RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

PLP IDSFIModulationCode RateLayerTI ModeLLSLockRequired SNRBitrate
00qam169/15corehtiYesYesAWGN: 7.32-7.58 dB
Rayleigh: 9.94-10.28 dB		N/A
10qam2569/15corehtiYesYesAWGN: 15.55-15.80 dB
Rayleigh: 18.23-18.64 dB		N/A
L1 Detail Information Not Available
Link Mapping Table Data Not Available

Service Summary (SLT BSID: 2510)

Service NameIDChannelProtocol / CategorySLS Destination
WPNT500122.1ROUTE / Linear A/V Service239.255.22.1:5001
WPGH500253.1ROUTE / Linear A/V Service239.255.53.1:5002
ESG5003ROUTE / ESG Service239.255.22.1:5100
WTAE Encrypted50044.1ROUTE / Linear A/V Service239.255.4.1:5001
T2 Internet Required500553.10ROUTE / Linear A/V Service239.255.53.10:5000
DDAAS Hidden5006ROUTE / App-Based Service239.255.22.100:6000
PBTV Internet Required500753.11ROUTE / Linear A/V Service239.255.53.11:5000
GMLOOP500853.20ROUTE / App-Based Service239.255.53.20:5000
ROXi500953.21ROUTE / App-Based Service239.255.53.21:5000
Signal Signing Not Available
Service List Table (SLT) Instance 1 - Raw XML
<?xml version="1.0" encoding="UTF-8"?>
<SLT bsid="2510" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SLT/1.0/ SLT-1.0-20211209.xsd">
    <Service globalServiceID="tag:sinclairplatform.com,2020:WPNT:2511" majorChannelNo="22" minorChannelNo="1" serviceCategory="1" serviceId="5001" shortServiceName="WPNT" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.22.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:WPGH:2513" majorChannelNo="53" minorChannelNo="1" serviceCategory="1" serviceId="5002" shortServiceName="WPGH" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.53.1" slsDestinationUdpPort="5002" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service serviceCategory="4" serviceId="5003" shortServiceName="ESG" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.22.1" slsDestinationUdpPort="5100" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/5B1F-815B" majorChannelNo="4" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5004" shortServiceName="WTAE" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.4.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:T2:WPGH" majorChannelNo="53" minorChannelNo="10" serviceCategory="1" serviceId="5005" shortServiceName="T2" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.53.10" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:broadspanwireless.com,2023:2510:WPNT:2511" hidden="true" hideInGuide="true" serviceCategory="3" serviceId="5006" shortServiceName="DDAAS" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.22.100" slsDestinationUdpPort="6000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:PBTV:WPGH" majorChannelNo="53" minorChannelNo="11" serviceCategory="1" serviceId="5007" shortServiceName="PBTV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.53.11" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:sinclairplatform.com,2020:Gameloop:WPGH" majorChannelNo="53" minorChannelNo="20" serviceCategory="3" serviceId="5008" shortServiceName="GMLOOP" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.53.20" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:Roxi:wpgh" majorChannelNo="53" minorChannelNo="21" serviceCategory="3" serviceId="5009" shortServiceName="ROXi" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.53.21" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
</SLT>

Service 5001: WPNT (22.1)

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.22.1:5001
Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0
Audio: 16 ch @ 192 kbps +1 additional audio stream
Codec: ac-4.02.01.02
Hidden: No
App: Run3TV
Service Details (from SLT)
  • Global Service ID: tag:sinclairplatform.com,2020:WPNT:2511
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.22.1:5001
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5001"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSIRepresentation IDContent TypeContent Ratings
100Video1_1video1,'TV-14 D-L',{0 'TV-14'}{1 'D'}{2 'L'}
200a02_2audioN/A
201a13_3audioN/A
300d4_4subtitlesN/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1"><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="4500000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-14 D-L',{0 'TV-14'}{1 'D'}{2 'L'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="192000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="23"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="90"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="55"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="5"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-10-03T15:11:47Z)
Type: dynamic
Min Buffer Time: PT2S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1
  • Bandwidth: 4500000 (4.5 Mbps)
  • Codecs: hev1.2.4.L120.B0
  • Resolution: 1280x720 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Initialization: video-init.mp4
    • Media URL: video-$Number$.mp4v
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2
  • Bandwidth: 192000 (192 kbps)
  • Codecs: ac-4.02.01.02
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 16
  • Segment Template:
    • Initialization: a0-$RepresentationID$-init.mp4
    • Media URL: a0-$RepresentationID$-$Number$.m4s
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3
  • Bandwidth: 48000 (48 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Initialization: a1-$RepresentationID$-init.mp4
    • Media URL: a1-$RepresentationID$-$Number$.m4s
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Initialization: $RepresentationID$-init.mp4
    • Media URL: $RepresentationID$-$Number$.m4s
    • Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<?xml version="1.0" encoding="UTF-8"?><MPD availabilityStartTime="2025-01-24T15:56:59Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT20S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-10-03T15:11:47Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14 D-L',{0 'TV-14'}{1 'D'}{2 'L'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>               <Representation bandwidth="4500000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280">            <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14 D-L',{0 'TV-14'}{1 'D'}{2 'L'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>               <Representation audioSamplingRate="48000" bandwidth="192000" codecs="ac-4.02.01.02" id="a02_2">            <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>            <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14 D-L',{0 'TV-14'}{1 'D'}{2 'L'}"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3">            <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>            <SegmentTemplate duration="480480" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14 D-L',{0 'TV-14'}{1 'D'}{2 'L'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4">            <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet>   </Period></MPD>
HTML Entry-point Description (HELD) Instance 1

