RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

PLP ID	SFI	Modulation	Code Rate	Layer	TI Mode	LLS	Lock	Required SNR	Bitrate
0	0	qam16	9/15	core	hti	Yes	Yes	AWGN: 7.32-7.58 dB Rayleigh: 9.94-10.28 dB	N/A
1	0	qam256	11/15	core	hti	Yes	Yes	AWGN: 18.76-19.08 dB Rayleigh: 21.94-22.40 dB	N/A

L1 Detail Information Not Available

Link Mapping Table Data Not Available

Service Summary (SLT BSID: 2250)

Service Name	ID	Channel	Protocol / Category	SLS Destination
WSTR	5001	64.1	ROUTE / Linear A/V Service	239.255.64.1:5001
WKRC	5002	12.1	ROUTE / Linear A/V Service	239.255.12.1:5002
WLWT	5003	5.1	ROUTE / Linear A/V Service	239.255.5.1:5003
WXIX	5004	19.1	ROUTE / Linear A/V Service	239.255.19.1:5004
WCPO	5005	9.1	ROUTE / Linear A/V Service	239.255.9.1:5005
ESG	5006		ROUTE / ESG Service	239.255.64.1:5100
T2	5007	12.10	ROUTE / Linear A/V Service	239.255.12.10:5000
DDAAS	5008		ROUTE / App-Based Service	239.255.64.1:6000
DDAAS	5009		ROUTE / App-Based Service	239.255.70.1:5009

Capability Descriptor Table (CDT) - 3 Certificate(s)

Attribute	Value
OCSP Refresh	P6DT18H
Certificate Count	3

Certificate Details

Certificate 1 - WSTR-TV Signaling Signing SMT 0001 (Valid Until: Sep 28 2025)

Field	Value
Subject	/C=US/ST=OH/L=Cincinnati/O=Sinclair Broadcast Group, Inc./CN=WSTR-TV Signaling Signing SMT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	3A2FC23F2EFA091C97689AEDEC2AC93D0180E763
Valid From	Sep 28 16:43:23 2023 GMT
Valid Until	Sep 28 16:43:23 2025 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	27:10:9E:D5:3D:A3:A6:BD:53:E9:31:2E:5D:0C:A1:6D:D9:D5:B1:97
SHA-256 Fingerprint	48:6A:CC:2D:9D:B2:A1:6E:2A:17:93:4E:34:15:56:0B:8B:9D:A4:BC:A1:6C:ED:DB:89:22:17:8B:E0:48:AB:
Certificate Authority	No
Self-Signed	No

Certificate 2 - WSTR-TV Signaling Signing CDT 0001 (Valid Until: Sep 28 2025)

Field	Value
Subject	/C=US/ST=OH/L=Cincinnati/O=Sinclair Broadcast Group, Inc./CN=WSTR-TV Signaling Signing CDT 0001
Issuer	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number	4967D743BA7D6D505D64E6BE459A934BF3FBA926
Valid From	Sep 28 16:42:19 2023 GMT
Valid Until	Sep 28 16:42:19 2025 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	09:4F:58:25:51:AB:2A:38:58:99:49:E8:BD:64:52:81:45:62:2A:EB
SHA-256 Fingerprint	4C:76:A6:AF:51:3B:59:13:4D:77:14:D0:2B:2B:14:D6:BF:D9:C0:3B:18:46:F4:08:9E:2F:AF:50:09:B8:42:
Certificate Authority	No
Self-Signed	No

Certificate 3 - ATSC 3.0 Signing CA-2 (Valid Until: Sep 8 2030)

Field	Value
Subject	/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Issuer	/C=US/O=Pearl TV/OU=Root CA-1/CN=ATSC3 Root-CA
Serial Number	1D81C0A269A03D9AAF128428593DB6B8
Valid From	Sep 8 00:00:00 2021 GMT
Valid Until	Sep 8 23:59:59 2030 GMT
Signature Algorithm	sha512WithRSAEncryption
Public Key	RSA (3072 bits)
SHA-1 Fingerprint	06:63:9A:0C:E9:C0:E7:2C:44:05:1C:8A:91:B6:68:FB:25:C4:38:75
SHA-256 Fingerprint	23:42:5B:1C:CA:CB:F3:31:7C:8B:03:59:DA:E0:A3:98:C4:84:05:DB:1B:6B:92:15:58:69:F7:89:30:9A:65:
Certificate Authority	Yes
Self-Signed	No

Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<CertificationData xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/CDT-1.0-20180706.xsd">
<ToBeSignedData OCSPRefresh="P6DT18H"><Certificates>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</Certificates><Certificates>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</Certificates><Certificates>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</Certificates><CurrentCert>DfLCpKnMJpJjZ1I/EbDsxyR40EM=</CurrentCert></ToBeSignedData>
<CMSSignedData>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</CMSSignedData>
<OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse>
</CertificationData>

Service List Table (SLT) Instance 1 - Raw XML

<?xml version="1.0" encoding="UTF-8"?>
<SLT bsid="2250" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SLT/1.0/ SLT-1.0-20211209.xsd">
    <Service globalServiceID="tag:sinclairplatform,2020:WSTR:2251" majorChannelNo="64" minorChannelNo="1" serviceCategory="1" serviceId="5001" shortServiceName="WSTR" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.64.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform,2020:WKRC:2247" majorChannelNo="12" minorChannelNo="1" serviceCategory="1" serviceId="5002" shortServiceName="WKRC" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.12.1" slsDestinationUdpPort="5002" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="tag:sinclairplatform,2020:WLWT:2243" majorChannelNo="5" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5003" shortServiceName="WLWT" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.5.1" slsDestinationUdpPort="5003" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/A27D-6D8B" majorChannelNo="19" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5004" shortServiceName="WXIX" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.19.1" slsDestinationUdpPort="5004" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/C607-57C6" majorChannelNo="9" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5005" shortServiceName="WCPO" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.9.1" slsDestinationUdpPort="5005" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service serviceCategory="4" serviceId="5006" shortServiceName="ESG" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.64.1" slsDestinationUdpPort="5100" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:T2:WKRC" majorChannelNo="12" minorChannelNo="10" serviceCategory="1" serviceId="5007" shortServiceName="T2" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.12.10" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:broadspanwireless.com,None:None:None" hidden="true" serviceCategory="3" serviceId="5008" shortServiceName="DDAAS" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.64.1" slsDestinationUdpPort="6000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:broadspanwireless.com,2250:WSTR-TV:2251" serviceCategory="3" serviceId="5009" shortServiceName="DDAAS" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.70.1" slsDestinationUdpPort="5009" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
</SLT>

Service 5001: WSTR (64.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.64.1:5001

Video: 1280x720p (59.94 fps)
Codec: hvc1.2.4.L120.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: Yes

Service Details (from SLT)

Global Service ID: tag:sinclairplatform,2020:WSTR:2251
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.64.1:5001
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5001"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	1,'TV-PG',{0 'TV-PG'}
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A
4725			N/A
4726			N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="3000000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-PG',{0 'TV-PG'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="4725"><SrcFlow><EFDT><FDT-Instance Expires="4294967295"><fdt:File TOI="3" Content-Location="App.pkg" Content-Length="6620307" Content-Type="multipart/related" afdt:appContextIdList="tag:sinclairplatform,2020:WSTR:2251"></fdt:File></FDT-Instance></EFDT><Payload codePoint="3" formatId="3" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="4726"><SrcFlow><EFDT><FDT-Instance Expires="4294967295"><fdt:File TOI="3" Content-Location="weather-7day.pkg" Content-Length="20142" Content-Type="multipart/related" afdt:appContextIdList="tag:sinclairplatform,2020:WSTR:2251"></fdt:File></FDT-Instance></EFDT><Payload codePoint="3" formatId="3" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="11"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="59"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="15"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2024-04-09T08:17:01Z)

Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 3000000 (3.0 Mbps)
Codecs: hvc1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 60000, Duration: 60060, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 60000, Duration: 60060, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT12H0M43S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2024-04-09T08:17:01Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1">                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>                       <Representation bandwidth="3000000" codecs="hvc1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280">                            <SegmentTemplate duration="60060" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="60000"/>                     </Representation></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>                       <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a02_2">                            <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>                            <SegmentTemplate duration="240240" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>                     </Representation></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">                       <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3">                            <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>                            <SegmentTemplate duration="240240" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>                     </Representation></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">                 <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="subtitle"/>                       <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4">                            <SegmentTemplate duration="60060" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="60000"/>                     </Representation></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://cdn.sinclairplatform.com/public/BA/515/20231003.194616/nrt-515/index.html
Coupled Services: 5001

