RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 3 PLPs (L1 BSID: Not Set)

PLP IDSFIModulationCode RateLayerTI ModeLLSLockRequired SNRBitrate
00qam169/15corehtiYesYesAWGN: 7.32-7.58 dB
Rayleigh: 9.94-10.28 dB		N/A
10qam6410/15corehtiYesYesAWGN: 12.88-13.13 dB
Rayleigh: 15.81-16.20 dB		N/A
21qam25611/15corehtiYesNoAWGN: 18.76-19.08 dB
Rayleigh: 21.94-22.40 dB		N/A
L1 Detail Information Not Available
Link Mapping Table Data Not Available

Service Summary (SLT BSID: 2200)

Service NameIDChannelProtocol / CategorySLS Destination
WSTM50013.1ROUTE / Linear A/V Service239.255.3.1:5000
WTVH50025.1ROUTE / Linear A/V Service239.255.5.1:5000
WSYR50039.1ROUTE / Linear A/V Service239.255.9.1:5000
ESG5004ROUTE / ESG Service239.255.3.1:5100
T2 Internet Required50053.10ROUTE / Linear A/V Service239.255.3.10:5000
DDAAS Hidden5006ROUTE / App-Based Service239.255.3.100:6000
PBTV Internet Required50073.11ROUTE / Linear A/V Service239.255.3.11:5000
GMLOOP50083.20ROUTE / App-Based Service239.255.3.20:5000
ROXi50093.21ROUTE / App-Based Service239.255.3.21:5000
Capability Descriptor Table (CDT) - 3 Certificate(s)
AttributeValue
OCSP RefreshP7DT0H
Certificate Count3

