RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

PLP ID	SFI	Modulation	Code Rate	Layer	TI Mode	LLS	Lock	Required SNR	Bitrate
0	0	qam16	9/15	core	hti	Yes	Yes	AWGN: 7.32-7.58 dB Rayleigh: 9.94-10.28 dB	N/A
1	0	qam256	11/15	core	hti	Yes	Yes	AWGN: 18.76-19.08 dB Rayleigh: 21.94-22.40 dB	N/A

L1 Detail Information Not Available

Link Mapping Table Data Not Available

Service Summary (SLT BSID: 2194)

Service Name	ID	Channel	Protocol / Category	SLS Destination
WCWN	5001	45.1	ROUTE / Linear A/V Service	239.255.45.1:5001
ESG	5002		ROUTE / ESG Service	239.255.45.1:5100
WRGB	5003	6.1	ROUTE / Linear A/V Service	239.255.6.1:5001
WTEN	5004	10.1	ROUTE / Linear A/V Service	239.255.10.1:5001
WXXA	5005	23.1	ROUTE / Linear A/V Service	239.255.23.1:5001
WMHT	5006	17.1	ROUTE / Linear A/V Service	239.255.17.1:5001
T2	5007	6.10	ROUTE / Linear A/V Service	239.255.6.10:5000
DDAAS	5008		ROUTE / App-Based Service	239.255.45.100:6000
PBTV	5009	6.11	ROUTE / Linear A/V Service	239.255.6.11:5000
GMLOOP	5010	6.20	ROUTE / App-Based Service	239.255.6.20:5000
ROXi	5011	6.21	ROUTE / App-Based Service	239.255.6.21:5000

Capability Descriptor Table (CDT) - 5 Certificate(s)

Attribute	Value
OCSP Refresh	P7DT0H
Certificate Count	5

Certificate Details

Certificate 1 - WCWN Signalling Signing SMT 0001 (Valid Until: Sep 16 2026)

Field	Value
Subject	/C=US/ST=New York/L=Albany/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=WCWN Signalling Signing SMT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	67BFD36F1CE6F11D770C6930FCD37EF86EE15580
Valid From	Sep 16 18:35:48 2025 GMT
Valid Until	Sep 16 18:35:48 2026 GMT
Signature Algorithm	sha256WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	0F:18:3B:C0:53:A4:30:62:18:06:EC:0E:3E:1A:FA:30:7E:37:F7:86
SHA-256 Fingerprint	07:1F:80:14:E7:E0:4C:5E:7B:F8:9C:0F:26:B1:49:64:5A:B4:7B:BF:B4:25:58:F6:5D:1E:F5:2E:64:F4:0A:
Certificate Authority	No
Self-Signed	No

Certificate 2 - WCWN Signaling Signing CDT 0001 (Valid Until: Oct 12 2025)

Field	Value
Subject	/C=US/ST=NY/L=Schenectady/O=Sinclair Broadcast Group, Inc./CN=WCWN Signaling Signing CDT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	015210CC06BDD781338F608B24A4C9FA7A82366F
Valid From	Oct 12 19:03:34 2023 GMT
Valid Until	Oct 12 19:03:34 2025 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	36:26:66:EC:17:93:83:F6:C9:75:A0:F4:D3:01:2D:C9:CE:8B:FD:4C
SHA-256 Fingerprint	AE:59:F7:76:19:6F:7E:1C:C0:54:5A:3F:BB:87:BF:C4:A3:BC:A7:E7:95:EC:2B:F6:D5:70:88:EA:F3:51:3B:
Certificate Authority	No
Self-Signed	No

Certificate 3 - WCWN Signalling Signing CDT 0001 (Valid Until: Sep 16 2026)