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tag:sinclairplatform,2020:WSTR:2251" appRendering="false" bcastEntryPackageUrl="App.pkg" bcastEntryPageUrl="index.html" bbandEntryPageUrl="https://cdn.sinclairplatform.com/public/BA/515/20231003.194616/nrt-515/index.html" coupledServices="5001"/>
</HELD>

Service 5002: WKRC (12.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.12.1:5002

Video: 1920x1080p (59.94 fps)
Codec: hvc1.2.4.L123.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: Yes

Service Details (from SLT)

Global Service ID: tag:sinclairplatform,2020:WKRC:2247
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.12.1:5002
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5002"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	1,'TV-G',{0 'TV-G'}
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A
93557			N/A
133876			N/A
133877			N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4500000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-G',{0 'TV-G'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="93557"><SrcFlow><EFDT><FDT-Instance Expires="4294967295"><fdt:File TOI="28" Content-Location="single-alert.pkg" Content-Length="1443" Content-Type="multipart/related" afdt:appContextIdList="tag:sinclairplatform,2020:WKRC:2247"></fdt:File></FDT-Instance></EFDT><Payload codePoint="3" formatId="3" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="133876"><SrcFlow><EFDT><FDT-Instance Expires="4294967295"><fdt:File TOI="3" Content-Location="App.pkg" Content-Length="1421801" Content-Type="multipart/related" afdt:appContextIdList="tag:sinclairplatform,2020:WKRC:2247"></fdt:File></FDT-Instance></EFDT><Payload codePoint="3" formatId="3" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="133877"><SrcFlow><EFDT><FDT-Instance Expires="4294967295"><fdt:File TOI="3" Content-Location="weather-7day.pkg" Content-Length="20142" Content-Type="multipart/related" afdt:appContextIdList="tag:sinclairplatform,2020:WKRC:2247"></fdt:File></FDT-Instance></EFDT><Payload codePoint="3" formatId="3" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="10"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="19"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="155"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2024-04-02T08:18:37Z)

Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4500000 (4.5 Mbps)
Codecs: hvc1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT240H26M4S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2024-04-02T08:18:37Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>                       <Representation bandwidth="4500000" codecs="hvc1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920">                            <SegmentTemplate duration="240240" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>                     </Representation></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>                       <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a02_2">                            <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>                            <SegmentTemplate duration="240240" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>                     </Representation></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">                       <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3">                            <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>                            <SegmentTemplate duration="240240" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>                     </Representation></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">                 <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>                       <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4">                            <SegmentTemplate duration="240240" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>                     </Representation></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://cdn.sinclairplatform.com/public/BA/515/20240320.003834/nrt-515/index.html
Coupled Services: 5002

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tag:sinclairplatform,2020:WKRC:2247" appRendering="false" bcastEntryPackageUrl="App.pkg" bcastEntryPageUrl="index.html" bbandEntryPageUrl="https://cdn.sinclairplatform.com/public/BA/515/20240320.003834/nrt-515/index.html" coupledServices="5002"/>
</HELD>

Service 5003: WLWT (5.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.5.1:5003

Video: 1920x1080p (59.94 fps)
Codec: hvc1.2.4.L123.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform,2020:WLWT:2243
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.5.1:5003
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Protected: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5003"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	1,'TV-PG',{0 'TV-PG'}
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4900000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-PG',{0 'TV-PG'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="10"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="90"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="139"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2024-04-09T15:42:28Z)

Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4900000 (4.9 Mbps)
Codecs: hvc1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 240240, Start: 1709470880
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wlwt_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1709470880
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wlwt_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1709470880
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wlwt_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1709470880

