RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

PLP ID	SFI	Modulation	Code Rate	Layer	TI Mode	LLS	Lock	Required SNR	Bitrate
0	0	qam16	9/15	core	hti	Yes	Yes	AWGN: 7.32-7.58 dB Rayleigh: 9.94-10.28 dB	N/A
1	0	qam256	9/15	core	hti	Yes	Yes	AWGN: 15.55-15.80 dB Rayleigh: 18.23-18.64 dB	N/A

L1 Detail Information Not Available

Link Mapping Table Data Not Available

Service Summary (SLT BSID: 1182)

Service Name	ID	Channel	Protocol / Category	SLS Destination
KMTW	5001	36.1	ROUTE / Linear A/V Service	239.255.36.1:5001
ESG	5002		ROUTE / ESG Service	239.255.36.1:5100
KSAS	5003	24.1	ROUTE / Linear A/V Service	239.255.24.1:5001
KSNW	5004	3.1	ROUTE / Linear A/V Service	239.255.3.1:5001
KAKE	5005	10.1	ROUTE / Linear A/V Service	239.255.10.1:5001
T2	5006	24.10	ROUTE / Linear A/V Service	239.255.24.10:5000
DDAAS	5007		ROUTE / App-Based Service	239.255.36.100:6000
PBTV	5008	24.11	ROUTE / Linear A/V Service	239.255.24.11:5000
GMLOOP	5009	24.20	ROUTE / App-Based Service	239.255.24.20:5000
ROXi	5010	24.21	ROUTE / App-Based Service	239.255.24.21:5000

Capability Descriptor Table (CDT) - 5 Certificate(s)

Attribute	Value
OCSP Refresh	P7DT0H
Certificate Count	5

Certificate Details

Certificate 1 - KMTW Signalling Signing SMT 0001 (Valid Until: Sep 16 2026)

Field	Value
Subject	/C=US/ST=Kansas/L=Wichita/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=KMTW Signalling Signing SMT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	288D69499A11510356E189203A7BE995F72EF5F7
Valid From	Sep 16 18:36:48 2025 GMT
Valid Until	Sep 16 18:36:48 2026 GMT
Signature Algorithm	sha256WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	43:C7:2C:CD:C0:4A:DE:AE:45:4D:74:C9:EA:EC:48:5A:EB:88:E5:82
SHA-256 Fingerprint	BD:BB:37:48:D5:0A:E6:FA:C7:46:DD:03:61:7F:68:BE:D9:9C:59:8A:B2:36:BB:B3:1F:51:94:25:AF:9B:DD:
Certificate Authority	No
Self-Signed	No

Certificate 2 - KMTW Signaling Signing SMT 0001 (Valid Until: Oct 12 2025)

Field	Value
Subject	/C=US/ST=KS/L=Wichita/O=Sinclair Broadcast Group, Inc./CN=KMTW Signaling Signing SMT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	2702F1EC3EEC5AFEF9ED3384ECB035F9A5007CA3
Valid From	Oct 12 17:38:52 2023 GMT
Valid Until	Oct 12 17:38:52 2025 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	68:2F:EA:23:59:E9:95:68:E2:05:7E:26:9E:49:AD:CA:BE:6C:D0:9F
SHA-256 Fingerprint	04:36:A1:D2:2C:22:BE:EE:87:94:1B:19:95:21:0A:01:C9:12:99:A1:29:1F:56:5E:EA:37:3A:A8:C1:36:11:
Certificate Authority	No
Self-Signed	No

Certificate 3 - KMTW Signalling Signing CDT 0001 (Valid Until: Sep 16 2026)

Field	Value
Subject	/C=US/ST=Kansas/L=Wichita/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=KMTW Signalling Signing CDT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	3E9F5C3BE5204097978A2F8B05FAE5262333E5C9
Valid From	Sep 16 18:36:47 2025 GMT
Valid Until	Sep 16 18:36:47 2026 GMT
Signature Algorithm	sha256WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	DB:EA:37:90:36:85:33:D9:2B:64:50:C8:3B:14:21:15:5C:32:87:8A
SHA-256 Fingerprint	9F:EE:36:44:FF:8B:84:58:4F:88:F3:DD:8A:44:E1:88:04:51:E9:21:F7:B3:0C:B6:9F:4C:1B:EF:6A:F6:D1:
Certificate Authority	No
Self-Signed	No

