RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

PLP IDSFIModulationCode RateLayerTI ModeLLSLockRequired SNRBitrate
00qam169/15corehtiYesYesAWGN: 7.32-7.58 dB
Rayleigh: 9.94-10.28 dB		N/A
11qam2569/15corehtiYesYesAWGN: 15.55-15.80 dB
Rayleigh: 18.23-18.64 dB		N/A
L1 Detail Information Not Available
Link Mapping Table Data Not Available

Service Summary (SLT BSID: 2730)

Service NameIDChannelProtocol / CategorySLS Destination
WKRN50012.1ROUTE / Linear A/V Service239.255.2.1:5001
WNAB500258.1ROUTE / Linear A/V Service239.255.58.1:5002
ESG5003ROUTE / ESG Service239.255.58.1:5100
WSMV Encrypted50054.1ROUTE / Linear A/V Service239.255.4.1:5005
Capability Descriptor Table (CDT) - 3 Certificate(s)
AttributeValue
OCSP RefreshP7DT0H
Certificate Count3

Certificate Details

Certificate 1 - WNAB Signalling Signing SMT 0001 (Valid Until: Aug 20 2026)
FieldValue
Subject/C=US/ST=Tennessee/L=Nashville/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=WNAB Signalling Signing SMT 0001
Issuer/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number1DDF8A2EC4C2B91F4DF5E7C46BD3328893A163D9
Valid FromAug 20 18:07:20 2025 GMT
Valid UntilAug 20 18:07:20 2026 GMT
Signature Algorithmsha256WithRSAEncryption
Public KeyRSA (3072 bits)
SHA-1 FingerprintF4:BD:D1:66:CC:94:BD:76:66:E4:87:33:65:25:4D:7F:FA:8D:01:91
SHA-256 FingerprintD0:85:DE:03:94:87:52:65:B8:11:9C:12:14:C6:89:93:C6:CA:7C:0B:1F:4A:33:1C:92:6F:56:A4:CE:4E:93:
Certificate AuthorityNo
Self-SignedNo
Certificate 2 - WNAB Signalling Signing CDT 0001 (Valid Until: Aug 20 2026)
FieldValue
Subject/C=US/ST=Tennessee/L=Nashville/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=WNAB Signalling Signing CDT 0001
Issuer/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number5A2C98A8C7F125FCD35A8BDC75669C16E254E53F
Valid FromAug 20 18:07:19 2025 GMT
Valid UntilAug 20 18:07:19 2026 GMT
Signature Algorithmsha256WithRSAEncryption
Public KeyRSA (3072 bits)
SHA-1 FingerprintD5:55:A6:87:67:D2:0C:63:65:86:D7:43:BD:E7:6E:9B:D4:27:C3:DD
SHA-256 FingerprintAA:97:C9:A2:68:39:2A:FE:A6:20:79:2B:1E:EE:ED:B5:33:25:7F:18:B1:E3:31:87:77:A0:65:8E:B3:22:C5:
Certificate AuthorityNo
Self-SignedNo
Certificate 3 - ATSC 3.0 Signing CA-2 (Valid Until: Sep 8 2030)
FieldValue
Subject/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Issuer/C=US/O=Pearl TV/OU=Root CA-1/CN=ATSC3 Root-CA
Serial Number1D81C0A269A03D9AAF128428593DB6B8
Valid FromSep 8 00:00:00 2021 GMT
Valid UntilSep 8 23:59:59 2030 GMT
Signature Algorithmsha512WithRSAEncryption
Public KeyRSA (3072 bits)
SHA-1 Fingerprint06:63:9A:0C:E9:C0:E7:2C:44:05:1C:8A:91:B6:68:FB:25:C4:38:75
SHA-256 Fingerprint23:42:5B:1C:CA:CB:F3:31:7C:8B:03:59:DA:E0:A3:98:C4:84:05:DB:1B:6B:92:15:58:69:F7:89:30:9A:65:
Certificate AuthorityYes
Self-SignedNo
Raw XML
<?xml version="1.0" encoding="UTF-8"?>
<CertificationData xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/CDT-1.0-20180706.xsd">
<ToBeSignedData OCSPRefresh="P7DT0H"><Certificates>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</Certificates><Certificates>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</Certificates><Certificates>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</Certificates><CurrentCert>BSePYLlkJciruU9h6GJMPWMtJxM=</CurrentCert></ToBeSignedData>
<CMSSignedData>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</CMSSignedData>
<OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse>
</CertificationData>
Service List Table (SLT) Instance 1 - Raw XML
<?xml version="1.0" encoding="UTF-8"?>
<SLT bsid="2730" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SLT/1.0/ SLT-1.0-20211209.xsd">
    <Service globalServiceID="tag:sinclairplatform.com,2020:WKRN:2719" majorChannelNo="2" minorChannelNo="1" serviceCategory="1" serviceId="5001" shortServiceName="WKRN" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.2.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:WNAB:2731" majorChannelNo="58" minorChannelNo="1" serviceCategory="1" serviceId="5002" shortServiceName="WNAB" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.58.1" slsDestinationUdpPort="5002" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service serviceCategory="4" serviceId="5003" shortServiceName="ESG" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.58.1" slsDestinationUdpPort="5100" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/A8C7-3C27" majorChannelNo="4" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5005" shortServiceName="WSMV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.4.1" slsDestinationUdpPort="5005" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
</SLT>

