RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

PLP IDSFIModulationCode RateLayerTI ModeLLSLockRequired SNRBitrate
00qam169/15corehtiYesYesAWGN: 7.32-7.58 dB
Rayleigh: 9.94-10.28 dB		N/A
10qam25611/15corehtiYesYesAWGN: 18.76-19.08 dB
Rayleigh: 21.94-22.40 dB		N/A
L1 Detail Information Not Available
Link Mapping Table Data Not Available

Service Summary (SLT BSID: 3008)

Service NameIDChannelProtocol / CategorySLS Destination
T2 Internet Required50012.10ROUTE / Linear A/V Service239.255.2.10:5001
KUCW500230.1ROUTE / Linear A/V Service239.255.30.1:5001
KUTV50032.1ROUTE / Linear A/V Service239.255.2.1:5001
KTVX50044.1ROUTE / Linear A/V Service239.255.4.1:5001
ESG5005ROUTE / ESG Service239.255.14.1:5100
KJZZ500614.1MMT / Linear A/V Service239.255.14.1:5001
DDAAS Hidden5007ROUTE / App-Based Service239.255.14.100:6000
GMLOOP50092.20ROUTE / App-Based Service239.255.2.20:5000
PBTV Internet Required50102.11ROUTE / Linear A/V Service239.255.2.11:5000
Signal Signing Not Available
Service List Table (SLT) Instance 1 - Raw XML
<?xml version="1.0" encoding="UTF-8"?>
<SLT bsid="3008" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SLT/1.0/ SLT-1.0-20211209.xsd">
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:T2:KUTV" majorChannelNo="2" minorChannelNo="10" serviceCategory="1" serviceId="5001" shortServiceName="T2" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.2.10" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:KUCW:2993" majorChannelNo="30" minorChannelNo="1" serviceCategory="1" serviceId="5002" shortServiceName="KUCW" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.30.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:KUTV:2998" majorChannelNo="2" minorChannelNo="1" serviceCategory="1" serviceId="5003" shortServiceName="KUTV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.2.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:KTVX:3001" majorChannelNo="4" minorChannelNo="1" serviceCategory="1" serviceId="5004" shortServiceName="KTVX" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.4.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service serviceCategory="4" serviceId="5005" shortServiceName="ESG" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.14.1" slsDestinationUdpPort="5100" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:KJZZ:3009" majorChannelNo="14" minorChannelNo="1" serviceCategory="1" serviceId="5006" shortServiceName="KJZZ" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.14.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="2" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:broadspanwireless.com,2023:3008:KJZZ-TV:3009" hidden="true" hideInGuide="true" serviceCategory="3" serviceId="5007" shortServiceName="DDAAS" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.14.100" slsDestinationUdpPort="6000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:sinclairplatform.com,2020:Gameloop:KUTV" majorChannelNo="2" minorChannelNo="20" serviceCategory="3" serviceId="5009" shortServiceName="GMLOOP" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.2.20" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:PBTV:KUTV" majorChannelNo="2" minorChannelNo="11" serviceCategory="1" serviceId="5010" shortServiceName="PBTV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.2.11" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
</SLT>

Service 5001: T2 (2.10) Internet Required

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.2.10:5001
Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0
Audio: 2 ch @ 192 kbps
Codec: ac-4.02.01.00
Hidden: No
App: No
Service Details (from SLT)
  • Global Service ID: tag:sinclairplatform.com,2020:T2:KUTV
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.2.10:5001
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
  • Broadband Required: Yes
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5001"><DeliveryMethod><UnicastAppService><BasePattern>a0-22-</BasePattern><BasePattern>d0-Data3_3-</BasePattern><BasePattern>video-Video1_1-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="22"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="16"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-05-01T17:12:01Z)
Type: dynamic
Min Buffer Time: PT10S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1
  • Bandwidth: 7000000 (7.0 Mbps)
  • Codecs: hev1.2.4.L123.B0
  • Resolution: 1920x1080 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Timescale: 240000
    • S: t=419068670660640, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22
  • Bandwidth: 192000 (192 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Timescale: 240000
    • S: t=419068670660640, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_3
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Timescale: 240000
    • S: t=419068670660640, d=480480, r=29

Raw XML

<?xml version="1.0" encoding="UTF-8"?><MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-05-01T17:12:01Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://ipc.atsc3.com/T2/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="419068670660640"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="7000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="419068670660640"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="192000" codecs="ac-4.02.01.00" id="22"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="419068670660640"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_3"/></AdaptationSet>   </Period></MPD>

Service 5002: KUCW (30.1)