Field	Value
Subject	/C=US/ST=New York/L=Albany/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=WCWN Signalling Signing CDT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	325B021B519C1532C3EB6EC39AA433D89692D92B
Valid From	Sep 16 18:35:46 2025 GMT
Valid Until	Sep 16 18:35:46 2026 GMT
Signature Algorithm	sha256WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	5A:5F:8E:FF:B9:24:34:B4:FE:52:73:5A:1B:75:19:B8:A0:C4:9F:DA
SHA-256 Fingerprint	C7:DD:42:0B:3B:6A:70:5A:27:78:E7:EB:96:EE:41:9C:03:4C:89:2E:37:1B:C9:F4:E8:EE:44:6C:8D:8B:A8:
Certificate Authority	No
Self-Signed	No

Certificate 4 - ATSC 3.0 Signing CA-2 (Valid Until: Sep 8 2030)

Field	Value
Subject	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Issuer	/C=US/O=Pearl TV/OU=Root CA-1/CN=ATSC3 Root-CA
Serial Number	1D81C0A269A03D9AAF128428593DB6B8
Valid From	Sep 8 00:00:00 2021 GMT
Valid Until	Sep 8 23:59:59 2030 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	06:63:9A:0C:E9:C0:E7:2C:44:05:1C:8A:91:B6:68:FB:25:C4:38:75
SHA-256 Fingerprint	23:42:5B:1C:CA:CB:F3:31:7C:8B:03:59:DA:E0:A3:98:C4:84:05:DB:1B:6B:92:15:58:69:F7:89:30:9A:65:
Certificate Authority	Yes
Self-Signed	No

Certificate 5 - WCWN Signaling Signing SMT 0001 (Valid Until: Oct 12 2025)

Field	Value
Subject	/C=US/ST=NY/L=Schenectady/O=Sinclair Broadcast Group, Inc./CN=WCWN Signaling Signing SMT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	12023E13695F4A7F72F3BE934413F4F5FEA25739
Valid From	Oct 12 19:04:29 2023 GMT
Valid Until	Oct 12 19:04:29 2025 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	6A:A1:A2:22:CD:94:7D:8E:5D:67:22:0B:EF:2D:1F:0B:7C:99:B6:DB
SHA-256 Fingerprint	DB:CE:45:49:1D:47:8B:EB:BD:81:F3:73:66:F3:42:57:B7:3D:B6:76:E2:50:B6:E9:93:7C:56:6D:3B:01:2F:
Certificate Authority	No
Self-Signed	No

Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<CertificationData xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/CDT-1.0-20180706.xsd">
<ToBeSignedData OCSPRefresh="P7DT0H"><Certificates>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</Certificates><Certificates>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</Certificates><Certificates>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</Certificates><Certificates>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</Certificates><Certificates>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</Certificates><CurrentCert>zvXXTSGGPAvCpO2U0W0c8b9ev9I=</CurrentCert></ToBeSignedData>
<CMSSignedData>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</CMSSignedData>
<OCSPResponse>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</OCSPResponse><OCSPResponse>MIIC0AoBAKCCAskwggLFBgkrBgEFBQcwAQEEggK2MIICsjCCARqiFgQUoN79JJBZSAIhlyd/4ZY74oFoxrYYDzIwMjUwOTE4MjI0NjM2WjCB7jB1ME0wCQYFKw4DAhoFAAQU5gvf52P7Wtda0EPbgrceW49evAMEFKDe/SSQWUgCIZcnf+GWO+KBaMa2AhQBUhDMBr3XgTOPYIskpMn6eoI2b4AAGA8yMDI1MDkxODIyNDYzNlqgERgPMjAyNTA5MjUyMjQ2MzZaMHUwTTAJBgUrDgMCGgUABBTmC9/nY/ta11rQQ9uCtx5bj168AwQUoN79JJBZSAIhlyd/4ZY74oFoxrYCFBICPhNpX0p/cvO+k0QT9PX+olc5gAAYDzIwMjUwOTE4MjI0NjM2WqARGA8yMDI1MDkyNTIyNDYzNlowDQYJKoZIhvcNAQENBQADggGBAEPyDvGXP2eF35VYOrm+xjCFKT009DRJxtDUZHLx//rXIQCgNwXb4NL9boR7d+8pn7SSGxtiZFhrnwBZj8I80LNWpgYdMwGy1q8hhHwHp25k1wEf7LN+g1gScts3v73TVUy0OIcvv5pihXhdS9DAQu39jRFUGAEgK93K+JTpmpYLLEaEpcMHziDcTwCwihaIW6xbVTF74Fchh+ntzMpd8Y3L59JxDPjnve3MZlLamn8v8X4yzmWqO4vHS/awdJOHwWm5f8IhTfr1utDekRQGEFEny1nHt2+OT7vMNPH45gY/9I4Kz5wxeaHSqjjgV8q0vlmITXTemoF+iIF3zb5tuoUx0XPcF/9AMq/slmakDprMiQoyC38EqYKAleYahNB7+fFuX0Gr3ApZaETjITqxwsU7D9ZRTc5BwwsH0NzqJq9ldtoy5sSjcB3zY+ruOpCRzJTIuAuqB+DVH0ETdwEGiC2CRVYgxwfDX4id1y2JmVgAbwnYfWBskO0QxSw+XjPrUA==</OCSPResponse><OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse>
</CertificationData>

