RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

PLP/L1 Information Not Available

Link Mapping Table (LMT) Version 0 - 11 Service(s)

PLP ID	Source IP:Port	Destination IP:Port	Service ID	Service Name	Flags
0	0.0.0.0:0	224.0.23.60:4937			None
0	0.0.0.0:0	239.255.31.100:6000	5007	DDAAS	None
1	0.0.0.0:0	224.0.23.60:4937			None
1	0.0.0.0:0	239.255.31.1:5001	5001	WUHF	None
1	0.0.0.0:0	239.255.13.1:5001	5002	WHAM	None
1	0.0.0.0:0	239.255.21.1:5001	5003	WXXI	None
1	0.0.0.0:0	239.255.8.1:5001	5004	WROC	None
1	0.0.0.0:0	239.255.31.1:5100	5005	ESG	None
1	0.0.0.0:0	239.255.31.10:5000	5006	T2	None
1	0.0.0.0:0	239.255.31.11:5000	5008	PBTV	None
1	0.0.0.0:0	239.255.31.20:5000	5009	GMLOOP	None

Service Summary (SLT BSID: 2188)

Service Name	ID	Channel	PLP	Protocol / Category	SLS Destination
WUHF	5001	31.1	1	ROUTE / Linear A/V Service	239.255.31.1:5001
WHAM	5002	13.1	1	ROUTE / Linear A/V Service	239.255.13.1:5001
WXXI	5003	21.1	1	ROUTE / Linear A/V Service	239.255.21.1:5001
WROC	5004	8.1	1	ROUTE / Linear A/V Service	239.255.8.1:5001
ESG	5005		1	ROUTE / ESG Service	239.255.31.1:5100
T2	5006	31.10	1	ROUTE / Linear A/V Service	239.255.31.10:5000
DDAAS	5007		0	ROUTE / App-Based Service	239.255.31.100:6000
PBTV	5008	31.11	1	ROUTE / Linear A/V Service	239.255.31.11:5000
GMLOOP	5009	31.20	1	ROUTE / App-Based Service	239.255.31.20:5000

Capability Descriptor Table (CDT) - 3 Certificate(s)

Attribute	Value
OCSP Refresh	P7DT0H
Certificate Count	3

Certificate Details

Certificate 1 - ATSC 3.0 Signing CA-2 (Valid Until: Sep 8 2030)

Field	Value
Subject	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Issuer	/C=US/O=Pearl TV/OU=Root CA-1/CN=ATSC3 Root-CA
Serial Number	1D81C0A269A03D9AAF128428593DB6B8
Valid From	Sep 8 00:00:00 2021 GMT
Valid Until	Sep 8 23:59:59 2030 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	06:63:9A:0C:E9:C0:E7:2C:44:05:1C:8A:91:B6:68:FB:25:C4:38:75
SHA-256 Fingerprint	23:42:5B:1C:CA:CB:F3:31:7C:8B:03:59:DA:E0:A3:98:C4:84:05:DB:1B:6B:92:15:58:69:F7:89:30:9A:65:
Certificate Authority	Yes
Self-Signed	No

Certificate 2 - WUHF Signaling Signing CDT 0001 (Valid Until: Oct 12 2025)

Field	Value
Subject	/C=US/ST=NY/L=Rochester/O=Sinclair Broadcast Group, Inc./CN=WUHF Signaling Signing CDT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	6187ECC854D160264B4481F644FBE66941793A4B
Valid From	Oct 12 19:44:30 2023 GMT
Valid Until	Oct 12 19:44:30 2025 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	E7:5A:62:19:C6:03:89:95:D6:1B:F5:9B:42:45:F6:26:59:E7:7B:F7
SHA-256 Fingerprint	B9:4A:A3:A9:27:1B:D7:6F:37:81:B7:9B:F2:31:41:CD:F8:00:24:C5:37:F3:0B:7A:E5:96:E5:86:EA:9E:C9:
Certificate Authority	No
Self-Signed	No

Certificate 3 - WUHF Signaling Signing SMT 0001 (Valid Until: Oct 12 2025)