Certificate 4 - KMTW Signaling Signing CDT 0001 (Valid Until: Oct 12 2025)

Field	Value
Subject	/C=US/ST=KS/L=Wichita/O=Sinclair Broadcast Group, Inc./CN=KMTW Signaling Signing CDT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	3ECD54AA84AADDFD0C81570D7FB30CD16D1F1123
Valid From	Oct 12 17:37:59 2023 GMT
Valid Until	Oct 12 17:37:59 2025 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	AA:CE:A3:E3:C6:73:8C:A4:37:F6:38:94:25:B8:CA:79:67:C6:31:90
SHA-256 Fingerprint	35:E9:F7:1E:24:40:77:61:5C:8E:6A:1B:7E:7B:06:D2:25:41:36:9A:47:03:51:AA:00:1D:5F:27:47:12:B5:
Certificate Authority	No
Self-Signed	No

Certificate 5 - ATSC 3.0 Signing CA-2 (Valid Until: Sep 8 2030)

Field	Value
Subject	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Issuer	/C=US/O=Pearl TV/OU=Root CA-1/CN=ATSC3 Root-CA
Serial Number	1D81C0A269A03D9AAF128428593DB6B8
Valid From	Sep 8 00:00:00 2021 GMT
Valid Until	Sep 8 23:59:59 2030 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	06:63:9A:0C:E9:C0:E7:2C:44:05:1C:8A:91:B6:68:FB:25:C4:38:75
SHA-256 Fingerprint	23:42:5B:1C:CA:CB:F3:31:7C:8B:03:59:DA:E0:A3:98:C4:84:05:DB:1B:6B:92:15:58:69:F7:89:30:9A:65:
Certificate Authority	Yes
Self-Signed	No

Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<CertificationData xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/CDT-1.0-20180706.xsd">
<ToBeSignedData OCSPRefresh="P7DT0H"><Certificates>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</Certificates><Certificates>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</Certificates><Certificates>MIIF4zCCBEugAwIBAgIUPp9cO+UgQJeXii+LBfrlJiMz5ckwDQYJKoZIhvcNAQELBQAwcDELMAkGA1UEBhMCVVMxKDAmBgNVBAoTH0FUU0MgMy4wIFNlY3VyaXR5IEF1dGhvcml0eSBMTEMxFzAVBgNVBAsTDlNpZ25pbmcgQ0EtREMxMR4wHAYDVQQDExVBVFNDIDMuMCBTaWduaW5nIENBLTIwHhcNMjUwOTE2MTgzNjQ3WhcNMjYwOTE2MTgzNjQ3WjCBrDELMAkGA1UEBhMCVVMxDzANBgNVBAgTBkthbnNhczEQMA4GA1UEBxMHV2ljaGl0YTEnMCUGA1UEChMeU2luY2xhaXIgQnJvYWRjYXN0IEdyb3VwLCBJbmMuMSYwJAYDVQQLEx1TaW5jbGFpciBCcm9hZGNhc3QgR3JvdXAsIEluYzEpMCcGA1UEAxMgS01UVyBTaWduYWxsaW5nIFNpZ25pbmcgQ0RUIDAwMDEwggGiMA0GCSqGSIb3DQEBAQUAA4IBjwAwggGKAoIBgQDNx4G99Hbiq3IgM7OYjdN1YqV0/QBzqBC9jXV5r7xhRW07x/B9re+U53WiAVasZi/qeYL6i/Eh3x34rikcOnUO8esf34PNMLfLZak4DKadc1XCu23DyXRAe3YrZhsmGIJWTTVb7oMzbOepArThTH1bJ35HLZaZRagChpRUHVWAQ25NE6Eo0cE1fTl/IRgPaVYw/4kLWpMkpV7zhlRYz9tvh4WubTtqpZlgTddpUmguNPNdRBOENSWYxwHk2uP317IT3b4/XTK92OZRS3xuBkm9kujsQ+qoX/f808h0js8VanWGpgkMt3ANjUgYz2gSUZe9vDtYq8F4XY5oo6MMo45SWJ/ZvcVsCebeLj36sM4aOXiTGotwowQyivyWrPVQEXwB2vwpoU2kWy+H0YiLFYV3dsbZRk+Fwtoa3/fz3lkJtn8JXuMcYzsnp8d6o6NSP48ChDYd0D2TrcxvG7DH7f/dkE/UQ4R7uhue5Ii1p1z0xAKjpx4IegN5RdQdMybg3u8CAwEAAaOCATYwggEyMAwGA1UdEwEB/wQCMAAwHQYDVR0OBBYEFIcEAoa8H+cb/gr0u2++iJymauIdMB8GA1UdIwQYMBaAFKDe/SSQWUgCIZcnf+GWO+KBaMa2MA4GA1UdDwEB/wQEAwIHgDAYBgNVHSUBAf8EDjAMBgorBgEEAYOSYCUDMDgGCCsGAQUFBwEBBCwwKjAoBggrBgEFBQcwAYYcaHR0cDovL29jc3Aub25lLmRpZ2ljZXJ0LmNvbTBDBgNVHR8EPDA6MDigNqA0hjJodHRwOi8vY3JsLm9uZS5kaWdpY2VydC5jb20vQVRTQzMuMFNpZ25pbmdDQS0yLmNybDAaBgNVHSABAf8EEDAOMAwGCisGAQQBg5RjAgEwHQYDVR0JBBYwFDASBgorBgEEAYOSYAkBMQQCAgSeMA0GCSqGSIb3DQEBCwUAA4IBgQCMU8OQ2WsyfosmFVnRYRayqQ33s9EKbimfOAeQQwFCuu7AR7F54flUFvpPZ+No/EVWov1ji8e+g0SFGthHu7Dv/TMeVALKquFVIqVsTHYZffKQhN5sQ1yZ9hv25RfjuEM6aEBhoBGQVVvPsdICGNPriLB18YZkJaj5R+j6DYtaJofVlbj0f3UEL7tasSZc0THZn8oNAnqqlwAeXj0gkVZYSZZ9UZOpNkIWeCbu9ABjr1xN0Vveo6KYTU/1TaKHTOTxpCCDatbXPT88mZssUwMuEnaIkBQzAPsrCv8P2s7Vw+U9P02HGdtItHp64HgSihrwCy1kUwRyFAAs7IThTr49CWhP3WEHWmQHcGo8aSGOZDSgVo498FBymb6yZJY/0I24cRcInRnoTk8lXv1Ko5oLjCKew4ZZ8JYnTaVGPTz2qoX5VjggAB2TuLW6Y3A9fkDGu0YAvzsYOvtC5yjRAYaxdfSiZ3EmH0PhPqhz0UFjo/V0wv9uHA8ONc2i+1LUj8o=</Certificates><Certificates>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</Certificates><Certificates>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</Certificates><CurrentCert>W/p8txL1+024pJ9/Yx1KaRYSXd4=</CurrentCert></ToBeSignedData>
<CMSSignedData>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</CMSSignedData>
<OCSPResponse>MIIC0AoBAKCCAskwggLFBgkrBgEFBQcwAQEEggK2MIICsjCCARqiFgQUoN79JJBZSAIhlyd/4ZY74oFoxrYYDzIwMjUwOTE3MTgzNjUzWjCB7jB1ME0wCQYFKw4DAhoFAAQU5gvf52P7Wtda0EPbgrceW49evAMEFKDe/SSQWUgCIZcnf+GWO+KBaMa2AhQojWlJmhFRA1bhiSA6e+mV9y7194AAGA8yMDI1MDkxNzE4MzY1M1qgERgPMjAyNTA5MjQxODM2NTNaMHUwTTAJBgUrDgMCGgUABBTmC9/nY/ta11rQQ9uCtx5bj168AwQUoN79JJBZSAIhlyd/4ZY74oFoxrYCFD6fXDvlIECXl4oviwX65SYjM+XJgAAYDzIwMjUwOTE3MTgzNjUzWqARGA8yMDI1MDkyNDE4MzY1M1owDQYJKoZIhvcNAQENBQADggGBAIbjfz/Qp+hhjLN0GwNkiMljUQp2v//7sRZSoJlrc+JXzJbQ36yGj6sHvOzyX+KNSMbXTzS1dIX1QBlf0pKUx4I+iZsbFd/IvTzo4y4NSgzFdc8+ZUE/SJY3EjEwFPza5am/6Ubq4KpeBsX5x9bQXmgsiRitNnmDFF2ZNrAMblbAuqR1x1nhfg3GrGo8BAMnG561JgX5Tc4cHNJ8pYz/wSunLPzj1nzIg19GYLOO7q3E5d5phMjdCDCGa8mZIFHf/phr5eEK2o32zJAQpk9ebzyqpjaYIXevlRWgcSJG20whh/82s/NpZ0d4UqtmN9/7w2IchsvqS0HjS2Pgc/cJqnd0Wq+wtBP1pdSD04ytNkKOxYIhzghIg4wxGu4RwYI2k4tvIuMfoB+/wIDJBIfX7NT4dY3IgLyVcD/V8HR71r39s0qKx8J8Ca/fX6ZwNVZ9RbnrLQTVxbvdk5J7HkH3czCNr6pZFmmrAr9LCXG1J2ZKeBPs+bL3bCUe6rdHQee9xw==</OCSPResponse><OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse><OCSPResponse>MIIC0AoBAKCCAskwggLFBgkrBgEFBQcwAQEEggK2MIICsjCCARqiFgQUoN79JJBZSAIhlyd/4ZY74oFoxrYYDzIwMjUwOTE3MjE0MTA0WjCB7jB1ME0wCQYFKw4DAhoFAAQU5gvf52P7Wtda0EPbgrceW49evAMEFKDe/SSQWUgCIZcnf+GWO+KBaMa2AhQnAvHsPuxa/vntM4TssDX5pQB8o4AAGA8yMDI1MDkxNzIxNDEwNFqgERgPMjAyNTA5MjQyMTQxMDRaMHUwTTAJBgUrDgMCGgUABBTmC9/nY/ta11rQQ9uCtx5bj168AwQUoN79JJBZSAIhlyd/4ZY74oFoxrYCFD7NVKqEqt39DIFXDX+zDNFtHxEjgAAYDzIwMjUwOTE3MjE0MTA0WqARGA8yMDI1MDkyNDIxNDEwNFowDQYJKoZIhvcNAQENBQADggGBABkkyJhpd0izO1Nd5mcLAr+LGag9fCsTcqc/AodiQjuE/Pgx6zdajzHjOQ8436p0MEEWopO8qF8U+eGLXWcmYDitFcS9bapSo8wISjT/gQl9UuLCAe+kO+WYRCO/R0bfgEYaGwrTbdRhrKIws2LzVb3w2ThDDPwPi68inoBEDbmDU/RqJ0wOOB3s1Li8nu/czfx9Sso6t7Qzz1yka7CGMCQl3JfnUyElzQXo5BfO+cVgd1S+n9ptZ0zPWJ3LxOUjHsmwv+oawa9Mzs1uB4wqVN6V6hQcJQz9idQXqVYIiSgpd+tnBYUKrkmWATvXuURznJiHepSV6kMVm5Qvv554EpWwv3/inl3hpnpX/XAI3szBUvoh9PwtsBNdblq1s3rzJd4AXMuW3r36w7rhS25fIzO8JqgcP1QkNsgiNbofSBdXWx3nI+mNIXZAd+9IY1xLMijOFnE+6dexgEDUPyoL5twa5IWnVlPhFBNWOBuGDEXXQ7b4d7oezperr7I/1hZs5Q==</OCSPResponse><OCSPResponse>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</OCSPResponse>
</CertificationData>