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.30.1:5001
Video: 1920x1080p (29.97 fps)
Codec: hev1.2.4.L120.B0
Audio: 6 ch @ 96 kbps +1 additional audio stream
Codec: ac-4.02.01.01
Hidden: No
App: No
Service Details (from SLT)
  • Global Service ID: tag:sinclairplatform.com,2020:KUCW:2993
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.30.1:5001
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5002"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>data-0-50000-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSIRepresentation IDContent TypeContent Ratings
100Video1_1video1,'TV-PG',{0 'TV-PG'}
20022audioN/A
201Audio3_3audioN/A
300Data4_4subtitlesN/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5100000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-PG',{0 'TV-PG'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="data-0-50000-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="data-0-50000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="62"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="159"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="175"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-05-01T16:09:02Z)
Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1
  • Bandwidth: 5100000 (5.1 Mbps)
  • Codecs: hev1.2.4.L120.B0
  • Resolution: 1920x1080 (16:9)
  • Frame Rate: 30000/1001 (29.97 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Initialization: video-init.mp4
    • Media URL: video-$Number$.mp4v
    • Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4)

Representation ID: 22
  • Bandwidth: 96000 (96 kbps)
  • Codecs: ac-4.02.01.01
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 6
  • Segment Template:
    • Initialization: a0-init.mp4
    • Media URL: a0-$Number$.mp4a
    • Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4)

Representation ID: Audio3_3
  • Bandwidth: 48000 (48 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Initialization: a1-init.mp4
    • Media URL: a1-$Number$.mp4a
    • Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data4_4
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Initialization: data-0-$Bandwidth$-init.mp4
    • Media URL: data-0-$Bandwidth$-$Number$.mp4s
    • Timescale: 240000, Duration: 240240, Start: 1

Raw XML

<?xml version="1.0" encoding="UTF-8"?><MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT15H5M54S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-05-01T16:09:02Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="30000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="30000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="5100000" codecs="hev1.2.4.L120.B0" frameRate="30000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SegmentTemplate duration="240240" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-PG',{0 'TV-PG'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="240240" initialization="data-0-$Bandwidth$-init.mp4" media="data-0-$Bandwidth$-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

Service 5003: KUTV (2.1)

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.2.1:5001
Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0
Audio: 16 ch @ 448 kbps +1 additional audio stream
Codec: ac-4.02.01.02
Hidden: No
App: Yes
Service Details (from SLT)
  • Global Service ID: tag:sinclairplatform.com,2020:KUTV:2998
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.2.1:5001
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5003"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>data-0-50000-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSIRepresentation IDContent TypeContent Ratings
100Video1_1video1,'TV-G',{0 'TV-G'}
20022audioN/A
201Audio3_3audioN/A
300Data4_4subtitlesN/A
1004N/A
1006N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5100000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-G',{0 'TV-G'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="448000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="data-0-50000-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="data-0-50000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="1004"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:appContextIdList="tag:sinclairplatform.com,2020:KUTV:2998"><fdt:File TOI="97356" Content-Location="weather-7day.pkg" Content-Length="20114" Content-Type="multipart/related"></fdt:File></FDT-Instance></EFDT><Payload codePoint="3" formatId="3" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="1006"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:appContextIdList="tag:sinclairplatform.com,2020:KUTV:2998"><fdt:File TOI="8571" Content-Location="App.pkg" Content-Length="6720277" Content-Type="multipart/related"></fdt:File></FDT-Instance></EFDT><Payload codePoint="3" formatId="3" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="63"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="159"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="146"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-05-01T17:11:59Z)
Type: dynamic
Min Buffer Time: PT2S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1
  • Bandwidth: 5100000 (5.1 Mbps)
  • Codecs: hev1.2.4.L123.B0
  • Resolution: 1920x1080 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Initialization: video-init.mp4
    • Media URL: video-$Number$.mp4v
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22
  • Bandwidth: 448000 (448 kbps)
  • Codecs: ac-4.02.01.02
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 16
  • Segment Template:
    • Initialization: a0-init.mp4
    • Media URL: a0-$Number$.mp4a
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: Audio3_3
  • Bandwidth: 48000 (48 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Initialization: a1-init.mp4
    • Media URL: a1-$Number$.mp4a
    • Timescale: 240000, Duration: 480480, Start: 1

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data4_4
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Initialization: data-0-$Bandwidth$-init.mp4
    • Media URL: data-0-$Bandwidth$-$Number$.mp4s
    • Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<?xml version="1.0" encoding="UTF-8"?><MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT20S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-05-01T17:11:59Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-G',{0 'TV-G'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="5100000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-G',{0 'TV-G'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>               <Representation audioSamplingRate="48000" bandwidth="448000" codecs="ac-4.02.01.02" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-G',{0 'TV-G'}"/>         <SegmentTemplate duration="480480" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-G',{0 'TV-G'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="data-0-$Bandwidth$-init.mp4" media="data-0-$Bandwidth$-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>
HTML Entry-point Description (HELD) Instance 1

