RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

PLP ID	SFI	Modulation	Code Rate	Layer	TI Mode	LLS	Lock	Required SNR	Bitrate
0	0	qam16	9/15	core	hti	Yes	Yes	AWGN: 7.32-7.58 dB Rayleigh: 9.94-10.28 dB	N/A
1	0	qam256	11/15	core	hti	Yes	Yes	AWGN: 18.76-19.08 dB Rayleigh: 21.94-22.40 dB	N/A

L1 Detail Information Not Available

Link Mapping Table Data Not Available

Service Summary (SLT BSID: 2090)

Service Name	ID	Channel	Protocol / Category	SLS Destination
KLAS	5001	8.1	ROUTE / Linear A/V Service	239.255.8.1:5001
KTNV	5002	13.1	ROUTE / Linear A/V Service	239.255.13.1:5002
KVCW	5003	33.1	MMT / Linear A/V Service	239.255.33.1:5003
KSNV	5004	3.1	ROUTE / Linear A/V Service	239.255.3.1:5004
ESG	5005		ROUTE / ESG Service	239.255.33.1:5100
T2	5006	3.10	ROUTE / Linear A/V Service	239.255.3.10:5000
KVVU	5007	5.1	ROUTE / Linear A/V Service	239.255.5.1:5000
DDAAS	5008		ROUTE / App-Based Service	239.255.33.100:6000
PBTV	5009	3.11	ROUTE / Linear A/V Service	239.255.3.11:5000
GMLOOP	5010	3.20	ROUTE / App-Based Service	239.255.3.20:5000
ROXi	5011	3.21	ROUTE / App-Based Service	239.255.3.21:5000

Capability Descriptor Table (CDT) - 3 Certificate(s)

Attribute	Value
OCSP Refresh	P7DT0H
Certificate Count	3

Certificate Details

Certificate 1 - KVCW Signalling Signing SMT 0001 (Valid Until: Feb 13 2026)

Field	Value
Subject	/C=US/ST=Nevada/L=Las Vegas/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=KVCW Signalling Signing SMT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	1841B31A9938988421636C3845786FDC77F0299D
Valid From	Feb 13 14:28:30 2025 GMT
Valid Until	Feb 13 14:28:30 2026 GMT
Signature Algorithm	sha256WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	FA:04:71:72:85:CB:30:E4:21:A0:EE:3C:5E:62:CF:B6:81:B1:04:62
SHA-256 Fingerprint	CD:68:B1:E5:D4:56:DE:C3:35:3D:82:EF:BD:62:D4:BE:55:05:C4:06:4A:05:45:3E:2E:F8:C3:51:8A:E5:C2:
Certificate Authority	No
Self-Signed	No

Certificate 2 - ATSC 3.0 Signing CA-2 (Valid Until: Sep 8 2030)

Field	Value
Subject	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Issuer	/C=US/O=Pearl TV/OU=Root CA-1/CN=ATSC3 Root-CA
Serial Number	1D81C0A269A03D9AAF128428593DB6B8
Valid From	Sep 8 00:00:00 2021 GMT
Valid Until	Sep 8 23:59:59 2030 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	06:63:9A:0C:E9:C0:E7:2C:44:05:1C:8A:91:B6:68:FB:25:C4:38:75
SHA-256 Fingerprint	23:42:5B:1C:CA:CB:F3:31:7C:8B:03:59:DA:E0:A3:98:C4:84:05:DB:1B:6B:92:15:58:69:F7:89:30:9A:65:
Certificate Authority	Yes
Self-Signed	No

Certificate 3 - KVCW Signalling Signing CDT 0001 (Valid Until: Feb 13 2026)

Field	Value
Subject	/C=US/ST=Nevada/L=Las Vegas/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=KVCW Signalling Signing CDT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	753B1F0FA39DC76B44B5B6BCDA704689E1511D59
Valid From	Feb 13 14:28:28 2025 GMT
Valid Until	Feb 13 14:28:28 2026 GMT
Signature Algorithm	sha256WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	AB:1C:3C:44:61:0A:F0:70:95:7D:40:2E:C3:49:95:F8:AE:2A:D2:4D
SHA-256 Fingerprint	CB:10:6F:49:A6:59:21:51:23:D2:B7:D4:C2:94:81:94:4C:32:5B:2C:B2:E0:6D:95:80:E8:CF:59:3A:51:69:
Certificate Authority	No
Self-Signed	No

Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<CertificationData xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/CDT-1.0-20180706.xsd">
<ToBeSignedData OCSPRefresh="P7DT0H"><Certificates>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</Certificates><Certificates>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</Certificates><Certificates>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</Certificates><CurrentCert>apmSiDy6l+Of6WuA+xIYQ6ET4UA=</CurrentCert></ToBeSignedData>
<CMSSignedData>MIICXgYJKoZIhvcNAQcCoIICTzCCAksCAQMxDTALBglghkgBZQMEAgEwCwYJKoZIhvcNAQcBMYICKDCCAiQCAQOAFLSQkS07op3qhtn3Qsgn6hHfSINiMAsGCWCGSAFlAwQCAaBpMBgGCSqGSIb3DQEJAzELBgkqhkiG9w0BBwEwHAYJKoZIhvcNAQkFMQ8XDTI1MDkxOTE2NTI1OVowLwYJKoZIhvcNAQkEMSIEIIotN/vcMMKWduWUqXRlsRLTZJaUOHRv4I1l11qRhrD3MA0GCSqGSIb3DQEBAQUABIIBgIVVNQP74V7B5WaG/3jAKkahoaH4ABsmlCOeFH+iqFIPifqQcP1SPRQ7zSwT87ImOpIu2yp2pWtC3nxqknROMfZXEMEJSEODHeonuNreCNN2d9MVeQE/TU1c0ut8Ye5PXPVtvZo/qCVcqmDlSvKAbTlEZscni14Sio5om2AbbpO6JoEScLJtsyVVfdzdHygaxOKtUz90r8jTxD/GEVpNjlnPKEUhV8Sz3GHy0WwYxvQEEvVGWWmcfhkrgpVC5AgsNjCJ7QMhDi4rwYZ2J0YE36kBupLoaVJjDO4D1ShkMqlD3G8CShics68lbDFAQRW8Wf78GdHS3PA2h6BEeyz/9Jvy4BV6g6nXXlrk9rzlO29yRyXy/SRI7Jx+/ruDxcA9NdRcM4PdJxahC/Ts9GeX9qHNpp9vK4rUd4x7rPCUdyi4X2xWCTwLXMJEN5eB/6C+RKz0LPJia6Ku+VOzxjbLYrNcPyux5YcGvCQOBfNEV7NJ3zW4AFWhFRX+da2soY/Opg==</CMSSignedData>
<OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse>
</CertificationData>

Service List Table (SLT) Instance 1 - Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<SLT bsid="2090" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SLT/1.0/ SLT-1.0-20211209.xsd">
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="tag:sinclairplatform.com,2020:KLAS:2081" majorChannelNo="8" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5001" shortServiceName="KLAS" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.8.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="192.168.202.202"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/39D1-BBA9" majorChannelNo="13" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5002" shortServiceName="KTNV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.13.1" slsDestinationUdpPort="5002" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="192.168.202.202"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:KVCW:2091" majorChannelNo="33" minorChannelNo="1" serviceCategory="1" serviceId="5003" shortServiceName="KVCW" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.33.1" slsDestinationUdpPort="5003" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="2" slsSourceIpAddress="192.168.202.202"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:KSNV:2089" majorChannelNo="3" minorChannelNo="1" serviceCategory="1" serviceId="5004" shortServiceName="KSNV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.3.1" slsDestinationUdpPort="5004" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="192.168.202.202"/>
    </Service>
    <Service serviceCategory="4" serviceId="5005" shortServiceName="ESG" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.33.1" slsDestinationUdpPort="5100" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="192.168.202.202"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:T2" majorChannelNo="3" minorChannelNo="10" serviceCategory="1" serviceId="5006" shortServiceName="T2" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.3.10" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="192.168.202.202"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/5C8F-2DB2" majorChannelNo="5" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5007" shortServiceName="KVVU" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.5.1" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="192.168.202.202"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:broadspanwireless.com,2023:2090:KVCW:2091" hidden="true" hideInGuide="true" serviceCategory="3" serviceId="5008" shortServiceName="DDAAS" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.33.100" slsDestinationUdpPort="6000" slsProtocol="1" slsSourceIpAddress="192.168.202.202"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:PBTV:KSNV" majorChannelNo="3" minorChannelNo="11" serviceCategory="1" serviceId="5009" shortServiceName="PBTV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.3.11" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="192.168.202.202"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:sinclairplatform.com,2020:Gameloop:KSNV" majorChannelNo="3" minorChannelNo="20" serviceCategory="3" serviceId="5010" shortServiceName="GMLOOP" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.3.20" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="192.168.202.202"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:Roxi:ksnv" majorChannelNo="3" minorChannelNo="21" serviceCategory="3" serviceId="5011" shortServiceName="ROXi" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.3.21" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="192.168.202.202"/>
    </Service>
</SLT>

Service 5001: KLAS (8.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 192.168.202.202
Destination: 239.255.8.1:5001

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:KLAS:2081
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.8.1:5001
SLS Source: 192.168.202.202
SLS Protocol Version: 0.0 (ROUTE)
Protected: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5001"><DeliveryMethod><BroadcastAppService><BasePattern>a096000-</BasePattern><BasePattern>a148000-</BasePattern><BasePattern>data-0-50000-</BasePattern><BasePattern>video-6000000-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	a022	audio	N/A
201	a13_3	audio	N/A
300	Data4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="192.168.202.202"><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="6000000" afdt:fileTemplate="video-6000000-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-6000000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a096000-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a096000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a022"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a148000-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a148000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="data-0-50000-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="data-0-50000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="68"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="235"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="213"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-05-27T18:14:13Z)