Raw XML

<?xml version="1.0" encoding="UTF-8"?><HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html"   appContextId="tag:sinclairplatform.com,2020:WPNT:2511" />
</HELD>

Service 5002: WPGH (53.1)

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.53.1:5002
Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0
Audio: 16 ch @ 192 kbps +1 additional audio stream
Codec: ac-4.02.01.02
Hidden: No
App: Run3TV
Service Details (from SLT)
  • Global Service ID: tag:sinclairplatform.com,2020:WPGH:2513
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.53.1:5002
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5002"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSIRepresentation IDContent TypeContent Ratings
100Video1_1video1,'TV-G',{0 'TV-G'}
200a02_2audioN/A
201a13_3audioN/A
300d4_4subtitlesN/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1"><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="6600000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-G',{0 'TV-G'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="192000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="21"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="75"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="38"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="2"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-10-03T15:11:47Z)
Type: dynamic
Min Buffer Time: PT2S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1
  • Bandwidth: 6600000 (6.6 Mbps)
  • Codecs: hev1.2.4.L120.B0
  • Resolution: 1280x720 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Initialization: video-init.mp4
    • Media URL: video-$Number$.mp4v
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2
  • Bandwidth: 192000 (192 kbps)
  • Codecs: ac-4.02.01.02
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 16
  • Segment Template:
    • Initialization: a0-$RepresentationID$-init.mp4
    • Media URL: a0-$RepresentationID$-$Number$.m4s
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3
  • Bandwidth: 48000 (48 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Initialization: a1-$RepresentationID$-init.mp4
    • Media URL: a1-$RepresentationID$-$Number$.m4s
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: d4_4
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Initialization: $RepresentationID$-init.mp4
    • Media URL: $RepresentationID$-$Number$.m4s
    • Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<?xml version="1.0" encoding="UTF-8"?><MPD availabilityStartTime="2025-01-24T15:56:59Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT20S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-10-03T15:11:47Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-G',{0 'TV-G'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>               <Representation bandwidth="6600000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280">            <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-G',{0 'TV-G'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>               <Representation audioSamplingRate="48000" bandwidth="192000" codecs="ac-4.02.01.02" id="a02_2">            <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>            <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-G',{0 'TV-G'}"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3">            <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>            <SegmentTemplate duration="480480" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-G',{0 'TV-G'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4">            <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet>   </Period></MPD>
HTML Entry-point Description (HELD) Instance 1

Raw XML

<?xml version="1.0" encoding="UTF-8"?><HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html"   appContextId="tag:sinclairplatform.com,2020:WPGH:2513" />
</HELD>

Service 5003: ESG

Protocol: ROUTE
Category: ESG Service
Source: 172.16.200.1
Destination: 239.255.22.1:5100
Hidden: No
App: No
Service Details (from SLT)
  • Global Service ID:
  • Category: 4 (ESG Service)
  • SLS Destination: 239.255.22.1:5100
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5003"></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: 239.255.22.1:5100