Service List Table (SLT) Instance 1 - Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<SLT bsid="1182" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SLT/1.0/ SLT-1.0-20211209.xsd">
    <Service globalServiceID="tag:sinclairplatform.com,2022:KMTW:1183" majorChannelNo="36" minorChannelNo="1" serviceCategory="1" serviceId="5001" shortServiceName="KMTW" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.36.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service serviceCategory="4" serviceId="5002" shortServiceName="ESG" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.36.1" slsDestinationUdpPort="5100" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com.2022:KSAS:1205" majorChannelNo="24" minorChannelNo="1" serviceCategory="1" serviceId="5003" shortServiceName="KSAS" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.24.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="tag:sinclairplatform.com,2022:KSNW:1201" majorChannelNo="3" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5004" shortServiceName="KSNW" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.3.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2022:KAKE:1203" majorChannelNo="10" minorChannelNo="1" serviceCategory="1" serviceId="5005" shortServiceName="KAKE" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.10.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:T2:KSAS" majorChannelNo="24" minorChannelNo="10" serviceCategory="1" serviceId="5006" shortServiceName="T2" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.24.10" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:broadspanwireless.com,2023:1182:KMTW:1183" hidden="true" hideInGuide="true" serviceCategory="3" serviceId="5007" shortServiceName="DDAAS" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.36.100" slsDestinationUdpPort="6000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:PBTV:KSAS" majorChannelNo="24" minorChannelNo="11" serviceCategory="1" serviceId="5008" shortServiceName="PBTV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.24.11" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:sinclairplatform.com,2020:Gameloop:KSAS" majorChannelNo="24" minorChannelNo="20" serviceCategory="3" serviceId="5009" shortServiceName="GMLOOP" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.24.20" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:Roxi:ksas" majorChannelNo="24" minorChannelNo="21" serviceCategory="3" serviceId="5010" shortServiceName="ROXi" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.24.21" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
</SLT>