Type: dynamic
Min Buffer Time: PT2S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 6000000 (6.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-$Bandwidth$-init.mp4
- Media URL: video-$Bandwidth$-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=klas_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a022

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0$Bandwidth$-init.mp4
- Media URL: a0$Bandwidth$-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=klas_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1$Bandwidth$-init.mp4
- Media URL: a1$Bandwidth$-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=klas_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: data-0-$Bandwidth$-init.mp4
- Media URL: data-0-$Bandwidth$-$Number$.mp4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT0S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-05-27T18:14:13Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="dbd775f0-9a40-5055-916f-1d0c8e36ea92" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="dbd775f0-9a40-5055-916f-1d0c8e36ea92" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=klas_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-$Bandwidth$-init.mp4" media="video-$Bandwidth$-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="6000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="dbd775f0-9a40-5055-916f-1d0c8e36ea92" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="dbd775f0-9a40-5055-916f-1d0c8e36ea92" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=klas_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0$Bandwidth$-init.mp4" media="a0$Bandwidth$-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a022"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="dbd775f0-9a40-5055-916f-1d0c8e36ea92" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="dbd775f0-9a40-5055-916f-1d0c8e36ea92" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=klas_g2_p2_1</dashif:Laurl>         </ContentProtection>         <SegmentTemplate duration="480480" initialization="a1$Bandwidth$-init.mp4" media="a1$Bandwidth$-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="data-0-$Bandwidth$-init.mp4" media="data-0-$Bandwidth$-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

Service 5002: KTNV (13.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 192.168.202.202
Destination: 239.255.13.1:5002

Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: https://doi.org/10.5239/39D1-BBA9
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.13.1:5002
SLS Source: 192.168.202.202
SLS Protocol Version: 0.0 (ROUTE)
Protected: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5002"><DeliveryMethod><BroadcastAppService><BasePattern>a096000-</BasePattern><BasePattern>a148000-</BasePattern><BasePattern>data-0-50000-</BasePattern><BasePattern>video-6000000-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	1,'TV-PG',{0 'TV-PG'}
200	a022	audio	N/A
201	a13_3	audio	N/A
300	Data4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="6000000" afdt:fileTemplate="video-6000000-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-6000000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-PG',{0 'TV-PG'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a096000-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a096000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a022"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a148000-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a148000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="data-0-50000-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="data-0-50000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="69"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="61"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="178"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="9"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-08-18T19:17:36Z)

Type: dynamic
Min Buffer Time: PT2S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 6000000 (6.0 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-$Bandwidth$-init.mp4
- Media URL: video-$Bandwidth$-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktnv_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a022

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0$Bandwidth$-init.mp4
- Media URL: a0$Bandwidth$-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktnv_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1$Bandwidth$-init.mp4
- Media URL: a1$Bandwidth$-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktnv_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: text, Mime: application/mp4, Lang: und)

Representation ID: Data4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: data-0-$Bandwidth$-init.mp4
- Media URL: data-0-$Bandwidth$-$Number$.mp4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT0S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-08-18T19:17:36Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <ContentProtection cenc:default_KID="a296c2bf-713b-5824-b23b-d273fa6ca44b" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="a296c2bf-713b-5824-b23b-d273fa6ca44b" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktnv_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-$Bandwidth$-init.mp4" media="video-$Bandwidth$-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="6000000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <ContentProtection cenc:default_KID="a296c2bf-713b-5824-b23b-d273fa6ca44b" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="a296c2bf-713b-5824-b23b-d273fa6ca44b" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktnv_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0$Bandwidth$-init.mp4" media="a0$Bandwidth$-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a022"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <ContentProtection cenc:default_KID="a296c2bf-713b-5824-b23b-d273fa6ca44b" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="a296c2bf-713b-5824-b23b-d273fa6ca44b" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=ktnv_g2_p2_1</dashif:Laurl>         </ContentProtection>         <SegmentTemplate duration="480480" initialization="a1$Bandwidth$-init.mp4" media="a1$Bandwidth$-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="und" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="data-0-$Bandwidth$-init.mp4" media="data-0-$Bandwidth$-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://ktnv-atsc3.scrippscloud.com/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage
      appContextId="tv:ota-ktnv.ewscloud.com"
      bbandEntryPageUrl="https://ktnv-atsc3.scrippscloud.com/run3tv-common/index.html" >
  </HTMLEntryPackage>
</HELD>

Service 5003: KVCW (33.1)

Protocol: MMT
Category: Linear A/V Service

Source: 192.168.202.202
Destination: 239.255.33.1:5003

Video:
Codec: hev1.2.X.L123.X

Audio: 6 ch
Codec: ac-4.02.01.00

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:KVCW:2091
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.33.1:5003
SLS Source: 192.168.202.202
SLS Protocol Version: 0.0 (MMT)

