSgNE08n4RkiVSsSFbhrCXh+ZrCF9wBpfCVoDaLemjriVy4SK7Hxmr39XxF66B9fBnGLXMvgyYRymNWPyys5j/wl+iZt4KTm5W5iOhdIXaJxOO6b+EFeNZsDi8p52nvi5L5rtxw/1GAIiz39RTGd/w2thKQ+USVa7zY5sllzUBMjepeog/OOPwtbGccP38U6oW8vL00bQGbW5HuWP58qGcY9Wk6I1mhinOmrpm1BsHqdYVFDCJZqQK4XMNukaxP6ey6xmJg=</Certificates><CurrentCert>ZOc2gIAEAlL9nJqKhCQma5ZUXNQ=</CurrentCert></ToBeSignedData>
<CMSSignedData>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</CMSSignedData>
<OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse>
</CertificationData>
Service List Table (SLT) Instance 1 - Raw XML
<?xml version="1.0" encoding="UTF-8"?>
<SLT bsid="918" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SLT/1.0/ SLT-1.0-20211209.xsd">
    <Service globalServiceID="tag:sinclairplatform.com,2022:KDSM;919" majorChannelNo="17" minorChannelNo="1" serviceCategory="1" serviceId="5001" shortServiceName="FOX" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.17.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/5013-EDCE" majorChannelNo="13" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5002" shortServiceName="WHO" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.13.1" slsDestinationUdpPort="5002" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="https://doi.org/10.5239/8B59-6808" majorChannelNo="11" minorChannelNo="1" serviceCategory="1" serviceId="5003" shortServiceName="KDIN" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.11.1" slsDestinationUdpPort="5003" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/69A5-DCC4" majorChannelNo="8" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5004" shortServiceName="KCCI" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.8.1" slsDestinationUdpPort="5004" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service serviceCategory="4" serviceId="5005" shortServiceName="ESG" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.17.1" slsDestinationUdpPort="5100" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:T2:KDSM" majorChannelNo="17" minorChannelNo="10" serviceCategory="1" serviceId="5006" shortServiceName="T2" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.17.10" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:broadspanwireless.com,2023:918:KDSM-TV :919" hidden="true" hideInGuide="true" serviceCategory="3" serviceId="5007" shortServiceName="DDAAS" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.17.100" slsDestinationUdpPort="6000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:PBTV:KDSM" majorChannelNo="17" minorChannelNo="11" serviceCategory="1" serviceId="5008" shortServiceName="PBTV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.17.11" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:sinclairplatform.com,2020:Gameloop:KDSM" majorChannelNo="17" minorChannelNo="20" serviceCategory="3" serviceId="5009" shortServiceName="GMLOOP" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.17.20" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:Roxi:kdsm" majorChannelNo="17" minorChannelNo="21" serviceCategory="3" serviceId="5010" shortServiceName="ROXi" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.17.21" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
</SLT>

Service 5001: FOX (17.1)

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.17.1:5001
Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0
Audio: 6 ch @ 384 kbps +1 additional audio stream
Codec: ac-4.02.01.01
Hidden: No
App: Run3TV
Service Details (from SLT)
  • Global Service ID: tag:sinclairplatform.com,2022:KDSM;919
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.17.1:5001
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5001"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSIRepresentation IDContent TypeContent Ratings
100Video1_1video1,'TV-PG',{0 'TV-PG'}
20022audioN/A
201Audio3_3audioN/A
300Data4_4subtitlesN/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="3750000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-PG',{0 'TV-PG'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="384000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="18"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="117"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="34"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="4"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-11-18T07:05:42Z)
Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1
  • Bandwidth: 3750000 (3.8 Mbps)
  • Codecs: hev1.2.4.L120.B0
  • Resolution: 1280x720 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Initialization: video-init.mp4
    • Media URL: video-$Number$.mp4v
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22
  • Bandwidth: 384000 (384 kbps)
  • Codecs: ac-4.02.01.01
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 6
  • Segment Template:
    • Initialization: a0-init.mp4
    • Media URL: a0-$Number$.mp4a
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3
  • Bandwidth: 48000 (48 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Initialization: a1-init.mp4
    • Media URL: a1-$Number$.mp4a
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data4_4
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Initialization: d0-init.mp4
    • Media URL: d0-$Number$.mp4s
    • Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT0S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-11-18T07:05:42Z" timeShiftBufferDepth="PT12.012S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="3750000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SegmentTemplate duration="480480" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>
HTML Entry-point Description (HELD) Instance 1