TSIRepresentation IDContent TypeContent Ratings
50N/A
60N/A
80N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1" dIpAddr="239.255.22.1" dPort="5100"><LS tsi="50"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="1243" Content-Location="sgdd_1243" Content-Length="35264" Transfer-Length="3591" Content-Type="application/vnd.oma.bcast.sgdd+xml" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="60"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="3667" Content-Location="sgdu_content_3667" Content-Length="264404" Transfer-Length="26803" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File><fdt:File TOI="4572" Content-Location="sgdu_service_schedule_4572" Content-Length="47688" Transfer-Length="4223" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="80"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="5861" Content-Location="s31747_ll_h15_aa.png" Content-Length="15055" Transfer-Length="14780" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5862" Content-Location="s28719_ll_h15_ac.png" Content-Length="8623" Transfer-Length="8258" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5863" Content-Location="s28708_h3_aa.png" Content-Length="15267" Transfer-Length="15140" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="10"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="5469"></item></metadataEnvelope>
Electronic Service Guide (ESG) - 3 Service(s), 260 Program(s) (from 266 fragments)
Service : WTAE (4.1)
FieldValue
IDurn:digicap:svc:5004:1759480736565
Statushttps://doi.org
DescriptionWTAE
Raw XML (0 fragments)


Service : WPGH (53.1)



FieldValue
IDurn:digicap:svc:5002:1759480736565
Statustag:sinclairpla
DescriptionWPGH
Raw XML (0 fragments)


Service : WPNT (22.1)



FieldValue
IDurn:digicap:svc:5001:1759480736565
Statustag:sinclairpla
DescriptionWPNT
Raw XML (0 fragments)






Service 5004: WTAE (4.1) Encrypted








Protocol: ROUTE

Category: Linear A/V Service


Source: 172.16.200.1

Destination: 239.255.4.1:5001


Video: 1920x1080p (59.94 fps)

Codec: hev1.2.4.L123.B0


Audio: 6 ch @ 96 kbps +1 additional audio stream

Codec: ac-4.02.01.01


Hidden: No

App: Run3TV




Service Details (from SLT)





  • Global Service ID: https://doi.org/10.5239/5B1F-815B
    •

  • Category: 1 (Linear A/V Service)
    •

  • SLS Destination: 239.255.4.1:5001
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: 0.0 (ROUTE)
    •

  • Protected: Yes
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5004"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>


S-TSID (Stream Description) Instance 1

ROUTE Stream: :


TSIRepresentation IDContent TypeContent Ratings



100Video1_1video1,'TV-14',{0 'TV-14'}


200a02_2audioN/A


201a13_3audioN/A


300d4_4subtitlesN/A


Raw XML
<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="7600000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-14',{0 'TV-14'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="23"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="9"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="223"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="6"></item></metadataEnvelope>


Media Presentation Description (MPD) Instance 1 (Published: 2025-10-03T15:11:34Z)

Type: dynamic

Min Buffer Time: PT2S

Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015



Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)


Representation ID: Video1_1


  • Bandwidth: 7600000 (7.6 Mbps)
    •

  • Codecs: hev1.2.4.L123.B0
    •

  • Resolution: 1920x1080 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:


    • Initialization: video-init.mp4
      •

    • Media URL: video-$Number$.mp4v
      •

    • Timescale: 240000, Duration: 480480, Start: 1
      •

  • DRM Protection:


Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)


Representation ID: a02_2


  • Bandwidth: 96000 (96 kbps)
    •

  • Codecs: ac-4.02.01.01
    •

  • Audio Sample Rate: 48000 Hz
    •

  • Audio Channels: 6
    •

  • Segment Template:


    • Initialization: a0-$RepresentationID$-init.mp4
      •

    • Media URL: a0-$RepresentationID$-$Number$.m4s
      •

    • Timescale: 240000, Duration: 480480, Start: 1
      •

  • DRM Protection:


Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)


Representation ID: a13_3


  • Bandwidth: 48000 (48 kbps)
    •

  • Codecs: ac-4.02.01.00
    •

  • Audio Sample Rate: 48000 Hz
    •

  • Audio Channels: 2
    •

  • Segment Template:


    • Initialization: a1-$RepresentationID$-init.mp4
      •

    • Media URL: a1-$RepresentationID$-$Number$.m4s
      •

    • Timescale: 240000, Duration: 480480, Start: 1
      •

  • DRM Protection:


Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)


Representation ID: d4_4


  • Bandwidth: 50000 (50 kbps)
    •

  • Codecs: stpp.ttml.im1t
    •

  • Segment Template:


    • Initialization: $RepresentationID$-init.mp4
      •

    • Media URL: $RepresentationID$-$Number$.m4s
      •

    • Timescale: 240000, Duration: 480480, Start: 1
      •



Raw XML
<?xml version="1.0" encoding="UTF-8"?><MPD availabilityStartTime="2025-08-21T14:20:19Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT20S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-10-03T15:11:34Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <ContentProtection cenc:default_KID="a9d84734-e785-5d02-ba27-0263a8d38b3f" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="a9d84734-e785-5d02-ba27-0263a8d38b3f" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=hci_wtae_g2p2</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>               <Representation bandwidth="7600000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920">            <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <ContentProtection cenc:default_KID="a9d84734-e785-5d02-ba27-0263a8d38b3f" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="a9d84734-e785-5d02-ba27-0263a8d38b3f" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=hci_wtae_g2p2</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a02_2">            <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>            <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <ContentProtection cenc:default_KID="a9d84734-e785-5d02-ba27-0263a8d38b3f" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="a9d84734-e785-5d02-ba27-0263a8d38b3f" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=hci_wtae_g2p2</dashif:Laurl>         </ContentProtection>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3">            <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>            <SegmentTemplate duration="480480" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4">            <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         </Representation></AdaptationSet>   </Period></MPD>


HTML Entry-point Description (HELD) Instance 1

Raw XML
<?xml version="1.0" encoding="UTF-8"?><HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage
      appContextId="tv:atsc3-app.wtae.hearst.com"
      bbandEntryPageUrl="https://atsc-ec2.htvapps.net/run3tv-common/index.html" ></HTMLEntryPackage>
</HELD>




Service 5005: T2 (53.10) Internet Required








Protocol: ROUTE

Category: Linear A/V Service


Source: 172.16.200.1

Destination: 239.255.53.10:5000


Video: 1920x1080p (59.94 fps)

Codec: hev1.2.4.L123.B0


Audio: 2 ch @ 192 kbps

Codec: ac-4.02.01.00


Hidden: No

App: No




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:T2:WPGH
    •

  • Category: 1 (Linear A/V Service)
    •

  • SLS Destination: 239.255.53.10:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: 0.0 (ROUTE)
    •

  • Broadband Required: Yes
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5005"><DeliveryMethod><UnicastAppService><BasePattern>a0-22-</BasePattern><BasePattern>d0-Data3_3-</BasePattern><BasePattern>video-Video1_1-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="8"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="190"></item></metadataEnvelope>


Media Presentation Description (MPD) Instance 1 (Published: 2025-10-03T15:11:47Z)

Type: dynamic

Min Buffer Time: PT10S

Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015



Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)


Representation ID: Video1_1


  • Bandwidth: 7000000 (7.0 Mbps)
    •

  • Codecs: hev1.2.4.L123.B0
    •

  • Resolution: 1920x1080 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422281018679520, d=480480, r=29


Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)


Representation ID: 22


  • Bandwidth: 192000 (192 kbps)
    •

  • Codecs: ac-4.02.01.00
    •

  • Audio Sample Rate: 48000 Hz
    •

  • Audio Channels: 2
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422281018679520, d=480480, r=29


Adaptation Set (Content: text, Mime: application/mp4)


Representation ID: Data3_3


  • Bandwidth: 50000 (50 kbps)
    •

  • Codecs: stpp.ttml.im1t
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422281018679520, d=480480, r=29


Raw XML
<?xml version="1.0" encoding="UTF-8"?><MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-10-03T15:11:47Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://wpgh-sbgtv.atsc.stream/t2/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422281018679520"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="7000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422281018679520"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="192000" codecs="ac-4.02.01.00" id="22"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422281018679520"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_3"/></AdaptationSet>   </Period></MPD>




Service 5006: DDAAS Hidden








Protocol: ROUTE

Category: App-Based Service


Source: 172.16.200.1

Destination: 239.255.22.100:6000


Hidden: Service & Guide

App: No




Service Details (from SLT)





  • Global Service ID: tag:broadspanwireless.com,2023:2510:WPNT:2511
    •

  • Category: 3 (App-Based Service)
    •

  • SLS Destination: 239.255.22.100:6000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: . (ROUTE)
    •

  • Hidden: Yes
    •

  • Hide in Guide: Yes
    •





Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="dwd.dwd" contentType="application/atsc-dwd+xml" version="1"></item></metadataEnvelope>


Dynamic Window Description (DWD) Instance 1

Raw XML
<?xml version="1.0" encoding="UTF-8"?><DWD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/DWD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/DWD/1.0/ DWD-1.0-20180830.xsd"><DistributionWindow startTime="2025-10-01T11:28:03Z" endTime="2025-10-01T11:30:58Z" lctTSIRef="1000" contentLabel="2"><AppContextId dwFilterCode="234232">base:context:id</AppContextId></DistributionWindow></DWD>