Service 5001: WKRN (2.1)

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.2.1:5001
Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0
Audio: 6 ch @ 96 kbps +1 additional audio stream
Codec: ac-4.02.01.01
Hidden: No
App: No
Service Details (from SLT)
  • Global Service ID: tag:sinclairplatform.com,2020:WKRN:2719
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.2.1:5001
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5001"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>data-0-50000-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSIRepresentation IDContent TypeContent Ratings
100Video1_1video1,'TV-PG',{0 'TV-PG'}
20022audioN/A
201Audio3_3audioN/A
300Data4_4subtitlesN/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="7500000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-PG',{0 'TV-PG'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="data-0-50000-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="data-0-50000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="38"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="47"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="167"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-10-18T05:10:00Z)
Type: dynamic
Min Buffer Time: PT2S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1
  • Bandwidth: 7500000 (7.5 Mbps)
  • Codecs: hev1.2.4.L120.B0
  • Resolution: 1280x720 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Initialization: video-init.mp4
    • Media URL: video-$Number$.mp4v
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22
  • Bandwidth: 96000 (96 kbps)
  • Codecs: ac-4.02.01.01
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 6
  • Segment Template:
    • Initialization: a0-init.mp4
    • Media URL: a0-$Number$.mp4a
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3
  • Bandwidth: 48000 (48 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Initialization: a1-init.mp4
    • Media URL: a1-$Number$.mp4a
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data4_4
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Initialization: data-0-$Bandwidth$-init.mp4
    • Media URL: data-0-$Bandwidth$-$Number$.mp4s
    • Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="2025-06-26T21:43:41Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT20S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-10-18T05:10:00Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="7500000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SegmentTemplate duration="480480" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="data-0-$Bandwidth$-init.mp4" media="data-0-$Bandwidth$-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

Service 5002: WNAB (58.1)