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html" appContextId="tag:sinclairplatform.com,2022:KDSM;919" />
</HELD>

Service 5002: WHO (13.1) Encrypted

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.13.1:5002
Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0
Audio: 6 ch @ 96 kbps +1 additional audio stream
Codec: ac-4.02.01.01
Hidden: No
App: No
Service Details (from SLT)
  • Global Service ID: https://doi.org/10.5239/5013-EDCE
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.13.1:5002
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
  • Protected: Yes
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5002"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSIRepresentation IDContent TypeContent Ratings
100Video1_1videoN/A
20022audioN/A
201Audio3_3audioN/A
300Data4_4subtitlesN/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5000000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="18"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="176"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="188"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-11-18T07:04:48Z)
Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1
  • Bandwidth: 5000000 (5.0 Mbps)
  • Codecs: hev1.2.4.L123.B0
  • Resolution: 1920x1080 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Initialization: video-init.mp4
    • Media URL: video-$Number$.mp4v
    • Timescale: 240000, Duration: 480480, Start: 1
  • DRM Protection:

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22
  • Bandwidth: 96000 (96 kbps)
  • Codecs: ac-4.02.01.01
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 6
  • Segment Template:
    • Initialization: a0-init.mp4
    • Media URL: a0-$Number$.mp4a
    • Timescale: 240000, Duration: 480480, Start: 1
  • DRM Protection:

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3
  • Bandwidth: 48000 (48 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Initialization: a1-init.mp4
    • Media URL: a1-$Number$.mp4a
    • Timescale: 240000, Duration: 480480, Start: 1
  • DRM Protection:

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data4_4
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Initialization: d0-init.mp4
    • Media URL: d0-$Number$.mp4s
    • Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT0S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-11-18T07:04:48Z" timeShiftBufferDepth="PT12.012S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="e385d6dd-c0b1-5c98-ba02-5935dbcf14aa" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="e385d6dd-c0b1-5c98-ba02-5935dbcf14aa" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=who_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="5000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="e385d6dd-c0b1-5c98-ba02-5935dbcf14aa" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="e385d6dd-c0b1-5c98-ba02-5935dbcf14aa" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=who_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="e385d6dd-c0b1-5c98-ba02-5935dbcf14aa" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="e385d6dd-c0b1-5c98-ba02-5935dbcf14aa" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>AAAASXBzc2gAAAAA7e+LqXnWSs6jyCfc1R0h7QAAACkiC3dob19nMl9wMl8xSOPclZsGahRhdHNjX2dyb3VwMl9wcm9maWxlMgAAAmdwc3NoAAAAAO3vi6l51krOo8gn3NUdIe0AAAJHIgt3aG9fZzJfcDJfMUjj3JWbBlgCahRhdHNjX2dyb3VwMl9wcm9maWxlMnJYChDzT9hQf3BbG5cawYIo9uEMEhDjhdbdwLFcmLoCWTXbzxSqGiBliv7rNqh1ABive/P2hMnLjniJsFIN8qdPCMCmyN/DiSIQGLqndnTQyGXJvazJMBpTAHJYChDLaJ5zLzNTW4gM2KGYoKRlEhDjhdbdwLFcmLoCWTXbzxSqGiDgOMzUN0sRhrBqMIJWEe0ZgQrW4JAp97eqFA438eXp9CIQQUqYtEUkaZ9Zn1bbPccFbnJYChAYzbUymb9SK49VZt2XC4czEhAnjLFpFF9Y+JOAw+EV7rpfGiA8cCi7luyjWgaWx+spnoeUIelcjwH+F4MVBn1xBmhG6CIQlEIsh3PTf07TF0/UFakuiXJYChAKsZ0XD/lQb40MA6tkFAOUEhAnjLFpFF9Y+JOAw+EV7rpfGiBhiLRa8dRNCcsKoaFklEi6wTi5tzSWInmZ37rivHqk7CIQNUDipargaqDG05vcAeMqJHJYChD5pnrZdPpbdb/46EqsxjXYEhBv1s1fk6JbwZVdF97gvBm0GiAd3M1TC6NY/3nDmxuJc+MRwn+u0Ysp4I685PoO2JQ+ryIQsRC3qXloQDdrHClpk8pwvnJYChB4OSweNyVSiI7gKVYR8mN8EhBv1s1fk6JbwZVdF97gvBm0GiB7TLla/wY/a/Q4hys/Pru6i33blWkCByyfdZy1ff24BCIQ1XURiOtBL8HrBBxJynPyfg==</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=who_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <SegmentTemplate duration="480480" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

