RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

PLP ID	SFI	Modulation	Code Rate	Layer	TI Mode	LLS	Lock	Required SNR	Bitrate
0	0	16QAM	9/15	core	hti	Yes	Yes	AWGN: 7.32 dB Rayleigh: 9.94 dB	0.617 Mbps
1	0	256QAM	11/15	core	hti	Yes	Yes	AWGN: 18.76 dB Rayleigh: 21.94 dB	27.730 Mbps

L1 Signaling Details (From L1Detail)

--- L1-Basic Signaling ---

L1B_version: 0

L1B_mimo_scattered_pilot_encoding: Walsh-Hadamard

L1B_lls_flag: LLS present

L1B_time_info_flag: ns precision

L1B_return_channel_flag: 0

L1B_papr_reduction: None

L1B_frame_length_mode: Symbol-aligned

  L1B_time_offset: 5376

  L1B_additional_samples: 0

L1B_num_subframes: 1

L1B_preamble_num_symbols: 1

L1B_preamble_reduced_carriers: 0

L1B_L1_Detail_content_tag: 0

L1B_L1_Detail_size_bytes: 42

L1B_L1_Detail_fec_type: Mode 1

L1B_L1_additional_parity_mode: K=0

L1B_L1_Detail_total_cells: 3611

L1B_first_sub_mimo: No MIMO

L1B_first_sub_miso: 0

L1B_first_sub_fft_size: 16K

L1B_first_sub_reduced_carriers: 0

L1B_first_sub_guard_interval: GI_6_1536

L1B_first_sub_num_ofdm_symbols: 95

L1B_first_sub_scattered_pilot_pattern: 7

L1B_first_sub_scattered_pilot_boost: 0

L1B_first_sub_sbs_first: 1

L1B_first_sub_sbs_last: 1

L1B_crc: 0x00000000

--- L1-Detail Signaling ---

L1D_version: 0

L1D_num_rf: 0

L1D_time_sec: 1758112805

L1D_time_msec: 544

L1D_time_usec: 874

L1D_time_nsec: 333

Subframe #0:

  L1D_frequency_interleaver: Preamble Only

  L1D_sbs_null_cells: 0

  L1D_num_plp: 2

    PLP #0:

      L1D_plp_id: 0

      L1D_plp_lls_flag: 1

      L1D_plp_layer: Core

      L1D_plp_start: 0

      L1D_plp_size: 64800

      L1D_plp_scrambler_type: PRBS

      L1D_plp_fec_type: BCH + 64K LDPC

      L1D_plp_mod: 16QAM

      L1D_plp_cod: 9/15

      L1D_plp_TI_mode: HTI

      L1D_plp_type: non-dispersed

      L1D_plp_HTI_inter_subframe: 0

      L1D_plp_HTI_num_ti_blocks: 1

      L1D_plp_HTI_num_fec_blocks_max: 4

      L1D_plp_HTI_num_fec_blocks: 4

      L1D_plp_HTI_cell_interleaver: 1

      -> PLP Bitrate: 0.617 Mbps

    PLP #1:

      L1D_plp_id: 1

      L1D_plp_lls_flag: 1

      L1D_plp_layer: Core

      L1D_plp_start: 64800

      L1D_plp_size: 1190700

      L1D_plp_scrambler_type: PRBS

      L1D_plp_fec_type: BCH + 64K LDPC

      L1D_plp_mod: 256QAM

      L1D_plp_cod: 11/15

      L1D_plp_TI_mode: HTI

      L1D_plp_type: non-dispersed

      L1D_plp_HTI_inter_subframe: 0

      L1D_plp_HTI_num_ti_blocks: 7

      L1D_plp_HTI_num_fec_blocks_max: 147

      L1D_plp_HTI_num_fec_blocks: 147

      L1D_plp_HTI_cell_interleaver: 1

      -> PLP Bitrate: 27.730 Mbps

L1D_crc: 0xffffffff9f471fba

Link Mapping Table Data Not Available

Service Summary (SLT BSID: 1968)

Service Name	ID	Channel	Protocol / Category	SLS Destination
KXVO	5001	15.1	ROUTE / Linear A/V Service	239.255.15.1:5001
ESG	5002		ROUTE / ESG Service	239.255.15.1:5100
KPTM	5003	42.1	ROUTE / Linear A/V Service	239.255.42.1:5001
WOWT	5004	6.1	ROUTE / Linear A/V Service	239.255.6.1:5001
KETV	5005	7.1	ROUTE / Linear A/V Service	239.255.7.1:5001
KMTV	5006	3.1	ROUTE / Linear A/V Service	239.255.3.1:5001
T2	5007	42.10	ROUTE / Linear A/V Service	239.255.42.10:5000
DDAAS	5008		ROUTE / App-Based Service	239.255.15.100:6000
NE-PBS	5009	26.1	ROUTE / Linear A/V Service	239.255.26.1:5000
PBTV	5010	42.11	ROUTE / Linear A/V Service	239.255.42.11:5000
GMLOOP	5011	42.20	ROUTE / App-Based Service	239.255.42.20:5000
ROXi	5012	42.21	ROUTE / App-Based Service	239.255.42.21:5000

Capability Descriptor Table (CDT) - 3 Certificate(s)

Attribute	Value
OCSP Refresh	P7DT0H
Certificate Count	3

Certificate Details

Certificate 1 - KXVO Signaling Signing CDT 0001 (Valid Until: Oct 12 2025)

Field	Value
Subject	/C=US/ST=NE/L=Omaha/O=Sinclair Broadcast Group, Inc./CN=KXVO Signaling Signing CDT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	4EEC606BF8645A78248322420C4A4EABDA618115
Valid From	Oct 12 17:46:36 2023 GMT
Valid Until	Oct 12 17:46:36 2025 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	62:48:A8:A3:15:ED:E4:F4:80:CD:CD:DA:42:20:FF:EE:54:01:0C:02
SHA-256 Fingerprint	4E:88:D2:5E:20:1F:F5:7F:42:CE:3F:67:94:A0:E5:02:CC:E1:E4:D7:AB:D9:FC:CE:3D:B8:FB:E2:99:B4:EC:
Certificate Authority	No
Self-Signed	No

Certificate 2 - KXVO Signaling Signing SMT 0001 (Valid Until: Oct 12 2025)

Field	Value
Subject	/C=US/ST=NE/L=Omaha/O=Sinclair Broadcast Group, Inc./CN=KXVO Signaling Signing SMT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	48933AB14A828192FFC679D4256FBEA178E96E5F
Valid From	Oct 12 17:47:32 2023 GMT
Valid Until	Oct 12 17:47:32 2025 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	FA:4E:2E:18:94:25:E9:EC:50:57:A7:4E:2F:EE:49:C4:C8:95:DE:E1
SHA-256 Fingerprint	15:C1:7E:5D:75:C5:58:F2:03:16:0A:A2:3D:F6:88:2E:37:6A:96:CC:67:21:66:DF:C1:89:97:6C:5C:90:CA:
Certificate Authority	No
Self-Signed	No

Certificate 3 - ATSC 3.0 Signing CA-2 (Valid Until: Sep 8 2030)

Field	Value
Subject	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Issuer	/C=US/O=Pearl TV/OU=Root CA-1/CN=ATSC3 Root-CA
Serial Number	1D81C0A269A03D9AAF128428593DB6B8
Valid From	Sep 8 00:00:00 2021 GMT
Valid Until	Sep 8 23:59:59 2030 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	06:63:9A:0C:E9:C0:E7:2C:44:05:1C:8A:91:B6:68:FB:25:C4:38:75
SHA-256 Fingerprint	23:42:5B:1C:CA:CB:F3:31:7C:8B:03:59:DA:E0:A3:98:C4:84:05:DB:1B:6B:92:15:58:69:F7:89:30:9A:65:
Certificate Authority	Yes
Self-Signed	No

Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<CertificationData xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/CDT-1.0-20180706.xsd">
<ToBeSignedData OCSPRefresh="P7DT0H"><Certificates>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</Certificates><Certificates>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</Certificates><Certificates>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</Certificates><CurrentCert>SkUmOS5cOFpf1ZqBDDvu3KLpp2w=</CurrentCert></ToBeSignedData>
<CMSSignedData>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</CMSSignedData>
<OCSPResponse>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</OCSPResponse><OCSPResponse>MIIC0AoBAKCCAskwggLFBgkrBgEFBQcwAQEEggK2MIICsjCCARqiFgQUoN79JJBZSAIhlyd/4ZY74oFoxrYYDzIwMjUwOTE1MjE0MTU0WjCB7jB1ME0wCQYFKw4DAhoFAAQU5gvf52P7Wtda0EPbgrceW49evAMEFKDe/SSQWUgCIZcnf+GWO+KBaMa2AhRIkzqxSoKBkv/GedQlb76heOluX4AAGA8yMDI1MDkxNTIxNDE1NFqgERgPMjAyNTA5MjIyMTQxNTRaMHUwTTAJBgUrDgMCGgUABBTmC9/nY/ta11rQQ9uCtx5bj168AwQUoN79JJBZSAIhlyd/4ZY74oFoxrYCFE7sYGv4ZFp4JIMiQgxKTqvaYYEVgAAYDzIwMjUwOTE1MjE0MTU0WqARGA8yMDI1MDkyMjIxNDE1NFowDQYJKoZIhvcNAQENBQADggGBAAaqgDog8SYCS+uqELYfMxpsMFa30M2aWQ6b0z/qtWqH19ObuJlm2niEL85jxeVNEbqZdi5CjapcP4zBvwy9AmhR6D8uQdf2IrEeiAKmC5GD1YO/KO6UMShV8AP0f/FgWdSxGpb9ilvo53dAB9ODXCMpxTsXIdwXLFavNJP6YbiLVgMD7U/iO+tQAOi7ed1fZhpHaO4gUfpUxRkbDxVvbLYTprZTM2E7viDkjSnQsin0jZMsZD/JOWzOeODiIr1grrI0BVJu+z54IVYLsoDtE7S9++U8zY4VH85WUDt70xHDAR4BGwqc36MzhpB85+NO57FlAv92G658VZMfNaMeNVNvBMSzjfdKCGbrHkqta18pHvktuU09IrJi6B/m2NDcf2siE0c6QZOalXUqD8cn7AHv5xeatTAk6C7upTBmD8lF3wQ3kMRQrI7uG84LLJHL4NVXicWtENPgX9nJaG0d3773CF3xFkx+ch+HLZtNubB80zgv6aRfVhLw9KgqNN7qrg==</OCSPResponse><OCSPResponse>MIIIsgoBAKCCCKswgginBgkrBgEFBQcwAQEEggiYMIIIlDCBnqIWBBQlGyMonliwHKjHqZYM3G5k9QwEFxgPMjAyNTA5MTUxNzA2NTRaMHMwcTBJMAkGBSsOAwIaBQAEFM+Hj12/7wjLRzG4kQv8vkI0u9TWBBQFacL8uojw4Bz4cnFYALieCoBxpgIQHYHAommgPZqvEoQoWT22uIAAGA8yMDI1MDkxNTE3MDY1NFqgERgPMjAyNTA5MjIxNzA2NTRaMA0GCSqGSIb3DQEBCwUAA4ICAQBarvXlOqcsr4wqaozs5M/+KhXSUmQkrMJ6MvvKkC/ED2mcO8vn4qzSjGMN9R1sbCbKITA5oBiyRqs9jTcALJegJMRhPWrmb4sMqZvzUUeinLsF0RrOumVm2NlE66HwOmsYlS0sNwI7VjCnKf0hK82S2/pDDUklyjC0vQokwgEIccXADUN734Xg+AWw7e0YGowiHlqbSHzlrGQ+zKnvQNQsB1CZy4uU98wyxyN9Z4Vf6jTMaZ6Mdw/3sNQg5aJ+19C/MhacRYv82vOa6QCeo3R0oCy61PIhsMHeE+YxWcp+JA1iHwKeWHlDB9S6lGmt7R30ARXzeg7JidCzPlcj5gFQfVm+lrFiMx0Qyh9QQhyyJ+leO/LxampOR/B+/Oz2vnYovDEE2LJRAUsZ5V5zXztoe2msKAxrAzV3ghb2slrJY/S6s150TyAruZwI0ygtypOhupETcpV74GvrcSNcwKtCG3B4qtA/uCjTmjCwk/TGbNgiLg2taXojboSD3aLi0TeNK2ip379i6bW2F7Sovzil7ALZorRor28EDuMXVY+uBMyybHuR/+4MtFcgLycFt5610gkQfoMOr4OBOHtqm7zfpN+ULtRDvqR9JGoIFDp7KlcZPa7KlcI9YNI4sxgOqpQbB+2G3JsHgaCn6J8W3jokTWRTjS62Zirmu2L8wZxNFaCCBdswggXXMIIF0zCCA7ugAwIBAgIQHMX0ZUcKBuKgYs03+pW++TANBgkqhkiG9w0BAQsFADBMMQswCQYDVQQGEwJVUzERMA8GA1UEChMIUGVhcmwgVFYxEjAQBgNVBAsTCVJvb3QgQ0EtMTEWMBQGA1UEAxMNQVRTQzMgUm9vdC1DQTAeFw0yMTA0MTQwMDAwMDBaFw0yNjA0MTMyMzU5NTlaMF0xCzAJBgNVBAYTAlVTMREwDwYDVQQKEwhQZWFybCBUVjESMBAGA1UECxMJUm9vdCBDQS0xMScwJQYDVQQDEx5BVFNDMyBSb290LUNBIE9DU1AgUmVzcG9uZGVyIDMwggIiMA0GCSqGSIb3DQEBAQUAA4ICDwAwggIKAoICAQDEmI+HliOvphPufaSpUoAxniQrf3iCrjaycSZ+tQgJlk0ZSux0r/K3GysVt+ZA11RqocX/23sgXfvxjNokhf4ssoADnJ+vv2ghbrmKoGK4NDUwAHw5n9KHZJM4Q6PGhwFm0qaC87zya2Fkks0PwGb/XMlzvd3dGjVpLVDrKQEKdLO9xgv8UE8EH/SfgMoi472BjPmN+lysFD0LkRiepGlP+nJBwklnq+eV7sMaBAMpx1CCcIT3cJx6tEEs4l+MWTQgArzLdyD7z0uFBxvaE6wK/FWx72Ep9fgLnonK/QRfev9z3Fwg8Z+XCbvVpP1DpeaLbmlzY46RHTIX7c31TCIjiCv1IpFg9O0b0ANyQ6xcWgH8fefY9Jylud/U73NivGy/XZXBRatlUf5CEXM54oZ2QNayKD6O4XlGGdmzxy4vz5cpNeaiSu65rUIBsxSBPTuWh9ZkDz5h0sOH4LNvfYrwV9+din0KqPoLyveuE9L8MTtqSN32SqkxAfzoNduL0hd/7TbgRGnNtliJMnLIWQzMcvWGHfKjGrmicNlJfvNE5L/Mkd+1ApOA4AsyQaToLBjB2mrJAvwDmd2s7ILO9mcF582WTgNvrjkEF1RUWtLXBGtaKgJlrc5CECMTIT9r+8hqF33IxSkVbyonMctuypi2z9whsB7b9vDlKBvFagC6hQIDAQABo4GfMIGcMAwGA1UdEwEB/wQCMAAwEwYDVR0lBAwwCgYIKwYBBQUHAwkwDgYDVR0PAQH/BAQDAgeAMA8GCSsGAQUFBzABBQQCBQAwFgYDVR0gBA8wDTALBgkrBgEEAYOUYwEwHQYDVR0OBBYEFCUbIyieWLAcqMeplgzcbmT1DAQXMB8GA1UdIwQYMBaAFAVpwvy6iPDgHPhycVgAuJ4KgHGmMA0GCSqGSIb3DQEBCwUAA4ICAQCRIOGMBfBBOuqVI+yc4iM5DcggxHyyQ7rOWUXefj+reCeofLldvaAUDdBhLoJFzBUPyY6hW0Sf9y3H9zQ/xkNZzuthE66hQ+ss9HsJWargjIqlLSc8AtSyeljcXvF7Ht1dEsQIWOh+rFmGWtvb3pjyVSf5Xhuox/4+MplJ1NcpI6SbbvWk0bSobRgaZfBXpwWCJOFOpBhxsKuQZp3GqeiBr7KaYVwKtKsrctMupYjm6Y2LPl8IPB3zMKFceRQKOAfQfWAcgTVkmDQeTYv910ris8YaX7kPotViuz/erJSTAhrcCx1OLdx3AHFch+QwRXAH+xwYE0Z0qQH95qduqgdUvOL74m90Nu3X88vy4mpyBnAhaZYimJlcPH7Ce1JBtIEX1T9Fhm6HPTj5BIkTRt+s/FQwrPlMjepm5aZbX1A4tDbcPDKyXdvmIIoGKxqbXkE47W4zlgr+YIVA5qIHwPtrE1OUy1n+NNPpXbLVS2AtW1fwLRbgkQtjT/Pu9ZQaB1RgrVpg9w9W1fY8C3vJvTPTVlUVy+MoAkXqXYWXEYxLMWzB0/AzO758LExkRNEl9ko53e5r91vnXPpPmrYSrNSXAXbTL6qVvuQmNvlPW+VmjrozI6TF5IkeLarjo9A9zfxVqGbiAXX/rVeiJr3gEyteGTYPCYEbUxhHeVPRR3xpww==</OCSPResponse>
</CertificationData>

Service List Table (SLT) Instance 1 - Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<SLT bsid="1968" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SLT/1.0/ SLT-1.0-20211209.xsd">
    <Service globalServiceID="tag:sinclairplatform.com,2022:KXVO:1969" majorChannelNo="15" minorChannelNo="1" serviceCategory="1" serviceId="5001" shortServiceName="KXVO" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.15.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service serviceCategory="4" serviceId="5002" shortServiceName="ESG" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.15.1" slsDestinationUdpPort="5100" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2022:KPTM:1973" majorChannelNo="42" minorChannelNo="1" serviceCategory="1" serviceId="5003" shortServiceName="KPTM" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.42.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/9DA4-022A" majorChannelNo="6" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5004" shortServiceName="WOWT" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.6.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/66C7-0A13" majorChannelNo="7" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5005" shortServiceName="KETV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.7.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/735F-698C" majorChannelNo="3" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5006" shortServiceName="KMTV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.3.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:T2:KPTM" majorChannelNo="42" minorChannelNo="10" serviceCategory="1" serviceId="5007" shortServiceName="T2" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.42.10" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:broadspanwireless.com,2023:1968:KXVO:1969" hidden="true" hideInGuide="true" serviceCategory="3" serviceId="5008" shortServiceName="DDAAS" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.15.100" slsDestinationUdpPort="6000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="https://doi.org/10.5239/68EE-3149" majorChannelNo="26" minorChannelNo="1" serviceCategory="1" serviceId="5009" shortServiceName="NE-PBS" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.26.1" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:PBTV:KPTM" majorChannelNo="42" minorChannelNo="11" serviceCategory="1" serviceId="5010" shortServiceName="PBTV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.42.11" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:sinclairplatform.com,2020:Gameloop:KPTM" majorChannelNo="42" minorChannelNo="20" serviceCategory="3" serviceId="5011" shortServiceName="GMLOOP" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.42.20" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:Roxi:kptm" majorChannelNo="42" minorChannelNo="21" serviceCategory="3" serviceId="5012" shortServiceName="ROXi" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.42.21" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
</SLT>

Service 5001: KXVO (15.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.15.1:5001

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 16 ch @ 448 kbps
Codec: ac-4.02.01.02

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2022:KXVO:1969
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.15.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5001"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>d3_3-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	1,'TV-14',{0 'TV-14'}
200	a02_2	audio	N/A
300	d3_3	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4300000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-14',{0 'TV-14'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="448000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d3_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d3_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="17"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="122"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="130"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-16T22:20:50Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4300000 (4.3 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 448000 (448 kbps)
Codecs: ac-4.02.01.02
Audio Sample Rate: 48000 Hz
Audio Channels: 16
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d3_3

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT10.01S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-16T22:20:50Z" timeShiftBufferDepth="PT6.006S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="4300000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>               <Representation audioSamplingRate="48000" bandwidth="448000" codecs="ac-4.02.01.02" id="a02_2"/></AdaptationSet><AdaptationSet contentType="text" id="2" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="subtitle"/>         <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d3_3"/></AdaptationSet>   </Period></MPD>

Service 5002: ESG

Protocol: ROUTE
Category: ESG Service

Source: 172.16.200.1
Destination: 239.255.15.1:5100

Hidden: No
App: No

Service Details (from SLT)

Global Service ID:
Category: 4 (ESG Service)
SLS Destination: 239.255.15.1:5100
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5002"></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: 239.255.15.1:5100

TSI	Representation ID	Content Type	Content Ratings
50			N/A
60			N/A
80			N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1" dIpAddr="239.255.15.1" dPort="5100"><LS tsi="50"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="1585" Content-Location="sgdd_1585" Content-Length="69780" Transfer-Length="6485" Content-Type="application/vnd.oma.bcast.sgdd+xml" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="60"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="3586" Content-Location="sgdu_content_3586" Content-Length="515136" Transfer-Length="43415" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File><fdt:File TOI="4874" Content-Location="sgdu_service_schedule_4874" Content-Length="94988" Transfer-Length="7180" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="80"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="5269" Content-Location="s102116_ll_h15_ac.png" Content-Length="9117" Transfer-Length="8676" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5270" Content-Location="s28719_ll_h15_ac.png" Content-Length="8623" Transfer-Length="8259" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5271" Content-Location="s28717_h3_aa.png" Content-Length="12435" Transfer-Length="11566" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5272" Content-Location="s28708_h3_aa.png" Content-Length="15267" Transfer-Length="15140" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5273" Content-Location="s28711_h3_ba.png" Content-Length="9147" Transfer-Length="8389" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5274" Content-Location="s11039_h3_ba.png" Content-Length="11628" Transfer-Length="10936" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="5"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="1054"></item></metadataEnvelope>

Electronic Service Guide (ESG) - 6 Service(s), 280 Program(s) (from 292 fragments)