Field	Value
Subject	/C=US/ST=NY/L=Rochester/O=Sinclair Broadcast Group, Inc./CN=WUHF Signaling Signing SMT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	69FA06A8E5DB8EA1CEA37F89D2B186A4A4DB0266
Valid From	Oct 12 19:45:28 2023 GMT
Valid Until	Oct 12 19:45:28 2025 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	90:7E:55:36:DD:CA:E8:0D:F1:7F:1A:C4:A8:3D:14:DC:75:C9:6D:78
SHA-256 Fingerprint	F7:3B:51:2F:CD:C7:51:5B:5D:22:A9:4A:C9:BC:3E:32:7C:35:B6:5C:56:52:17:DF:E1:73:9E:0D:90:44:DF:
Certificate Authority	No
Self-Signed	No

Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<CertificationData xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/CDT-1.0-20180706.xsd">
<ToBeSignedData OCSPRefresh="P7DT0H"><Certificates>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</Certificates><Certificates>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</Certificates><Certificates>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</Certificates><CurrentCert>8bvwZcPyNqjOwA0q/zGwTBLFh5g=</CurrentCert></ToBeSignedData>
<CMSSignedData>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</CMSSignedData>
<OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse>
</CertificationData>

Service List Table (SLT) Instance 1 - Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<SLT bsid="2188" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SLT/1.0/ SLT-1.0-20211209.xsd">
    <Service globalServiceID="tag:sinclairplatform.com,2023:WUHF:2189" majorChannelNo="31" minorChannelNo="1" serviceCategory="1" serviceId="5001" shortServiceName="WUHF" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.31.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2023:WHAM:2185" majorChannelNo="13" minorChannelNo="1" serviceCategory="1" serviceId="5002" shortServiceName="WHAM" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.13.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="https://www.doi.org/10.5239/2327-C678" majorChannelNo="21" minorChannelNo="1" serviceCategory="1" serviceId="5003" shortServiceName="WXXI" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.21.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://www.doi.org/10.5239/5B01-F8C6" majorChannelNo="8" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5004" shortServiceName="WROC" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.8.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service serviceCategory="4" serviceId="5005" shortServiceName="ESG" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.31.1" slsDestinationUdpPort="5100" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:T2:WUHF" majorChannelNo="31" minorChannelNo="10" serviceCategory="1" serviceId="5006" shortServiceName="T2" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.31.10" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:broadspanwireless.com,2023:2188:WUHF:2189" hidden="true" hideInGuide="true" serviceCategory="3" serviceId="5007" shortServiceName="DDAAS" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.31.100" slsDestinationUdpPort="6000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:PBTV:WUHF" majorChannelNo="31" minorChannelNo="11" serviceCategory="1" serviceId="5008" shortServiceName="PBTV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.31.11" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:sinclairplatform.com,2020:Gameloop:WUHF" majorChannelNo="31" minorChannelNo="20" serviceCategory="3" serviceId="5009" shortServiceName="GMLOOP" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.31.20" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
</SLT>

Service 5001: WUHF (31.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.31.1:5001

Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2023:WUHF:2189
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.31.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5001"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>v-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	22	audio	N/A
201	Audio3_3	audio	N/A
300	Data4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5000000" afdt:fileTemplate="v-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="v-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="12"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="159"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="172"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="2"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-06-04T02:14:48Z)

Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 5000000 (5.0 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: v-init.mp4
- Media URL: v-$Number$.mp4v
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-init.mp4
- Media URL: a0-$Number$.mp4a
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-init.mp4
- Media URL: a1-$Number$.mp4a
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: d0-init.mp4
- Media URL: d0-$Number$.mp4s
- Timescale: 240000, Duration: 240240, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT10S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-06-04T02:14:48Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="v-init.mp4" media="v-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="5000000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <SegmentTemplate duration="240240" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="240240" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html" appContextId="tag:sinclairplatform.com,2023:WUHF:2189" />
</HELD>

Service 5002: WHAM (13.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.13.1:5001

Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2023:WHAM:2185
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.13.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5002"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>v-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	1,'TV-14',{0 'TV-14'}
200	22	audio	N/A
201	Audio3_3	audio	N/A
300	Data4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5200000" afdt:fileTemplate="v-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="v-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-14',{0 'TV-14'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="13"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="111"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="109"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="2"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-06-04T02:14:48Z)

Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 5200000 (5.2 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: v-init.mp4
- Media URL: v-$Number$.mp4v
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-init.mp4
- Media URL: a0-$Number$.mp4a
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-init.mp4
- Media URL: a1-$Number$.mp4a
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: d0-init.mp4
- Media URL: d0-$Number$.mp4s
- Timescale: 240000, Duration: 240240, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT10S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-06-04T02:14:48Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="v-init.mp4" media="v-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="5200000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <SegmentTemplate duration="240240" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="240240" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html" appContextId="tag:sinclairplatform.com,2023:WHAM:2185" />
</HELD>

Service 5003: WXXI (21.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.21.1:5001

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 2 ch @ 48 kbps
Codec: ac-4.02.01.00

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: https://www.doi.org/10.5239/2327-C678
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.21.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5003"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>a2-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>v-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	a022	audio	N/A
201	A13_3	audio	N/A
202	A24_4	audio	N/A
300	Data5_5	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5500000" afdt:fileTemplate="v-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="v-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a022"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="A13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="202"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a2-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="A24_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data5_5"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="18"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="183"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="90"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-03-05T18:13:11Z)

Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 5500000 (5.5 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: v-init.mp4
- Media URL: v-$Number$.mp4v
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a022

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a0-init.mp4
- Media URL: a0-$Number$.mp4a
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: A13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-init.mp4
- Media URL: a1-$Number$.mp4a
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: AD)

Representation ID: A24_4

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a2-init.mp4
- Media URL: a2-$Number$.mp4a
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data5_5

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: d0-init.mp4
- Media URL: d0-$Number$.mp4s
- Timescale: 240000, Duration: 240240, Start: 1

Raw XML

<MPD availabilityStartTime="2025-03-05T18:13:11Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT0S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-03-05T18:13:11Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="v-init.mp4" media="v-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="5500000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a022"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <SegmentTemplate duration="240240" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="A13_3"/></AdaptationSet><AdaptationSet contentType="audio" id="3" lang="AD" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <SegmentTemplate duration="240240" initialization="a2-init.mp4" media="a2-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="A24_4"/></AdaptationSet><AdaptationSet contentType="text" id="4" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="240240" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data5_5"/></AdaptationSet>   </Period></MPD>

Service 5004: WROC (8.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.8.1:5001

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: https://www.doi.org/10.5239/5B01-F8C6
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.8.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Protected: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5004"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>d0-</BasePattern><BasePattern>v-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	1,'TV-14 L-V',{0 'TV-14'}{2 'L'}{4 'V'}
200	22	audio	N/A
201	Audio3_3	audio	N/A
300	Data4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5500000" afdt:fileTemplate="v-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="v-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-14 L-V',{0 'TV-14'}{2 'L'}{4 'V'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d0-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="d0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="14"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="7"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="116"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-05-27T18:16:43Z)

Type: dynamic
Min Buffer Time: PT2S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 5500000 (5.5 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: v-init.mp4
- Media URL: v-$Number$.mp4v
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wroc_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-init.mp4
- Media URL: a0-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wroc_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-init.mp4
- Media URL: a1-$Number$.mp4a
- Timescale: 240000, Duration: 480480, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wroc_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: d0-init.mp4
- Media URL: d0-$Number$.mp4s
- Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT0S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-05-27T18:16:43Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14 L-V',{0 'TV-14'}{2 'L'}{4 'V'}"/>         <ContentProtection cenc:default_KID="545ff41f-51a3-5691-b4de-c172271f22a5" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="545ff41f-51a3-5691-b4de-c172271f22a5" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wroc_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="v-init.mp4" media="v-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="5500000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14 L-V',{0 'TV-14'}{2 'L'}{4 'V'}"/>         <ContentProtection cenc:default_KID="545ff41f-51a3-5691-b4de-c172271f22a5" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="545ff41f-51a3-5691-b4de-c172271f22a5" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wroc_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14 L-V',{0 'TV-14'}{2 'L'}{4 'V'}"/>         <ContentProtection cenc:default_KID="545ff41f-51a3-5691-b4de-c172271f22a5" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="545ff41f-51a3-5691-b4de-c172271f22a5" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wroc_g2_p2_1</dashif:Laurl>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>         </ContentProtection>         <SegmentTemplate duration="480480" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14 L-V',{0 'TV-14'}{2 'L'}{4 'V'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="d0-init.mp4" media="d0-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