Service 5003: KDIN (11.1)

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.11.1:5003
Video: 1920x1080p (29.97 fps)
Codec: hev1.2.4.L120.B0
Audio: 6 ch @ 96 kbps +1 additional audio stream
Codec: ac-4.02.01.01
Hidden: No
App: No
Service Details (from SLT)
  • Global Service ID: https://doi.org/10.5239/8B59-6808
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.11.1:5003
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5003"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSIRepresentation IDContent TypeContent Ratings
100Video1_1video1,'TV-Y',{5 'TV-Y'}
20022audioN/A
201Audio3_3audioN/A
300Data4_4subtitlesN/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5000000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-Y',{5 'TV-Y'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="17"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="211"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="11"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-11-18T07:04:47Z)
Type: dynamic
Min Buffer Time: PT1.001S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1
  • Bandwidth: 5000000 (5.0 Mbps)
  • Codecs: hev1.2.4.L120.B0
  • Resolution: 1920x1080 (16:9)
  • Frame Rate: 30000/1001 (29.97 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Initialization: video-init.mp4
    • Media URL: video-$Number$.mp4v
    • Timescale: 240000, Duration: 240240, Start: 1761687800

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22
  • Bandwidth: 96000 (96 kbps)
  • Codecs: ac-4.02.01.01
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 6
  • Segment Template:
    • Initialization: a0-init.mp4
    • Media URL: a0-$Number$.mp4a
    • Timescale: 240000, Duration: 240240, Start: 1761687800

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3
  • Bandwidth: 48000 (48 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Initialization: a1-init.mp4
    • Media URL: a1-$Number$.mp4a
    • Timescale: 240000, Duration: 240240, Start: 1761687800

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data4_4
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Initialization: d0-init.mp4
    • Media URL: d0-$Number$.mp4s
    • Timescale: 240000, Duration: 240240, Start: 1761687800

Raw XML

<MPD availabilityStartTime="2025-11-18T07:04:47Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1.001S" minimumUpdatePeriod="PT0S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-11-18T07:04:47Z" timeShiftBufferDepth="PT6.006S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="30000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="30000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-Y',{5 'TV-Y'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1761687800" timescale="240000"/>               <Representation bandwidth="5000000" codecs="hev1.2.4.L120.B0" frameRate="30000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-Y',{5 'TV-Y'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1761687800" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-Y',{5 'TV-Y'}"/>         <SegmentTemplate duration="240240" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1761687800" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-Y',{5 'TV-Y'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="240240" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1761687800" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

Service 5004: KCCI (8.1) Encrypted

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.8.1:5004
Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0
Audio: 6 ch @ 96 kbps +1 additional audio stream
Codec: ac-4.02.01.01
Hidden: No
App: Run3TV
Service Details (from SLT)
  • Global Service ID: https://doi.org/10.5239/69A5-DCC4
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.8.1:5004
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
  • Protected: Yes
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5004"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSIRepresentation IDContent TypeContent Ratings
100Video1_1video1,'TV-PG',{0 'TV-PG'}
20022audioN/A
201Audio3_3audioN/A
300Data4_4subtitlesN/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5000000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-PG',{0 'TV-PG'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="20"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="44"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="128"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="3"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-11-18T07:04:47Z)
Type: dynamic
Min Buffer Time: PT1.001S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1
  • Bandwidth: 5000000 (5.0 Mbps)
  • Codecs: hev1.2.4.L123.B0
  • Resolution: 1920x1080 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Initialization: video-init.mp4
    • Media URL: video-$Number$.mp4v
    • Timescale: 240000, Duration: 240240, Start: 1
  • DRM Protection:

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22
  • Bandwidth: 96000 (96 kbps)
  • Codecs: ac-4.02.01.01
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 6
  • Segment Template:
    • Initialization: a0-init.mp4
    • Media URL: a0-$Number$.mp4a
    • Timescale: 240000, Duration: 240240, Start: 1
  • DRM Protection:

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3
  • Bandwidth: 48000 (48 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Initialization: a1-init.mp4
    • Media URL: a1-$Number$.mp4a
    • Timescale: 240000, Duration: 240240, Start: 1
  • DRM Protection:

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data4_4
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Initialization: d0-init.mp4
    • Media URL: d0-$Number$.mp4s
    • Timescale: 240000, Duration: 240240, Start: 1

Raw XML

<MPD availabilityStartTime="2025-11-18T07:04:47Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1.001S" minimumUpdatePeriod="PT0S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-11-18T07:04:47Z" timeShiftBufferDepth="PT6.006S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <ContentProtection cenc:default_KID="0720b5fe-0c73-59ee-855e-723c484ab1ba" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="0720b5fe-0c73-59ee-855e-723c484ab1ba" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kcci_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="5000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <ContentProtection cenc:default_KID="0720b5fe-0c73-59ee-855e-723c484ab1ba" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="0720b5fe-0c73-59ee-855e-723c484ab1ba" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kcci_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <ContentProtection cenc:default_KID="0720b5fe-0c73-59ee-855e-723c484ab1ba" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="0720b5fe-0c73-59ee-855e-723c484ab1ba" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kcci_g2_p2_1</dashif:Laurl>         </ContentProtection>         <SegmentTemplate duration="240240" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="240240" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>
HTML Entry-point Description (HELD) Instance 1

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage      appContextId="tv:atsc3-app.kcci.hearst.com"      bbandEntryPageUrl="https://atsc-ec2.htvapps.net/run3tv-common/index.html" ></HTMLEntryPackage>
</HELD>

Service 5005: ESG

Protocol: ROUTE
Category: ESG Service
Source: 172.16.200.1
Destination: 239.255.17.1:5100
Hidden: No
App: No
Service Details (from SLT)
  • Global Service ID:
  • Category: 4 (ESG Service)
  • SLS Destination: 239.255.17.1:5100
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5005"></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: 239.255.17.1:5100

TSIRepresentation IDContent TypeContent Ratings
50N/A
60N/A
80N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1" dIpAddr="239.255.17.1" dPort="5100"><LS tsi="50"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="1772" Content-Location="sgdd_1772" Content-Length="45959" Transfer-Length="4752" Content-Type="application/vnd.oma.bcast.sgdd+xml" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="60"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="3493" Content-Location="sgdu_content_3493" Content-Length="328641" Transfer-Length="31530" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File><fdt:File TOI="4703" Content-Location="sgdu_service_schedule_4703" Content-Length="62958" Transfer-Length="5752" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="80"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="5745" Content-Location="s28719_ll_h15_ac.png" Content-Length="8623" Transfer-Length="8260" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5746" Content-Location="s28717_h3_aa.png" Content-Length="12435" Transfer-Length="11563" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5747" Content-Location="s32356_h3_aa.png" Content-Length="11802" Transfer-Length="11112" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5748" Content-Location="s28711_h3_aa.png" Content-Length="8304" Transfer-Length="7564" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5749" Content-Location="GNLZZGG002BLPWC.png" Content-Length="10543" Transfer-Length="10051" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="4"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="67"></item></metadataEnvelope>
Electronic Service Guide (ESG) - 5 Service(s), 14 Program(s) (from 24 fragments)
Service : ROXi (17.21)
FieldValue
IDurn:digicap:svc:5010:1763737907862
Statustag:sinclairpla
DescriptionROXi
Raw XML (0 fragments)


Service : KCCI (8.1)



FieldValue
IDurn:digicap:svc:5004:1763737907862
Statushttps://doi.org
DescriptionKCCI
Raw XML (0 fragments)