Service : NE-PBS (26.1)

Field	Value
ID	urn:digicap:svc:5009:1758031880476
Status	https://doi.org
Description	NE-PBS

Raw XML (0 fragments)

Service : KMTV (3.1)

Field	Value
ID	urn:digicap:svc:5006:1758031880476
Status	https://doi.org
Description	KMTV

Raw XML (0 fragments)

Service : KETV (7.1)

Field	Value
ID	urn:digicap:svc:5005:1758031880476
Status	https://doi.org
Description	KETV

Raw XML (0 fragments)

Service : WOWT (6.1)

Field	Value
ID	urn:digicap:svc:5004:1758031880476
Status	https://doi.org
Description	WOWT

Raw XML (0 fragments)

Service : KPTM (42.1)

Field	Value
ID	urn:digicap:svc:5003:1758031880476
Status	tag:sinclairpla
Description	KPTM

Raw XML (0 fragments)

Service : KXVO (15.1)

Field	Value
ID	urn:digicap:svc:5001:1758031880476
Status	tag:sinclairpla
Description	KXVO

Raw XML (0 fragments)

Service 5003: KPTM (42.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.42.1:5001

Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0

Audio: 16 ch @ 448 kbps
Codec: ac-4.02.01.02

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2022:KPTM:1973
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.42.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5003"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4500000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="448000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="14"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="163"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="182"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-16T22:21:00Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4500000 (4.5 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 448000 (448 kbps)
Codecs: ac-4.02.01.02
Audio Sample Rate: 48000 Hz
Audio Channels: 16
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT10.01S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-16T22:21:00Z" timeShiftBufferDepth="PT6.006S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="4500000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>               <Representation audioSamplingRate="48000" bandwidth="448000" codecs="ac-4.02.01.02" id="a02_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <SegmentTemplate duration="480480" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>

Service 5004: WOWT (6.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.6.1:5001

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: https://doi.org/10.5239/9DA4-022A
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.6.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Protected: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5004"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4700000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="20"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="1"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="197"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="3"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-16T22:20:57Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4700000 (4.7 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wowt_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wowt_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wowt_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT20.02S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-16T22:20:57Z" timeShiftBufferDepth="PT12.012S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="182fd3d6-da9a-595f-b653-769dbbbeed45" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="182fd3d6-da9a-595f-b653-769dbbbeed45" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wowt_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <Supplemental schemeIdUri="http://dashif.org/metadata/hdr" value="SMPTE2094-10"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="4700000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" segmentProfiles="cdm1" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="182fd3d6-da9a-595f-b653-769dbbbeed45" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="182fd3d6-da9a-595f-b653-769dbbbeed45" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wowt_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a02_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="182fd3d6-da9a-595f-b653-769dbbbeed45" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="182fd3d6-da9a-595f-b653-769dbbbeed45" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wowt_g2_p2_1</dashif:Laurl>         </ContentProtection>         <SegmentTemplate duration="480480" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://atsc-v2.gdm-connect.com/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage      appContextId="tv:wowt.gray.tv"      bbandEntryPageUrl="https://atsc-v2.gdm-connect.com/run3tv-common/index.html"></HTMLEntryPackage>
</HELD>

Service 5005: KETV (7.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.7.1:5001

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: https://doi.org/10.5239/66C7-0A13
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.7.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Protected: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5005"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5200000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="16"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="227"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="40"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="2"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-16T22:20:41Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 5200000 (5.2 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ketv_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ketv_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ketv_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="2025-09-16T16:24:59Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT20.02S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-16T22:20:41Z" timeShiftBufferDepth="PT12.012S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="3cc88a74-6817-5d44-be2f-b97a06791df8" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="3cc88a74-6817-5d44-be2f-b97a06791df8" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ketv_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="5200000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="3cc88a74-6817-5d44-be2f-b97a06791df8" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="3cc88a74-6817-5d44-be2f-b97a06791df8" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ketv_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a02_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="3cc88a74-6817-5d44-be2f-b97a06791df8" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="3cc88a74-6817-5d44-be2f-b97a06791df8" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ketv_g2_p2_1</dashif:Laurl>         </ContentProtection>         <SegmentTemplate duration="480480" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://atsc-ec2.htvapps.net/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tv:atsc3-app.ketv.hearst.com"    bbandEntryPageUrl="https://atsc-ec2.htvapps.net/run3tv-common/index.html"></HTMLEntryPackage>
</HELD>

Service 5006: KMTV (3.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.3.1:5001

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: https://doi.org/10.5239/735F-698C
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.3.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Protected: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5006"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-4700000-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4700000" afdt:fileTemplate="video-4700000-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-4700000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="15"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="85"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="247"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-16T22:20:57Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4700000 (4.7 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-$Bandwidth$-init.mp4
- Media URL: video-$Bandwidth$-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kmtv_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kmtv_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kmtv_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2.002S" minimumUpdatePeriod="PT20.02S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-16T22:20:57Z" timeShiftBufferDepth="PT12.012S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="2dc99c37-ca3f-5728-97b7-f6a7bace36b6" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="2dc99c37-ca3f-5728-97b7-f6a7bace36b6" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kmtv_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-$Bandwidth$-init.mp4" media="video-$Bandwidth$-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="4700000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="2dc99c37-ca3f-5728-97b7-f6a7bace36b6" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="2dc99c37-ca3f-5728-97b7-f6a7bace36b6" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>AAAASnBzc2gAAAAA7e+LqXnWSs6jyCfc1R0h7QAAACoiDGttdHZfZzJfcDJfMUjj3JWbBmoUYXRzY19ncm91cDJfcHJvZmlsZTIAAAJocHNzaAAAAADt74upedZKzqPIJ9zVHSHtAAACSCIMa210dl9nMl9wMl8xSOPclZsGWAJqFGF0c2NfZ3JvdXAyX3Byb2ZpbGUyclgKELI+NGFBelB3nq+LC6N25EwSEC3JnDfKP1col7f2p7rONrYaIPIXktkZ3RGivTvoygFqszdx33a6/mLrI9HOcfEP5pIKIhBR+SydVC/RGi58FHIAR6kRclgKEMtonnMvM1NbiAzYoZigpGUSEC3JnDfKP1col7f2p7rONrYaIBHZhsx30nqfvp9ff3aPdtsKB/5t0XFNby9G4NNI7eHqIhCwftqmYdC4F21xSroNzU1pclgKEH4A7S10GVmEiomTF43f9CUSEEDN8FKytVGyh5JkH4zEAasaICflPt7joUHhAUCeneT6KyIse/zoOO1z257XnHLObrzjIhCro0xmQm0eyOe2IPGVABDIclgKEAqxnRcP+VBvjQwDq2QUA5QSEEDN8FKytVGyh5JkH4zEAasaIGoHznH1cRncQDoMrOKFvemQH8E3OoizH0+V01GYTGcDIhAGSCRj2p5X1Wz/m9aMy1PVclgKEIl4mRqH51qelQI9pF9v0BsSEM1P2wWMvV6eieCvZJ4jKtEaIG9bsfIKsE+o68POUl1e45NYNGfu84BsE6DtX7CVR1GEIhBsQpt2yuaPZjL5qmk7g5vLclgKEHg5LB43JVKIjuApVhHyY3wSEM1P2wWMvV6eieCvZJ4jKtEaIOkZKqzVex/BOOie5ZENi4u1u1yLk1tvNp0Eqt56a2uNIhD5Dw361JC64Q93bjPWr3aO</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kmtv_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a02_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="2dc99c37-ca3f-5728-97b7-f6a7bace36b6" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="2dc99c37-ca3f-5728-97b7-f6a7bace36b6" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>AAAASnBzc2gAAAAA7e+LqXnWSs6jyCfc1R0h7QAAACoiDGttdHZfZzJfcDJfMUjj3JWbBmoUYXRzY19ncm91cDJfcHJvZmlsZTIAAAJocHNzaAAAAADt74upedZKzqPIJ9zVHSHtAAACSCIMa210dl9nMl9wMl8xSOPclZsGWAJqFGF0c2NfZ3JvdXAyX3Byb2ZpbGUyclgKELI+NGFBelB3nq+LC6N25EwSEC3JnDfKP1col7f2p7rONrYaIPIXktkZ3RGivTvoygFqszdx33a6/mLrI9HOcfEP5pIKIhBR+SydVC/RGi58FHIAR6kRclgKEMtonnMvM1NbiAzYoZigpGUSEC3JnDfKP1col7f2p7rONrYaIBHZhsx30nqfvp9ff3aPdtsKB/5t0XFNby9G4NNI7eHqIhCwftqmYdC4F21xSroNzU1pclgKEH4A7S10GVmEiomTF43f9CUSEEDN8FKytVGyh5JkH4zEAasaICflPt7joUHhAUCeneT6KyIse/zoOO1z257XnHLObrzjIhCro0xmQm0eyOe2IPGVABDIclgKEAqxnRcP+VBvjQwDq2QUA5QSEEDN8FKytVGyh5JkH4zEAasaIGoHznH1cRncQDoMrOKFvemQH8E3OoizH0+V01GYTGcDIhAGSCRj2p5X1Wz/m9aMy1PVclgKEIl4mRqH51qelQI9pF9v0BsSEM1P2wWMvV6eieCvZJ4jKtEaIG9bsfIKsE+o68POUl1e45NYNGfu84BsE6DtX7CVR1GEIhBsQpt2yuaPZjL5qmk7g5vLclgKEHg5LB43JVKIjuApVhHyY3wSEM1P2wWMvV6eieCvZJ4jKtEaIOkZKqzVex/BOOie5ZENi4u1u1yLk1tvNp0Eqt56a2uNIhD5Dw361JC64Q93bjPWr3aO</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kmtv_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <SegmentTemplate duration="480480" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://ota.ewscloud.com/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage
      appContextId="tv:ota-kmtv.ewscloud.com"
      bbandEntryPageUrl="https://ota.ewscloud.com/run3tv-common/index.html" >
  </HTMLEntryPackage>
</HELD>

Service 5007: T2 (42.10)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.42.10:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 384 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:T2:KPTM
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.42.10:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5007"><DeliveryMethod><UnicastAppService><BasePattern>a0-22-</BasePattern><BasePattern>d0-Data3_3-</BasePattern><BasePattern>video-Video1_1-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="18"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="226"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-16T22:20:58Z)

Type: dynamic
Min Buffer Time: PT10S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 7000000 (7.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=421934687734560, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 384000 (384 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Timescale: 240000
- S: t=421934687734560, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_3

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 240000
- S: t=421934687734560, d=480480, r=29

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-16T22:20:58Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://kptm-sbgtv.atsc.stream/t2/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421934687734560"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="7000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421934687734560"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421934687734560"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_3"/></AdaptationSet>   </Period></MPD>

Service 5008: DDAAS

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.15.100:6000

Hidden: Service & Guide
App: No

Service Details (from SLT)

Global Service ID: tag:broadspanwireless.com,2023:1968:KXVO:1969
Category: 3 (App-Based Service)
SLS Destination: 239.255.15.100:6000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)
Hidden: Yes
Hide in Guide: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5008"></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item></metadataEnvelope>

Service 5009: NE-PBS (26.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.26.1:5000