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.58.1:5002
Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0
Audio: 2 ch @ 96 kbps +1 additional audio stream
Codec: ac-4.02.01.00
Hidden: No
App: Run3TV
Service Details (from SLT)
  • Global Service ID: tag:sinclairplatform.com,2020:WNAB:2731
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.58.1:5002
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5002"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>data-0-50000-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSIRepresentation IDContent TypeContent Ratings
100Video1_1video1,'TV-14',{0 'TV-14'}
20022audioN/A
201Audio3_3audioN/A
300Data4_4subtitlesN/A
87846N/A
133779N/A
133780N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="3500000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-14',{0 'TV-14'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="data-0-50000-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="data-0-50000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="87846"><SrcFlow><EFDT><FDT-Instance Expires="4294967295"><fdt:File TOI="14" Content-Location="single-alert.pkg" Content-Length="4621" Content-Type="multipart/related" afdt:appContextIdList="tag:sinclairplatform.com,2020:WNAB:2731"></fdt:File></FDT-Instance></EFDT><Payload codePoint="3" formatId="3" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="133779"><SrcFlow><EFDT><FDT-Instance Expires="4294967295"><fdt:File TOI="3" Content-Location="App.pkg" Content-Length="1296288" Content-Type="multipart/related" afdt:appContextIdList="tag:sinclairplatform.com,2020:WNAB:2731"></fdt:File></FDT-Instance></EFDT><Payload codePoint="3" formatId="3" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="133780"><SrcFlow><EFDT><FDT-Instance Expires="4294967295"><fdt:File TOI="3" Content-Location="weather-7day.pkg" Content-Length="30359" Content-Type="multipart/related" afdt:appContextIdList="tag:sinclairplatform.com,2020:WNAB:2731"></fdt:File></FDT-Instance></EFDT><Payload codePoint="3" formatId="3" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="41"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="161"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="33"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="3"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-08-14T12:07:55Z)
Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1
  • Bandwidth: 3500000 (3.5 Mbps)
  • Codecs: hev1.2.4.L120.B0
  • Resolution: 1280x720 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Initialization: video-init.mp4
    • Media URL: video-$Number$.mp4v
    • Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22
  • Bandwidth: 96000 (96 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Initialization: a0-init.mp4
    • Media URL: a0-$Number$.mp4a
    • Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3
  • Bandwidth: 48000 (48 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Initialization: a1-init.mp4
    • Media URL: a1-$Number$.mp4a
    • Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)

Representation ID: Data4_4
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Initialization: data-0-$Bandwidth$-init.mp4
    • Media URL: data-0-$Bandwidth$-$Number$.mp4s
    • Timescale: 240000, Duration: 240240, Start: 1

Raw XML

<MPD availabilityStartTime="2025-08-14T12:07:55Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT0S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-08-14T12:07:55Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="3500000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.00" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <SegmentTemplate duration="240240" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="240240" initialization="data-0-$Bandwidth$-init.mp4" media="data-0-$Bandwidth$-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>
HTML Entry-point Description (HELD) Instance 1

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html" appContextId="tag:sinclairplatform.com,2020:WNAB:2731" />
</HELD>

Service 5003: ESG

Protocol: ROUTE
Category: ESG Service
Source: 172.16.200.1
Destination: 239.255.58.1:5100
Hidden: No
App: No
Service Details (from SLT)
  • Global Service ID:
  • Category: 4 (ESG Service)
  • SLS Destination: 239.255.58.1:5100
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5003"></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: 239.255.58.1:5100

TSIRepresentation IDContent TypeContent Ratings
50N/A
60N/A
80N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1" dIpAddr="239.255.58.1" dPort="5100"><LS tsi="50"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="1404" Content-Location="sgdd_1404" Content-Length="35003" Transfer-Length="3461" Content-Type="application/vnd.oma.bcast.sgdd+xml" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="60"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="3906" Content-Location="sgdu_content_3906" Content-Length="245230" Transfer-Length="19612" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File><fdt:File TOI="4702" Content-Location="sgdu_service_schedule_4702" Content-Length="47339" Transfer-Length="4129" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="80"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="5472" Content-Location="s28708_ll_h15_ac.png" Content-Length="16622" Transfer-Length="16458" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5473" Content-Location="s102116_ll_h15_ac.png" Content-Length="9117" Transfer-Length="8677" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5474" Content-Location="s28717_ll_h15_ad.png" Content-Length="9006" Transfer-Length="8526" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="10"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="9058"></item></metadataEnvelope>
Electronic Service Guide (ESG) - 3 Service(s), 258 Program(s) (from 264 fragments)
Service : WSMV (4.1)
FieldValue
IDurn:digicap:svc:5005:1760732403653
Statushttps://doi.org
DescriptionWSMV
Raw XML (0 fragments)