Certificate Details

Certificate 1 - WSTM-TV Signalling Signing CDT 0001 (Valid Until: Sep 2 2026)
FieldValue
Subject/C=US/ST=New York/L=Syracuse/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=WSTM-TV Signalling Signing CDT 0001
Issuer/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number0F97737F11A350A103F850C909EA2A9C1068D343
Valid FromSep 2 16:49:35 2025 GMT
Valid UntilSep 2 16:49:35 2026 GMT
Signature Algorithmsha256WithRSAEncryption
Public KeyRSA (3072 bits)
SHA-1 Fingerprint38:A3:E7:0B:F1:08:2C:73:58:02:F2:22:AD:C4:9E:F7:4B:48:CE:4E
SHA-256 FingerprintD9:39:6B:CE:2E:26:C1:B5:D2:F1:5C:60:22:45:64:2A:19:71:2D:9A:0A:7D:88:21:D5:4C:A9:C2:53:83:90:
Certificate AuthorityNo
Self-SignedNo
Certificate 2 - WSTM-TV Signalling Signing SMT 0001 (Valid Until: Sep 2 2026)
FieldValue
Subject/C=US/ST=New York/L=Syracuse/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=WSTM-TV Signalling Signing SMT 0001
Issuer/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number1026AD4A5D02DD3BFFBABF34CD59FF251D931548
Valid FromSep 2 16:49:37 2025 GMT
Valid UntilSep 2 16:49:37 2026 GMT
Signature Algorithmsha256WithRSAEncryption
Public KeyRSA (3072 bits)
SHA-1 FingerprintDF:CF:87:12:59:8D:48:F6:48:D1:F5:06:15:9D:5D:EC:FE:3A:27:F4
SHA-256 Fingerprint12:50:60:CA:06:38:C0:81:D4:A3:8F:87:A0:32:28:95:68:4A:9B:F7:0F:AF:E2:7D:0E:5C:10:7E:D7:25:F5:
Certificate AuthorityNo
Self-SignedNo
Certificate 3 - ATSC 3.0 Signing CA-2 (Valid Until: Sep 8 2030)
FieldValue
Subject/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Issuer/C=US/O=Pearl TV/OU=Root CA-1/CN=ATSC3 Root-CA
Serial Number1D81C0A269A03D9AAF128428593DB6B8
Valid FromSep 8 00:00:00 2021 GMT
Valid UntilSep 8 23:59:59 2030 GMT
Signature Algorithmsha512WithRSAEncryption
Public KeyRSA (3072 bits)
SHA-1 Fingerprint06:63:9A:0C:E9:C0:E7:2C:44:05:1C:8A:91:B6:68:FB:25:C4:38:75
SHA-256 Fingerprint23:42:5B:1C:CA:CB:F3:31:7C:8B:03:59:DA:E0:A3:98:C4:84:05:DB:1B:6B:92:15:58:69:F7:89:30:9A:65:
Certificate AuthorityYes
Self-SignedNo
Raw XML
<?xml version="1.0" encoding="UTF-8"?>
<CertificationData xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/CDT-1.0-20180706.xsd">
<ToBeSignedData OCSPRefresh="P7DT0H"><Certificates>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</Certificates><Certificates>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</Certificates><Certificates>MIIF7zCCA9egAwIBAgIQHYHAommgPZqvEoQoWT22uDANBgkqhkiG9w0BAQ0FADBMMQswCQYDVQQGEwJVUzERMA8GA1UEChMIUGVhcmwgVFYxEjAQBgNVBAsTCVJvb3QgQ0EtMTEWMBQGA1UEAxMNQVRTQzMgUm9vdC1DQTAeFw0yMTA5MDgwMDAwMDBaFw0zMDA5MDgyMzU5NTlaMHAxCzAJBgNVBAYTAlVTMSgwJgYDVQQKEx9BVFNDIDMuMCBTZWN1cml0eSBBdXRob3JpdHkgTExDMRcwFQYDVQQLEw5TaWduaW5nIENBLURDMTEeMBwGA1UEAxMVQVRTQyAzLjAgU2lnbmluZyBDQS0yMIIBojANBgkqhkiG9w0BAQEFAAOCAY8AMIIBigKCAYEAu7US2OxGzCtEMQZ7FR0fNv6d6hd+x3hV7Uu0H8wso+rXbr4+WhHmenMLLSS5VT0qchH9Bs8ntS15Ijxvgj8rj1ZzeHY7p9enLp9LnbmC4/VtiRM9W5w4oqCt7rHYG2soYweyoedjyhvXQSZzZPi3gSX5wgjwAINLbPc+1KwL61nPFqwuy8QeEitV9dhR+V5HS3kt7jkIru+aHFvmDhEKRxrZTZ1c1ayEC8AKnwABhTodRpvq14yNuAppStJ71DIIsqZk7H4YcUDSLhbgbGxN6UMWPb+U7zzTIGQBCp297vFCOUHjvJvSM5QU3tfZM1QDNkftyIqDohKKBJKQGSODGPOHCkXPPisv9itKaM4gPMh/GcZZRwiwt0i+nQwndmleViUGD9LMiDeNnm5z6qIO+YwaV4G+/HKUJ0SpVmA3vH/UPu0Zc0nvk8wvcVZtjdsu6m/ncSMQBjslZ6spgt01OQNGas4ODHyeqt46vdL2MxB8bjv0zOa3DwOx2FvbJQnhAgMBAAGjggEnMIIBIzASBgNVHRMBAf8ECDAGAQH/AgEAMDUGA1UdIAEB/wQrMCkwCwYJKwYBBAGDlGMCMAwGCisGAQQBg5RjAgEwDAYKKwYBBAGDlGMCAjBMBgNVHR8ERTBDMEGgP6A9hjtodHRwOi8vcGtpLWNybC5zeW1hdXRoLmNvbS9vZmZsaW5lY2EvUGVhcmxUVkFUU0MzUm9vdENBLmNybDAOBgNVHQ8BAf8EBAMCAcYwHQYDVR0OBBYEFKDe/SSQWUgCIZcnf+GWO+KBaMa2MB8GA1UdIwQYMBaAFAVpwvy6iPDgHPhycVgAuJ4KgHGmMDgGCCsGAQUFBwEBBCwwKjAoBggrBgEFBQcwAYYcaHR0cDovL3BraS1vY3NwLmRpZ2ljZXJ0LmNvbTANBgkqhkiG9w0BAQ0FAAOCAgEAEtmDPuS023t4GSaMMtMkPyh8IG5B2HOPtnwjXzf418ar2XCMcaRI7jGk12+VPOg5S6baCKin+QSgbGonU6mH9eLEhl2fCpRMnM6XhzdplCCj7xMZAHf5AhuCz+M5tqaQelVv4WJrWHvMK1Jdw4q6GDtEKxF0cIYXyrinMqR65P2qvjEaJZUNdRSo/yuxu0UrkbNtuJ9TzQABnY5y7pTgcJOBbGes6bC/VrWurUXDFpeNfybm5PRZE9rlsIIeT4J+3i7BGpUdnrPWQrk6NNa6M36XKxe1dh1HptyNXwOPamS5qpw7ewQARlP495uORvAM3p50TN2vtXKLgDQENi+Kmo/E+ORKaLJtgbet0jllhR9L7Gau8DdykvnTHkm2/yxB0tDZTbrTRJciPjFHsRXmYQAyQYaod729shWngSgNE08n4RkiVSsSFbhrCXh+ZrCF9wBpfCVoDaLemjriVy4SK7Hxmr39XxF66B9fBnGLXMvgyYRymNWPyys5j/wl+iZt4KTm5W5iOhdIXaJxOO6b+EFeNZsDi8p52nvi5L5rtxw/1GAIiz39RTGd/w2thKQ+USVa7zY5sllzUBMjepeog/OOPwtbGccP38U6oW8vL00bQGbW5HuWP58qGcY9Wk6I1mhinOmrpm1BsHqdYVFDCJZqQK4XMNukaxP6ey6xmJg=</Certificates><CurrentCert>KMGJEwjd0KOhKzl1hYsqBSeeFd0=</CurrentCert></ToBeSignedData>
<CMSSignedData>MIICXgYJKoZIhvcNAQcCoIICTzCCAksCAQMxDTALBglghkgBZQMEAgEwCwYJKoZIhvcNAQcBMYICKDCCAiQCAQOAFBxqzUMgvogIGZ4oHgAC6KSMmfYvMAsGCWCGSAFlAwQCAaBpMBgGCSqGSIb3DQEJAzELBgkqhkiG9w0BBwEwHAYJKoZIhvcNAQkFMQ8XDTI1MTAyMjE5MzkwNlowLwYJKoZIhvcNAQkEMSIEIKGEbteFtsfnR3z0FhlDrn0ufWvmOsMkJD6P/NlE4ieaMA0GCSqGSIb3DQEBAQUABIIBgEgqCbGcWvAKdXvH6pjV2JbprP85H51x+6hKtDHsJ5GP+66JaejIr46L/ZVDEsTK9V98D1FhTmaa5t2KFyxdGIBja5CiTZH0Fz2oxfFNsF19JyifuUppUiOeitg7w10uJq9fLZUT7eaGatgjLuCBiXmbqttWeVE/GkrbB0bQSUViqmr/Lxt6cbC8BYZMGi1sCe77BowTXFE+gCn+vQhz7J2L+HpwDgLNElcEsquu73RYBAnrV7o5ZdXxxFaAtNFPSOK3kqCwQH8WNmqzfTg+F6SjRVfjzlzKkVIu9nsz1zm5oW3WCzDcqOtSC6PTl8ju2tY7w/CBWEv2Dc84mVMoPmXmZ/Z9iP0Syx+KHFfKhRg928L/MOWMtXmRVCv4nJhPtRmkzs6PSkBXWr5ztLvGkApgXDGBCawrszxYMMWpMUBQ9Ogkt715tY5BepocNw+8C9UZrqqkMsCHv6xIx5snqzUhfE+AXWJXMuVHImUbFSKP2VjDICdfz9OTCQUrsOfXjw==</CMSSignedData>
<OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse><OCSPResponse>MIIIsgoBAKCCCKswgginBgkrBgEFBQcwAQEEggiYMIIIlDCBnqIWBBQlGyMonliwHKjHqZYM3G5k9QwEFxgPMjAyNTEwMjExNzQwNDFaMHMwcTBJMAkGBSsOAwIaBQAEFM+Hj12/7wjLRzG4kQv8vkI0u9TWBBQFacL8uojw4Bz4cnFYALieCoBxpgIQHYHAommgPZqvEoQoWT22uIAAGA8yMDI1MTAyMTE3NDA0MVqgERgPMjAyNTEwMjgxNzQwNDFaMA0GCSqGSIb3DQEBCwUAA4ICAQCbMLyYGdYQqYcffJeLMI0yCiGzRLoByb8I2YjVf58gvnxatOnl5/Ci6coYiCGMmf8L1CBPIrMr9PG4NtHVnN1foEx0kdx5VOJzRFUgB2p4M2zeL9cAEfGR0JPYIxNKYh29eg5M0d4w/yqf4cXylh67jJvgzOb5uUjGqcJMLJnCWcmATJOgkb2hCWw+yDg4PXqy6tgCuYnzgF76ziecK+AOaI0LrFoLQf8DQ5S2HdE1OUXu04Fa24ZP4MadYcaimuQjQAymQGj8fxAXvN3RN/ATs3Rq80MwzTpKY1Uhr9WW5Q/5fNzAAnVkEEzgkX6UnRvGelPaignADO7XpA5LQfVKFop4RN3z3+8gO5nQzjDBwzHCjRBHA11t6dBeEbe1OupwKimVG0wy+z6TgUcKK2Rhwo5k+K4xwYtEJ2bmINj1/nrF38PdcRbjmdb6wMfCnj/ZDsbQRbB3Fj4eTHSD/o+sQnMUYqjqdXTfs/Zw7aGALq49utN7kyFGbgfPL+CI+k3ktSxtWbQwX13sa3yBdta/3NNkMm/yGXq0UeOvXxo99lc6QHMJfPSeYWd4T/cpWUMOTCICNNCdS9b+rQLtwgeQmxCYaBsARM0MycX+2ZxEAC/XgWefrzDeY7wrGAYnGBHYkd0Dvcf+F5kp1KmvyhkLW/WFdK1WAJbEZwN7XrT+JqCCBdswggXXMIIF0zCCA7ugAwIBAgIQHMX0ZUcKBuKgYs03+pW++TANBgkqhkiG9w0BAQsFADBMMQswCQYDVQQGEwJVUzERMA8GA1UEChMIUGVhcmwgVFYxEjAQBgNVBAsTCVJvb3QgQ0EtMTEWMBQGA1UEAxMNQVRTQzMgUm9vdC1DQTAeFw0yMTA0MTQwMDAwMDBaFw0yNjA0MTMyMzU5NTlaMF0xCzAJBgNVBAYTAlVTMREwDwYDVQQKEwhQZWFybCBUVjESMBAGA1UECxMJUm9vdCBDQS0xMScwJQYDVQQDEx5BVFNDMyBSb290LUNBIE9DU1AgUmVzcG9uZGVyIDMwggIiMA0GCSqGSIb3DQEBAQUAA4ICDwAwggIKAoICAQDEmI+HliOvphPufaSpUoAxniQrf3iCrjaycSZ+tQgJlk0ZSux0r/K3GysVt+ZA11RqocX/23sgXfvxjNokhf4ssoADnJ+vv2ghbrmKoGK4NDUwAHw5n9KHZJM4Q6PGhwFm0qaC87zya2Fkks0PwGb/XMlzvd3dGjVpLVDrKQEKdLO9xgv8UE8EH/SfgMoi472BjPmN+lysFD0LkRiepGlP+nJBwklnq+eV7sMaBAMpx1CCcIT3cJx6tEEs4l+MWTQgArzLdyD7z0uFBxvaE6wK/FWx72Ep9fgLnonK/QRfev9z3Fwg8Z+XCbvVpP1DpeaLbmlzY46RHTIX7c31TCIjiCv1IpFg9O0b0ANyQ6xcWgH8fefY9Jylud/U73NivGy/XZXBRatlUf5CEXM