Raw XML

<?xml version="1.0" encoding="UTF-8"?><HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tag:sinclairplatform.com,2020:KUTV:2998" bcastEntryPackageUrl="App.pkg" bcastEntryPageUrl="index.html" bbandEntryPageUrl="https://cdn.sinclairplatform.com/public/BA/770/20230929.125934/nrt-770/index.html"/>
</HELD>

Service 5004: KTVX (4.1)

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.4.1:5001
Video: 1280x720p (59.94 fps)
Codec: hev1.2.4.L120.B0
Audio: 6 ch @ 96 kbps +1 additional audio stream
Codec: ac-4.02.01.01
Hidden: No
App: No
Service Details (from SLT)
  • Global Service ID: tag:sinclairplatform.com,2020:KTVX:3001
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.4.1:5001
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5004"><DeliveryMethod><BroadcastAppService><BasePattern>a0-</BasePattern><BasePattern>a1-</BasePattern><BasePattern>data-0-50000-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSIRepresentation IDContent TypeContent Ratings
100Video1_1video1,'TV-14',{0 'TV-14'}
20022audioN/A
201Audio3_3audioN/A
300Data4_4subtitlesN/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="5100000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"><ContentRating value="1,'TV-14',{0 'TV-14'}"></ContentRating></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a0-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="22"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-$TOI$.mp4a"><fdt:File TOI="1" Content-Location="a1-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="Audio3_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="data-0-50000-$TOI$.mp4s"><fdt:File TOI="1" Content-Location="data-0-50000-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="Data4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="61"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="80"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="248"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-05-01T16:09:03Z)
Type: dynamic
Min Buffer Time: PT1S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1
  • Bandwidth: 5100000 (5.1 Mbps)
  • Codecs: hev1.2.4.L120.B0
  • Resolution: 1280x720 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Initialization: video-init.mp4
    • Media URL: video-$Number$.mp4v
    • Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4)

Representation ID: 22
  • Bandwidth: 96000 (96 kbps)
  • Codecs: ac-4.02.01.01
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 6
  • Segment Template:
    • Initialization: a0-init.mp4
    • Media URL: a0-$Number$.mp4a
    • Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: audio, Mime: audio/mp4)

Representation ID: Audio3_3
  • Bandwidth: 48000 (48 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Initialization: a1-init.mp4
    • Media URL: a1-$Number$.mp4a
    • Timescale: 240000, Duration: 240240, Start: 1

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data4_4
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Initialization: data-0-$Bandwidth$-init.mp4
    • Media URL: data-0-$Bandwidth$-$Number$.mp4s
    • Timescale: 240000, Duration: 240240, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT1.001S" minBufferTime="PT1S" minimumUpdatePeriod="PT15H5M54S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-05-01T16:09:03Z" timeShiftBufferDepth="PT6S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="5100000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet contentType="audio" id="1" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="240240" initialization="a0-init.mp4" media="a0-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="22"/></AdaptationSet><AdaptationSet contentType="audio" id="2" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <SegmentTemplate duration="240240" initialization="a1-init.mp4" media="a1-$Number$.mp4a" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-14',{0 'TV-14'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="240240" initialization="data-0-$Bandwidth$-init.mp4" media="data-0-$Bandwidth$-$Number$.mp4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data4_4"/></AdaptationSet>   </Period></MPD>

Service 5005: ESG

Protocol: ROUTE
Category: ESG Service
Source: 172.16.200.1
Destination: 239.255.14.1:5100
Hidden: No
App: No
Service Details (from SLT)
  • Global Service ID:
  • Category: 4 (ESG Service)
  • SLS Destination: 239.255.14.1:5100
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5005"></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: 239.255.14.1:5100

TSIRepresentation IDContent TypeContent Ratings
50N/A
60N/A
80N/A

Raw XML

<?xml version="1.0" encoding="utf-8"?><S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1" dIpAddr="239.255.14.1" dPort="5100"><LS tsi="50"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="1890" Content-Location="sgdd_1890" Content-Length="36051" Transfer-Length="3622" Content-Type="application/vnd.oma.bcast.sgdd+xml" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="60"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="3743" Content-Location="sgdu_content_3743" Content-Length="257003" Transfer-Length="23362" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File><fdt:File TOI="4458" Content-Location="sgdu_service_schedule_4458" Content-Length="48717" Transfer-Length="4242" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="80"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="5522" Content-Location="s53098_ll_h15_ac.png" Content-Length="6025" Transfer-Length="5789" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5523" Content-Location="s28711_h3_aa.png" Content-Length="8304" Transfer-Length="7564" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5524" Content-Location="s28708_h3_aa.png" Content-Length="15267" Transfer-Length="15140" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="9"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="6793"></item></metadataEnvelope>
Electronic Service Guide (ESG) - 3 Service(s), 277 Program(s) (from 400 fragments)
Service : KTVX (4.1)
FieldValue
IDurn:digicap:svc:5004:1746101131650
Statustag:sinclairpla
DescriptionKTVX
Raw XML (0 fragments)