Service List Table (SLT) Instance 1 - Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<SLT bsid="2194" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SLT/1.0/ SLT-1.0-20211209.xsd">
    <Service globalServiceID="tag:sinclairplatform.com,2022:WCWN:2195" majorChannelNo="45" minorChannelNo="1" serviceCategory="1" serviceId="5001" shortServiceName="WCWN" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.45.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service serviceCategory="4" serviceId="5002" shortServiceName="ESG" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.45.1" slsDestinationUdpPort="5100" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2022:2191" majorChannelNo="6" minorChannelNo="1" serviceCategory="1" serviceId="5003" shortServiceName="WRGB" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.6.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2022:WTEN:2111" majorChannelNo="10" minorChannelNo="1" serviceCategory="1" serviceId="5004" shortServiceName="WTEN" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.10.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2022:WXXA:2115" majorChannelNo="23" minorChannelNo="1" serviceCategory="1" serviceId="5005" shortServiceName="WXXA" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.23.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2022:WMHT:2193" majorChannelNo="17" minorChannelNo="1" serviceCategory="1" serviceId="5006" shortServiceName="WMHT" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.17.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:T2:WRGB" majorChannelNo="6" minorChannelNo="10" serviceCategory="1" serviceId="5007" shortServiceName="T2" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.6.10" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:broadspanwireless.com,2023:2194:WCWN:2195" hidden="true" hideInGuide="true" serviceCategory="3" serviceId="5008" shortServiceName="DDAAS" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.45.100" slsDestinationUdpPort="6000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:PBTV:WRGB" majorChannelNo="6" minorChannelNo="11" serviceCategory="1" serviceId="5009" shortServiceName="PBTV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.6.11" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:sinclairplatform.com,2020:Gameloop:WRGB" majorChannelNo="6" minorChannelNo="20" serviceCategory="3" serviceId="5010" shortServiceName="GMLOOP" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.6.20" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:Roxi:wrgb" majorChannelNo="6" minorChannelNo="21" serviceCategory="3" serviceId="5011" shortServiceName="ROXi" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.6.21" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
</SLT>

Service 5001: WCWN (45.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.45.1:5001

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 16 ch @ 448 kbps
Codec: ac-4.02.01.02

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2022:WCWN:2195
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.45.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5001"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	1,'TV-PG',{0 'TV-PG'}
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4500000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-PG',{0 'TV-PG'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="448000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="11"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="163"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="143"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="2"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-19T22:13:51Z)