54oZ2QNayKD6O4XlGGdmzxy4vz5cpNeaiSu65rUIBsxSBPTuWh9ZkDz5h0sOH4LNvfYrwV9+din0KqPoLyveuE9L8MTtqSN32SqkxAfzoNduL0hd/7TbgRGnNtliJMnLIWQzMcvWGHfKjGrmicNlJfvNE5L/Mkd+1ApOA4AsyQaToLBjB2mrJAvwDmd2s7ILO9mcF582WTgNvrjkEF1RUWtLXBGtaKgJlrc5CECMTIT9r+8hqF33IxSkVbyonMctuypi2z9whsB7b9vDlKBvFagC6hQIDAQABo4GfMIGcMAwGA1UdEwEB/wQCMAAwEwYDVR0lBAwwCgYIKwYBBQUHAwkwDgYDVR0PAQH/BAQDAgeAMA8GCSsGAQUFBzABBQQCBQAwFgYDVR0gBA8wDTALBgkrBgEEAYOUYwEwHQYDVR0OBBYEFCUbIyieWLAcqMeplgzcbmT1DAQXMB8GA1UdIwQYMBaAFAVpwvy6iPDgHPhycVgAuJ4KgHGmMA0GCSqGSIb3DQEBCwUAA4ICAQCRIOGMBfBBOuqVI+yc4iM5DcggxHyyQ7rOWUXefj+reCeofLldvaAUDdBhLoJFzBUPyY6hW0Sf9y3H9zQ/xkNZzuthE66hQ+ss9HsJWargjIqlLSc8AtSyeljcXvF7Ht1dEsQIWOh+rFmGWtvb3pjyVSf5Xhuox/4+MplJ1NcpI6SbbvWk0bSobRgaZfBXpwWCJOFOpBhxsKuQZp3GqeiBr7KaYVwKtKsrctMupYjm6Y2LPl8IPB3zMKFceRQKOAfQfWAcgTVkmDQeTYv910ris8YaX7kPotViuz/erJSTAhrcCx1OLdx3AHFch+QwRXAH+xwYE0Z0qQH95qduqgdUvOL74m90Nu3X88vy4mpyBnAhaZYimJlcPH7Ce1JBtIEX1T9Fhm6HPTj5BIkTRt+s/FQwrPlMjepm5aZbX1A4tDbcPDKyXdvmIIoGKxqbXkE47W4zlgr+YIVA5qIHwPtrE1OUy1n+NNPpXbLVS2AtW1fwLRbgkQtjT/Pu9ZQaB1RgrVpg9w9W1fY8C3vJvTPTVlUVy+MoAkXqXYWXEYxLMWzB0/AzO758LExkRNEl9ko53e5r91vnXPpPmrYSrNSXAXbTL6qVvuQmNvlPW+VmjrozI6TF5IkeLarjo9A9zfxVqGbiAXX/rVeiJr3gEyteGTYPCYEbUxhHeVPRR3xpww==</OCSPResponse>
</CertificationData>
Service List Table (SLT) Instance 1 - Raw XML
<?xml version="1.0" encoding="UTF-8"?>
<SLT bsid="2200" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SLT/1.0/ SLT-1.0-20211209.xsd">
    <Service globalServiceID="tag:sinclairplatform.com,2020:WSTM:2201" majorChannelNo="3" minorChannelNo="1" serviceCategory="1" serviceId="5001" shortServiceName="WSTM" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.3.1" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:WTVH:2203" majorChannelNo="5" minorChannelNo="1" serviceCategory="1" serviceId="5002" shortServiceName="WTVH" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.5.1" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:WSYR:2205" majorChannelNo="9" minorChannelNo="1" serviceCategory="1" serviceId="5003" shortServiceName="WSYR" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.9.1" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service serviceCategory="4" serviceId="5004" shortServiceName="ESG" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.3.1" slsDestinationUdpPort="5100" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:T2:WSTM" majorChannelNo="3" minorChannelNo="10" serviceCategory="1" serviceId="5005" shortServiceName="T2" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.3.10" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:broadspanwireless.com,2023:2200:WSTM-TV:2201" hidden="true" hideInGuide="true" serviceCategory="3" serviceId="5006" shortServiceName="DDAAS" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.3.100" slsDestinationUdpPort="6000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:PBTV:WSTM" majorChannelNo="3" minorChannelNo="11" serviceCategory="1" serviceId="5007" shortServiceName="PBTV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.3.11" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:sinclairplatform.com,2020:Gameloop:WSTM" majorChannelNo="3" minorChannelNo="20" serviceCategory="3" serviceId="5008" shortServiceName="GMLOOP" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.3.20" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:Roxi:wstm" majorChannelNo="3" minorChannelNo="21" serviceCategory="3" serviceId="5009" shortServiceName="ROXi" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.3.21" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
</SLT>