Service 5007: PBTV (53.11) Internet Required








Protocol: ROUTE

Category: Linear A/V Service


Source: 172.16.200.1

Destination: 239.255.53.11:5000


Video: 1920x1080p (59.94 fps)

Codec: hev1.2.4.L123.B0


Audio: 2 ch @ 384 kbps

Codec: ac-4.02.01.00


Hidden: No

App: No




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:PBTV:WPGH
    •

  • Category: 1 (Linear A/V Service)
    •

  • SLS Destination: 239.255.53.11:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: 0.0 (ROUTE)
    •

  • Broadband Required: Yes
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5007"><DeliveryMethod><UnicastAppService><BasePattern>a0-24-</BasePattern><BasePattern>d0-Data3_5-</BasePattern><BasePattern>video-Video1_1-</BasePattern><BasePattern>video-Video1_2-</BasePattern><BasePattern>video-Video1_3-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="5"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="228"></item></metadataEnvelope>


Media Presentation Description (MPD) Instance 1 (Published: 2025-10-03T15:11:46Z)

Type: dynamic

Min Buffer Time: PT10S

Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015



Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)


Representation ID: Video1_3


  • Bandwidth: 1000000 (1000 kbps)
    •

  • Codecs: hev1.2.4.L93.B0
    •

  • Resolution: 960x540 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422281018199040, d=480480, r=29


Representation ID: Video1_2


  • Bandwidth: 4000000 (4.0 Mbps)
    •

  • Codecs: hev1.2.4.L120.B0
    •

  • Resolution: 1280x720 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422281018199040, d=480480, r=29


Representation ID: Video1_1


  • Bandwidth: 8000000 (8.0 Mbps)
    •

  • Codecs: hev1.2.4.L123.B0
    •

  • Resolution: 1920x1080 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422281018199040, d=480480, r=29


Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)


Representation ID: 24


  • Bandwidth: 384000 (384 kbps)
    •

  • Codecs: ac-4.02.01.00
    •

  • Audio Sample Rate: 48000 Hz
    •

  • Audio Channels: 2
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422281018203044, d=480480, r=29


Adaptation Set (Content: text, Mime: application/mp4)


Representation ID: Data3_5


  • Bandwidth: 50000 (50 kbps)
    •

  • Codecs: stpp.ttml.im1t
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422281018199040, d=480480, r=29


Raw XML
<?xml version="1.0" encoding="UTF-8"?><MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-10-03T15:11:46Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://wpgh-sbgtv.atsc.stream/pickleball/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="540" minWidth="960" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422281018199040"/>            </SegmentTimeline>         </SegmentTemplate>                                 <Representation bandwidth="1000000" codecs="hev1.2.4.L93.B0" frameRate="60000/1001" height="540" id="Video1_3" sar="1:1" scanType="progressive" width="960"/><Representation bandwidth="4000000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_2" sar="1:1" scanType="progressive" width="1280"/><Representation bandwidth="8000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422281018203044"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.00" id="24"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422281018199040"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_5"/></AdaptationSet>   </Period></MPD>




Service 5008: GMLOOP (53.20)








Protocol: ROUTE

Category: App-Based Service


Source: 172.16.200.1

Destination: 239.255.53.20:5000


Hidden: No

App: GameLoop




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:Gameloop:WPGH
    •

  • Category: 3 (App-Based Service)
    •

  • SLS Destination: 239.255.53.20:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: . (ROUTE)
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5008"></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>


HTML Entry-point Description (HELD) Instance 1

Raw XML
<?xml version="1.0" encoding="UTF-8"?><HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tag:sinclairplatform.com,2020:Gameloop:WPGH" bbandEntryPageUrl="https://nextgen.gameloop.tv/run3tv-common/index.html"></HTMLEntryPackage>
</HELD>




Service 5009: ROXi (53.21)








Protocol: ROUTE

Category: App-Based Service


Source: 172.16.200.1

Destination: 239.255.53.21:5000


Hidden: No

App: ROXi




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:Roxi:wpgh
    •

  • Category: 3 (App-Based Service)
    •

  • SLS Destination: 239.255.53.21:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: . (ROUTE)
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5009"></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="2"></item></metadataEnvelope>