Video: 1920x1080p (59.94 fps)
Codec: hvc1.2.4.L153.B0

Audio: 2 ch @ 96 kbps
Codec: ac-4.02.01.00

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: https://doi.org/10.5239/68EE-3149
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.26.1:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5009"><DeliveryMethod><UnicastAppService><BasePattern>01item_Segment-</BasePattern><BasePattern>02item_Segment-</BasePattern><BasePattern>03item_Segment-</BasePattern><BasePattern>04item_Segment-</BasePattern><BasePattern>05item_Segment-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="50"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="115"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="2"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-16T22:20:49.763Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: , Mime: video/mp4, PAR: 16:9)

Representation ID: 01item

Bandwidth: 5000000 (5.0 Mbps)
Codecs: hvc1.2.4.L153.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 48000
- S: t=1361409992289, d=96096, r=29

Adaptation Set (Content: , Mime: audio/mp4, Lang: eng)

Representation ID: 02item

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 48000
- S: t=1361410008305, d=80080, r=0
- S: t=1361410088385, d=120120, r=0
- S: t=1361410208505, d=80080, r=0
- S: t=1361410288585, d=120120, r=0
- S: t=1361410408705, d=80080, r=1
- S: t=1361410568865, d=120120, r=0
- S: t=1361410688985, d=80080, r=0
- S: t=1361410769065, d=120120, r=0
- S: t=1361410889185, d=80080, r=1
- S: t=1361411049345, d=120120, r=0
- S: t=1361411169465, d=80080, r=0
- S: t=1361411249545, d=120120, r=0
- S: t=1361411369665, d=80080, r=1
- S: t=1361411529825, d=120120, r=0
- S: t=1361411649945, d=80080, r=0
- S: t=1361411730025, d=120120, r=0
- S: t=1361411850145, d=80080, r=1
- S: t=1361412010305, d=120120, r=0
- S: t=1361412130425, d=80080, r=0
- S: t=1361412210505, d=120120, r=0
- S: t=1361412330625, d=80080, r=1
- S: t=1361412490785, d=120120, r=0
- S: t=1361412610905, d=80080, r=0
- S: t=1361412690985, d=120120, r=0
- S: t=1361412811105, d=80080, r=0

Adaptation Set (Content: , Mime: audio/mp4, Lang: spa)

Representation ID: 03item

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 48000
- S: t=1361410008305, d=80080, r=0
- S: t=1361410088385, d=120120, r=0
- S: t=1361410208505, d=80080, r=0
- S: t=1361410288585, d=120120, r=0
- S: t=1361410408705, d=80080, r=1
- S: t=1361410568865, d=120120, r=0
- S: t=1361410688985, d=80080, r=0
- S: t=1361410769065, d=120120, r=0
- S: t=1361410889185, d=80080, r=1
- S: t=1361411049345, d=120120, r=0
- S: t=1361411169465, d=80080, r=0
- S: t=1361411249545, d=120120, r=0
- S: t=1361411369665, d=80080, r=1
- S: t=1361411529825, d=120120, r=0
- S: t=1361411649945, d=80080, r=0
- S: t=1361411730025, d=120120, r=0
- S: t=1361411850145, d=80080, r=1
- S: t=1361412010305, d=120120, r=0
- S: t=1361412130425, d=80080, r=0
- S: t=1361412210505, d=120120, r=0
- S: t=1361412330625, d=80080, r=1
- S: t=1361412490785, d=120120, r=0
- S: t=1361412610905, d=80080, r=0
- S: t=1361412690985, d=120120, r=0
- S: t=1361412811105, d=80080, r=0

Adaptation Set (Content: , Mime: audio/mp4, Lang: eng)

Representation ID: 04item

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 48000
- S: t=1361410008305, d=80080, r=0
- S: t=1361410088385, d=120120, r=0
- S: t=1361410208505, d=80080, r=0
- S: t=1361410288585, d=120120, r=0
- S: t=1361410408705, d=80080, r=1
- S: t=1361410568865, d=120120, r=0
- S: t=1361410688985, d=80080, r=0
- S: t=1361410769065, d=120120, r=0
- S: t=1361410889185, d=80080, r=1
- S: t=1361411049345, d=120120, r=0
- S: t=1361411169465, d=80080, r=0
- S: t=1361411249545, d=120120, r=0
- S: t=1361411369665, d=80080, r=1
- S: t=1361411529825, d=120120, r=0
- S: t=1361411649945, d=80080, r=0
- S: t=1361411730025, d=120120, r=0
- S: t=1361411850145, d=80080, r=1
- S: t=1361412010305, d=120120, r=0
- S: t=1361412130425, d=80080, r=0
- S: t=1361412210505, d=120120, r=0
- S: t=1361412330625, d=80080, r=1
- S: t=1361412490785, d=120120, r=0
- S: t=1361412610905, d=80080, r=0
- S: t=1361412690985, d=120120, r=0
- S: t=1361412811105, d=80080, r=0

Adaptation Set (Content: , Mime: application/mp4, Lang: eng)

Representation ID: 05item

Bandwidth: 15000 (15 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 48000
- S: t=1361409992289, d=96096, r=29

Raw XML

<MPD profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" type="dynamic" availabilityStartTime="2024-10-23T15:48:09Z" minimumUpdatePeriod="PT2.0S" minBufferTime="PT2.002S" publishTime="2025-09-16T22:20:49.763Z" timeShiftBufferDepth="PT60.0S" suggestedPresentationDelay="PT2.002S" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:dolby="http://www.dolby.com/ns/online/DASH" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd">	<Period start="PT0S" id="1">		<BaseURL>https://nebraskapublicmedia.atsc.stream/pbs/</BaseURL><AdaptationSet mimeType="video/mp4" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-cgcompatibility" value="1"/>			<RandomAccess interval="96096"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4v" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="96096" r="29" t="1361409992289"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation bandwidth="5000000" codecs="hvc1.2.4.L153.B0" frameRate="60000/1001" height="1080" id="01item" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<RandomAccess interval="96096"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4a" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="80080" t="1361410008305"/>					<S d="120120" t="1361410088385"/>					<S d="80080" t="1361410208505"/>					<S d="120120" t="1361410288585"/>					<S d="80080" r="1" t="1361410408705"/>					<S d="120120" t="1361410568865"/>					<S d="80080" t="1361410688985"/>					<S d="120120" t="1361410769065"/>					<S d="80080" r="1" t="1361410889185"/>					<S d="120120" t="1361411049345"/>					<S d="80080" t="1361411169465"/>					<S d="120120" t="1361411249545"/>					<S d="80080" r="1" t="1361411369665"/>					<S d="120120" t="1361411529825"/>					<S d="80080" t="1361411649945"/>					<S d="120120" t="1361411730025"/>					<S d="80080" r="1" t="1361411850145"/>					<S d="120120" t="1361412010305"/>					<S d="80080" t="1361412130425"/>					<S d="120120" t="1361412210505"/>					<S d="80080" r="1" t="1361412330625"/>					<S d="120120" t="1361412490785"/>					<S d="80080" t="1361412610905"/>					<S d="120120" t="1361412690985"/>					<S d="80080" t="1361412811105"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="02item">				<AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>			</Representation></AdaptationSet><AdaptationSet lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<RandomAccess interval="96096"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="alternate"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4a" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="80080" t="1361410008305"/>					<S d="120120" t="1361410088385"/>					<S d="80080" t="1361410208505"/>					<S d="120120" t="1361410288585"/>					<S d="80080" r="1" t="1361410408705"/>					<S d="120120" t="1361410568865"/>					<S d="80080" t="1361410688985"/>					<S d="120120" t="1361410769065"/>					<S d="80080" r="1" t="1361410889185"/>					<S d="120120" t="1361411049345"/>					<S d="80080" t="1361411169465"/>					<S d="120120" t="1361411249545"/>					<S d="80080" r="1" t="1361411369665"/>					<S d="120120" t="1361411529825"/>					<S d="80080" t="1361411649945"/>					<S d="120120" t="1361411730025"/>					<S d="80080" r="1" t="1361411850145"/>					<S d="120120" t="1361412010305"/>					<S d="80080" t="1361412130425"/>					<S d="120120" t="1361412210505"/>					<S d="80080" r="1" t="1361412330625"/>					<S d="120120" t="1361412490785"/>					<S d="80080" t="1361412610905"/>					<S d="120120" t="1361412690985"/>					<S d="80080" t="1361412811105"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="03item">				<AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>			</Representation></AdaptationSet><AdaptationSet lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<RandomAccess interval="96096"/>			<Accessibility schemeIdUri="urn:tva:metadata:cs:AudioPurposeCS:2007" value="1"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="alternate"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4a" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="80080" t="1361410008305"/>					<S d="120120" t="1361410088385"/>					<S d="80080" t="1361410208505"/>					<S d="120120" t="1361410288585"/>					<S d="80080" r="1" t="1361410408705"/>					<S d="120120" t="1361410568865"/>					<S d="80080" t="1361410688985"/>					<S d="120120" t="1361410769065"/>					<S d="80080" r="1" t="1361410889185"/>					<S d="120120" t="1361411049345"/>					<S d="80080" t="1361411169465"/>					<S d="120120" t="1361411249545"/>					<S d="80080" r="1" t="1361411369665"/>					<S d="120120" t="1361411529825"/>					<S d="80080" t="1361411649945"/>					<S d="120120" t="1361411730025"/>					<S d="80080" r="1" t="1361411850145"/>					<S d="120120" t="1361412010305"/>					<S d="80080" t="1361412130425"/>					<S d="120120" t="1361412210505"/>					<S d="80080" r="1" t="1361412330625"/>					<S d="120120" t="1361412490785"/>					<S d="80080" t="1361412610905"/>					<S d="120120" t="1361412690985"/>					<S d="80080" t="1361412811105"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="04item">				<AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>			</Representation></AdaptationSet><AdaptationSet lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4s" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="96096" r="29" t="1361409992289"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation bandwidth="15000" codecs="stpp.ttml.im1t" id="05item"/></AdaptationSet>	</Period></MPD>

Media Presentation Description (MPD) Instance 2 (Published: 2025-09-16T22:20:51.565Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: , Mime: video/mp4, PAR: 16:9)

Representation ID: 01item

Bandwidth: 5000000 (5.0 Mbps)
Codecs: hvc1.2.4.L153.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 48000
- S: t=1361410088385, d=96096, r=29

Adaptation Set (Content: , Mime: audio/mp4, Lang: eng)

Representation ID: 02item

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 48000
- S: t=1361410088385, d=120120, r=0
- S: t=1361410208505, d=80080, r=0
- S: t=1361410288585, d=120120, r=0
- S: t=1361410408705, d=80080, r=1
- S: t=1361410568865, d=120120, r=0
- S: t=1361410688985, d=80080, r=0
- S: t=1361410769065, d=120120, r=0
- S: t=1361410889185, d=80080, r=1
- S: t=1361411049345, d=120120, r=0
- S: t=1361411169465, d=80080, r=0
- S: t=1361411249545, d=120120, r=0
- S: t=1361411369665, d=80080, r=1
- S: t=1361411529825, d=120120, r=0
- S: t=1361411649945, d=80080, r=0
- S: t=1361411730025, d=120120, r=0
- S: t=1361411850145, d=80080, r=1
- S: t=1361412010305, d=120120, r=0
- S: t=1361412130425, d=80080, r=0
- S: t=1361412210505, d=120120, r=0
- S: t=1361412330625, d=80080, r=1
- S: t=1361412490785, d=120120, r=0
- S: t=1361412610905, d=80080, r=0
- S: t=1361412690985, d=120120, r=0
- S: t=1361412811105, d=80080, r=1