Type: dynamic
Min Buffer Time: PT2S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4500000 (4.5 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 448000 (448 kbps)
Codecs: ac-4.02.01.02
Audio Sample Rate: 48000 Hz
Audio Channels: 16
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT20S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-19T22:13:51Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="4500000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>               <Representation audioSamplingRate="48000" bandwidth="448000" codecs="ac-4.02.01.02" id="a02_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SegmentTemplate duration="480480" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="subtitle"/>         <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html" appContextId="tag:sinclairplatform.com,2022:WCWN:2195" />
</HELD>

Service 5002: ESG

Protocol: ROUTE
Category: ESG Service

Source: 172.16.200.1
Destination: 239.255.45.1:5100

Hidden: No
App: No

Service Details (from SLT)

Global Service ID:
Category: 4 (ESG Service)
SLS Destination: 239.255.45.1:5100
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5002"></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: 239.255.45.1:5100

TSI	Representation ID	Content Type	Content Ratings
50			N/A
60			N/A
80			N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1" dIpAddr="239.255.45.1" dPort="5100"><LS tsi="50"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="1546" Content-Location="sgdd_1546" Content-Length="61942" Transfer-Length="6188" Content-Type="application/vnd.oma.bcast.sgdd+xml" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="60"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="3914" Content-Location="sgdu_content_3914" Content-Length="448306" Transfer-Length="45432" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File><fdt:File TOI="4779" Content-Location="sgdu_service_schedule_4779" Content-Length="84087" Transfer-Length="7029" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="80"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="5742" Content-Location="s53098_ll_h15_ac.png" Content-Length="6025" Transfer-Length="5795" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5743" Content-Location="s28711_h3_ba.png" Content-Length="9147" Transfer-Length="8389" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5744" Content-Location="s28708_h3_aa.png" Content-Length="15267" Transfer-Length="15140" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5745" Content-Location="s28719_ll_h15_ac.png" Content-Length="8623" Transfer-Length="8259" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5746" Content-Location="s32356_ll_h15_ac.png" Content-Length="12457" Transfer-Length="12112" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="4"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="4774"></item></metadataEnvelope>

Electronic Service Guide (ESG) - 5 Service(s), 36 Program(s) (from 46 fragments)

Service : WMHT (17.1)

Field	Value
ID	urn:digicap:svc:5006:1758275698056
Status	tag:sinclairpla
Description	WMHT

Raw XML (0 fragments)

Service : WXXA (23.1)

Field	Value
ID	urn:digicap:svc:5005:1758275698056
Status	tag:sinclairpla
Description	WXXA

Raw XML (0 fragments)

Service : WTEN (10.1)

Field	Value
ID	urn:digicap:svc:5004:1758275698056
Status	tag:sinclairpla
Description	WTEN

Raw XML (0 fragments)

Service : WRGB (6.1)

Field	Value
ID	urn:digicap:svc:5003:1758275698056
Status	tag:sinclairpla
Description	WRGB

Raw XML (0 fragments)

Service : WCWN (45.1)

Field	Value
ID	urn:digicap:svc:5001:1758275698056
Status	tag:sinclairpla
Description	WCWN

Raw XML (0 fragments)

Service 5003: WRGB (6.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.6.1:5001

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 16 ch @ 448 kbps
Codec: ac-4.02.01.02

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2022:2191
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.6.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5003"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4500000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="448000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="10"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="98"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="237"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="2"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-19T22:13:51Z)

Type: dynamic
Min Buffer Time: PT2S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4500000 (4.5 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 448000 (448 kbps)
Codecs: ac-4.02.01.02
Audio Sample Rate: 48000 Hz
Audio Channels: 16
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: und)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT20S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-19T22:13:51Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="4500000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>               <Representation audioSamplingRate="48000" bandwidth="448000" codecs="ac-4.02.01.02" id="a02_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <SegmentTemplate duration="480480" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="und" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html" appContextId="tag:sinclairplatform.com,2022:2191" />
</HELD>