Service 5001: WSTM (3.1)

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.3.1:5000
Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0
Audio: 16 ch @ 384 kbps +1 additional audio stream
Codec: ac-4.02.01.02
Hidden: No
App: Run3TV
Service Details (from SLT)
  • Global Service ID: tag:sinclairplatform.com,2020:WSTM:2201
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.3.1:5000
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5001"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSIRepresentation IDContent TypeContent Ratings
100Video1_1video1,'TV-14 D-L-V',{0 'TV-14'}{1 'D'}{2 'L'}{4 'V'}
200a02_2audioN/A
201a13_3audioN/A
300d4_4subtitlesN/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="3650000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-14 D-L-V',{0 'TV-14'}{1 'D'}{2 'L'}{4 'V'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="384000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="30"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="107"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="112"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="3"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-10-23T02:05:21Z)
Type: dynamic
Min Buffer Time: PT2S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1
  • Bandwidth: 3650000 (3.6 Mbps)
  • Codecs: hev1.2.4.L123.B0
  • Resolution: 1920x1080 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Initialization: video-init.mp4
    • Media URL: video-$Number$.mp4v
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2
  • Bandwidth: 384000 (384 kbps)
  • Codecs: ac-4.02.01.02
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 16
  • Segment Template:
    • Initialization: a0-$RepresentationID$-init.mp4
    • Media URL: a0-$RepresentationID$-$Number$.m4s
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3
  • Bandwidth: 48000 (48 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Initialization: a1-$RepresentationID$-init.mp4
    • Media URL: a1-$RepresentationID$-$Number$.m4s
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: und)

Representation ID: d4_4
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Initialization: $RepresentationID$-init.mp4
    • Media URL: $RepresentationID$-$Number$.m4s
    • Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT20S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-10-23T02:05:21Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14 D-L-V',{0 'TV-14'}{1 'D'}{2 'L'}{4 'V'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>               <Representation bandwidth="3650000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920">            <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14 D-L-V',{0 'TV-14'}{1 'D'}{2 'L'}{4 'V'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.02" id="a02_2">            <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>            <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14 D-L-V',{0 'TV-14'}{1 'D'}{2 'L'}{4 'V'}"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3">            <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>            <SegmentTemplate duration="480480" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet><AdaptationSet contentType="text" id="3" lang="und" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14 D-L-V',{0 'TV-14'}{1 'D'}{2 'L'}{4 'V'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4">            <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet>   </Period></MPD>
HTML Entry-point Description (HELD) Instance 1

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html" appContextId="tag:sinclairplatform.com,2020:WSTM:2201" />
</HELD>

Service 5002: WTVH (5.1)

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.5.1:5000
Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0
Audio: 16 ch @ 384 kbps +1 additional audio stream
Codec: ac-4.02.01.02
Hidden: No
App: Run3TV
Service Details (from SLT)
  • Global Service ID: tag:sinclairplatform.com,2020:WTVH:2203
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.5.1:5000
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5002"><DeliveryMethod><BroadcastAppService><BasePattern>audio-0-</BasePattern><BasePattern>audio-1-</BasePattern><BasePattern>data-0-50000-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSIRepresentation IDContent TypeContent Ratings
100Video1_1video1,'TV-PG L',{0 'TV-PG'}{2 'L'}
200Audio2_2audioN/A
201Audio3_3audioN/A
300Data4_4subtitlesN/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1"><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="3650000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="384000" afdt:fileTemplate="audio-0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="audio-0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio2_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="audio-1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="audio-1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="data-0-50000-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="data-0-50000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="24"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="141"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="241"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="3"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-10-23T02:05:19Z)
Type: dynamic
Min Buffer Time: PT2S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1
  • Bandwidth: 3650000 (3.6 Mbps)
  • Codecs: hev1.2.4.L123.B0
  • Resolution: 1920x1080 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Initialization: video-init.mp4
    • Media URL: video-$Number$.mp4v
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: Audio2_2
  • Bandwidth: 384000 (384 kbps)
  • Codecs: ac-4.02.01.02
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 16
  • Segment Template:
    • Initialization: audio-0-init.mp4
    • Media URL: audio-0-$Number$.mp4a
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3
  • Bandwidth: 48000 (48 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Initialization: audio-1-init.mp4
    • Media URL: audio-1-$Number$.mp4a
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: und)