Raw XML

<MPD availabilityStartTime="2024-03-23T07:52:32Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT8M20S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2024-04-09T15:42:28Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet xmlns:cenc="urn:mpeg:cenc:2013" contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">                 <ContentProtection cenc:default_KID="9559c3e5-d7b2-5baa-9aeb-47121650ed89" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>                 <ContentProtection cenc:default_KID="9559c3e5-d7b2-5baa-9aeb-47121650ed89" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">                            <cenc:pssh>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</cenc:pssh>                            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>                            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wlwt_g2_p2_1</dashif:Laurl>                     </ContentProtection>                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>                 <SegmentTemplate duration="240240" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1709470880" timescale="240000"/>                       <Representation bandwidth="4900000" codecs="hvc1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet xmlns:cenc="urn:mpeg:cenc:2013" contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">                 <ContentProtection cenc:default_KID="9559c3e5-d7b2-5baa-9aeb-47121650ed89" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>                 <ContentProtection cenc:default_KID="9559c3e5-d7b2-5baa-9aeb-47121650ed89" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">                            <cenc:pssh>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</cenc:pssh>                            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>                            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wlwt_g2_p2_1</dashif:Laurl>                     </ContentProtection>                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>                 <SegmentTemplate duration="240240" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1709470880" timescale="240000"/>                 <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>                       <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a02_2"/></AdaptationSet><AdaptationSet xmlns:cenc="urn:mpeg:cenc:2013" contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">                 <ContentProtection cenc:default_KID="9559c3e5-d7b2-5baa-9aeb-47121650ed89" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>                 <ContentProtection cenc:default_KID="9559c3e5-d7b2-5baa-9aeb-47121650ed89" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">                            <cenc:pssh>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</cenc:pssh>                            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>                            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wlwt_g2_p2_1</dashif:Laurl>                     </ContentProtection>                 <SegmentTemplate duration="240240" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1709470880" timescale="240000"/>                 <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>                       <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">                 <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>                 <SegmentTemplate duration="240240" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1709470880" timescale="240000"/>                       <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>

Service 5004: WXIX (19.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.19.1:5004

Video: 1280x720p (59.94 fps)
Codec: hvc1.2.4.L120.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: https://doi.org/10.5239/A27D-6D8B
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.19.1:5004
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Protected: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5004"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	N/A
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4900000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="11"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="7"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="46"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2024-04-02T08:18:38Z)

Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4900000 (4.9 Mbps)
Codecs: hvc1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 240240, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=gray_wxix_g2p2
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=gray_wxix_g2p2
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=gray_wxix_g2p2
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: text, Mime: application/mp4, Lang: und)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT240H26M4S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2024-04-02T08:18:38Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet xmlns:cenc="urn:mpeg:cenc:2013" contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1">                 <ContentProtection cenc:default_KID="534de7b7-4667-5397-a4f2-677fe01e8f1b" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>                 <ContentProtection cenc:default_KID="534de7b7-4667-5397-a4f2-677fe01e8f1b" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">                            <cenc:pssh>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</cenc:pssh>                            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>                            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=gray_wxix_g2p2</dashif:Laurl>                     </ContentProtection>                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>                       <Representation bandwidth="4900000" codecs="hvc1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280">                            <SegmentTemplate duration="240240" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>                     </Representation></AdaptationSet><AdaptationSet xmlns:cenc="urn:mpeg:cenc:2013" contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">                 <ContentProtection cenc:default_KID="534de7b7-4667-5397-a4f2-677fe01e8f1b" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>                 <ContentProtection cenc:default_KID="534de7b7-4667-5397-a4f2-677fe01e8f1b" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">                            <cenc:pssh>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</cenc:pssh>                            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>                            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=gray_wxix_g2p2</dashif:Laurl>                     </ContentProtection>                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>                       <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a02_2">                            <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>                            <SegmentTemplate duration="240240" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>                     </Representation></AdaptationSet><AdaptationSet xmlns:cenc="urn:mpeg:cenc:2013" contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">                 <ContentProtection cenc:default_KID="534de7b7-4667-5397-a4f2-677fe01e8f1b" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>                 <ContentProtection cenc:default_KID="534de7b7-4667-5397-a4f2-677fe01e8f1b" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">                            <cenc:pssh>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</cenc:pssh>                            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>                            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=gray_wxix_g2p2</dashif:Laurl>                     </ContentProtection>                       <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3">                            <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>                            <SegmentTemplate duration="240240" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>                     </Representation></AdaptationSet><AdaptationSet contentType="text" id="3" lang="und" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">                 <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>                       <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4">                            <SegmentTemplate duration="240240" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>                     </Representation></AdaptationSet>   </Period></MPD>

Service 5005: WCPO (9.1)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.9.1:5005

Video: 1280x720p (59.94 fps)
Codec: hvc1.2.4.L120.B0

Audio: 6 ch @ 96 kbps
Codec: ac-4.02.01.01

Hidden: No
App: Run3TV

Service Details (from SLT)