Service 5001: KMTW (36.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.36.1:5001

Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0

Audio: 16 ch @ 448 kbps
Codec: ac-4.02.01.02

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2022:KMTW:1183
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.36.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5001"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	1,'TV-PG',{0 'TV-PG'}
200	22	audio	N/A
300	Data3_3	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="6704208" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-PG',{0 'TV-PG'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="448000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="13"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="129"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="46"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-19T15:22:02Z)

Type: dynamic
Min Buffer Time: PT2S
Profiles: urn:mpeg:dash:profile:isoff-live:2011

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 6704208 (6.7 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4)

Representation ID: 22

Bandwidth: 448000 (448 kbps)
Codecs: ac-4.02.01.02
Audio Sample Rate: 48000 Hz
Audio Channels: 16
Segment Template:
- Initialization: a0-init.mp4
- Media URL: a0-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: und)

Representation ID: Data3_3

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: d0-init.mp4
- Media URL: d0-$Number$.mp4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT1M0S" profiles="urn:mpeg:dash:profile:isoff-live:2011" publishTime="2025-09-19T15:22:02Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="6704208" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet contentType="audio" id="1" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>               <Representation audioSamplingRate="48000" bandwidth="448000" codecs="ac-4.02.01.02" id="22"/></AdaptationSet><AdaptationSet contentType="text" id="2" lang="und" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_3"/></AdaptationSet>   </Period></MPD>

Service 5002: ESG

Protocol: ROUTE
Category: ESG Service

Source: 172.16.200.1
Destination: 239.255.36.1:5100

Hidden: No
App: No

Service Details (from SLT)

Global Service ID:
Category: 4 (ESG Service)
SLS Destination: 239.255.36.1:5100
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5002"></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: 239.255.36.1:5100

TSI	Representation ID	Content Type	Content Ratings
50			N/A
60			N/A
80			N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1" dIpAddr="239.255.36.1" dPort="5100"><LS tsi="50"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="1116" Content-Location="sgdd_1116" Content-Length="46637" Transfer-Length="4500" Content-Type="application/vnd.oma.bcast.sgdd+xml" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="60"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="3105" Content-Location="sgdu_content_3105" Content-Length="340405" Transfer-Length="30202" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File><fdt:File TOI="4099" Content-Location="sgdu_service_schedule_4099" Content-Length="63301" Transfer-Length="5310" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="80"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="5280" Content-Location="s102116_ll_h15_ac.png" Content-Length="9117" Transfer-Length="8676" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5281" Content-Location="s28719_ll_h15_ac.png" Content-Length="8623" Transfer-Length="8259" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5282" Content-Location="s28717_ll_h15_ad.png" Content-Length="9006" Transfer-Length="8526" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5283" Content-Location="s28708_h3_aa.png" Content-Length="15267" Transfer-Length="15140" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="4"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="3063"></item></metadataEnvelope>

Electronic Service Guide (ESG) - 4 Service(s), 345 Program(s) (from 353 fragments)

Service : KAKE (10.1)

Field	Value
ID	urn:digicap:svc:5005:1758276094461
Status	tag:sinclairpla
Description	KAKE

Raw XML (0 fragments)

Service : KSNW (3.1)

Field	Value
ID	urn:digicap:svc:5004:1758276094461
Status	tag:sinclairpla
Description	KSNW

Raw XML (0 fragments)

Service : KSAS (24.1)