User Service Bundle Description (USBD) Instance 1

ID	Content Type	Version
5003	UserServiceDescription	1.0

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionMMT xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/MMTUSD/1.0/" xmlns:sa="tag:atsc.org,2016:XMLSchemas/ATSC3/SA/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/MMTUSD/1.0/ MMTUSD-1.0-20210401.xsd"><UserServiceDescription serviceId="5003"><ContentAdvisoryRating><sa:RegionIdentifier>1</sa:RegionIdentifier><sa:RatingDescription xml:lang="en">TV-14 L-V</sa:RatingDescription><sa:RatedDimensions>3</sa:RatedDimensions><sa:RatingDimVal><sa:RatingDimension>0</sa:RatingDimension><sa:RatingValueString>TV-14</sa:RatingValueString></sa:RatingDimVal><sa:RatingDimVal><sa:RatingDimension>2</sa:RatingDimension><sa:RatingValueString>L</sa:RatingValueString></sa:RatingDimVal><sa:RatingDimVal><sa:RatingDimension>4</sa:RatingDimension><sa:RatingValueString>V</sa:RatingValueString></sa:RatingDimVal></ContentAdvisoryRating><Channel serviceIcon="service_icon"><ServiceDescription serviceDescrText="TBD" serviceDescrLang="en"></ServiceDescription></Channel><MPUComponent mmtPackageId="mmt"></MPUComponent><ComponentInfo componentType="1" componentRole="0" componentProtectedFlag="false" componentId="videoasset01"></ComponentInfo><ComponentInfo componentType="0" componentRole="0" componentProtectedFlag="false" componentId="audioasset02"></ComponentInfo><ComponentInfo componentType="0" componentRole="0" componentProtectedFlag="false" componentId="audioasset03"></ComponentInfo><ComponentInfo componentType="2" componentRole="0" componentProtectedFlag="false" componentId="subtitleasset04"></ComponentInfo></UserServiceDescription></BundleDescriptionMMT>

User Service Description (USD) -

Field	Value
Service ID	5003
MMT Package ID	mmt

Components:

Component ID	Type	Description
videoasset01	1	Main Video
audioasset02	0	Main Audio
audioasset03	0	Main Audio
subtitleasset04	2	Main Data/Captions

Raw XML

<?xml version="1.0" encoding="UTF-8"?><UserServiceDescription serviceId="5003">
  <ContentAdvisoryRating>
    <sa:RegionIdentifier>1</sa:RegionIdentifier>
    <sa:RatingDescription xml:lang="en">TV-14 L-V</sa:RatingDescription>
    <sa:RatedDimensions>3</sa:RatedDimensions>
    <sa:RatingDimVal>
      <sa:RatingDimension>0</sa:RatingDimension>
      <sa:RatingValueString>TV-14</sa:RatingValueString>
    </sa:RatingDimVal>
    <sa:RatingDimVal>
      <sa:RatingDimension>2</sa:RatingDimension>
      <sa:RatingValueString>L</sa:RatingValueString>
    </sa:RatingDimVal>
    <sa:RatingDimVal>
      <sa:RatingDimension>4</sa:RatingDimension>
      <sa:RatingValueString>V</sa:RatingValueString>
    </sa:RatingDimVal>
  </ContentAdvisoryRating>
  <Channel serviceIcon="service_icon">
    <ServiceDescription serviceDescrText="TBD" serviceDescrLang="en"/>
  </Channel>
  <MPUComponent mmtPackageId="mmt"/>
  <ComponentInfo componentType="1" componentRole="0" componentProtectedFlag="false" componentId="videoasset01"/>
  <ComponentInfo componentType="0" componentRole="0" componentProtectedFlag="false" componentId="audioasset02"/>
  <ComponentInfo componentType="0" componentRole="0" componentProtectedFlag="false" componentId="audioasset03"/>
  <ComponentInfo componentType="2" componentRole="0" componentProtectedFlag="false" componentId="subtitleasset04"/>
</UserServiceDescription>

MMT Signaling (MP Table - Binary)

Binary MMT Package Table

Asset ID	Asset Type	Codec	Packet ID
videoasset01	hev1	HEVC/H.265	100
audioasset02	ac-4	AC-4 Audio	200
audioasset03	ac-4	AC-4 Audio	201
subtitleasset04	stpp	TTML Subtitles	300

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html

Raw XML

<?xml version="1.0" encoding="UTF-8"?><HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html"   appContextId="tag:sinclairplatform.com,2020:KVCW:2091" ></HTMLEntryPackage>
</HELD>

MMT Stream Descriptors Instance 1

Video Stream Properties Descriptor (VSPD)

Codec: hev1.2.2.L123.B (HEVC/H.265)
HEVC Profile: Main 10 (supports 10-bit color depth for HDR content)
HEVC Level: 4.1 (defines maximum resolution, frame rate, and bitrate capabilities)
Tier: Main (Main tier: standard bitrates, High tier: allows higher bitrates)
Scan Type: Progressive (full frames, better quality)

Audio Stream Properties Descriptor (ASPD)

Codec: ac-4 (Dolby AC-4 - next-generation audio codec)
Language: en
Presentations: 1 (separate audio mixes, e.g., main, commentary, descriptive)
Sample Rate: 48000 Hz