Service 5004: WTEN (10.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.10.1:5001

Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2022:WTEN:2111
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.10.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5004"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	1,'TV-MA',{0 'TV-MA'}
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5250000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-MA',{0 'TV-MA'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="10"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="193"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="157"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-19T21:07:51Z)

Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 5250000 (5.2 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 60000, Duration: 60060, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 60000, Duration: 60060, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT12H0M43S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-19T21:07:51Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-MA',{0 'TV-MA'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="60060" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="60000"/>               <Representation bandwidth="5250000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-MA',{0 'TV-MA'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a02_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-MA',{0 'TV-MA'}"/>         <SegmentTemplate duration="240240" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-MA',{0 'TV-MA'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="60060" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="60000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>

Service 5005: WXXA (23.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.23.1:5001

Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2022:WXXA:2115
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.23.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5005"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-5250000-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	1,'TV-PG',{0 'TV-PG'}
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5250000" afdt:fileTemplate="video-5250000-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-5250000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-PG',{0 'TV-PG'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="14"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="156"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="27"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-19T21:07:51Z)

Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-live:2011

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 5250000 (5.2 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-$Bandwidth$-init.mp4
- Media URL: video-$Bandwidth$-$Number$.mp4v
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT12H0M43S" profiles="urn:mpeg:dash:profile:isoff-live:2011" publishTime="2025-09-19T21:07:51Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="video-$Bandwidth$-init.mp4" media="video-$Bandwidth$-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="5250000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a02_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SegmentTemplate duration="240240" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="240240" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>

Service 5006: WMHT (17.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.17.1:5001

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2022:WMHT:2193
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.17.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5006"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5250000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="10"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="181"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="162"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-19T21:07:48Z)

Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 5250000 (5.2 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 60000, Duration: 60060, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 60000, Duration: 60060, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT12H0M43S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-19T21:07:48Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="60060" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="60000"/>               <Representation bandwidth="5250000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a02_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <SegmentTemplate duration="240240" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="60060" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="60000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>

Service 5007: T2 (6.10)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.6.10:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 384 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:T2:WRGB
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.6.10:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5007"><DeliveryMethod><UnicastAppService><BasePattern>a0-22-</BasePattern><BasePattern>d0-Data3_3-</BasePattern><BasePattern>video-Video1_1-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="55"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="228"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-19T22:14:09Z)

Type: dynamic
Min Buffer Time: PT10S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 7000000 (7.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=421996797462240, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 384000 (384 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Timescale: 240000
- S: t=421996797466244, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_3

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 240000
- S: t=421996797462240, d=480480, r=29

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-19T22:14:09Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://wrgb-sbgtv.atsc.stream/t2/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421996797462240"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="7000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421996797466244"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421996797462240"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_3"/></AdaptationSet>   </Period></MPD>

Service 5008: DDAAS

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.45.100:6000

Hidden: Service & Guide
App: No

Service Details (from SLT)

Global Service ID: tag:broadspanwireless.com,2023:2194:WCWN:2195
Category: 3 (App-Based Service)
SLS Destination: 239.255.45.100:6000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)
Hidden: Yes
Hide in Guide: Yes

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="dwd.dwd" contentType="application/atsc-dwd+xml" version="1"></item></metadataEnvelope>

Dynamic Window Description (DWD) Instance 1

Raw XML

<?xml version="1.0" encoding="UTF-8"?><DWD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/DWD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/DWD/1.0/ DWD-1.0-20180830.xsd"><DistributionWindow startTime="2025-09-18T11:25:00Z" endTime="2025-09-18T11:26:53Z" lctTSIRef="1000" contentLabel="2"><AppContextId dwFilterCode="1">http://testorder.com</AppContextId></DistributionWindow></DWD>

Service 5009: PBTV (6.11)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.6.11:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 2 ch @ 384 kbps
Codec: ac-4.02.01.00