Field	Value
ID	urn:digicap:svc:5003:1758276094461
Status	tag:sinclairpla
Description	KSAS

Raw XML (0 fragments)

Service : KMTW (36.1)

Field	Value
ID	urn:digicap:svc:5001:1758276094461
Status	tag:sinclairpla
Description	KMTW

Raw XML (0 fragments)

Service 5003: KSAS (24.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.24.1:5001

Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0

Audio: 16 ch @ 448 kbps
Codec: ac-4.02.01.02

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com.2022:KSAS:1205
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.24.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5003"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	1,'TV-PG',{0 'TV-PG'}
200	22	audio	N/A
201	Audio3_3	audio	N/A
300	Data4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="6608448" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-PG',{0 'TV-PG'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="448000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="13"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="51"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="154"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-19T15:22:32Z)

Type: dynamic
Min Buffer Time: PT2S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 6608448 (6.6 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 448000 (448 kbps)
Codecs: ac-4.02.01.02
Audio Sample Rate: 48000 Hz
Audio Channels: 16
Segment Template:
- Initialization: a0-init.mp4
- Media URL: a0-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-init.mp4
- Media URL: a1-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: und)

Representation ID: Data4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: d0-init.mp4
- Media URL: d0-$Number$.mp4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT1M0S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-19T15:22:32Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="6608448" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>               <Representation audioSamplingRate="48000" bandwidth="448000" codecs="ac-4.02.01.02" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SegmentTemplate duration="480480" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="und" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

Service 5004: KSNW (3.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.3.1:5001

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2022:KSNW:1201
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.3.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Protected: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5004"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	22	audio	N/A
201	Audio3_3	audio	N/A
300	Data4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5400000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="12"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="127"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="140"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-19T11:29:14Z)

Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 5400000 (5.4 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 240240, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ksnw_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-init.mp4
- Media URL: a0-$Number$.mp4a
- Timescale: 240000, Duration: 240240, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ksnw_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-init.mp4
- Media URL: a1-$Number$.mp4a
- Timescale: 240000, Duration: 240240, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ksnw_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: text, Mime: application/mp4, Lang: und)

Representation ID: Data4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: d0-init.mp4
- Media URL: d0-$Number$.mp4s
- Timescale: 240000, Duration: 240240, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT15H5M54S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-19T11:29:14Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="c9a58cd7-90db-52a0-b217-ab6f944a4160" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="c9a58cd7-90db-52a0-b217-ab6f944a4160" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ksnw_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="5400000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="c9a58cd7-90db-52a0-b217-ab6f944a4160" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="c9a58cd7-90db-52a0-b217-ab6f944a4160" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ksnw_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="c9a58cd7-90db-52a0-b217-ab6f944a4160" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="c9a58cd7-90db-52a0-b217-ab6f944a4160" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ksnw_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <SegmentTemplate duration="240240" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="und" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="240240" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

Service 5005: KAKE (10.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.10.1:5001

Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2022:KAKE:1203
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.10.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5005"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	1,'TV-14',{0 'TV-14'}
200	22	audio	N/A
201	Audio3_3	audio	N/A
300	Data4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5400000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-14',{0 'TV-14'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="13"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="51"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="242"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-19T11:29:14Z)

Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 5400000 (5.4 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-init.mp4
- Media URL: a0-$Number$.mp4a
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-init.mp4
- Media URL: a1-$Number$.mp4a
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: d0-init.mp4
- Media URL: d0-$Number$.mp4s
- Timescale: 240000, Duration: 240240, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT15H5M54S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-19T11:29:14Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="5400000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <SegmentTemplate duration="240240" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="240240" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

Service 5006: T2 (24.10)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.24.10:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 384 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:T2:KSAS
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.24.10:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5006"><DeliveryMethod><UnicastAppService><BasePattern>a0-22-</BasePattern><BasePattern>d0-Data3_3-</BasePattern><BasePattern>video-Video1_1-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="8"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="140"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-19T15:22:34Z)

Type: dynamic
Min Buffer Time: PT10S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 7000000 (7.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=421990870741440, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 384000 (384 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Timescale: 240000
- S: t=421990870745444, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_3

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 240000
- S: t=421990870741440, d=480480, r=29

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-19T15:22:34Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://ksas-sbgtv.atsc.stream/t2/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421990870741440"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="7000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421990870745444"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421990870741440"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_3"/></AdaptationSet>   </Period></MPD>