Adaptation Set (Content: , Mime: audio/mp4, Lang: spa)

Representation ID: 03item

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 48000
- S: t=1361410088385, d=120120, r=0
- S: t=1361410208505, d=80080, r=0
- S: t=1361410288585, d=120120, r=0
- S: t=1361410408705, d=80080, r=1
- S: t=1361410568865, d=120120, r=0
- S: t=1361410688985, d=80080, r=0
- S: t=1361410769065, d=120120, r=0
- S: t=1361410889185, d=80080, r=1
- S: t=1361411049345, d=120120, r=0
- S: t=1361411169465, d=80080, r=0
- S: t=1361411249545, d=120120, r=0
- S: t=1361411369665, d=80080, r=1
- S: t=1361411529825, d=120120, r=0
- S: t=1361411649945, d=80080, r=0
- S: t=1361411730025, d=120120, r=0
- S: t=1361411850145, d=80080, r=1
- S: t=1361412010305, d=120120, r=0
- S: t=1361412130425, d=80080, r=0
- S: t=1361412210505, d=120120, r=0
- S: t=1361412330625, d=80080, r=1
- S: t=1361412490785, d=120120, r=0
- S: t=1361412610905, d=80080, r=0
- S: t=1361412690985, d=120120, r=0
- S: t=1361412811105, d=80080, r=1

Adaptation Set (Content: , Mime: audio/mp4, Lang: eng)

Representation ID: 04item

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 48000
- S: t=1361410088385, d=120120, r=0
- S: t=1361410208505, d=80080, r=0
- S: t=1361410288585, d=120120, r=0
- S: t=1361410408705, d=80080, r=1
- S: t=1361410568865, d=120120, r=0
- S: t=1361410688985, d=80080, r=0
- S: t=1361410769065, d=120120, r=0
- S: t=1361410889185, d=80080, r=1
- S: t=1361411049345, d=120120, r=0
- S: t=1361411169465, d=80080, r=0
- S: t=1361411249545, d=120120, r=0
- S: t=1361411369665, d=80080, r=1
- S: t=1361411529825, d=120120, r=0
- S: t=1361411649945, d=80080, r=0
- S: t=1361411730025, d=120120, r=0
- S: t=1361411850145, d=80080, r=1
- S: t=1361412010305, d=120120, r=0
- S: t=1361412130425, d=80080, r=0
- S: t=1361412210505, d=120120, r=0
- S: t=1361412330625, d=80080, r=1
- S: t=1361412490785, d=120120, r=0
- S: t=1361412610905, d=80080, r=0
- S: t=1361412690985, d=120120, r=0
- S: t=1361412811105, d=80080, r=1

Adaptation Set (Content: , Mime: application/mp4, Lang: eng)

Representation ID: 05item

Bandwidth: 15000 (15 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 48000
- S: t=1361410088385, d=96096, r=29

Raw XML

<MPD profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" type="dynamic" availabilityStartTime="2024-10-23T15:48:09Z" minimumUpdatePeriod="PT2.0S" minBufferTime="PT2.002S" publishTime="2025-09-16T22:20:51.565Z" timeShiftBufferDepth="PT60.0S" suggestedPresentationDelay="PT2.002S" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:dolby="http://www.dolby.com/ns/online/DASH" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd">	<Period start="PT0S" id="1">		<BaseURL>https://nebraskapublicmedia.atsc.stream/pbs/</BaseURL><AdaptationSet mimeType="video/mp4" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-cgcompatibility" value="1"/>			<RandomAccess interval="96096"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4v" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="96096" r="29" t="1361410088385"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation bandwidth="5000000" codecs="hvc1.2.4.L153.B0" frameRate="60000/1001" height="1080" id="01item" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<RandomAccess interval="96096"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4a" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="120120" t="1361410088385"/>					<S d="80080" t="1361410208505"/>					<S d="120120" t="1361410288585"/>					<S d="80080" r="1" t="1361410408705"/>					<S d="120120" t="1361410568865"/>					<S d="80080" t="1361410688985"/>					<S d="120120" t="1361410769065"/>					<S d="80080" r="1" t="1361410889185"/>					<S d="120120" t="1361411049345"/>					<S d="80080" t="1361411169465"/>					<S d="120120" t="1361411249545"/>					<S d="80080" r="1" t="1361411369665"/>					<S d="120120" t="1361411529825"/>					<S d="80080" t="1361411649945"/>					<S d="120120" t="1361411730025"/>					<S d="80080" r="1" t="1361411850145"/>					<S d="120120" t="1361412010305"/>					<S d="80080" t="1361412130425"/>					<S d="120120" t="1361412210505"/>					<S d="80080" r="1" t="1361412330625"/>					<S d="120120" t="1361412490785"/>					<S d="80080" t="1361412610905"/>					<S d="120120" t="1361412690985"/>					<S d="80080" r="1" t="1361412811105"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="02item">				<AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>			</Representation></AdaptationSet><AdaptationSet lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<RandomAccess interval="96096"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="alternate"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4a" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="120120" t="1361410088385"/>					<S d="80080" t="1361410208505"/>					<S d="120120" t="1361410288585"/>					<S d="80080" r="1" t="1361410408705"/>					<S d="120120" t="1361410568865"/>					<S d="80080" t="1361410688985"/>					<S d="120120" t="1361410769065"/>					<S d="80080" r="1" t="1361410889185"/>					<S d="120120" t="1361411049345"/>					<S d="80080" t="1361411169465"/>					<S d="120120" t="1361411249545"/>					<S d="80080" r="1" t="1361411369665"/>					<S d="120120" t="1361411529825"/>					<S d="80080" t="1361411649945"/>					<S d="120120" t="1361411730025"/>					<S d="80080" r="1" t="1361411850145"/>					<S d="120120" t="1361412010305"/>					<S d="80080" t="1361412130425"/>					<S d="120120" t="1361412210505"/>					<S d="80080" r="1" t="1361412330625"/>					<S d="120120" t="1361412490785"/>					<S d="80080" t="1361412610905"/>					<S d="120120" t="1361412690985"/>					<S d="80080" r="1" t="1361412811105"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="03item">				<AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>			</Representation></AdaptationSet><AdaptationSet lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<RandomAccess interval="96096"/>			<Accessibility schemeIdUri="urn:tva:metadata:cs:AudioPurposeCS:2007" value="1"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="alternate"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4a" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="120120" t="1361410088385"/>					<S d="80080" t="1361410208505"/>					<S d="120120" t="1361410288585"/>					<S d="80080" r="1" t="1361410408705"/>					<S d="120120" t="1361410568865"/>					<S d="80080" t="1361410688985"/>					<S d="120120" t="1361410769065"/>					<S d="80080" r="1" t="1361410889185"/>					<S d="120120" t="1361411049345"/>					<S d="80080" t="1361411169465"/>					<S d="120120" t="1361411249545"/>					<S d="80080" r="1" t="1361411369665"/>					<S d="120120" t="1361411529825"/>					<S d="80080" t="1361411649945"/>					<S d="120120" t="1361411730025"/>					<S d="80080" r="1" t="1361411850145"/>					<S d="120120" t="1361412010305"/>					<S d="80080" t="1361412130425"/>					<S d="120120" t="1361412210505"/>					<S d="80080" r="1" t="1361412330625"/>					<S d="120120" t="1361412490785"/>					<S d="80080" t="1361412610905"/>					<S d="120120" t="1361412690985"/>					<S d="80080" r="1" t="1361412811105"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="04item">				<AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>			</Representation></AdaptationSet><AdaptationSet lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4s" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="96096" r="29" t="1361410088385"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation bandwidth="15000" codecs="stpp.ttml.im1t" id="05item"/></AdaptationSet>	</Period></MPD>

Media Presentation Description (MPD) Instance 3 (Published: 2025-09-16T22:20:52.366Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: , Mime: video/mp4, PAR: 16:9)

Representation ID: 01item

Bandwidth: 5000000 (5.0 Mbps)
Codecs: hvc1.2.4.L153.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 48000
- S: t=1361410184481, d=96096, r=29

Adaptation Set (Content: , Mime: audio/mp4, Lang: eng)

Representation ID: 02item

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 48000
- S: t=1361410208505, d=80080, r=0
- S: t=1361410288585, d=120120, r=0
- S: t=1361410408705, d=80080, r=1
- S: t=1361410568865, d=120120, r=0
- S: t=1361410688985, d=80080, r=0
- S: t=1361410769065, d=120120, r=0
- S: t=1361410889185, d=80080, r=1
- S: t=1361411049345, d=120120, r=0
- S: t=1361411169465, d=80080, r=0
- S: t=1361411249545, d=120120, r=0
- S: t=1361411369665, d=80080, r=1
- S: t=1361411529825, d=120120, r=0
- S: t=1361411649945, d=80080, r=0
- S: t=1361411730025, d=120120, r=0
- S: t=1361411850145, d=80080, r=1
- S: t=1361412010305, d=120120, r=0
- S: t=1361412130425, d=80080, r=0
- S: t=1361412210505, d=120120, r=0
- S: t=1361412330625, d=80080, r=1
- S: t=1361412490785, d=120120, r=0
- S: t=1361412610905, d=80080, r=0
- S: t=1361412690985, d=120120, r=0
- S: t=1361412811105, d=80080, r=1

Adaptation Set (Content: , Mime: audio/mp4, Lang: spa)

Representation ID: 03item

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 48000
- S: t=1361410208505, d=80080, r=0
- S: t=1361410288585, d=120120, r=0
- S: t=1361410408705, d=80080, r=1
- S: t=1361410568865, d=120120, r=0
- S: t=1361410688985, d=80080, r=0
- S: t=1361410769065, d=120120, r=0
- S: t=1361410889185, d=80080, r=1
- S: t=1361411049345, d=120120, r=0
- S: t=1361411169465, d=80080, r=0
- S: t=1361411249545, d=120120, r=0
- S: t=1361411369665, d=80080, r=1
- S: t=1361411529825, d=120120, r=0
- S: t=1361411649945, d=80080, r=0
- S: t=1361411730025, d=120120, r=0
- S: t=1361411850145, d=80080, r=1
- S: t=1361412010305, d=120120, r=0
- S: t=1361412130425, d=80080, r=0
- S: t=1361412210505, d=120120, r=0
- S: t=1361412330625, d=80080, r=1
- S: t=1361412490785, d=120120, r=0
- S: t=1361412610905, d=80080, r=0
- S: t=1361412690985, d=120120, r=0
- S: t=1361412811105, d=80080, r=1

Adaptation Set (Content: , Mime: audio/mp4, Lang: eng)