Caption Asset Descriptor (CAD)

Caption Track 1:
- Language: und
- Role: main (primary captions)
- Aspect Ratio: 16:9
- Profile: text (text-based captions)

Service 5004: KSNV (3.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 192.168.202.202
Destination: 239.255.3.1:5004

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 16 ch @ 448 kbps
Codec: ac-4.02.01.02

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:KSNV:2089
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.3.1:5004
SLS Source: 192.168.202.202
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5004"><DeliveryMethod><BroadcastAppService><BasePattern>a0448000-</BasePattern><BasePattern>a148000-</BasePattern><BasePattern>data-0-50000-</BasePattern><BasePattern>video-5000000-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	a022	audio	N/A
201	a13_3	audio	N/A
300	Data4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5000000" afdt:fileTemplate="video-5000000-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-5000000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="448000" afdt:fileTemplate="a0448000-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0448000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a022"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a148000-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a148000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="data-0-50000-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="data-0-50000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="79"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="217"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="80"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="3"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-08-18T19:17:22Z)

Type: dynamic
Min Buffer Time: PT2S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 5000000 (5.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-$Bandwidth$-init.mp4
- Media URL: video-$Bandwidth$-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a022

Bandwidth: 448000 (448 kbps)
Codecs: ac-4.02.01.02
Audio Sample Rate: 48000 Hz
Audio Channels: 16
Segment Template:
- Initialization: a0$Bandwidth$-init.mp4
- Media URL: a0$Bandwidth$-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1$Bandwidth$-init.mp4
- Media URL: a1$Bandwidth$-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: und)

Representation ID: Data4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: data-0-$Bandwidth$-init.mp4
- Media URL: data-0-$Bandwidth$-$Number$.mp4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT0S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-08-18T19:17:22Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-$Bandwidth$-init.mp4" media="video-$Bandwidth$-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="5000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0$Bandwidth$-init.mp4" media="a0$Bandwidth$-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>               <Representation audioSamplingRate="48000" bandwidth="448000" codecs="ac-4.02.01.02" id="a022"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <SegmentTemplate duration="480480" initialization="a1$Bandwidth$-init.mp4" media="a1$Bandwidth$-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="und" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="data-0-$Bandwidth$-init.mp4" media="data-0-$Bandwidth$-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html"   appContextId="tag:sinclairplatform.com,2020:KSNV:2089" ></HTMLEntryPackage>
</HELD>

Service 5005: ESG

Protocol: ROUTE
Category: ESG Service

Source: 192.168.202.202
Destination: 239.255.33.1:5100

Hidden: No
App: No

Service Details (from SLT)

Global Service ID:
Category: 4 (ESG Service)
SLS Destination: 239.255.33.1:5100
SLS Source: 192.168.202.202
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5005"></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: 239.255.33.1:5100

TSI	Representation ID	Content Type	Content Ratings
50			N/A
60			N/A
80			N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="192.168.202.202" dIpAddr="239.255.33.1" dPort="5100"><LS tsi="50"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="1297" Content-Location="sgdd_1297" Content-Length="73863" Transfer-Length="6766" Content-Type="application/vnd.oma.bcast.sgdd+xml" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="60"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="3006" Content-Location="sgdu_content_3006" Content-Length="515658" Transfer-Length="45656" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File><fdt:File TOI="4000" Content-Location="sgdu_service_schedule_4000" Content-Length="99829" Transfer-Length="7694" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="80"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="5662" Content-Location="s28711_ll_h15_ab.png" Content-Length="9791" Transfer-Length="9275" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5663" Content-Location="s28708_h3_aa.png" Content-Length="15267" Transfer-Length="15140" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5664" Content-Location="s28717_ll_h15_ad.png" Content-Length="9006" Transfer-Length="8526" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5665" Content-Location="s53098_ll_h15_ac.png" Content-Length="6025" Transfer-Length="5795" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5666" Content-Location="s28719_ll_h15_ac.png" Content-Length="8623" Transfer-Length="8259" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="16"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="3944"></item></metadataEnvelope>

Electronic Service Guide (ESG) - 5 Service(s), 551 Program(s) (from 561 fragments)

Service : KVVU (5.1)

Field	Value
ID	urn:digicap:svc:5007:1758283668740
Status	https://doi.org
Description	KVVU

Raw XML (0 fragments)

Service : KVCW (33.1)

Field	Value
ID	urn:digicap:svc:5003:1758283668740
Status	tag:sinclairpla
Description	KVCW

Raw XML (0 fragments)

Service : KSNV (3.1)

Field	Value
ID	urn:digicap:svc:5004:1758283668740
Status	tag:sinclairpla
Description	KSNV

Raw XML (0 fragments)

Service : KTNV (13.1)

Field	Value
ID	urn:digicap:svc:5002:1758283668740
Status	https://doi.org
Description	KTNV

Raw XML (0 fragments)

Service : KLAS (8.1)

Field	Value
ID	urn:digicap:svc:5001:1758283668740
Status	tag:sinclairpla
Description	KLAS

Raw XML (0 fragments)