Service 5007: DDAAS

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.36.100:6000

Hidden: Service & Guide
App: No

Service Details (from SLT)

Global Service ID: tag:broadspanwireless.com,2023:1182:KMTW:1183
Category: 3 (App-Based Service)
SLS Destination: 239.255.36.100:6000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)
Hidden: Yes
Hide in Guide: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5007"></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item></metadataEnvelope>

Service 5008: PBTV (24.11)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.24.11:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 2 ch @ 384 kbps
Codec: ac-4.02.01.00

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:PBTV:KSAS
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.24.11:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5008"><DeliveryMethod><UnicastAppService><BasePattern>a0-24-</BasePattern><BasePattern>d0-Data3_5-</BasePattern><BasePattern>video-Video1_1-</BasePattern><BasePattern>video-Video1_2-</BasePattern><BasePattern>video-Video1_3-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="4"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="234"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-19T15:22:32Z)

Type: dynamic
Min Buffer Time: PT10S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_3

Bandwidth: 1000000 (1000 kbps)
Codecs: hev1.2.4.L93.B0
Resolution: 960x540 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=421990870260960, d=480480, r=29

Representation ID: Video1_2

Bandwidth: 4000000 (4.0 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=421990870260960, d=480480, r=29

Representation ID: Video1_1

Bandwidth: 8000000 (8.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=421990870260960, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 24

Bandwidth: 384000 (384 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 240000
- S: t=421990870260960, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_5

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 240000
- S: t=421990870260960, d=480480, r=29

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-19T15:22:32Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://ksas-sbgtv.atsc.stream/pickleball/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="540" minWidth="960" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421990870260960"/>            </SegmentTimeline>         </SegmentTemplate>                                 <Representation bandwidth="1000000" codecs="hev1.2.4.L93.B0" frameRate="60000/1001" height="540" id="Video1_3" sar="1:1" scanType="progressive" width="960"/><Representation bandwidth="4000000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_2" sar="1:1" scanType="progressive" width="1280"/><Representation bandwidth="8000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421990870260960"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.00" id="24"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421990870260960"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_5"/></AdaptationSet>   </Period></MPD>

Service 5009: GMLOOP (24.20)

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.24.20:5000

Hidden: No
App: GameLoop

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:Gameloop:KSAS
Category: 3 (App-Based Service)
SLS Destination: 239.255.24.20:5000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5009"></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://nextgen.gameloop.tv/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tag:sinclairplatform.com,2020:Gameloop:KSAS" bbandEntryPageUrl="https://nextgen.gameloop.tv/run3tv-common/index.html"></HTMLEntryPackage>
</HELD>

Service 5010: ROXi (24.21)

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.24.21:5000

Hidden: No
App: ROXi

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:Roxi:ksas
Category: 3 (App-Based Service)
SLS Destination: 239.255.24.21:5000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5010"></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="2"></item></metadataEnvelope>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://cdn.prod.tvapp.roxi.tv/releases/prod-atsc/index.html#/atsc,faststream,showId=46eb1cf29052,prod

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://cdn.prod.tvapp.roxi.tv/releases/prod-atsc/index.html#/atsc,faststream,showId=46eb1cf29052,prod" appContextId="tag:sinclairplatform.com,2020:Roxi:ksas" />
</HELD>

Other Global LLS Tables

System Time Details - Actual Timestamp in L1Detail

Attribute	Value
currentUtcOffset	37
utcLocalOffset	-PT5H
dsStatus	true

Raw XML

<?xml version="1.0" encoding="utf-8"?>
<SystemTime xmlns="http://www.atsc.org/XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/ SYSTIME-1.0-20211208.xsd" currentUtcOffset="37" utcLocalOffset="-PT5H" dsStatus="true"/>

Input Info

Attribute	Value
Input Type	Debug File
File Name	77063-0-20250919-112318-p0p1-dbg.dbg
Total Packets Processed	31508
File Last Modified	2025-09-19 11:23:18 EDT
Analysis Run Time	2025-11-23 16:15:33 EST