Representation ID: 04item

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 48000
- S: t=1361410208505, d=80080, r=0
- S: t=1361410288585, d=120120, r=0
- S: t=1361410408705, d=80080, r=1
- S: t=1361410568865, d=120120, r=0
- S: t=1361410688985, d=80080, r=0
- S: t=1361410769065, d=120120, r=0
- S: t=1361410889185, d=80080, r=1
- S: t=1361411049345, d=120120, r=0
- S: t=1361411169465, d=80080, r=0
- S: t=1361411249545, d=120120, r=0
- S: t=1361411369665, d=80080, r=1
- S: t=1361411529825, d=120120, r=0
- S: t=1361411649945, d=80080, r=0
- S: t=1361411730025, d=120120, r=0
- S: t=1361411850145, d=80080, r=1
- S: t=1361412010305, d=120120, r=0
- S: t=1361412130425, d=80080, r=0
- S: t=1361412210505, d=120120, r=0
- S: t=1361412330625, d=80080, r=1
- S: t=1361412490785, d=120120, r=0
- S: t=1361412610905, d=80080, r=0
- S: t=1361412690985, d=120120, r=0
- S: t=1361412811105, d=80080, r=1

Adaptation Set (Content: , Mime: application/mp4, Lang: eng)

Representation ID: 05item

Bandwidth: 15000 (15 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 48000
- S: t=1361410184481, d=96096, r=29

Raw XML

<MPD profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" type="dynamic" availabilityStartTime="2024-10-23T15:48:09Z" minimumUpdatePeriod="PT2.0S" minBufferTime="PT2.002S" publishTime="2025-09-16T22:20:52.366Z" timeShiftBufferDepth="PT60.0S" suggestedPresentationDelay="PT2.002S" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:dolby="http://www.dolby.com/ns/online/DASH" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd">	<Period start="PT0S" id="1">		<BaseURL>https://nebraskapublicmedia.atsc.stream/pbs/</BaseURL><AdaptationSet mimeType="video/mp4" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-cgcompatibility" value="1"/>			<RandomAccess interval="96096"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4v" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="96096" r="29" t="1361410184481"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation bandwidth="5000000" codecs="hvc1.2.4.L153.B0" frameRate="60000/1001" height="1080" id="01item" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<RandomAccess interval="96096"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4a" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="80080" t="1361410208505"/>					<S d="120120" t="1361410288585"/>					<S d="80080" r="1" t="1361410408705"/>					<S d="120120" t="1361410568865"/>					<S d="80080" t="1361410688985"/>					<S d="120120" t="1361410769065"/>					<S d="80080" r="1" t="1361410889185"/>					<S d="120120" t="1361411049345"/>					<S d="80080" t="1361411169465"/>					<S d="120120" t="1361411249545"/>					<S d="80080" r="1" t="1361411369665"/>					<S d="120120" t="1361411529825"/>					<S d="80080" t="1361411649945"/>					<S d="120120" t="1361411730025"/>					<S d="80080" r="1" t="1361411850145"/>					<S d="120120" t="1361412010305"/>					<S d="80080" t="1361412130425"/>					<S d="120120" t="1361412210505"/>					<S d="80080" r="1" t="1361412330625"/>					<S d="120120" t="1361412490785"/>					<S d="80080" t="1361412610905"/>					<S d="120120" t="1361412690985"/>					<S d="80080" r="1" t="1361412811105"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="02item">				<AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>			</Representation></AdaptationSet><AdaptationSet lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<RandomAccess interval="96096"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="alternate"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4a" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="80080" t="1361410208505"/>					<S d="120120" t="1361410288585"/>					<S d="80080" r="1" t="1361410408705"/>					<S d="120120" t="1361410568865"/>					<S d="80080" t="1361410688985"/>					<S d="120120" t="1361410769065"/>					<S d="80080" r="1" t="1361410889185"/>					<S d="120120" t="1361411049345"/>					<S d="80080" t="1361411169465"/>					<S d="120120" t="1361411249545"/>					<S d="80080" r="1" t="1361411369665"/>					<S d="120120" t="1361411529825"/>					<S d="80080" t="1361411649945"/>					<S d="120120" t="1361411730025"/>					<S d="80080" r="1" t="1361411850145"/>					<S d="120120" t="1361412010305"/>					<S d="80080" t="1361412130425"/>					<S d="120120" t="1361412210505"/>					<S d="80080" r="1" t="1361412330625"/>					<S d="120120" t="1361412490785"/>					<S d="80080" t="1361412610905"/>					<S d="120120" t="1361412690985"/>					<S d="80080" r="1" t="1361412811105"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="03item">				<AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>			</Representation></AdaptationSet><AdaptationSet lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<RandomAccess interval="96096"/>			<Accessibility schemeIdUri="urn:tva:metadata:cs:AudioPurposeCS:2007" value="1"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="alternate"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4a" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="80080" t="1361410208505"/>					<S d="120120" t="1361410288585"/>					<S d="80080" r="1" t="1361410408705"/>					<S d="120120" t="1361410568865"/>					<S d="80080" t="1361410688985"/>					<S d="120120" t="1361410769065"/>					<S d="80080" r="1" t="1361410889185"/>					<S d="120120" t="1361411049345"/>					<S d="80080" t="1361411169465"/>					<S d="120120" t="1361411249545"/>					<S d="80080" r="1" t="1361411369665"/>					<S d="120120" t="1361411529825"/>					<S d="80080" t="1361411649945"/>					<S d="120120" t="1361411730025"/>					<S d="80080" r="1" t="1361411850145"/>					<S d="120120" t="1361412010305"/>					<S d="80080" t="1361412130425"/>					<S d="120120" t="1361412210505"/>					<S d="80080" r="1" t="1361412330625"/>					<S d="120120" t="1361412490785"/>					<S d="80080" t="1361412610905"/>					<S d="120120" t="1361412690985"/>					<S d="80080" r="1" t="1361412811105"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="04item">				<AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>			</Representation></AdaptationSet><AdaptationSet lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4s" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="96096" r="29" t="1361410184481"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation bandwidth="15000" codecs="stpp.ttml.im1t" id="05item"/></AdaptationSet>	</Period></MPD>

Media Presentation Description (MPD) Instance 4 (Published: 2025-09-16T22:20:55.669Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: , Mime: video/mp4, PAR: 16:9)

Representation ID: 01item

Bandwidth: 5000000 (5.0 Mbps)
Codecs: hvc1.2.4.L153.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 48000
- S: t=1361410280577, d=96096, r=29

Adaptation Set (Content: , Mime: audio/mp4, Lang: eng)

Representation ID: 02item

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 48000
- S: t=1361410288585, d=120120, r=0
- S: t=1361410408705, d=80080, r=1
- S: t=1361410568865, d=120120, r=0
- S: t=1361410688985, d=80080, r=0
- S: t=1361410769065, d=120120, r=0
- S: t=1361410889185, d=80080, r=1
- S: t=1361411049345, d=120120, r=0
- S: t=1361411169465, d=80080, r=0
- S: t=1361411249545, d=120120, r=0
- S: t=1361411369665, d=80080, r=1
- S: t=1361411529825, d=120120, r=0
- S: t=1361411649945, d=80080, r=0
- S: t=1361411730025, d=120120, r=0
- S: t=1361411850145, d=80080, r=1
- S: t=1361412010305, d=120120, r=0
- S: t=1361412130425, d=80080, r=0
- S: t=1361412210505, d=120120, r=0
- S: t=1361412330625, d=80080, r=1
- S: t=1361412490785, d=120120, r=0
- S: t=1361412610905, d=80080, r=0
- S: t=1361412690985, d=120120, r=0
- S: t=1361412811105, d=80080, r=1
- S: t=1361412971265, d=120120, r=0
- S: t=1361413091385, d=80080, r=0

Adaptation Set (Content: , Mime: audio/mp4, Lang: spa)

Representation ID: 03item

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 48000
- S: t=1361410288585, d=120120, r=0
- S: t=1361410408705, d=80080, r=1
- S: t=1361410568865, d=120120, r=0
- S: t=1361410688985, d=80080, r=0
- S: t=1361410769065, d=120120, r=0
- S: t=1361410889185, d=80080, r=1
- S: t=1361411049345, d=120120, r=0
- S: t=1361411169465, d=80080, r=0
- S: t=1361411249545, d=120120, r=0
- S: t=1361411369665, d=80080, r=1
- S: t=1361411529825, d=120120, r=0
- S: t=1361411649945, d=80080, r=0
- S: t=1361411730025, d=120120, r=0
- S: t=1361411850145, d=80080, r=1
- S: t=1361412010305, d=120120, r=0
- S: t=1361412130425, d=80080, r=0
- S: t=1361412210505, d=120120, r=0
- S: t=1361412330625, d=80080, r=1
- S: t=1361412490785, d=120120, r=0
- S: t=1361412610905, d=80080, r=0
- S: t=1361412690985, d=120120, r=0
- S: t=1361412811105, d=80080, r=1
- S: t=1361412971265, d=120120, r=0
- S: t=1361413091385, d=80080, r=0

Adaptation Set (Content: , Mime: audio/mp4, Lang: eng)

Representation ID: 04item

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 48000
- S: t=1361410288585, d=120120, r=0
- S: t=1361410408705, d=80080, r=1
- S: t=1361410568865, d=120120, r=0
- S: t=1361410688985, d=80080, r=0
- S: t=1361410769065, d=120120, r=0
- S: t=1361410889185, d=80080, r=1
- S: t=1361411049345, d=120120, r=0
- S: t=1361411169465, d=80080, r=0
- S: t=1361411249545, d=120120, r=0
- S: t=1361411369665, d=80080, r=1
- S: t=1361411529825, d=120120, r=0
- S: t=1361411649945, d=80080, r=0
- S: t=1361411730025, d=120120, r=0
- S: t=1361411850145, d=80080, r=1
- S: t=1361412010305, d=120120, r=0
- S: t=1361412130425, d=80080, r=0
- S: t=1361412210505, d=120120, r=0
- S: t=1361412330625, d=80080, r=1
- S: t=1361412490785, d=120120, r=0
- S: t=1361412610905, d=80080, r=0
- S: t=1361412690985, d=120120, r=0
- S: t=1361412811105, d=80080, r=1
- S: t=1361412971265, d=120120, r=0
- S: t=1361413091385, d=80080, r=0

Adaptation Set (Content: , Mime: application/mp4, Lang: eng)

Representation ID: 05item

Bandwidth: 15000 (15 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 48000
- S: t=1361410280577, d=96096, r=29