Service 5006: T2 (3.10)

Protocol: ROUTE
Category: Linear A/V Service

Source: 192.168.202.202
Destination: 239.255.3.10:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 384 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:T2
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.3.10:5000
SLS Source: 192.168.202.202
SLS Protocol Version: 0.0 (ROUTE)
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5006"><DeliveryMethod><UnicastAppService><BasePattern>a0-22-</BasePattern><BasePattern>d0-Data3_3-</BasePattern><BasePattern>video-Video1_1-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="32"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="132"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-19T19:19:35Z)

Type: dynamic
Min Buffer Time: PT10S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 7000000 (7.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=421994283590880, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 384000 (384 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Timescale: 240000
- S: t=421994283594884, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_3

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 240000
- S: t=421994283590880, d=480480, r=29

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-19T19:19:35Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://ksnv-sbgtv.atsc.stream/t2/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421994283590880"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="7000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421994283594884"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421994283590880"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_3"/></AdaptationSet>   </Period></MPD>

Service 5007: KVVU (5.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 192.168.202.202
Destination: 239.255.5.1:5000

Video: 1920x1080p (59.94 fps)
Codec: hvc1.2.4.L123.B0

Audio: 6 ch @ 192 kbps
Codec: ac-4.02.01.01

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: https://doi.org/10.5239/5C8F-2DB2
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.5.1:5000
SLS Source: 192.168.202.202
SLS Protocol Version: 0.0 (ROUTE)
Protected: Yes
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5007"><DeliveryMethod><UnicastAppService><BasePattern>audio-0-192000-</BasePattern><BasePattern>audio-1-96000-</BasePattern><BasePattern>data-0-50000-</BasePattern><BasePattern>video-4000000-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="34"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="155"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="7"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-19T19:19:31Z)

Type: dynamic
Min Buffer Time: PT2S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4000000 (4.0 Mbps)
Codecs: hvc1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=3406377854880, d=480480, r=9
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kvvu_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 192000 (192 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Timescale: 240000
- S: t=3406377854880, d=480480, r=9
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kvvu_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 240000
- S: t=3406377854880, d=480480, r=9
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kvvu_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 240000
- S: t=3406377854880, d=480480, r=9

Raw XML

<MPD availabilityStartTime="2025-04-08T12:45:10Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT6S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-19T19:19:31Z" timeShiftBufferDepth="PT40S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">      <Period id="P0" start="PT0S">      <BaseURL>https://kvvu.atsc.stream/kvvutv1/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <ContentProtection cenc:default_KID="5e166f55-e093-5f88-8b30-1177b478c867" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="5e166f55-e093-5f88-8b30-1177b478c867" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kvvu_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <Supplemental schemeIdUri="http://dashif.org/metadata/hdr" value="SMPTE2094-10"/>         <SegmentTemplate initialization="video-$Bandwidth$-init.mp4" media="video-$Bandwidth$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="9" t="3406377854880"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="4000000" codecs="hvc1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" segmentProfiles="cdm1" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <ContentProtection cenc:default_KID="5e166f55-e093-5f88-8b30-1177b478c867" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="5e166f55-e093-5f88-8b30-1177b478c867" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kvvu_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="audio-0-$Bandwidth$-init.mp4" media="audio-0-$Bandwidth$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="9" t="3406377854880"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="192000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <ContentProtection cenc:default_KID="5e166f55-e093-5f88-8b30-1177b478c867" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="5e166f55-e093-5f88-8b30-1177b478c867" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kvvu_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <SegmentTemplate initialization="audio-1-$Bandwidth$-init.mp4" media="audio-1-$Bandwidth$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="9" t="3406377854880"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="data-0-$Bandwidth$-init.mp4" media="data-0-$Bandwidth$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="9" t="3406377854880"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://atsc-v2.gdm-connect.com/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tv:kvvu.gray.tv" bbandEntryPageUrl="https://atsc-v2.gdm-connect.com/run3tv-common/index.html" ></HTMLEntryPackage>
</HELD>

Service 5008: DDAAS

Protocol: ROUTE
Category: App-Based Service

Source: 192.168.202.202
Destination: 239.255.33.100:6000

Hidden: Service & Guide
App: No

Service Details (from SLT)

Global Service ID: tag:broadspanwireless.com,2023:2090:KVCW:2091
Category: 3 (App-Based Service)
SLS Destination: 239.255.33.100:6000
SLS Source: 192.168.202.202
SLS Protocol Version: . (ROUTE)
Hidden: Yes
Hide in Guide: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5008"></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
1000			N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="192.168.202.202"><LS tsi="1000"><SrcFlow><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="209"></item></metadataEnvelope>

Data Distribution & Ancillary Services (UDST) Instance 1

BroadSpan Service: DDAAS

Reservation Name: NRT
Service ID in UDST: 5008
Destination: 239.255.33.100:6000
Order ID: 2025-001754-00015

Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<UDST version="0.1">
    <UDS>
        <broadSpanServices>
            <broadSpanService name="DDAAS">
                <rsrv apiKey="" callbackUrl="https://api.prod.castera.dev/orders/v1" destIP="239.255.33.100" destPort="6000" fileName="HoustonTest.png" name="NRT" orderId="2025-001026-00005" srvid="5008"/>
                <rsrv apiKey="" callbackUrl="" destIP="239.255.33.103" destPort="6123" mktid="" name="RTK" orderId="2025-09-02-RTK-Route" srvid="5012"/>
                <rsrv apiKey="" callbackUrl="https://api.prod.castera.dev/orders/v1" destIP="239.255.33.100" destPort="6000" fileName="9E-61-C6-E8-28-E9-F8-6F-E9-E4-6E-1D-3B-37-32-4B.png" name="NRT" orderId="2025-001754-00015" srvid="5008"/>
            </broadSpanService>
        </broadSpanServices>
    </UDS>
</UDST>

Service 5009: PBTV (3.11)

Protocol: ROUTE
Category: Linear A/V Service

Source: 192.168.202.202
Destination: 239.255.3.11:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 2 ch @ 384 kbps
Codec: ac-4.02.01.00

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:PBTV:KSNV
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.3.11:5000
SLS Source: 192.168.202.202
SLS Protocol Version: 0.0 (ROUTE)
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5009"><DeliveryMethod><UnicastAppService><BasePattern>a0-24-</BasePattern><BasePattern>d0-Data3_5-</BasePattern><BasePattern>video-Video1_1-</BasePattern><BasePattern>video-Video1_2-</BasePattern><BasePattern>video-Video1_3-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="4"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="158"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-19T19:19:33Z)

Type: dynamic
Min Buffer Time: PT10S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_3

Bandwidth: 1000000 (1000 kbps)
Codecs: hev1.2.4.L93.B0
Resolution: 960x540 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=421994283110400, d=480480, r=29

Representation ID: Video1_2

Bandwidth: 4000000 (4.0 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=421994283110400, d=480480, r=29

Representation ID: Video1_1

Bandwidth: 8000000 (8.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=421994283110400, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 24

Bandwidth: 384000 (384 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 240000
- S: t=421994283110400, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_5

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 240000
- S: t=421994283110400, d=480480, r=29

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-19T19:19:33Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://ksnv-sbgtv.atsc.stream/pickleball/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="540" minWidth="960" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421994283110400"/>            </SegmentTimeline>         </SegmentTemplate>                                 <Representation bandwidth="1000000" codecs="hev1.2.4.L93.B0" frameRate="60000/1001" height="540" id="Video1_3" sar="1:1" scanType="progressive" width="960"/><Representation bandwidth="4000000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_2" sar="1:1" scanType="progressive" width="1280"/><Representation bandwidth="8000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421994283110400"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.00" id="24"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421994283110400"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_5"/></AdaptationSet>   </Period></MPD>

Service 5010: GMLOOP (3.20)

Protocol: ROUTE
Category: App-Based Service

Source: 192.168.202.202
Destination: 239.255.3.20:5000

Hidden: No
App: GameLoop

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:Gameloop:KSNV
Category: 3 (App-Based Service)
SLS Destination: 239.255.3.20:5000
SLS Source: 192.168.202.202
SLS Protocol Version: . (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5010"></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://nextgen.gameloop.tv/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tag:sinclairplatform.com,2020:Gameloop:KSNV" bbandEntryPageUrl="https://nextgen.gameloop.tv/run3tv-common/index.html"></HTMLEntryPackage>
</HELD>

Service 5011: ROXi (3.21)

Protocol: ROUTE
Category: App-Based Service

Source: 192.168.202.202
Destination: 239.255.3.21:5000

Hidden: No
App: ROXi

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:Roxi:ksnv
Category: 3 (App-Based Service)
SLS Destination: 239.255.3.21:5000
SLS Source: 192.168.202.202
SLS Protocol Version: . (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5011"></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="3"></item></metadataEnvelope>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://cdn.prod.tvapp.roxi.tv/releases/prod-atsc/index.html#/atsc,faststream,showId=46eb1cf29052,prod

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://cdn.prod.tvapp.roxi.tv/releases/prod-atsc/index.html#/atsc,faststream,showId=46eb1cf29052,prod" appContextId="tag:sinclairplatform.com,2020:Roxi:ksnv" />
</HELD>

Other Global LLS Tables

System Time Details - Actual Timestamp in L1Detail

Attribute	Value
currentUtcOffset	37
utcLocalOffset	-PT7H
dsStatus	true

Raw XML

<?xml version="1.0" encoding="utf-8"?>
<SystemTime xmlns="http://www.atsc.org/XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/ SYSTIME-1.0-20211208.xsd" currentUtcOffset="37" utcLocalOffset="-PT7H" dsStatus="true"/>

Input Info

Attribute	Value
Input Type	Debug File
File Name	10195-0-20250919-200255-p0p1-dbg.dbg
Total Packets Processed	34039
File Last Modified	2025-09-19 20:02:55 EDT
Analysis Run Time	2025-11-23 16:15:56 EST