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:PBTV:WRGB
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.6.11:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5009"><DeliveryMethod><UnicastAppService><BasePattern>a0-24-</BasePattern><BasePattern>d0-Data3_5-</BasePattern><BasePattern>video-Video1_1-</BasePattern><BasePattern>video-Video1_2-</BasePattern><BasePattern>video-Video1_3-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="4"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="188"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-09-19T22:14:07Z)

Type: dynamic
Min Buffer Time: PT10S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_3

Bandwidth: 1000000 (1000 kbps)
Codecs: hev1.2.4.L93.B0
Resolution: 960x540 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=421996796981760, d=480480, r=29

Representation ID: Video1_2

Bandwidth: 4000000 (4.0 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=421996796981760, d=480480, r=29

Representation ID: Video1_1

Bandwidth: 8000000 (8.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=421996796981760, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 24

Bandwidth: 384000 (384 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 240000
- S: t=421996796981760, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_5

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 240000
- S: t=421996796981760, d=480480, r=29

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-09-19T22:14:07Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://wrgb-sbgtv.atsc.stream/pickleball/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="540" minWidth="960" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421996796981760"/>            </SegmentTimeline>         </SegmentTemplate>                                 <Representation bandwidth="1000000" codecs="hev1.2.4.L93.B0" frameRate="60000/1001" height="540" id="Video1_3" sar="1:1" scanType="progressive" width="960"/><Representation bandwidth="4000000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_2" sar="1:1" scanType="progressive" width="1280"/><Representation bandwidth="8000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421996796981760"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.00" id="24"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="421996796981760"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_5"/></AdaptationSet>   </Period></MPD>

Service 5010: GMLOOP (6.20)

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.6.20:5000

Hidden: No
App: GameLoop

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:Gameloop:WRGB
Category: 3 (App-Based Service)
SLS Destination: 239.255.6.20:5000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5010"></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://nextgen.gameloop.tv/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tag:sinclairplatform.com,2020:Gameloop:WRGB" bbandEntryPageUrl="https://nextgen.gameloop.tv/run3tv-common/index.html"></HTMLEntryPackage>
</HELD>

Service 5011: ROXi (6.21)

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.6.21:5000

Hidden: No
App: ROXi

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:Roxi:wrgb
Category: 3 (App-Based Service)
SLS Destination: 239.255.6.21:5000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5011"></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="8"></item></metadataEnvelope>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://cdn.prod.tvapp.roxi.tv/releases/prod-atsc/index.html#/atsc,faststream,showId=46eb1cf29052,prod

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://cdn.prod.tvapp.roxi.tv/releases/prod-atsc/index.html#/atsc,faststream,showId=46eb1cf29052,prod" appContextId="tag:sinclairplatform.com,2020:Roxi:wbff" />
</HELD>

Other Global LLS Tables

System Time Details - Actual Timestamp in L1Detail

Attribute	Value
currentUtcOffset	37
utcLocalOffset	-PT4H
dsStatus	true

Raw XML

<?xml version="1.0" encoding="utf-8"?>
<SystemTime xmlns="http://www.atsc.org/XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/ SYSTIME-1.0-20211208.xsd" currentUtcOffset="37" utcLocalOffset="-PT4H" dsStatus="true"/>

Input Info

Attribute	Value
Input Type	Debug File
File Name	73264-0-20250919-204332-p0p1-dbg.dbg
Total Packets Processed	37785
File Last Modified	2025-09-19 20:43:32 EDT
Analysis Run Time	2025-11-22 05:59:53 EST