Service 5005: ESG

Protocol: ROUTE
Category: ESG Service

Source: 172.16.200.1
Destination: 239.255.31.1:5100

Hidden: No
App: No

Service Details (from SLT)

Global Service ID:
Category: 4 (ESG Service)
SLS Destination: 239.255.31.1:5100
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5005"></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: 239.255.31.1:5100

TSI	Representation ID	Content Type	Content Ratings
50			N/A
60			N/A
80			N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1" dIpAddr="239.255.31.1" dPort="5100"><LS tsi="50"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="1334" Content-Location="sgdd_1334" Content-Length="48470" Transfer-Length="4787" Content-Type="application/vnd.oma.bcast.sgdd+xml" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="60"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="3055" Content-Location="sgdu_content_3055" Content-Length="353003" Transfer-Length="32645" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File><fdt:File TOI="4265" Content-Location="sgdu_service_schedule_4265" Content-Length="65703" Transfer-Length="5421" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="80"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="5494" Content-Location="s28719_ll_h15_ac.png" Content-Length="8623" Transfer-Length="8259" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5495" Content-Location="s28708_ll_h15_ac.png" Content-Length="16622" Transfer-Length="16457" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5496" Content-Location="s32356_h3_aa.png" Content-Length="11802" Transfer-Length="11117" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5497" Content-Location="s28711_h3_aa.png" Content-Length="8304" Transfer-Length="7564" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="3"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="2260"></item></metadataEnvelope>

Electronic Service Guide (ESG) - 4 Service(s), 103 Program(s) (from 111 fragments)

Service : WROC (8.1)

Field	Value
ID	urn:digicap:svc:5004:1748986708542
Status	https://www.doi
Description	WROC

Raw XML (0 fragments)

Service : WXXI (21.1)

Field	Value
ID	urn:digicap:svc:5003:1748986708542
Status	https://www.doi
Description	WXXI

Raw XML (0 fragments)

Service : WHAM (13.1)

Field	Value
ID	urn:digicap:svc:5002:1748986708542
Status	tag:sinclairpla
Description	WHAM

Raw XML (0 fragments)

Service : WUHF (31.1)

Field	Value
ID	urn:digicap:svc:5001:1748986708542
Status	tag:sinclairpla
Description	WUHF

Raw XML (0 fragments)

Service 5006: T2 (31.10)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.31.10:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 2 ch @ 192 kbps
Codec: ac-4.02.01.00

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:T2:WUHF
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.31.10:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5006"><DeliveryMethod><UnicastAppService><BasePattern>a0-22-</BasePattern><BasePattern>d0-Data3_3-</BasePattern><BasePattern>video-Video1_1-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="8"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="82"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-06-04T02:14:54Z)

Type: dynamic
Min Buffer Time: PT10S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 7000000 (7.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=419760776154720, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 192000 (192 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 240000
- S: t=419760776154720, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_3

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 240000
- S: t=419760776154720, d=480480, r=29

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-06-04T02:14:54Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://ipc.atsc3.com/T2/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="419760776154720"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="7000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="419760776154720"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="192000" codecs="ac-4.02.01.00" id="22"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="419760776154720"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_3"/></AdaptationSet>   </Period></MPD>

Service 5007: DDAAS

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.31.100:6000

Hidden: Service & Guide
App: No

Service Details (from SLT)

Global Service ID: tag:broadspanwireless.com,2023:2188:WUHF:2189
Category: 3 (App-Based Service)
SLS Destination: 239.255.31.100:6000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)
Hidden: Yes
Hide in Guide: Yes

No associated ROUTE/DASH or MMT signaling tables found for this service.