ATSC 3.0 Data Usage Analysis

IP:Port (ID)	Usage ↓	Service	Type	Total Data	Bitrate
239.255.13.1:5002 (TSI 100)	20.11%	KTNV	Video	11.34 MB	N/A
239.255.8.1:5001 (TSI 100)	20.01%	KLAS	Video	11.28 MB	N/A
239.255.3.1:5004 (TSI 100)	16.76%	KSNV	Video	9.45 MB	N/A
239.255.33.1:5003 (PID 100)	15.40%	KVCW	Video	8.68 MB	N/A
239.255.33.1:5003 (PID 36424)	2.12%	KVCW	Data/Captions	1.20 MB	N/A
239.255.33.1:5003 (PID 200)	1.59%	KVCW	Audio	899.1 KB	N/A
239.255.3.1:5004 (TSI 200)	1.52%	KSNV	Audio	858.4 KB	N/A
224.0.23.60:4937 (LLS)	1.00%	LLS Signaling	LLS Signaling	561.6 KB	N/A
239.255.13.1:5002 (TSI 0)	0.90%	KTNV	Service Signaling	509.3 KB	N/A
239.255.8.1:5001 (TSI 0)	0.83%	KLAS	Service Signaling	468.8 KB	N/A
239.255.3.1:5004 (TSI 0)	0.60%	KSNV	Service Signaling	338.0 KB	N/A
239.255.13.1:5002 (TSI 200)	0.36%	KTNV	Audio	203.4 KB	N/A
239.255.8.1:5001 (TSI 200)	0.36%	KLAS	Audio	203.3 KB	N/A
239.255.5.1:5000 (TSI 0)	0.34%	KVVU	Service Signaling	191.7 KB	N/A
239.255.33.1:5003 (PID 201)	0.25%	KVCW	Audio	142.4 KB	N/A
239.255.33.1:5100 (TSI 80)	0.23%	ESG	ROUTE Media	131.2 KB	N/A
239.255.33.1:5100 (TSI 0)	0.23%	ESG	Service Signaling	130.0 KB	N/A
239.255.8.1:5001 (TSI 201)	0.20%	KLAS	Audio	112.0 KB	N/A
239.255.13.1:5002 (TSI 201)	0.20%	KTNV	Audio	111.0 KB	N/A
239.255.3.1:5004 (TSI 201)	0.18%	KSNV	Audio	102.2 KB	N/A
239.255.3.21:5000 (TSI 0)	0.18%	ROXi	Service Signaling	100.4 KB	N/A
239.255.3.11:5000 (TSI 0)	0.17%	PBTV	Service Signaling	97.5 KB	N/A
239.255.33.1:5100 (TSI 50)	0.16%	ESG	ROUTE Media	91.0 KB	N/A
239.255.3.10:5000 (TSI 0)	0.16%	T2	Service Signaling	90.6 KB	N/A
239.255.33.1:5100 (TSI 60)	0.16%	ESG	ROUTE Media	89.6 KB	N/A
239.255.33.1:5003 (PID 0)	0.16%	KVCW	Service Signaling	89.6 KB	N/A
239.255.33.100:6000 (TSI 0)	0.13%	DDAAS	Service Signaling	73.1 KB	N/A
239.255.33.103:6123	0.10%	Unknown Service	Other UDP	56.6 KB	N/A
239.255.3.20:5000 (TSI 0)	0.09%	GMLOOP	Service Signaling	49.2 KB	N/A
239.255.33.1:5003 (PID 300)	0.06%	KVCW	stpp	36.6 KB	N/A
239.255.8.1:5001 (TSI 300)	0.05%	KLAS	Captions	30.9 KB	N/A
239.255.13.1:5002 (TSI 300)	0.04%	KTNV	Captions	20.9 KB	N/A

Total: 56.37 MB | Signaling: 4.79% | Media: 79.78% | Other: 0.10%

RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

Service Summary (SLT BSID: 2090)

Certificate Details

Service 5001: KLAS (8.1) Encrypted

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a022

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data4_4

Raw XML

Service 5002: KTNV (13.1) Encrypted

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a022

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: und)

Representation ID: Data4_4

Raw XML

Raw XML

Service 5003: KVCW (33.1)

Raw XML

Components:

Raw XML

Binary MMT Package Table

Raw XML

Video Stream Properties Descriptor (VSPD)

Audio Stream Properties Descriptor (ASPD)

Caption Asset Descriptor (CAD)

Service 5004: KSNV (3.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a022

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: und)

Representation ID: Data4_4

Raw XML

Raw XML

Service 5005: ESG

Raw XML

ROUTE Stream: 239.255.33.1:5100

Raw XML

Raw XML

Service 5006: T2 (3.10) Internet Required

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_3

Raw XML

Service 5007: KVVU (5.1) Encrypted Internet Required

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Service 5001: KLAS (8.1)

Service 5002: KTNV (13.1)

Service 5006: T2 (3.10)

Service 5007: KVVU (5.1)

Service 5008: DDAAS

Service 5009: PBTV (3.11)