ATSC 3.0 Data Usage Analysis

IP:Port (ID)	Usage ↓	Service	Type	Total Data	Bitrate
239.255.17.1:5001 (TSI 100)	18.71%	WMHT	Video	9.98 MB	N/A
239.255.10.1:5001 (TSI 100)	18.51%	WTEN	Video	9.87 MB	N/A
239.255.23.1:5001 (TSI 100)	18.15%	WXXA	Video	9.68 MB	N/A
239.255.6.1:5001 (TSI 100)	16.42%	WRGB	Video	8.76 MB	N/A
239.255.45.1:5001 (TSI 100)	15.88%	WCWN	Video	8.47 MB	N/A
239.255.6.1:5001 (TSI 200)	1.60%	WRGB	Audio	854.7 KB	N/A
239.255.45.1:5001 (TSI 200)	1.60%	WCWN	Audio	852.0 KB	N/A
224.0.23.60:4937 (LLS)	1.26%	LLS Signaling	LLS Signaling	671.5 KB	N/A
239.255.10.1:5001 (TSI 0)	0.74%	WTEN	Service Signaling	392.4 KB	N/A
239.255.45.1:5001 (TSI 0)	0.72%	WCWN	Service Signaling	384.6 KB	N/A
239.255.6.1:5001 (TSI 0)	0.70%	WRGB	Service Signaling	373.2 KB	N/A
239.255.17.1:5001 (TSI 0)	0.69%	WMHT	Service Signaling	370.0 KB	N/A
239.255.23.1:5001 (TSI 0)	0.68%	WXXA	Service Signaling	361.1 KB	N/A
239.255.17.1:5001 (TSI 200)	0.37%	WMHT	Audio	198.6 KB	N/A
239.255.17.1:5001 (TSI 201)	0.37%	WMHT	Audio	198.6 KB	N/A
239.255.23.1:5001 (TSI 200)	0.37%	WXXA	Audio	198.5 KB	N/A
239.255.10.1:5001 (TSI 200)	0.37%	WTEN	Audio	198.5 KB	N/A
239.255.10.1:5001 (TSI 201)	0.37%	WTEN	Audio	198.3 KB	N/A
239.255.23.1:5001 (TSI 201)	0.37%	WXXA	Audio	198.1 KB	N/A
239.255.45.1:5100 (TSI 0)	0.31%	ESG	Service Signaling	166.0 KB	N/A
239.255.6.1:5001 (TSI 201)	0.19%	WRGB	Audio	100.7 KB	N/A
239.255.45.1:5001 (TSI 201)	0.19%	WCWN	Audio	100.5 KB	N/A
239.255.6.21:5000 (TSI 0)	0.19%	ROXi	Service Signaling	100.4 KB	N/A
239.255.6.11:5000 (TSI 0)	0.18%	PBTV	Service Signaling	97.5 KB	N/A
239.255.6.10:5000 (TSI 0)	0.17%	T2	Service Signaling	90.6 KB	N/A
239.255.45.1:5100 (TSI 80)	0.16%	ESG	ROUTE Media	87.2 KB	N/A
239.255.10.1:5001 (TSI 300)	0.10%	WTEN	Captions	52.3 KB	N/A
239.255.17.1:5001 (TSI 300)	0.09%	WMHT	Captions	49.7 KB	N/A
239.255.6.20:5000 (TSI 0)	0.09%	GMLOOP	Service Signaling	49.2 KB	N/A
239.255.23.1:5001 (TSI 300)	0.09%	WXXA	Captions	48.5 KB	N/A
239.255.45.100:6000 (TSI 0)	0.08%	DDAAS	Service Signaling	42.8 KB	N/A
239.255.6.1:5001 (TSI 300)	0.07%	WRGB	Captions	36.7 KB	N/A
239.255.45.1:5100 (TSI 50)	0.07%	ESG	ROUTE Media	36.4 KB	N/A
239.255.45.1:5100 (TSI 60)	0.07%	ESG	ROUTE Media	35.9 KB	N/A
239.255.45.1:5001 (TSI 300)	0.05%	WCWN	Captions	28.5 KB	N/A

Total: 53.33 MB | Signaling: 5.81% | Media: 94.19% | Other: 0.00%