ATSC 3.0 Data Usage Analysis

IP:Port (ID)	Usage ↓	Service	Type	Total Data	Bitrate
239.255.36.1:5001 (TSI 100)	24.11%	KMTW	Video	10.77 MB	N/A
239.255.3.1:5001 (TSI 100)	22.97%	KSNW	Video	10.26 MB	N/A
239.255.10.1:5001 (TSI 100)	22.81%	KAKE	Video	10.20 MB	N/A
239.255.24.1:5001 (TSI 100)	17.84%	KSAS	Video	7.98 MB	N/A
239.255.24.1:5001 (TSI 200)	1.92%	KSAS	Audio	857.1 KB	N/A
239.255.36.1:5001 (TSI 200)	1.91%	KMTW	Audio	855.1 KB	N/A
224.0.23.60:4937 (LLS)	1.53%	LLS Signaling	LLS Signaling	682.2 KB	N/A
239.255.3.1:5001 (TSI 0)	1.11%	KSNW	Service Signaling	496.5 KB	N/A
239.255.10.1:5001 (TSI 0)	0.81%	KAKE	Service Signaling	361.7 KB	N/A
239.255.36.1:5001 (TSI 0)	0.78%	KMTW	Service Signaling	346.4 KB	N/A
239.255.24.1:5001 (TSI 0)	0.77%	KSAS	Service Signaling	342.7 KB	N/A
239.255.3.1:5001 (TSI 200)	0.47%	KSNW	Audio	211.2 KB	N/A
239.255.10.1:5001 (TSI 200)	0.45%	KAKE	Audio	199.9 KB	N/A
239.255.36.1:5100 (TSI 0)	0.36%	ESG	Service Signaling	160.4 KB	N/A
239.255.3.1:5001 (TSI 201)	0.27%	KSNW	Audio	119.7 KB	N/A
239.255.10.1:5001 (TSI 201)	0.25%	KAKE	Audio	109.6 KB	N/A
239.255.24.1:5001 (TSI 201)	0.23%	KSAS	Audio	104.0 KB	N/A
239.255.24.11:5000 (TSI 0)	0.22%	PBTV	Service Signaling	97.5 KB	N/A
239.255.36.1:5100 (TSI 80)	0.20%	ESG	ROUTE Media	91.4 KB	N/A
239.255.24.10:5000 (TSI 0)	0.20%	T2	Service Signaling	90.6 KB	N/A
239.255.24.21:5000 (TSI 0)	0.12%	ROXi	Service Signaling	52.0 KB	N/A
239.255.3.1:5001 (TSI 300)	0.11%	KSNW	Captions	49.5 KB	N/A
239.255.24.20:5000 (TSI 0)	0.11%	GMLOOP	Service Signaling	49.2 KB	N/A
239.255.10.1:5001 (TSI 300)	0.10%	KAKE	Captions	44.4 KB	N/A
239.255.36.100:6000 (TSI 0)	0.09%	DDAAS	Service Signaling	41.4 KB	N/A
239.255.36.1:5100 (TSI 50)	0.08%	ESG	ROUTE Media	36.8 KB	N/A
239.255.36.1:5100 (TSI 60)	0.08%	ESG	ROUTE Media	36.1 KB	N/A
239.255.24.1:5001 (TSI 300)	0.07%	KSAS	Captions	32.4 KB	N/A
239.255.36.1:5001 (TSI 300)	0.04%	KMTW	Captions	15.8 KB	N/A

Total: 44.69 MB | Signaling: 6.09% | Media: 93.91% | Other: 0.00%

RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

Service Summary (SLT BSID: 1182)

Certificate Details

Service 5001: KMTW (36.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4)

Representation ID: 22

Adaptation Set (Content: text, Mime: application/mp4, Lang: und)

Representation ID: Data3_3

Raw XML

Service 5002: ESG

Raw XML

ROUTE Stream: 239.255.36.1:5100

Raw XML

Raw XML

Service 5003: KSAS (24.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: und)

Representation ID: Data4_4

Raw XML

Service 5004: KSNW (3.1) Encrypted

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: und)

Representation ID: Data4_4

Raw XML

Service 5005: KAKE (10.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data4_4

Raw XML

Service 5006: T2 (24.10) Internet Required

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_3

Raw XML

Service 5007: DDAAS Hidden

Raw XML

Raw XML

Service 5008: PBTV (24.11) Internet Required

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Service 5004: KSNW (3.1)

Service 5006: T2 (24.10)

Service 5007: DDAAS

Service 5008: PBTV (24.11)