Service : WNAB (58.1)



FieldValue
IDurn:digicap:svc:5002:1760732403653
Statustag:sinclairpla
DescriptionWNAB
Raw XML (0 fragments)


Service : WKRN (2.1)



FieldValue
IDurn:digicap:svc:5001:1760732403653
Statustag:sinclairpla
DescriptionWKRN
Raw XML (0 fragments)






Service 5005: WSMV (4.1) Encrypted








Protocol: ROUTE

Category: Linear A/V Service


Source: 172.16.200.1

Destination: 239.255.4.1:5005


Video: 1920x1080p (59.94 fps)

Codec: hev1.2.4.L123.B0


Audio: 6 ch @ 96 kbps +1 additional audio stream

Codec: ac-4.02.01.01


Hidden: No

App: Run3TV




Service Details (from SLT)





  • Global Service ID: https://doi.org/10.5239/A8C7-3C27
    •

  • Category: 1 (Linear A/V Service)
    •

  • SLS Destination: 239.255.4.1:5005
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: 0.0 (ROUTE)
    •

  • Protected: Yes
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5005"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>data-0-50000-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>


S-TSID (Stream Description) Instance 1

ROUTE Stream: :


TSIRepresentation IDContent TypeContent Ratings



100Video1_1video1,'TV-14',{0 'TV-14'}


20022audioN/A


201Audio3_3audioN/A


300Data4_4subtitlesN/A


Raw XML
<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="7500000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-14',{0 'TV-14'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="data-0-50000-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="data-0-50000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="25"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="226"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="3"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>


Media Presentation Description (MPD) Instance 1 (Published: 2025-07-14T13:04:52Z)

Type: dynamic

Min Buffer Time: PT2S

Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015



Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)


Representation ID: Video1_1


  • Bandwidth: 7500000 (7.5 Mbps)
    •

  • Codecs: hev1.2.4.L123.B0
    •

  • Resolution: 1920x1080 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:


    • Initialization: video-init.mp4
      •

    • Media URL: video-$Number$.mp4v
      •

    • Timescale: 240000, Duration: 480480, Start: 1
      •

  • DRM Protection:


Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)


Representation ID: 22


  • Bandwidth: 96000 (96 kbps)
    •

  • Codecs: ac-4.02.01.01
    •

  • Audio Sample Rate: 48000 Hz
    •

  • Audio Channels: 6
    •

  • Segment Template:


    • Initialization: a0-init.mp4
      •

    • Media URL: a0-$Number$.mp4a
      •

    • Timescale: 240000, Duration: 480480, Start: 1
      •

  • DRM Protection:


Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)


Representation ID: Audio3_3


  • Bandwidth: 48000 (48 kbps)
    •

  • Codecs: ac-4.02.01.00
    •

  • Audio Sample Rate: 48000 Hz
    •

  • Audio Channels: 2
    •

  • Segment Template:


    • Initialization: a1-init.mp4
      •

    • Media URL: a1-$Number$.mp4a
      •

    • Timescale: 240000, Duration: 480480, Start: 1
      •

  • DRM Protection:


Adaptation Set (Content: text, Mime: application/mp4, Lang: eng)


Representation ID: Data4_4


  • Bandwidth: 50000 (50 kbps)
    •

  • Codecs: stpp.ttml.im1t
    •

  • Segment Template:


    • Initialization: data-0-$Bandwidth$-init.mp4
      •

    • Media URL: data-0-$Bandwidth$-$Number$.mp4s
      •

    • Timescale: 240000, Duration: 480480, Start: 1
      •



Raw XML
<MPD availabilityStartTime="2025-07-14T13:04:52Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT0S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-07-14T13:04:52Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <ContentProtection cenc:default_KID="82958a8b-efdf-5ce7-b983-85346107b46b" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="82958a8b-efdf-5ce7-b983-85346107b46b" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>AAAATHBzc2gAAAAA7e+LqXnWSs6jyCfc1R0h7QAAACwiDmdyYXlfd3Ntdl9nMnAySOPclZsGahRhdHNjX2dyb3VwMl9wcm9maWxlMgAAAmpwc3NoAAAAAO3vi6l51krOo8gn3NUdIe0AAAJKIg5ncmF5X3dzbXZfZzJwMkjj3JWbBlgCahRhdHNjX2dyb3VwMl9wcm9maWxlMnJYChCu60ti6M9RIbRLALMvRgTxEhCClYqL799c57mDhTRhB7RrGiCoSNoySHSnNDChkhQBMQlkM4kE0HlcBcuTEi6Wt/zwRiIQltpNQXeOEd/A8LPn1T4asXJYChDLaJ5zLzNTW4gM2KGYoKRlEhCClYqL799c57mDhTRhB7RrGiDoZrk6zSnGwOJg0d932PQmPSqfkjgINJoXsZ9U7x+lASIQyDrJGuZCHXbC7cTlJJRlKnJYChBIyjKjQdpQ75rZP36RbK0CEhC2Xnhu8Y1SrJ49pvGcWtaJGiBFzAnKhpjhSLTGxtRKQFJtUfXeRPSomykMZ9dcSFfRJSIQJH/dI7gfc24XzjfjEAMfZ3JYChAKsZ0XD/lQb40MA6tkFAOUEhC2Xnhu8Y1SrJ49pvGcWtaJGiCGYkPeGGusOmUCvj4etyxfVm7d4+aBksUQmkaAicJ6yiIQ/6NadGB2jb6agtN0K8biOXJYChCIqchAt7ZaS66Jg0YpDizgEhD0LVLyBwFfZrDe2TMTyu46GiB3d0IybpolO3YSPe0ydGW10mby+GIjsh7erl5CE0uYpiIQSJTDyqOzoby9RHvfKJktSnJYChB4OSweNyVSiI7gKVYR8mN8EhD0LVLyBwFfZrDe2TMTyu46GiBaRVBQKi13qprRETe3MM/OFWAp6dj2NQ2fq3ZsLXMQXiIQO3fN5sYweYMaQCge2tbpDA==</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=gray_wsmv_g2p2</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="7500000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <ContentProtection cenc:default_KID="82958a8b-efdf-5ce7-b983-85346107b46b" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="82958a8b-efdf-5ce7-b983-85346107b46b" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>AAAATHBzc2gAAAAA7e+LqXnWSs6jyCfc1R0h7QAAACwiDmdyYXlfd3Ntdl9nMnAySOPclZsGahRhdHNjX2dyb3VwMl9wcm9maWxlMgAAAmpwc3NoAAAAAO3vi6l51krOo8gn3NUdIe0AAAJKIg5ncmF5X3dzbXZfZzJwMkjj3JWbBlgCahRhdHNjX2dyb3VwMl9wcm9maWxlMnJYChCu60ti6M9RIbRLALMvRgTxEhCClYqL799c57mDhTRhB7RrGiCoSNoySHSnNDChkhQBMQlkM4kE0HlcBcuTEi6Wt/zwRiIQltpNQXeOEd/A8LPn1T4asXJYChDLaJ5zLzNTW4gM2KGYoKRlEhCClYqL799c57mDhTRhB7RrGiDoZrk6zSnGwOJg0d932PQmPSqfkjgINJoXsZ9U7x+lASIQyDrJGuZCHXbC7cTlJJRlKnJYChBIyjKjQdpQ75rZP36RbK0CEhC2Xnhu8Y1SrJ49pvGcWtaJGiBFzAnKhpjhSLTGxtRKQFJtUfXeRPSomykMZ9dcSFfRJSIQJH/dI7gfc24XzjfjEAMfZ3JYChAKsZ0XD/lQb40MA6tkFAOUEhC2Xnhu8Y1SrJ49pvGcWtaJGiCGYkPeGGusOmUCvj4etyxfVm7d4+aBksUQmkaAicJ6yiIQ/6NadGB2jb6agtN0K8biOXJYChCIqchAt7ZaS66Jg0YpDizgEhD0LVLyBwFfZrDe2TMTyu46GiB3d0IybpolO3YSPe0ydGW10mby+GIjsh7erl5CE0uYpiIQSJTDyqOzoby9RHvfKJktSnJYChB4OSweNyVSiI7gKVYR8mN8EhD0LVLyBwFfZrDe2TMTyu46GiBaRVBQKi13qprRETe3MM/OFWAp6dj2NQ2fq3ZsLXMQXiIQO3fN5sYweYMaQCge2tbpDA==</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=gray_wsmv_g2p2</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <ContentProtection cenc:default_KID="82958a8b-efdf-5ce7-b983-85346107b46b" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="82958a8b-efdf-5ce7-b983-85346107b46b" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>AAAATHBzc2gAAAAA7e+LqXnWSs6jyCfc1R0h7QAAACwiDmdyYXlfd3Ntdl9nMnAySOPclZsGahRhdHNjX2dyb3VwMl9wcm9maWxlMgAAAmpwc3NoAAAAAO3vi6l51krOo8gn3NUdIe0AAAJKIg5ncmF5X3dzbXZfZzJwMkjj3JWbBlgCahRhdHNjX2dyb3VwMl9wcm9maWxlMnJYChCu60ti6M9RIbRLALMvRgTxEhCClYqL799c57mDhTRhB7RrGiCoSNoySHSnNDChkhQBMQlkM4kE0HlcBcuTEi6Wt/zwRiIQltpNQXeOEd/A8LPn1T4asXJYChDLaJ5zLzNTW4gM2KGYoKRlEhCClYqL799c57mDhTRhB7RrGiDoZrk6zSnGwOJg0d932PQmPSqfkjgINJoXsZ9U7x+lASIQyDrJGuZCHXbC7cTlJJRlKnJYChBIyjKjQdpQ75rZP36RbK0CEhC2Xnhu8Y1SrJ49pvGcWtaJGiBFzAnKhpjhSLTGxtRKQFJtUfXeRPSomykMZ9dcSFfRJSIQJH/dI7gfc24XzjfjEAMfZ3JYChAKsZ0XD/lQb40MA6tkFAOUEhC2Xnhu8Y1SrJ49pvGcWtaJGiCGYkPeGGusOmUCvj4etyxfVm7d4+aBksUQmkaAicJ6yiIQ/6NadGB2jb6agtN0K8biOXJYChCIqchAt7ZaS66Jg0YpDizgEhD0LVLyBwFfZrDe2TMTyu46GiB3d0IybpolO3YSPe0ydGW10mby+GIjsh7erl5CE0uYpiIQSJTDyqOzoby9RHvfKJktSnJYChB4OSweNyVSiI7gKVYR8mN8EhD0LVLyBwFfZrDe2TMTyu46GiBaRVBQKi13qprRETe3MM/OFWAp6dj2NQ2fq3ZsLXMQXiIQO3fN5sYweYMaQCge2tbpDA==</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=gray_wsmv_g2p2</dashif:Laurl>         </ContentProtection>         <SegmentTemplate duration="480480" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="eng" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="data-0-$Bandwidth$-init.mp4" media="data-0-$Bandwidth$-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>