Service 5008: PBTV (31.11)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.31.11:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 2 ch @ 384 kbps
Codec: ac-4.02.01.00

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:PBTV:WUHF
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.31.11:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5008"><DeliveryMethod><UnicastAppService><BasePattern>a0-24-</BasePattern><BasePattern>d0-Data3_5-</BasePattern><BasePattern>video-Video1_1-</BasePattern><BasePattern>video-Video1_2-</BasePattern><BasePattern>video-Video1_3-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="6"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="118"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2025-06-04T02:14:53Z)

Type: dynamic
Min Buffer Time: PT10S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_3

Bandwidth: 1000000 (1000 kbps)
Codecs: hev1.2.4.L93.B0
Resolution: 960x540 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=419760776154720, d=480480, r=29

Representation ID: Video1_2

Bandwidth: 4000000 (4.0 Mbps)
Codecs: hev1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=419760776154720, d=480480, r=29

Representation ID: Video1_1

Bandwidth: 8000000 (8.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=419760776154720, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 24

Bandwidth: 384000 (384 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 240000
- S: t=419760776154720, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_5

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 240000
- S: t=419760776154720, d=480480, r=29

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-06-04T02:14:53Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://wuhf-sbgtv.atsc.stream/pickleball/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="540" minWidth="960" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="419760776154720"/>            </SegmentTimeline>         </SegmentTemplate>                                 <Representation bandwidth="1000000" codecs="hev1.2.4.L93.B0" frameRate="60000/1001" height="540" id="Video1_3" sar="1:1" scanType="progressive" width="960"/><Representation bandwidth="4000000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_2" sar="1:1" scanType="progressive" width="1280"/><Representation bandwidth="8000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="419760776154720"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.00" id="24"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="419760776154720"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_5"/></AdaptationSet>   </Period></MPD>

Service 5009: GMLOOP (31.20)

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.31.20:5000

Hidden: No
App: GameLoop

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:Gameloop:WUHF
Category: 3 (App-Based Service)
SLS Destination: 239.255.31.20:5000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5009"></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://nextgen.gameloop.tv/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tag:sinclairplatform.com,2020:Gameloop:WUHF" bbandEntryPageUrl="https://nextgen.gameloop.tv/run3tv-common/index.html"></HTMLEntryPackage>
</HELD>

Other Global LLS Tables

System Time Details - Actual Timestamp in L1Detail

Attribute	Value
currentUtcOffset	37
utcLocalOffset	-PT4H
dsStatus	false

Raw XML

<?xml version="1.0" encoding="utf-8"?>
<SystemTime xmlns="http://www.atsc.org/XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/ SYSTIME-1.0-20211208.xsd" currentUtcOffset="37" utcLocalOffset="-PT4H" dsStatus="false"/>

Input Info

Attribute	Value
Input Type	ALP-PCAP File
File Name	413-0-20250603-221450-p-ipv4.pcap
Total Packets Processed	20826
File Last Modified	2025-09-23 12:50:21 EDT
Analysis Run Time	2025-11-23 16:16:04 EST