Service : KDIN (11.1)



FieldValue
IDurn:digicap:svc:5003:1763737907862
Statushttps://doi.org
DescriptionKDIN
Raw XML (0 fragments)


Service : WHO (13.1)



FieldValue
IDurn:digicap:svc:5002:1763737907862
Statushttps://doi.org
DescriptionWHO
Raw XML (0 fragments)


Service : FOX (17.1)



FieldValue
IDurn:digicap:svc:5001:1763737907862
Statustag:sinclairpla
DescriptionFOX
Raw XML (0 fragments)






Service 5006: T2 (17.10) Internet Required








Protocol: ROUTE

Category: Linear A/V Service


Source: 172.16.200.1

Destination: 239.255.17.10:5000


Video: 1920x1080p (59.94 fps)

Codec: hev1.2.4.L123.B0


Audio: 2 ch @ 192 kbps

Codec: ac-4.02.01.00


Hidden: No

App: No




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:T2:KDSM
    •

  • Category: 1 (Linear A/V Service)
    •

  • SLS Destination: 239.255.17.10:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: 0.0 (ROUTE)
    •

  • Broadband Required: Yes
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5006"><DeliveryMethod><UnicastAppService><BasePattern>a0-22-</BasePattern><BasePattern>d0-Data3_3-</BasePattern><BasePattern>video-Video1_1-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="11"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="205"></item></metadataEnvelope>


Media Presentation Description (MPD) Instance 1 (Published: 2025-11-21T15:34:16Z)

Type: dynamic

Min Buffer Time: PT10S

Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015



Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)


Representation ID: Video1_1


  • Bandwidth: 7000000 (7.0 Mbps)
    •

  • Codecs: hev1.2.4.L123.B0
    •

  • Resolution: 1920x1080 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=423297406371840, d=480480, r=29


Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)


Representation ID: 22


  • Bandwidth: 192000 (192 kbps)
    •

  • Codecs: ac-4.02.01.00
    •

  • Audio Sample Rate: 48000 Hz
    •

  • Audio Channels: 2
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=423297406375844, d=480480, r=29


Adaptation Set (Content: text, Mime: application/mp4)


Representation ID: Data3_3


  • Bandwidth: 50000 (50 kbps)
    •

  • Codecs: stpp.ttml.im1t
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=423297406371840, d=480480, r=29


Raw XML
<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-11-21T15:34:16Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://kdsm-sbgtv.atsc.stream/t2/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="423297406371840"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="7000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="423297406375844"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="192000" codecs="ac-4.02.01.00" id="22"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="423297406371840"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_3"/></AdaptationSet>   </Period></MPD>




Service 5007: DDAAS Hidden








Protocol: ROUTE

Category: App-Based Service


Source: 172.16.200.1

Destination: 239.255.17.100:6000


Hidden: Service & Guide

App: No




Service Details (from SLT)





  • Global Service ID: tag:broadspanwireless.com,2023:918:KDSM-TV :919
    •

  • Category: 3 (App-Based Service)
    •

  • SLS Destination: 239.255.17.100:6000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: . (ROUTE)
    •

  • Hidden: Yes
    •

  • Hide in Guide: Yes
    •





Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"></metadataEnvelope>




Service 5008: PBTV (17.11) Internet Required








Protocol: ROUTE

Category: Linear A/V Service


Source: 172.16.200.1

Destination: 239.255.17.11:5000


Video: 1920x1080p (59.94 fps)

Codec: hev1.2.4.L123.B0


Audio: 2 ch @ 384 kbps

Codec: ac-4.02.01.00


Hidden: No

App: No




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:PBTV:KDSM
    •

  • Category: 1 (Linear A/V Service)
    •

  • SLS Destination: 239.255.17.11:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: 0.0 (ROUTE)
    •

  • Broadband Required: Yes
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5008"><DeliveryMethod><UnicastAppService><BasePattern>a0-24-</BasePattern><BasePattern>d0-Data3_5-</BasePattern><BasePattern>video-Video1_1-</BasePattern><BasePattern>video-Video1_2-</BasePattern><BasePattern>video-Video1_3-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="8"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="12"></item></metadataEnvelope>