Representation ID: Data4_4
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Initialization: data-0-$Bandwidth$-init.mp4
    • Media URL: data-0-$Bandwidth$-$Number$.mp4s
    • Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT1M0S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-10-23T02:05:19Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="3650000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>         <SegmentTemplate duration="480480" initialization="audio-0-init.mp4" media="audio-0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.02" id="Audio2_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>         <SegmentTemplate duration="480480" initialization="audio-1-init.mp4" media="audio-1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="und" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG L',{0 'TV-PG'}{2 'L'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="data-0-$Bandwidth$-init.mp4" media="data-0-$Bandwidth$-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>
HTML Entry-point Description (HELD) Instance 1

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html" appContextId="tag:sinclairplatform.com,2020:WTVH:2203" />
</HELD>

Service 5003: WSYR (9.1)

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.9.1:5000
Hidden: No
App: No
Service Details (from SLT)
  • Global Service ID: tag:sinclairplatform.com,2020:WSYR:2205
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.9.1:5000
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)

No associated ROUTE/DASH or MMT signaling tables found for this service.

Service 5004: ESG

Protocol: ROUTE
Category: ESG Service
Source: 172.16.200.1
Destination: 239.255.3.1:5100
Hidden: No
App: No
Service Details (from SLT)
  • Global Service ID:
  • Category: 4 (ESG Service)
  • SLS Destination: 239.255.3.1:5100
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5004"></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: 239.255.3.1:5100

TSIRepresentation IDContent TypeContent Ratings
50N/A
60N/A
80N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1" dIpAddr="239.255.3.1" dPort="5100"><LS tsi="50"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="1138" Content-Location="sgdd_1138" Content-Length="36836" Transfer-Length="3620" Content-Type="application/vnd.oma.bcast.sgdd+xml" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="60"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="3859" Content-Location="sgdu_content_3859" Content-Length="242977" Transfer-Length="18892" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File><fdt:File TOI="4069" Content-Location="sgdu_service_schedule_4069" Content-Length="49758" Transfer-Length="4031" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="80"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="5467" Content-Location="s28717_ll_h15_ad.png" Content-Length="9006" Transfer-Length="8526" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5468" Content-Location="s28711_ll_h15_ab.png" Content-Length="9791" Transfer-Length="9276" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5469" Content-Location="s28708_h3_aa.png" Content-Length="15267" Transfer-Length="15140" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="2"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="2062"></item></metadataEnvelope>
Electronic Service Guide (ESG) - 3 Service(s), 272 Program(s) (from 278 fragments)
Service : WSYR (9.1)
FieldValue
IDurn:digicap:svc:5003:1761173360714
Statustag:sinclairpla
DescriptionWSYR
Raw XML (0 fragments)


Service : WTVH (5.1)



FieldValue
IDurn:digicap:svc:5002:1761173360714
Statustag:sinclairpla
DescriptionWTVH
Raw XML (0 fragments)


Service : WSTM (3.1)



FieldValue
IDurn:digicap:svc:5001:1761173360714
Statustag:sinclairpla
DescriptionWSTM
Raw XML (0 fragments)






Service 5005: T2 (3.10) Internet Required








Protocol: ROUTE

Category: Linear A/V Service


Source: 172.16.200.1

Destination: 239.255.3.10:5000


Video: 1920x1080p (59.94 fps)

Codec: hev1.2.4.L123.B0


Audio: 2 ch @ 192 kbps

Codec: ac-4.02.01.00


Hidden: No

App: No




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:T2:WSTM
    •

  • Category: 1 (Linear A/V Service)
    •

  • SLS Destination: 239.255.3.10:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: 0.0 (ROUTE)
    •

  • Broadband Required: Yes
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5005"><DeliveryMethod><UnicastAppService><BasePattern>a0-22-</BasePattern><BasePattern>d0-Data3_3-</BasePattern><BasePattern>video-Video1_1-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="18"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="77"></item></metadataEnvelope>


Media Presentation Description (MPD) Instance 1 (Published: 2025-10-23T02:05:28Z)