Global Service ID: https://doi.org/10.5239/C607-57C6
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.9.1:5005
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Protected: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5005"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
100	Video1_1	video	1,'TV-14',{0 'TV-14'}
200	a02_2	audio	N/A
201	a13_3	audio	N/A
300	d4_4	subtitles	N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4900000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-14',{0 'TV-14'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="12"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="155"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="111"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="4"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2024-04-09T08:17:02Z)

Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 4900000 (4.9 Mbps)
Codecs: hvc1.2.4.L120.B0
Resolution: 1280x720 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Initialization: video-init.mp4
- Media URL: video-$Number$.mp4v
- Timescale: 240000, Duration: 240240, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wcpo_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Bandwidth: 96000 (96 kbps)
Codecs: ac-4.02.01.01
Audio Sample Rate: 48000 Hz
Audio Channels: 6
Segment Template:
- Initialization: a0-$RepresentationID$-init.mp4
- Media URL: a0-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wcpo_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Bandwidth: 48000 (48 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Initialization: a1-$RepresentationID$-init.mp4
- Media URL: a1-$RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1
DRM Protection:
- System: Unknown
- System: Widevine
  License URL: https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wcpo_g2_p2_1
  Group License: file://atsc_group2_profile2.lic

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: d4_4

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Initialization: $RepresentationID$-init.mp4
- Media URL: $RepresentationID$-$Number$.m4s
- Timescale: 240000, Duration: 240240, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT12H0M43S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2024-04-09T08:17:02Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet xmlns:cenc="urn:mpeg:cenc:2013" contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1">                 <ContentProtection cenc:default_KID="ecace0d2-5c4a-5c4e-96c0-594ed0f5d188" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>                 <ContentProtection cenc:default_KID="ecace0d2-5c4a-5c4e-96c0-594ed0f5d188" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">                            <cenc:pssh>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</cenc:pssh>                            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>                            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wcpo_g2_p2_1</dashif:Laurl>                     </ContentProtection>                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>                 <SegmentTemplate duration="240240" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>                       <Representation bandwidth="4900000" codecs="hvc1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet xmlns:cenc="urn:mpeg:cenc:2013" contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">                 <ContentProtection cenc:default_KID="ecace0d2-5c4a-5c4e-96c0-594ed0f5d188" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>                 <ContentProtection cenc:default_KID="ecace0d2-5c4a-5c4e-96c0-594ed0f5d188" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">                            <cenc:pssh>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</cenc:pssh>                            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>                            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wcpo_g2_p2_1</dashif:Laurl>                     </ContentProtection>                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>                 <SegmentTemplate duration="240240" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>                 <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>                       <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a02_2"/></AdaptationSet><AdaptationSet xmlns:cenc="urn:mpeg:cenc:2013" contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">                 <ContentProtection cenc:default_KID="ecace0d2-5c4a-5c4e-96c0-594ed0f5d188" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>                 <ContentProtection cenc:default_KID="ecace0d2-5c4a-5c4e-96c0-594ed0f5d188" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">                            <cenc:pssh>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</cenc:pssh>                            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>                            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=wcpo_g2_p2_1</dashif:Laurl>                     </ContentProtection>                 <SegmentTemplate duration="240240" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>                 <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>                       <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">                 <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="subtitle"/>                 <SegmentTemplate duration="240240" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>                       <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>

HTML Entry-point Description (HELD) Instance 1

Broadband Entry Page: https://ota.ewscloud.com/run3tv-common/index.html

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage
      appContextId="tv:ota-wcpo.ewscloud.com"
      bbandEntryPageUrl="https://ota.ewscloud.com/run3tv-common/index.html" >
  </HTMLEntryPackage>
</HELD>

Service 5006: ESG

Protocol: ROUTE
Category: ESG Service

Source: 172.16.200.1
Destination: 239.255.64.1:5100

Hidden: No
App: No

Service Details (from SLT)

Global Service ID:
Category: 4 (ESG Service)
SLS Destination: 239.255.64.1:5100
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5006"></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: 239.255.64.1:5100