Raw XML

<MPD profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" type="dynamic" availabilityStartTime="2024-10-23T15:48:09Z" minimumUpdatePeriod="PT2.0S" minBufferTime="PT2.002S" publishTime="2025-09-16T22:20:55.669Z" timeShiftBufferDepth="PT60.0S" suggestedPresentationDelay="PT2.002S" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:dolby="http://www.dolby.com/ns/online/DASH" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd">	<Period start="PT0S" id="1">		<BaseURL>https://nebraskapublicmedia.atsc.stream/pbs/</BaseURL><AdaptationSet mimeType="video/mp4" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-cgcompatibility" value="1"/>			<RandomAccess interval="96096"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4v" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="96096" r="29" t="1361410280577"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation bandwidth="5000000" codecs="hvc1.2.4.L153.B0" frameRate="60000/1001" height="1080" id="01item" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<RandomAccess interval="96096"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4a" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="120120" t="1361410288585"/>					<S d="80080" r="1" t="1361410408705"/>					<S d="120120" t="1361410568865"/>					<S d="80080" t="1361410688985"/>					<S d="120120" t="1361410769065"/>					<S d="80080" r="1" t="1361410889185"/>					<S d="120120" t="1361411049345"/>					<S d="80080" t="1361411169465"/>					<S d="120120" t="1361411249545"/>					<S d="80080" r="1" t="1361411369665"/>					<S d="120120" t="1361411529825"/>					<S d="80080" t="1361411649945"/>					<S d="120120" t="1361411730025"/>					<S d="80080" r="1" t="1361411850145"/>					<S d="120120" t="1361412010305"/>					<S d="80080" t="1361412130425"/>					<S d="120120" t="1361412210505"/>					<S d="80080" r="1" t="1361412330625"/>					<S d="120120" t="1361412490785"/>					<S d="80080" t="1361412610905"/>					<S d="120120" t="1361412690985"/>					<S d="80080" r="1" t="1361412811105"/>					<S d="120120" t="1361412971265"/>					<S d="80080" t="1361413091385"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="02item">				<AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>			</Representation></AdaptationSet><AdaptationSet lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<RandomAccess interval="96096"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="alternate"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4a" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="120120" t="1361410288585"/>					<S d="80080" r="1" t="1361410408705"/>					<S d="120120" t="1361410568865"/>					<S d="80080" t="1361410688985"/>					<S d="120120" t="1361410769065"/>					<S d="80080" r="1" t="1361410889185"/>					<S d="120120" t="1361411049345"/>					<S d="80080" t="1361411169465"/>					<S d="120120" t="1361411249545"/>					<S d="80080" r="1" t="1361411369665"/>					<S d="120120" t="1361411529825"/>					<S d="80080" t="1361411649945"/>					<S d="120120" t="1361411730025"/>					<S d="80080" r="1" t="1361411850145"/>					<S d="120120" t="1361412010305"/>					<S d="80080" t="1361412130425"/>					<S d="120120" t="1361412210505"/>					<S d="80080" r="1" t="1361412330625"/>					<S d="120120" t="1361412490785"/>					<S d="80080" t="1361412610905"/>					<S d="120120" t="1361412690985"/>					<S d="80080" r="1" t="1361412811105"/>					<S d="120120" t="1361412971265"/>					<S d="80080" t="1361413091385"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="03item">				<AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>			</Representation></AdaptationSet><AdaptationSet lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<RandomAccess interval="96096"/>			<Accessibility schemeIdUri="urn:tva:metadata:cs:AudioPurposeCS:2007" value="1"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="alternate"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4a" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="120120" t="1361410288585"/>					<S d="80080" r="1" t="1361410408705"/>					<S d="120120" t="1361410568865"/>					<S d="80080" t="1361410688985"/>					<S d="120120" t="1361410769065"/>					<S d="80080" r="1" t="1361410889185"/>					<S d="120120" t="1361411049345"/>					<S d="80080" t="1361411169465"/>					<S d="120120" t="1361411249545"/>					<S d="80080" r="1" t="1361411369665"/>					<S d="120120" t="1361411529825"/>					<S d="80080" t="1361411649945"/>					<S d="120120" t="1361411730025"/>					<S d="80080" r="1" t="1361411850145"/>					<S d="120120" t="1361412010305"/>					<S d="80080" t="1361412130425"/>					<S d="120120" t="1361412210505"/>					<S d="80080" r="1" t="1361412330625"/>					<S d="120120" t="1361412490785"/>					<S d="80080" t="1361412610905"/>					<S d="120120" t="1361412690985"/>					<S d="80080" r="1" t="1361412811105"/>					<S d="120120" t="1361412971265"/>					<S d="80080" t="1361413091385"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="04item">				<AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>			</Representation></AdaptationSet><AdaptationSet lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4s" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="96096" r="29" t="1361410280577"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation bandwidth="15000" codecs="stpp.ttml.im1t" id="05item"/></AdaptationSet>	</Period></MPD>

Media Presentation Description (MPD) Instance 5 (Published: 2025-09-16T22:20:56.470Z)

Type: dynamic
Min Buffer Time: PT2.002S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: , Mime: video/mp4, PAR: 16:9)

Representation ID: 01item

Bandwidth: 5000000 (5.0 Mbps)
Codecs: hvc1.2.4.L153.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 48000
- S: t=1361410376673, d=96096, r=29

Adaptation Set (Content: , Mime: audio/mp4, Lang: eng)

Representation ID: 02item

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 48000
- S: t=1361410408705, d=80080, r=1
- S: t=1361410568865, d=120120, r=0
- S: t=1361410688985, d=80080, r=0
- S: t=1361410769065, d=120120, r=0
- S: t=1361410889185, d=80080, r=1
- S: t=1361411049345, d=120120, r=0
- S: t=1361411169465, d=80080, r=0
- S: t=1361411249545, d=120120, r=0
- S: t=1361411369665, d=80080, r=1
- S: t=1361411529825, d=120120, r=0
- S: t=1361411649945, d=80080, r=0
- S: t=1361411730025, d=120120, r=0
- S: t=1361411850145, d=80080, r=1
- S: t=1361412010305, d=120120, r=0
- S: t=1361412130425, d=80080, r=0
- S: t=1361412210505, d=120120, r=0
- S: t=1361412330625, d=80080, r=1
- S: t=1361412490785, d=120120, r=0
- S: t=1361412610905, d=80080, r=0
- S: t=1361412690985, d=120120, r=0
- S: t=1361412811105, d=80080, r=1
- S: t=1361412971265, d=120120, r=0
- S: t=1361413091385, d=80080, r=0

Adaptation Set (Content: , Mime: audio/mp4, Lang: spa)

Representation ID: 03item

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 48000
- S: t=1361410408705, d=80080, r=1
- S: t=1361410568865, d=120120, r=0
- S: t=1361410688985, d=80080, r=0
- S: t=1361410769065, d=120120, r=0
- S: t=1361410889185, d=80080, r=1
- S: t=1361411049345, d=120120, r=0
- S: t=1361411169465, d=80080, r=0
- S: t=1361411249545, d=120120, r=0
- S: t=1361411369665, d=80080, r=1
- S: t=1361411529825, d=120120, r=0
- S: t=1361411649945, d=80080, r=0
- S: t=1361411730025, d=120120, r=0
- S: t=1361411850145, d=80080, r=1
- S: t=1361412010305, d=120120, r=0
- S: t=1361412130425, d=80080, r=0
- S: t=1361412210505, d=120120, r=0
- S: t=1361412330625, d=80080, r=1
- S: t=1361412490785, d=120120, r=0
- S: t=1361412610905, d=80080, r=0
- S: t=1361412690985, d=120120, r=0
- S: t=1361412811105, d=80080, r=1
- S: t=1361412971265, d=120120, r=0
- S: t=1361413091385, d=80080, r=0

Adaptation Set (Content: , Mime: audio/mp4, Lang: eng)

Representation ID: 04item

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 48000
- S: t=1361410408705, d=80080, r=1
- S: t=1361410568865, d=120120, r=0
- S: t=1361410688985, d=80080, r=0
- S: t=1361410769065, d=120120, r=0
- S: t=1361410889185, d=80080, r=1
- S: t=1361411049345, d=120120, r=0
- S: t=1361411169465, d=80080, r=0
- S: t=1361411249545, d=120120, r=0
- S: t=1361411369665, d=80080, r=1
- S: t=1361411529825, d=120120, r=0
- S: t=1361411649945, d=80080, r=0
- S: t=1361411730025, d=120120, r=0
- S: t=1361411850145, d=80080, r=1
- S: t=1361412010305, d=120120, r=0
- S: t=1361412130425, d=80080, r=0
- S: t=1361412210505, d=120120, r=0
- S: t=1361412330625, d=80080, r=1
- S: t=1361412490785, d=120120, r=0
- S: t=1361412610905, d=80080, r=0
- S: t=1361412690985, d=120120, r=0
- S: t=1361412811105, d=80080, r=1
- S: t=1361412971265, d=120120, r=0
- S: t=1361413091385, d=80080, r=0

Adaptation Set (Content: , Mime: application/mp4, Lang: eng)

Representation ID: 05item

Bandwidth: 15000 (15 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 48000
- S: t=1361410376673, d=96096, r=29

Raw XML

<MPD profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" type="dynamic" availabilityStartTime="2024-10-23T15:48:09Z" minimumUpdatePeriod="PT2.0S" minBufferTime="PT2.002S" publishTime="2025-09-16T22:20:56.470Z" timeShiftBufferDepth="PT60.0S" suggestedPresentationDelay="PT2.002S" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:dolby="http://www.dolby.com/ns/online/DASH" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd">	<Period start="PT0S" id="1">		<BaseURL>https://nebraskapublicmedia.atsc.stream/pbs/</BaseURL><AdaptationSet mimeType="video/mp4" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-cgcompatibility" value="1"/>			<RandomAccess interval="96096"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4v" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="96096" r="29" t="1361410376673"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation bandwidth="5000000" codecs="hvc1.2.4.L153.B0" frameRate="60000/1001" height="1080" id="01item" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<RandomAccess interval="96096"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4a" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="80080" r="1" t="1361410408705"/>					<S d="120120" t="1361410568865"/>					<S d="80080" t="1361410688985"/>					<S d="120120" t="1361410769065"/>					<S d="80080" r="1" t="1361410889185"/>					<S d="120120" t="1361411049345"/>					<S d="80080" t="1361411169465"/>					<S d="120120" t="1361411249545"/>					<S d="80080" r="1" t="1361411369665"/>					<S d="120120" t="1361411529825"/>					<S d="80080" t="1361411649945"/>					<S d="120120" t="1361411730025"/>					<S d="80080" r="1" t="1361411850145"/>					<S d="120120" t="1361412010305"/>					<S d="80080" t="1361412130425"/>					<S d="120120" t="1361412210505"/>					<S d="80080" r="1" t="1361412330625"/>					<S d="120120" t="1361412490785"/>					<S d="80080" t="1361412610905"/>					<S d="120120" t="1361412690985"/>					<S d="80080" r="1" t="1361412811105"/>					<S d="120120" t="1361412971265"/>					<S d="80080" t="1361413091385"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="02item">				<AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>			</Representation></AdaptationSet><AdaptationSet lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<RandomAccess interval="96096"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="alternate"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4a" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="80080" r="1" t="1361410408705"/>					<S d="120120" t="1361410568865"/>					<S d="80080" t="1361410688985"/>					<S d="120120" t="1361410769065"/>					<S d="80080" r="1" t="1361410889185"/>					<S d="120120" t="1361411049345"/>					<S d="80080" t="1361411169465"/>					<S d="120120" t="1361411249545"/>					<S d="80080" r="1" t="1361411369665"/>					<S d="120120" t="1361411529825"/>					<S d="80080" t="1361411649945"/>					<S d="120120" t="1361411730025"/>					<S d="80080" r="1" t="1361411850145"/>					<S d="120120" t="1361412010305"/>					<S d="80080" t="1361412130425"/>					<S d="120120" t="1361412210505"/>					<S d="80080" r="1" t="1361412330625"/>					<S d="120120" t="1361412490785"/>					<S d="80080" t="1361412610905"/>					<S d="120120" t="1361412690985"/>					<S d="80080" r="1" t="1361412811105"/>					<S d="120120" t="1361412971265"/>					<S d="80080" t="1361413091385"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="03item">				<AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>			</Representation></AdaptationSet><AdaptationSet lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<RandomAccess interval="96096"/>			<Accessibility schemeIdUri="urn:tva:metadata:cs:AudioPurposeCS:2007" value="1"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="alternate"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4a" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="80080" r="1" t="1361410408705"/>					<S d="120120" t="1361410568865"/>					<S d="80080" t="1361410688985"/>					<S d="120120" t="1361410769065"/>					<S d="80080" r="1" t="1361410889185"/>					<S d="120120" t="1361411049345"/>					<S d="80080" t="1361411169465"/>					<S d="120120" t="1361411249545"/>					<S d="80080" r="1" t="1361411369665"/>					<S d="120120" t="1361411529825"/>					<S d="80080" t="1361411649945"/>					<S d="120120" t="1361411730025"/>					<S d="80080" r="1" t="1361411850145"/>					<S d="120120" t="1361412010305"/>					<S d="80080" t="1361412130425"/>					<S d="120120" t="1361412210505"/>					<S d="80080" r="1" t="1361412330625"/>					<S d="120120" t="1361412490785"/>					<S d="80080" t="1361412610905"/>					<S d="120120" t="1361412690985"/>					<S d="80080" r="1" t="1361412811105"/>					<S d="120120" t="1361412971265"/>					<S d="80080" t="1361413091385"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="04item">				<AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>			</Representation></AdaptationSet><AdaptationSet lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>			<SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>			<Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>			<SegmentTemplate initialization="$RepresentationID$_init.m4i" media="$RepresentationID$_Segment-$Time$.m4s" presentationTimeOffset="0" timescale="48000">				<SegmentTimeline>					<S d="96096" r="29" t="1361410376673"/>				</SegmentTimeline>			</SegmentTemplate>					<Representation bandwidth="15000" codecs="stpp.ttml.im1t" id="05item"/></AdaptationSet>	</Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://pbs-nebraska.prod.run3tv.com/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="pbs_kyne_app.run3tv.com" bbandEntryPageUrl="https://pbs-nebraska.prod.run3tv.com/run3tv-common/index.html"></HTMLEntryPackage></HELD>