Type: dynamic

Min Buffer Time: PT10S

Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015



Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)


Representation ID: Video1_1


  • Bandwidth: 7000000 (7.0 Mbps)
    •

  • Codecs: hev1.2.4.L123.B0
    •

  • Resolution: 1920x1080 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422684415273120, d=480480, r=29


Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)


Representation ID: 22


  • Bandwidth: 192000 (192 kbps)
    •

  • Codecs: ac-4.02.01.00
    •

  • Audio Sample Rate: 48000 Hz
    •

  • Audio Channels: 2
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422684415277124, d=480480, r=29


Adaptation Set (Content: text, Mime: application/mp4)


Representation ID: Data3_3


  • Bandwidth: 50000 (50 kbps)
    •

  • Codecs: stpp.ttml.im1t
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422684415273120, d=480480, r=29


Raw XML
<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-10-23T02:05:28Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://wstm-sbgtv.atsc.stream/t2/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422684415273120"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="7000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422684415277124"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="192000" codecs="ac-4.02.01.00" id="22"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422684415273120"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_3"/></AdaptationSet>   </Period></MPD>




Service 5006: DDAAS Hidden








Protocol: ROUTE

Category: App-Based Service


Source: 172.16.200.1

Destination: 239.255.3.100:6000


Hidden: Service & Guide

App: No




Service Details (from SLT)





  • Global Service ID: tag:broadspanwireless.com,2023:2200:WSTM-TV:2201
    •

  • Category: 3 (App-Based Service)
    •

  • SLS Destination: 239.255.3.100:6000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: . (ROUTE)
    •

  • Hidden: Yes
    •

  • Hide in Guide: Yes
    •





Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"></metadataEnvelope>




Service 5007: PBTV (3.11) Internet Required








Protocol: ROUTE

Category: Linear A/V Service


Source: 172.16.200.1

Destination: 239.255.3.11:5000


Video: 1920x1080p (59.94 fps)

Codec: hev1.2.4.L123.B0


Audio: 2 ch @ 384 kbps

Codec: ac-4.02.01.00


Hidden: No

App: No




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:PBTV:WSTM
    •

  • Category: 1 (Linear A/V Service)
    •

  • SLS Destination: 239.255.3.11:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: 0.0 (ROUTE)
    •

  • Broadband Required: Yes
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5007"><DeliveryMethod><UnicastAppService><BasePattern>a0-24-</BasePattern><BasePattern>d0-Data3_5-</BasePattern><BasePattern>video-Video1_1-</BasePattern><BasePattern>video-Video1_2-</BasePattern><BasePattern>video-Video1_3-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="8"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="211"></item></metadataEnvelope>


Media Presentation Description (MPD) Instance 1 (Published: 2025-10-23T02:05:28Z)

Type: dynamic

Min Buffer Time: PT10S

Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015



Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)


Representation ID: Video1_3


  • Bandwidth: 1000000 (1000 kbps)
    •

  • Codecs: hev1.2.4.L93.B0
    •

  • Resolution: 960x540 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422684415273120, d=480480, r=29


Representation ID: Video1_2


  • Bandwidth: 4000000 (4.0 Mbps)
    •

  • Codecs: hev1.2.4.L120.B0
    •

  • Resolution: 1280x720 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422684415273120, d=480480, r=29


Representation ID: Video1_1


  • Bandwidth: 8000000 (8.0 Mbps)
    •

  • Codecs: hev1.2.4.L123.B0
    •

  • Resolution: 1920x1080 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422684415273120, d=480480, r=29


Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)


Representation ID: 24


  • Bandwidth: 384000 (384 kbps)
    •

  • Codecs: ac-4.02.01.00
    •

  • Audio Sample Rate: 48000 Hz
    •

  • Audio Channels: 2
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422684415277124, d=480480, r=29


Adaptation Set (Content: text, Mime: application/mp4)


Representation ID: Data3_5


  • Bandwidth: 50000 (50 kbps)
    •

  • Codecs: stpp.ttml.im1t
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422684415273120, d=480480, r=29


Raw XML
<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-10-23T02:05:28Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://wstm-sbgtv.atsc.stream/pickleball/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="540" minWidth="960" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422684415273120"/>            </SegmentTimeline>         </SegmentTemplate>                                 <Representation bandwidth="1000000" codecs="hev1.2.4.L93.B0" frameRate="60000/1001" height="540" id="Video1_3" sar="1:1" scanType="progressive" width="960"/><Representation bandwidth="4000000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_2" sar="1:1" scanType="progressive" width="1280"/><Representation bandwidth="8000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422684415277124"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.00" id="24"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422684415273120"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_5"/></AdaptationSet>   </Period></MPD>




Service 5008: GMLOOP (3.20)








Protocol: ROUTE

Category: App-Based Service


Source: 172.16.200.1

Destination: 239.255.3.20:5000


Hidden: No

App: GameLoop




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:Gameloop:WSTM
    •

  • Category: 3 (App-Based Service)
    •

  • SLS Destination: 239.255.3.20:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: . (ROUTE)
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5008"></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>