TSI	Representation ID	Content Type	Content Ratings
50			N/A
60			N/A
80			N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1" dIpAddr="239.255.64.1" dPort="5100"><LS tsi="50"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="1738" Content-Location="sgdd_1738" Content-Length="57095" Transfer-Length="5510" Content-Type="application/vnd.oma.bcast.sgdd+xml" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="60"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="3903" Content-Location="sgdu_content_3903" Content-Length="395005" Transfer-Length="35710" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File><fdt:File TOI="4616" Content-Location="sgdu_service_schedule_4616" Content-Length="77655" Transfer-Length="6077" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="80"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="5189" Content-Location="s51307_ll_h15_aa.png" Content-Length="20029" Transfer-Length="19610" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5190" Content-Location="s28711_h3_aa.png" Content-Length="8304" Transfer-Length="7562" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5191" Content-Location="s28717_h3_ba.png" Content-Length="12443" Transfer-Length="11419" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5192" Content-Location="s28719_ll_h15_ac.png" Content-Length="8623" Transfer-Length="8254" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5193" Content-Location="s28708_ll_h15_ac.png" Content-Length="16622" Transfer-Length="16455" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="3"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="4610"></item></metadataEnvelope>

Electronic Service Guide (ESG) - 5 Service(s), 423 Program(s) (from 433 fragments)

Service : WCPO (9.1)

Field	Value
ID	urn:digicap:svc:5005:1712659308241
Status	https://doi.org
Description	WCPO

Raw XML (0 fragments)

Service : WXIX (19.1)

Field	Value
ID	urn:digicap:svc:5004:1712659308241
Status	https://doi.org
Description	WXIX

Raw XML (0 fragments)

Service : WLWT (5.1)

Field	Value
ID	urn:digicap:svc:5003:1712659308241
Status	tag:sinclairpla
Description	WLWT

Raw XML (0 fragments)

Service : WKRC (12.1)

Field	Value
ID	urn:digicap:svc:5002:1712659308241
Status	tag:sinclairpla
Description	WKRC

Raw XML (0 fragments)

Service : WSTR (64.1)

Field	Value
ID	urn:digicap:svc:5001:1712659308241
Status	tag:sinclairpla
Description	WSTR

Raw XML (0 fragments)

Service 5007: T2 (12.10)

Protocol: ROUTE
Category: Linear A/V Service

Source: 172.16.200.1
Destination: 239.255.12.10:5000

Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0

Audio: 2 ch @ 192 kbps
Codec: ac-4.02.01.00

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:sinclairplatform.com,2020:T2:WKRC
Category: 1 (Linear A/V Service)
SLS Destination: 239.255.12.10:5000
SLS Source: 172.16.200.1
SLS Protocol Version: 0.0 (ROUTE)
Broadband Required: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5007"><DeliveryMethod><UnicastAppService><BasePattern>a0-22-</BasePattern><BasePattern>d0-Data3_3-</BasePattern><BasePattern>video-Video1_1-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="4"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="45"></item></metadataEnvelope>

Media Presentation Description (MPD) Instance 1 (Published: 2024-04-09T15:47:38Z)

Type: dynamic
Min Buffer Time: PT10S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Bandwidth: 7000000 (7.0 Mbps)
Codecs: hev1.2.4.L123.B0
Resolution: 1920x1080 (16:9)
Frame Rate: 60000/1001 (59.94 fps)
Scan Type: progressive
Sample Aspect Ratio: 1:1
Segment Template:
- Timescale: 240000
- S: t=432898065600, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22

Bandwidth: 192000 (192 kbps)
Codecs: ac-4.02.01.00
Audio Sample Rate: 48000 Hz
Audio Channels: 2
Segment Template:
- Timescale: 240000
- S: t=432898065600, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_3

Bandwidth: 50000 (50 kbps)
Codecs: stpp.ttml.im1t
Segment Template:
- Timescale: 240000
- S: t=432898065600, d=480480, r=29

Raw XML

<MPD availabilityStartTime="2024-03-19T18:44:16Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2024-04-09T15:47:38Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://ipc.atsc3.com/T2/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>                 <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">                            <SegmentTimeline>                                       <S d="480480" r="29" t="432898065600"/>                                </SegmentTimeline>                     </SegmentTemplate>                       <Representation bandwidth="7000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">                 <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>                 <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">                            <SegmentTimeline>                                       <S d="480480" r="29" t="432898065600"/>                                </SegmentTimeline>                     </SegmentTemplate>                 <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>                       <Representation audioSamplingRate="48000" bandwidth="192000" codecs="ac-4.02.01.00" id="22"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">                 <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>                 <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>                 <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">                            <SegmentTimeline>                                       <S d="480480" r="29" t="432898065600"/>                                </SegmentTimeline>                     </SegmentTemplate>                       <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_3"/></AdaptationSet>   </Period></MPD>