Media Presentation Description (MPD) Instance 1 (Published: 2025-11-21T15:34:17Z)

Type: dynamic

Min Buffer Time: PT10S

Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015



Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)


Representation ID: Video1_3


  • Bandwidth: 1000000 (1000 kbps)
    •

  • Codecs: hev1.2.4.L93.B0
    •

  • Resolution: 960x540 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=423297406371840, d=480480, r=29


Representation ID: Video1_2


  • Bandwidth: 4000000 (4.0 Mbps)
    •

  • Codecs: hev1.2.4.L120.B0
    •

  • Resolution: 1280x720 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=423297406371840, d=480480, r=29


Representation ID: Video1_1


  • Bandwidth: 8000000 (8.0 Mbps)
    •

  • Codecs: hev1.2.4.L123.B0
    •

  • Resolution: 1920x1080 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=423297406371840, d=480480, r=29


Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)


Representation ID: 24


  • Bandwidth: 384000 (384 kbps)
    •

  • Codecs: ac-4.02.01.00
    •

  • Audio Sample Rate: 48000 Hz
    •

  • Audio Channels: 2
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=423297406375844, d=480480, r=29


Adaptation Set (Content: text, Mime: application/mp4)


Representation ID: Data3_5


  • Bandwidth: 50000 (50 kbps)
    •

  • Codecs: stpp.ttml.im1t
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=423297406371840, d=480480, r=29


Raw XML
<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-11-21T15:34:17Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://kdsm-sbgtv.atsc.stream/pickleball/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="540" minWidth="960" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="423297406371840"/>            </SegmentTimeline>         </SegmentTemplate>                                 <Representation bandwidth="1000000" codecs="hev1.2.4.L93.B0" frameRate="60000/1001" height="540" id="Video1_3" sar="1:1" scanType="progressive" width="960"/><Representation bandwidth="4000000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_2" sar="1:1" scanType="progressive" width="1280"/><Representation bandwidth="8000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="423297406375844"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.00" id="24"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="423297406371840"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_5"/></AdaptationSet>   </Period></MPD>




Service 5009: GMLOOP (17.20)








Protocol: ROUTE

Category: App-Based Service


Source: 172.16.200.1

Destination: 239.255.17.20:5000


Hidden: No

App: GameLoop




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:Gameloop:KDSM
    •

  • Category: 3 (App-Based Service)
    •

  • SLS Destination: 239.255.17.20:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: . (ROUTE)
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5009"></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>


HTML Entry-point Description (HELD) Instance 1

Raw XML
<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tag:sinclairplatform.com,2020:Gameloop:KDSM" bbandEntryPageUrl="https://nextgen.gameloop.tv/run3tv-common/index.html"></HTMLEntryPackage>
</HELD>




Service 5010: ROXi (17.21)








Protocol: ROUTE

Category: App-Based Service


Source: 172.16.200.1

Destination: 239.255.17.21:5000


Hidden: No

App: ROXi




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:Roxi:kdsm
    •

  • Category: 3 (App-Based Service)
    •

  • SLS Destination: 239.255.17.21:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: . (ROUTE)
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5010"></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="3"></item></metadataEnvelope>


HTML Entry-point Description (HELD) Instance 1

Raw XML
<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://cdn.prod.tvapp.roxi.tv/releases/prod-atsc/index.html#/atsc,faststream,showId=46eb1cf29052,prod" appContextId="tag:sinclairplatform.com,2020:Roxi:kdsm" />
</HELD>




Other Global LLS Tables


System Time Details - Actual Timestamp in L1Detail




AttributeValue



currentUtcOffset37


utcLocalOffset-PT6H


dsStatusfalse




Raw XML
<?xml version="1.0" encoding="utf-8"?>
<SystemTime xmlns="http://www.atsc.org/XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/ SYSTIME-1.0-20211208.xsd" currentUtcOffset="37" utcLocalOffset="-PT6H" dsStatus="false"/>