HTML Entry-point Description (HELD) Instance 1

Raw XML
<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tag:sinclairplatform.com,2020:Gameloop:WSTM" bbandEntryPageUrl="https://nextgen.gameloop.tv/run3tv-common/index.html"></HTMLEntryPackage>
</HELD>




Service 5009: ROXi (3.21)








Protocol: ROUTE

Category: App-Based Service


Source: 172.16.200.1

Destination: 239.255.3.21:5000


Hidden: No

App: ROXi




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:Roxi:wstm
    •

  • Category: 3 (App-Based Service)
    •

  • SLS Destination: 239.255.3.21:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: . (ROUTE)
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5009"></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="3"></item></metadataEnvelope>


HTML Entry-point Description (HELD) Instance 1

Raw XML
<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://cdn.prod.tvapp.roxi.tv/releases/prod-atsc/index.html#/atsc,faststream,showId=46eb1cf29052,prod" appContextId="tag:sinclairplatform.com,2020:Roxi:wstm" />
</HELD>




Other Global LLS Tables


System Time Details - Actual Timestamp in L1Detail




AttributeValue



currentUtcOffset37


utcLocalOffset-PT4H


dsStatustrue


dsDayOfMonth2


dsHour2




Raw XML
<?xml version="1.0" encoding="utf-8"?>
<SystemTime xmlns="http://www.atsc.org/XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/ SYSTIME-1.0-20211208.xsd" currentUtcOffset="37" utcLocalOffset="-PT4H" dsStatus="true" dsDayOfMonth="2" dsHour="2"/>



Input Info




AttributeValue



Input TypeDebug File


File Name21252-0-20251023-210027-p0p1-dbg.dbg


Total Packets Processed12409


File Last Modified2025-10-23 21:00:16 EDT


Analysis Run Time2025-11-22 05:59:59 EST




ATSC 3.0 Data Usage Analysis





IP:Port (ID)Usage ↓ServiceTypeTotal DataBitrate



  239.255.3.1:5000 (TSI 100)

 39.32%
  WSTM
  Video
  6.93 MB
  N/A




  239.255.5.1:5000 (TSI 100)

 39.25%
  WTVH
  Video
  6.91 MB
  N/A




  239.255.5.1:5000 (TSI 200)

 4.17%
  WTVH
  Audio
  735.1 KB
  N/A




  239.255.3.1:5000 (TSI 200)

 4.16%
  WSTM
  Audio
  732.6 KB
  N/A




  224.0.23.60:4937 (LLS)

 3.03%
  LLS Signaling
  LLS Signaling
  534.6 KB
  N/A




  239.255.3.1:5000 (TSI 0)

 2.39%
  WSTM
  Service Signaling
  420.4 KB
  N/A




  239.255.5.1:5000 (TSI 0)

 2.38%
  WTVH
  Service Signaling
  419.7 KB
  N/A




  239.255.3.1:5100 (TSI 0)

 0.89%
  ESG
  Service Signaling
  157.6 KB
  N/A




  239.255.3.1:5000 (TSI 201)

 0.59%
  WSTM
  Audio
  103.2 KB
  N/A




  239.255.5.1:5000 (TSI 201)

 0.58%
  WTVH
  Audio
  102.3 KB
  N/A




  239.255.3.11:5000 (TSI 0)

 0.55%
  PBTV
  Service Signaling
  97.5 KB
  N/A




  239.255.3.1:5100 (TSI 80)

 0.52%
  ESG
  ROUTE Media
  91.0 KB
  N/A




  239.255.3.10:5000 (TSI 0)

 0.51%
  T2
  Service Signaling
  90.6 KB
  N/A




  239.255.3.21:5000 (TSI 0)

 0.28%
  ROXi
  Service Signaling
  50.2 KB
  N/A




  239.255.3.20:5000 (TSI 0)

 0.28%
  GMLOOP
  Service Signaling
  49.2 KB
  N/A




  239.255.3.1:5100 (TSI 50)

 0.21%
  ESG
  ROUTE Media
  36.9 KB
  N/A




  239.255.3.1:5100 (TSI 60)

 0.21%
  ESG
  ROUTE Media
  36.5 KB
  N/A




  239.255.5.1:5000 (TSI 300)

 0.19%
  WTVH
  Captions
  34.3 KB
  N/A




  239.255.3.1:5000 (TSI 300)

 0.19%
  WSTM
  Captions
  32.7 KB
  N/A




  225.107.113.49:654

 0.17%
  Unknown Service
  Other UDP
  29.6 KB
  N/A




  239.255.3.100:6000 (TSI 0)

 0.12%
  DDAAS
  Service Signaling
  21.9 KB
  N/A






Total: 17.62 MB | Signaling: 10.45% | Media: 89.38% | Other: 0.17%