HTML Entry-point Description (HELD) Instance 1

Raw XML
<?xml version="1.0" encoding="UTF-8"?><HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://cdn.prod.tvapp.roxi.tv/releases/prod-atsc/index.html#/atsc,faststream,showId=46eb1cf29052,prod" appContextId="tag:sinclairplatform.com,2020:Roxi:wpgh" />
</HELD>




Other Global LLS Tables


System Time Details - Actual Timestamp in L1Detail




AttributeValue



currentUtcOffset37


utcLocalOffset-PT4H


dsStatustrue




Raw XML
<?xml version="1.0" encoding="utf-8"?>
<SystemTime xmlns="http://www.atsc.org/XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/ SYSTIME-1.0-20211208.xsd" currentUtcOffset="37" utcLocalOffset="-PT4H" dsStatus="true"/>



Input Info




AttributeValue



Input TypeDebug File


File Name73907-0-20251003-112119-p0p1-dbg.dbg


Total Packets Processed27689


File Last Modified2025-10-03 11:21:19 EDT


Analysis Run Time2025-11-22 06:00:11 EST




ATSC 3.0 Data Usage Analysis





IP:Port (ID)Usage ↓ServiceTypeTotal DataBitrate



  239.255.4.1:5001 (TSI 100)

 37.31%
  WTAE
  Video
  14.47 MB
  N/A




  239.255.53.1:5002 (TSI 100)

 32.15%
  WPGH
  Video
  12.47 MB
  N/A




  239.255.22.1:5001 (TSI 100)

 21.98%
  WPNT
  Video
  8.52 MB
  N/A




  239.255.4.1:5001 (TSI 0)

 1.33%
  WTAE
  Service Signaling
  514.0 KB
  N/A




  239.255.53.1:5002 (TSI 200)

 0.97%
  WPGH
  Audio
  374.3 KB
  N/A




  239.255.22.1:5001 (TSI 200)

 0.96%
  WPNT
  Audio
  373.1 KB
  N/A




  239.255.53.1:5002 (TSI 0)

 0.94%
  WPGH
  Service Signaling
  365.6 KB
  N/A




  239.255.22.1:5001 (TSI 0)

 0.87%
  WPNT
  Service Signaling
  335.6 KB
  N/A




  239.255.4.1:5001 (TSI 200)

 0.52%
  WTAE
  Audio
  201.8 KB
  N/A




  239.255.22.1:5100 (TSI 80)

 0.35%
  ESG
  ROUTE Media
  135.6 KB
  N/A




  239.255.22.1:5100 (TSI 0)

 0.31%
  ESG
  Service Signaling
  119.3 KB
  N/A




  239.255.4.1:5001 (TSI 201)

 0.29%
  WTAE
  Audio
  112.1 KB
  N/A




  239.255.22.1:5001 (TSI 201)

 0.27%
  WPNT
  Audio
  103.0 KB
  N/A




  239.255.53.1:5002 (TSI 201)

 0.26%
  WPGH
  Audio
  101.6 KB
  N/A




  239.255.22.1:5100 (TSI 60)

 0.23%
  ESG
  ROUTE Media
  90.3 KB
  N/A




  239.255.22.1:5100 (TSI 50)

 0.23%
  ESG
  ROUTE Media
  89.4 KB
  N/A




  239.255.53.11:5000 (TSI 0)

 0.20%
  PBTV
  Service Signaling
  78.6 KB
  N/A




  239.255.53.10:5000 (TSI 0)

 0.19%
  T2
  Service Signaling
  72.3 KB
  N/A




  224.0.23.60:4937 (LLS)

 0.14%
  LLS Signaling
  LLS Signaling
  55.5 KB
  N/A




  239.255.22.100:6000 (TSI 0)

 0.11%
  DDAAS
  Service Signaling
  42.8 KB
  N/A




  239.255.22.1:5001 (TSI 300)

 0.09%
  WPNT
  Captions
  36.5 KB
  N/A




  239.255.53.1:5002 (TSI 300)

 0.08%
  WPGH
  Captions
  32.3 KB
  N/A




  239.255.53.21:5000 (TSI 0)

 0.08%
  ROXi
  Service Signaling
  31.4 KB
  N/A




  239.255.53.20:5000 (TSI 0)

 0.08%
  GMLOOP
  Service Signaling
  30.9 KB
  N/A




  239.255.4.1:5001 (TSI 300)

 0.07%
  WTAE
  Captions
  27.4 KB
  N/A






Total: 38.78 MB | Signaling: 4.24% | Media: 95.76% | Other: 0.00%