ATSC 3.0 Data Usage Analysis

IP:Port (ID)	Usage ↓	Service	Type	Total Data	Bitrate
239.255.21.1:5001 (TSI 100)	23.37%	WXXI	Video	6.96 MB	5.57 Mbps
239.255.8.1:5001 (TSI 100)	23.01%	WROC	Video	6.85 MB	5.49 Mbps
239.255.13.1:5001 (TSI 100)	22.11%	WHAM	Video	6.58 MB	5.27 Mbps
239.255.31.1:5001 (TSI 100)	20.49%	WUHF	Video	6.10 MB	4.89 Mbps
239.255.8.1:5001 (TSI 0)	1.63%	WROC	Service Signaling	486.0 KB	389.3 Kbps
239.255.31.1:5001 (TSI 0)	1.47%	WUHF	Service Signaling	436.2 KB	349.4 Kbps
239.255.21.1:5001 (TSI 0)	1.37%	WXXI	Service Signaling	408.6 KB	327.3 Kbps
239.255.13.1:5001 (TSI 0)	1.33%	WHAM	Service Signaling	397.3 KB	318.2 Kbps
224.0.23.60:4937 (LLS)	0.60%	LLS Signaling	LLS Signaling	178.0 KB	142.6 Kbps
239.255.8.1:5001 (TSI 200)	0.46%	WROC	Audio	136.1 KB	109.0 Kbps
239.255.31.1:5001 (TSI 200)	0.45%	WUHF	Audio	134.8 KB	108.0 Kbps
239.255.13.1:5001 (TSI 200)	0.45%	WHAM	Audio	134.5 KB	107.8 Kbps
239.255.31.10:5000 (TSI 0)	0.41%	T2	Service Signaling	123.6 KB	99.0 Kbps
239.255.31.1:5100 (TSI 0)	0.30%	ESG	Service Signaling	89.1 KB	71.3 Kbps
239.255.8.1:5001 (TSI 201)	0.25%	WROC	Audio	75.4 KB	60.4 Kbps
239.255.13.1:5001 (TSI 201)	0.25%	WHAM	Audio	73.8 KB	59.1 Kbps
239.255.21.1:5001 (TSI 200)	0.25%	WXXI	Audio	73.4 KB	58.8 Kbps
239.255.21.1:5001 (TSI 202)	0.25%	WXXI	Audio	73.4 KB	58.8 Kbps
239.255.21.1:5001 (TSI 201)	0.25%	WXXI	Audio	73.3 KB	58.7 Kbps
239.255.31.1:5001 (TSI 201)	0.24%	WUHF	Audio	72.1 KB	57.8 Kbps
239.255.31.11:5000 (TSI 0)	0.22%	PBTV	Service Signaling	66.8 KB	53.5 Kbps
239.255.31.1:5100 (TSI 80)	0.20%	ESG	ROUTE Media	59.6 KB	47.8 Kbps
239.255.31.20:5000 (TSI 0)	0.11%	GMLOOP	Service Signaling	33.7 KB	27.0 Kbps
239.255.31.1:5001 (TSI 300)	0.11%	WUHF	Captions	31.4 KB	25.2 Kbps
239.255.21.1:5001 (TSI 300)	0.10%	WXXI	Captions	30.7 KB	24.6 Kbps
239.255.31.1:5100 (TSI 60)	0.08%	ESG	ROUTE Media	24.7 KB	19.8 Kbps
239.255.31.1:5100 (TSI 50)	0.08%	ESG	ROUTE Media	23.5 KB	18.8 Kbps
239.255.8.1:5001 (TSI 300)	0.07%	WROC	Captions	21.8 KB	17.5 Kbps
239.255.13.1:5001 (TSI 300)	0.07%	WHAM	Captions	21.8 KB	17.5 Kbps

Total: 29.78 MB | Signaling: 7.45% | Media: 92.55% | Other: 0.00%

RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Service Summary (SLT BSID: 2188)

Certificate Details

Service 5001: WUHF (31.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data4_4

Raw XML

Raw XML

Service 5002: WHAM (13.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data4_4

Raw XML

Raw XML

Service 5003: WXXI (21.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a022

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: A13_3

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: AD)

Representation ID: A24_4

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data5_5

Raw XML

Service 5004: WROC (8.1) Encrypted

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data4_4

Raw XML

Service 5005: ESG

Raw XML

ROUTE Stream: 239.255.31.1:5100

Raw XML

Raw XML

Service 5006: T2 (31.10) Internet Required

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_3

Raw XML

Service 5007: DDAAS Hidden

Service 5008: PBTV (31.11) Internet Required

Service 5004: WROC (8.1)

Service 5006: T2 (31.10)

Service 5007: DDAAS

Service 5008: PBTV (31.11)