Service 5008: DDAAS

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.64.1:6000

Hidden: Service
App: No

Service Details (from SLT)

Global Service ID: tag:broadspanwireless.com,None:None:None
Category: 3 (App-Based Service)
SLS Destination: 239.255.64.1:6000
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)
Hidden: Yes

User Service Description (ROUTE) Instance 1

Content Type	Version	User Agent	Filter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5008"></UserServiceDescription></BundleDescriptionROUTE>

S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSI	Representation ID	Content Type	Content Ratings
1000			N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1"><LS tsi="1000"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:appContextIdList="NKAppContext" afdt:filterCodes="340 855"><fdt:File TOI="3" Content-Location="helloworld.zip" Content-Length="138" Content-Type="application/zip" Content-MD5="5684334df8ba07f2bb50d88c7f14101d6ef5e04e58b8cda4d81097e79e32b771" afdt:appContextIdList="NKAppContext" afdt:filterCodes="340 855"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>

Service Signaling (Metadata Envelope) 1

Content Type	Version

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="21"></item></metadataEnvelope>

Service 5009: DDAAS

Protocol: ROUTE
Category: App-Based Service

Source: 172.16.200.1
Destination: 239.255.70.1:5009

Hidden: No
App: No

Service Details (from SLT)

Global Service ID: tag:broadspanwireless.com,2250:WSTR-TV:2251
Category: 3 (App-Based Service)
SLS Destination: 239.255.70.1:5009
SLS Source: 172.16.200.1
SLS Protocol Version: . (ROUTE)

No associated ROUTE/DASH or MMT signaling tables found for this service.

Other Global LLS Tables

System Time Details - Actual Timestamp in L1Detail

Attribute	Value
currentUtcOffset	37
utcLocalOffset	-PT4H
dsStatus	false

Raw XML

<?xml version="1.0" encoding="utf-8"?>
<SystemTime xmlns="http://www.atsc.org/XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/ SYSTIME-1.0-20211208.xsd" currentUtcOffset="37" utcLocalOffset="-PT4H" dsStatus="false"/>

Input Info

Attribute	Value
Input Type	PCAP File
File Name	11204-0-20240904-114743-p0p1-ipv4.pcap
Total Packets Processed	72115
Capture Duration	33.5 seconds
File Last Modified	2024-04-09 11:47:43 EDT
Analysis Run Time	2025-11-22 06:00:01 EST