Service 5010: PBTV (42.11)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.42.11:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 2 ch @ 384 kbps
Codec: ac-4.02.01.00

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:PBTV:KPTM
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.42.11:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5010"><DeliveryMethod><UnicastAppService><BasePattern>a0-24-</BasePattern><BasePattern>d0-Data3_5-</BasePattern><BasePattern>video-Video1_1-</BasePattern><BasePattern>video-Video1_2-</BasePattern><BasePattern>video-Video1_3-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="13"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="39"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-16T22:20:58Z)

Type: dynamic
Min Buffer Time: PT10S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_3

Bandwidth: 1000000 (1000 kbps)
Codecs: hev1.2.4.L93.B0
Resolution: 960x540 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=421934686773600, d=480480, r=29

Representation ID: Video1_2

Bandwidth: 4000000 (4.0 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=421934686773600, d=480480, r=29

Representation ID: Video1_1

Bandwidth: 8000000 (8.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=421934686773600, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 24

Bandwidth: 384000 (384 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 240000
- S: t=421934686777604, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_5

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 240000
- S: t=421934686773600, d=480480, r=29

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-16T22:20:58Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://kptm-sbgtv.atsc.stream/pickleball/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="540" minWidth="960" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421934686773600"/>            </SegmentTimeline>         </SegmentTemplate>                                 <Representation bandwidth="1000000" codecs="hev1.2.4.L93.B0" frameRate="60000/1001" height="540" id="Video1_3" sar="1:1" scanType="progressive" width="960"/><Representation bandwidth="4000000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_2" sar="1:1" scanType="progressive" width="1280"/><Representation bandwidth="8000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421934686777604"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.00" id="24"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421934686773600"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_5"/></AdaptationSet>   </Period></MPD>

Service 5011: GMLOOP (42.20)

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.42.20:5000

Hidden: No
App: GameLoop

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:Gameloop:KPTM
Category: 3 (App-Based Service)
SLS Destination: 239.255.42.20:5000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5011"></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://nextgen.gameloop.tv/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tag:sinclairplatform.com,2020:Gameloop:KPTM" bbandEntryPageUrl="https://nextgen.gameloop.tv/run3tv-common/index.html"></HTMLEntryPackage>
</HELD>

Service 5012: ROXi (42.21)

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.42.21:5000

Hidden: No
App: ROXi

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:Roxi:kptm
Category: 3 (App-Based Service)
SLS Destination: 239.255.42.21:5000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5012"></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://cdn.prod.tvapp.roxi.tv/releases/prod-atsc/index.html#/atsc,faststream,showId=46eb1cf29052,prod

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://cdn.prod.tvapp.roxi.tv/releases/prod-atsc/index.html#/atsc,faststream,showId=46eb1cf29052,prod" appContextId="tag:sinclairplatform.com,2020:Roxi:kptm" />
</HELD>

Other Global LLS Tables

System Time Details - Actual Timestamp in L1Detail

Attribute	Value
currentUtcOffset	37
utcLocalOffset	-PT5H
dsStatus	true

Raw XML

<?xml version="1.0" encoding="utf-8"?>
<SystemTime xmlns="http://www.atsc.org/XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/ SYSTIME-1.0-20211208.xsd" currentUtcOffset="37" utcLocalOffset="-PT5H" dsStatus="true"/>

Input Info

Attribute	Value
Input Type	Debug File
File Name	23277-0-20250916-191032-p0p1-dbg.dbg
Total Packets Processed	36129
File Last Modified	2025-09-16 19:10:32 EDT
Analysis Run Time	2025-11-23 16:15:52 EST

ATSC 3.0 Data Usage Analysis

IP:Port (ID)	Usage ↓	Service	Type	Total Data	Bitrate
239.255.7.1:5001 (TSI 100)	19.75%	KETV	Video	10.08 MB	N/A
239.255.3.1:5001 (TSI 100)	17.72%	KMTV	Video	9.05 MB	N/A
239.255.6.1:5001 (TSI 100)	17.59%	WOWT	Video	8.98 MB	N/A
239.255.42.1:5001 (TSI 100)	16.89%	KPTM	Video	8.62 MB	N/A
239.255.15.1:5001 (TSI 100)	15.94%	KXVO	Video	8.14 MB	N/A
239.255.42.1:5001 (TSI 200)	1.69%	KPTM	Audio	860.8 KB	N/A
239.255.15.1:5001 (TSI 200)	1.69%	KXVO	Audio	860.4 KB	N/A
224.0.23.60:4937 (LLS)	1.05%	LLS Signaling	LLS Signaling	534.4 KB	N/A
239.255.7.1:5001 (TSI 0)	0.87%	KETV	Service Signaling	442.7 KB	N/A
239.255.3.1:5001 (TSI 0)	0.86%	KMTV	Service Signaling	441.6 KB	N/A
239.255.6.1:5001 (TSI 0)	0.85%	WOWT	Service Signaling	435.1 KB	N/A
239.255.42.1:5001 (TSI 0)	0.54%	KPTM	Service Signaling	276.6 KB	N/A
239.255.15.1:5001 (TSI 0)	0.50%	KXVO	Service Signaling	257.7 KB	N/A
239.255.7.1:5001 (TSI 200)	0.40%	KETV	Audio	203.2 KB	N/A
239.255.3.1:5001 (TSI 200)	0.40%	KMTV	Audio	203.1 KB	N/A
239.255.6.1:5001 (TSI 200)	0.40%	WOWT	Audio	203.1 KB	N/A
239.255.26.1:5000 (TSI 0)	0.33%	NE-PBS	Service Signaling	168.7 KB	N/A
239.255.15.1:5100 (TSI 0)	0.33%	ESG	Service Signaling	168.7 KB	N/A
239.255.6.1:5001 (TSI 201)	0.22%	WOWT	Audio	112.2 KB	N/A
239.255.7.1:5001 (TSI 201)	0.22%	KETV	Audio	112.1 KB	N/A
239.255.3.1:5001 (TSI 201)	0.22%	KMTV	Audio	112.0 KB	N/A
239.255.42.1:5001 (TSI 201)	0.20%	KPTM	Audio	103.6 KB	N/A
239.255.42.21:5000 (TSI 0)	0.20%	ROXi	Service Signaling	100.4 KB	N/A
239.255.15.1:5100 (TSI 80)	0.18%	ESG	ROUTE Media	91.5 KB	N/A
239.255.42.11:5000 (TSI 0)	0.18%	PBTV	Service Signaling	91.3 KB	N/A
239.255.42.10:5000 (TSI 0)	0.18%	T2	Service Signaling	90.6 KB	N/A
239.255.42.20:5000 (TSI 0)	0.10%	GMLOOP	Service Signaling	49.2 KB	N/A
239.255.15.100:6000 (TSI 0)	0.08%	DDAAS	Service Signaling	41.4 KB	N/A
239.255.7.1:5001 (TSI 300)	0.08%	KETV	Captions	38.8 KB	N/A
239.255.15.1:5100 (TSI 50)	0.07%	ESG	ROUTE Media	35.9 KB	N/A
239.255.15.1:5100 (TSI 60)	0.07%	ESG	ROUTE Media	35.5 KB	N/A
239.255.6.1:5001 (TSI 300)	0.06%	WOWT	Captions	32.4 KB	N/A
239.255.15.1:5001 (TSI 300)	0.06%	KXVO	Captions	32.1 KB	N/A
239.255.3.1:5001 (TSI 300)	0.06%	KMTV	Captions	31.2 KB	N/A
239.255.42.1:5001 (TSI 300)	0.02%	KPTM	Captions	9.3 KB	N/A
230.240.87.136:18218	0.02%	Unknown Service	Other UDP	7.9 KB	N/A

Total: 51.06 MB | Signaling: 6.07% | Media: 93.92% | Other: 0.02%

RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

Service Summary (SLT BSID: 1968)

Certificate Details

Service 5001: KXVO (15.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d3_3

Raw XML

Service 5002: ESG

Raw XML

ROUTE Stream: 239.255.15.1:5100

Raw XML

Raw XML

Service 5003: KPTM (42.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4

Raw XML

Service 5004: WOWT (6.1) Encrypted

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4

Raw XML

Raw XML

Service 5005: KETV (7.1) Encrypted

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4

Raw XML

Raw XML

Service 5006: KMTV (3.1) Encrypted

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4

Raw XML

Raw XML

Service 5004: WOWT (6.1)

Service 5005: KETV (7.1)

Service 5006: KMTV (3.1)

Service 5007: T2 (42.10)

Service 5008: DDAAS

Service 5009: NE-PBS (26.1)