Input Info




AttributeValue



Input TypeDebug File


File Name56527-0-20251120-120200-p0p1-dbg.dbg


Total Packets Processed28552


File Last Modified2025-11-21 13:16:38 EST


Analysis Run Time2025-11-22 05:59:23 EST




ATSC 3.0 Data Usage Analysis





IP:Port (ID)Usage ↓ServiceTypeTotal DataBitrate



  239.255.8.1:5004 (TSI 100)

 23.11%
  KCCI
  Video
  9.31 MB
  N/A




  239.255.13.1:5002 (TSI 100)

 23.02%
  WHO
  Video
  9.28 MB
  N/A




  239.255.11.1:5003 (TSI 100)

 22.91%
  KDIN
  Video
  9.23 MB
  N/A




  239.255.17.1:5001 (TSI 100)

 17.63%
  FOX
  Video
  7.10 MB
  N/A




  239.255.17.1:5001 (TSI 200)

 1.80%
  FOX
  Audio
  723.2 KB
  N/A




  239.255.8.1:5004 (TSI 0)

 1.74%
  KCCI
  Service Signaling
  702.7 KB
  N/A




  239.255.13.1:5002 (TSI 0)

 1.57%
  WHO
  Service Signaling
  630.9 KB
  N/A




  224.0.23.60:4937 (LLS)

 1.34%
  LLS Signaling
  LLS Signaling
  538.1 KB
  N/A




  239.255.17.1:5001 (TSI 0)

 1.20%
  FOX
  Service Signaling
  484.4 KB
  N/A




  239.255.11.1:5003 (TSI 0)

 1.17%
  KDIN
  Service Signaling
  473.4 KB
  N/A




  239.255.8.1:5004 (TSI 200)

 0.51%
  KCCI
  Audio
  204.2 KB
  N/A




  239.255.13.1:5002 (TSI 200)

 0.49%
  WHO
  Audio
  199.1 KB
  N/A




  239.255.11.1:5003 (TSI 200)

 0.49%
  KDIN
  Audio
  197.0 KB
  N/A




  239.255.17.1:5100 (TSI 0)

 0.42%
  ESG
  Service Signaling
  167.3 KB
  N/A




  239.255.8.1:5004 (TSI 201)

 0.29%
  KCCI
  Audio
  117.6 KB
  N/A




  239.255.13.1:5002 (TSI 201)

 0.27%
  WHO
  Audio
  110.2 KB
  N/A




  239.255.11.1:5003 (TSI 201)

 0.27%
  KDIN
  Audio
  107.0 KB
  N/A




  239.255.17.1:5001 (TSI 201)

 0.25%
  FOX
  Audio
  100.6 KB
  N/A




  239.255.17.11:5000 (TSI 0)

 0.23%
  PBTV
  Service Signaling
  91.0 KB
  N/A




  239.255.17.10:5000 (TSI 0)

 0.22%
  T2
  Service Signaling
  90.6 KB
  N/A




  239.255.17.1:5100 (TSI 80)

 0.22%
  ESG
  ROUTE Media
  88.6 KB
  N/A




  239.255.17.21:5000 (TSI 0)

 0.12%
  ROXi
  Service Signaling
  50.2 KB
  N/A




  239.255.17.20:5000 (TSI 0)

 0.12%
  GMLOOP
  Service Signaling
  49.2 KB
  N/A




  239.255.8.1:5004 (TSI 300)

 0.12%
  KCCI
  Captions
  47.3 KB
  N/A




  239.255.11.1:5003 (TSI 300)

 0.11%
  KDIN
  Captions
  46.1 KB
  N/A




  239.255.17.1:5100 (TSI 60)

 0.09%
  ESG
  ROUTE Media
  36.5 KB
  N/A




  239.255.17.1:5100 (TSI 50)

 0.09%
  ESG
  ROUTE Media
  34.4 KB
  N/A




  239.255.17.1:5001 (TSI 300)

 0.07%
  FOX
  Captions
  29.0 KB
  N/A




  239.255.13.1:5002 (TSI 300)

 0.07%
  WHO
  Captions
  27.8 KB
  N/A




  239.255.17.100:6000 (TSI 0)

 0.06%
  DDAAS
  Service Signaling
  22.6 KB
  N/A






Total: 40.29 MB | Signaling: 8.19% | Media: 91.81% | Other: 0.00%