ATSC 3.0 Data Usage Analysis

IP:Port (ID)	Usage ↓	Service	Type	Total Data	Bitrate
239.255.9.1:5005 (TSI 100)	19.70%	WCPO	Video	19.99 MB	4.78 Mbps
239.255.19.1:5004 (TSI 100)	19.65%	WXIX	Video	19.94 MB	4.76 Mbps
239.255.5.1:5003 (TSI 100)	19.64%	WLWT	Video	19.93 MB	4.76 Mbps
239.255.12.1:5002 (TSI 100)	17.96%	WKRC	Video	18.22 MB	4.35 Mbps
239.255.64.1:5001 (TSI 100)	12.04%	WSTR	Video	12.22 MB	2.92 Mbps
224.0.23.60:4937 (LLS)	1.25%	LLS Signaling	LLS Signaling	1.27 MB	302.4 Kbps
239.255.9.1:5005 (TSI 0)	0.92%	WCPO	Service Signaling	938.7 KB	224.3 Kbps
239.255.19.1:5004 (TSI 0)	0.91%	WXIX	Service Signaling	927.0 KB	221.5 Kbps
239.255.5.1:5003 (TSI 0)	0.88%	WLWT	Service Signaling	889.5 KB	212.5 Kbps
239.255.12.1:5002 (TSI 0)	0.69%	WKRC	Service Signaling	695.9 KB	166.3 Kbps
239.255.64.1:5001 (TSI 0)	0.68%	WSTR	Service Signaling	694.9 KB	166.0 Kbps
239.255.12.1:5002 (TSI 133876)	0.49%	WKRC	ROUTE Media	494.0 KB	118.0 Kbps
239.255.5.1:5003 (TSI 200)	0.44%	WLWT	Audio	451.4 KB	107.8 Kbps
239.255.9.1:5005 (TSI 200)	0.44%	WCPO	Audio	450.5 KB	107.6 Kbps
239.255.19.1:5004 (TSI 200)	0.44%	WXIX	Audio	449.2 KB	107.3 Kbps
239.255.12.1:5002 (TSI 200)	0.43%	WKRC	Audio	434.1 KB	103.7 Kbps
239.255.64.1:5001 (TSI 200)	0.43%	WSTR	Audio	433.4 KB	103.6 Kbps
239.255.64.1:5100 (TSI 0)	0.27%	ESG	Service Signaling	270.8 KB	64.7 Kbps
239.255.5.1:5003 (TSI 201)	0.25%	WLWT	Audio	258.8 KB	61.8 Kbps
239.255.19.1:5004 (TSI 201)	0.25%	WXIX	Audio	258.4 KB	61.7 Kbps
239.255.9.1:5005 (TSI 201)	0.25%	WCPO	Audio	250.0 KB	59.7 Kbps
239.255.64.1:5001 (TSI 201)	0.23%	WSTR	Audio	237.6 KB	56.8 Kbps
239.255.12.1:5002 (TSI 201)	0.23%	WKRC	Audio	232.9 KB	55.7 Kbps
239.255.12.10:5000 (TSI 0)	0.20%	T2	Service Signaling	203.5 KB	48.6 Kbps
239.255.64.1:6000 (TSI 0)	0.19%	DDAAS	Service Signaling	194.1 KB	46.4 Kbps
239.255.64.1:5100 (TSI 80)	0.19%	ESG	ROUTE Media	193.2 KB	46.2 Kbps
239.255.12.1:5002 (TSI 133877)	0.12%	WKRC	ROUTE Media	123.0 KB	29.4 Kbps
239.255.64.1:5001 (TSI 4726)	0.12%	WSTR	ROUTE Media	121.9 KB	29.1 Kbps
239.255.64.1:5001 (TSI 4725)	0.12%	WSTR	ROUTE Media	118.9 KB	28.4 Kbps
239.255.64.1:5001 (TSI 300)	0.08%	WSTR	Captions	85.6 KB	20.4 Kbps
239.255.9.1:5005 (TSI 300)	0.08%	WCPO	Captions	79.6 KB	19.0 Kbps
239.255.64.1:5100 (TSI 60)	0.08%	ESG	ROUTE Media	77.8 KB	18.6 Kbps
239.255.64.1:5100 (TSI 50)	0.08%	ESG	ROUTE Media	77.4 KB	18.5 Kbps
239.255.19.1:5004 (TSI 300)	0.07%	WXIX	Captions	72.0 KB	17.2 Kbps
239.255.5.1:5003 (TSI 300)	0.07%	WLWT	Captions	70.7 KB	16.9 Kbps
239.255.12.1:5002 (TSI 93557)	0.07%	WKRC	ROUTE Media	70.1 KB	16.7 Kbps
239.255.12.1:5002 (TSI 300)	0.06%	WKRC	Captions	61.4 KB	14.7 Kbps

Total: 101.48 MB | Signaling: 5.99% | Media: 94.01% | Other: 0.00%

RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

Service Summary (SLT BSID: 2250)

Certificate Details

Service 5001: WSTR (64.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: d4_4

Raw XML

Raw XML

Service 5002: WKRC (12.1)

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: d4_4

Raw XML

Raw XML

Service 5003: WLWT (5.1) Encrypted

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: d4_4

Raw XML

Service 5004: WXIX (19.1) Encrypted

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Adaptation Set (Content: text, Mime: application/mp4, Lang: und)

Representation ID: d4_4

Raw XML

Service 5005: WCPO (9.1) Encrypted

Raw XML

ROUTE Stream: :

Raw XML

Raw XML

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: d4_4

Raw XML

Raw XML

Service 5006: ESG

Raw XML

ROUTE Stream: 239.255.64.1:5100

Service 5003: WLWT (5.1)

Service 5004: WXIX (19.1)

Service 5005: WCPO (9.1)

Service 5007: T2 (12.10)

Service 5008: DDAAS