HTML Entry-point Description (HELD) Instance 1

Raw XML
<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tv:wsmv.gray.tv" bbandEntryPageUrl="https://atsc-v2.gdm-connect.com/run3tv-common/index.html"></HTMLEntryPackage>
</HELD>




Other Global LLS Tables


System Time Details - Actual Timestamp in L1Detail




AttributeValue



currentUtcOffset37


utcLocalOffset-PT5H


dsStatustrue




Raw XML
<?xml version="1.0" encoding="utf-8"?>
<SystemTime xmlns="http://www.atsc.org/XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/ SYSTIME-1.0-20211208.xsd" currentUtcOffset="37" utcLocalOffset="-PT5H" dsStatus="true"/>



Input Info




AttributeValue



Input TypeDebug File


File Name73310-0-20251018-012850-p0p1-dbg.dbg


Total Packets Processed27106


File Last Modified2025-10-18 01:28:50 EDT


Analysis Run Time2025-11-23 16:16:21 EST




ATSC 3.0 Data Usage Analysis





IP:Port (ID)Usage ↓ServiceTypeTotal DataBitrate



  239.255.2.1:5001 (TSI 100)

 37.11%
  WKRN
  Video
  14.26 MB
  N/A




  239.255.4.1:5005 (TSI 100)

 36.61%
  WSMV
  Video
  14.07 MB
  N/A




  239.255.58.1:5002 (TSI 100)

 17.02%
  WNAB
  Video
  6.54 MB
  N/A




  239.255.4.1:5005 (TSI 0)

 1.50%
  WSMV
  Service Signaling
  575.2 KB
  N/A




  224.0.23.60:4937 (LLS)

 1.35%
  LLS Signaling
  LLS Signaling
  520.3 KB
  N/A




  239.255.2.1:5001 (TSI 0)

 1.04%
  WKRN
  Service Signaling
  398.4 KB
  N/A




  239.255.58.1:5002 (TSI 0)

 1.03%
  WNAB
  Service Signaling
  394.4 KB
  N/A




  239.255.4.1:5005 (TSI 200)

 0.53%
  WSMV
  Audio
  201.8 KB
  N/A




  239.255.58.1:5002 (TSI 200)

 0.51%
  WNAB
  Audio
  197.7 KB
  N/A




  239.255.2.1:5001 (TSI 200)

 0.50%
  WKRN
  Audio
  193.5 KB
  N/A




  239.255.58.1:5100 (TSI 0)

 0.41%
  ESG
  Service Signaling
  159.2 KB
  N/A




  239.255.58.1:5100 (TSI 80)

 0.35%
  ESG
  ROUTE Media
  135.6 KB
  N/A




  239.255.4.1:5005 (TSI 201)

 0.29%
  WSMV
  Audio
  110.9 KB
  N/A




  239.255.58.1:5002 (TSI 201)

 0.28%
  WNAB
  Audio
  106.7 KB
  N/A




  239.255.2.1:5001 (TSI 201)

 0.27%
  WKRN
  Audio
  103.1 KB
  N/A




  239.255.58.1:5100 (TSI 50)

 0.23%
  ESG
  ROUTE Media
  89.8 KB
  N/A




  239.255.58.1:5100 (TSI 60)

 0.23%
  ESG
  ROUTE Media
  89.3 KB
  N/A




  239.255.58.1:5002 (TSI 133779)

 0.15%
  WNAB
  ROUTE Media
  57.2 KB
  N/A




  239.255.58.1:5002 (TSI 133780)

 0.14%
  WNAB
  ROUTE Media
  55.6 KB
  N/A




  239.255.58.1:5002 (TSI 87846)

 0.14%
  WNAB
  ROUTE Media
  52.8 KB
  N/A




  239.255.2.1:5001 (TSI 300)

 0.12%
  WKRN
  Captions
  44.5 KB
  N/A




  239.255.4.1:5005 (TSI 300)

 0.10%
  WSMV
  Captions
  38.4 KB
  N/A




  239.255.58.1:5002 (TSI 300)

 0.09%
  WNAB
  Captions
  35.4 KB
  N/A






Total: 38.43 MB | Signaling: 5.33% | Media: 94.67% | Other: 0.00%