Service : KUTV (2.1)



FieldValue
IDurn:digicap:svc:5003:1746101131650
Statustag:sinclairpla
DescriptionKUTV
Raw XML (0 fragments)


Service : KUCW (30.1)



FieldValue
IDurn:digicap:svc:5002:1746101131650
Statustag:sinclairpla
DescriptionKUCW
Raw XML (0 fragments)






Service 5006: KJZZ (14.1)








Protocol: MMT

Category: Linear A/V Service


Source: 172.16.200.1

Destination: 239.255.14.1:5001


Video:

Codec: hev1.2.X.L123.X


Audio: 6 ch+1 additional audio stream

Codec: ac-4.02.01.00


Hidden: No

App: Yes




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:KJZZ:3009
    •

  • Category: 1 (Linear A/V Service)
    •

  • SLS Destination: 239.255.14.1:5001
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: 0.0 (MMT)
    •





User Service Bundle Description (USBD) Instance 1



IDContent TypeVersion



5006UserServiceDescription1.0


Raw XML
<?xml version="1.0" encoding="utf-8"?><BundleDescriptionMMT xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/MMTUSD/1.0/" xmlns:sa="tag:atsc.org,2016:XMLSchemas/ATSC3/SA/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/MMTUSD/1.0/ MMTUSD-1.0-20210401.xsd"><UserServiceDescription serviceId="5006"><Channel serviceIcon="service_icon"><ServiceDescription serviceDescrText="TBD" serviceDescrLang="en"></ServiceDescription></Channel><MPUComponent mmtPackageId="mmt"></MPUComponent><ComponentInfo componentType="1" componentRole="0" componentProtectedFlag="false" componentId="videoasset01"></ComponentInfo><ComponentInfo componentType="0" componentRole="0" componentProtectedFlag="false" componentId="audioasset02"></ComponentInfo><ComponentInfo componentType="0" componentRole="0" componentProtectedFlag="false" componentId="audioasset03"></ComponentInfo><ComponentInfo componentType="2" componentRole="0" componentProtectedFlag="false" componentId="subtitleasset04"></ComponentInfo></UserServiceDescription></BundleDescriptionMMT>


User Service Description (USD) -



FieldValue
Service ID5006
MMT Package IDmmt
Components:
Component IDTypeRoleDescription
videoasset0110Main Video
audioasset0200Main Audio
audioasset0300Main Audio
subtitleasset0420Main Data/Captions
Raw XML
<?xml version="1.0" encoding="UTF-8"?><UserServiceDescription serviceId="5006">
  <Channel serviceIcon="service_icon">
    <ServiceDescription serviceDescrText="TBD" serviceDescrLang="en"/>
  </Channel>
  <MPUComponent mmtPackageId="mmt"/>
  <ComponentInfo componentType="1" componentRole="0" componentProtectedFlag="false" componentId="videoasset01"/>
  <ComponentInfo componentType="0" componentRole="0" componentProtectedFlag="false" componentId="audioasset02"/>
  <ComponentInfo componentType="0" componentRole="0" componentProtectedFlag="false" componentId="audioasset03"/>
  <ComponentInfo componentType="2" componentRole="0" componentProtectedFlag="false" componentId="subtitleasset04"/>
</UserServiceDescription>


MMT Signaling (MP Table - Binary)

Binary MMT Package Table


Asset IDAsset TypeCodecPacket ID



videoasset01hev1HEVC/H.265100


audioasset02ac-4AC-4 Audio200


audioasset03ac-4AC-4 Audio201


subtitleasset04stppTTML Subtitles300




HTML Entry-point Description (HELD) Instance 1

Raw XML
<?xml version="1.0" encoding="UTF-8"?><HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tag:sinclairplatform.com,2020:KJZZ:3009" bcastEntryPackageUrl="App.pkg" bcastEntryPageUrl="index.html" bbandEntryPageUrl="https://cdn.sinclairplatform.com/public/BA/770/20230907.170724/nrt-770/index.html"/></HELD>


MMT Stream Descriptors Instance 1



Video Stream Properties Descriptor (VSPD)




  • Codec: hev1.2.2.L123.B (HEVC/H.265)
    •

  • HEVC Profile: Main 10 (supports 10-bit color depth for HDR content)
    •

  • HEVC Level: 4.1 (defines maximum resolution, frame rate, and bitrate capabilities)
    •

  • Tier: Main (Main tier: standard bitrates, High tier: allows higher bitrates)
    •

  • Scan Type: Progressive (full frames, better quality)
    •



Audio Stream Properties Descriptor (ASPD)




  • Codec: ac-4 (Dolby AC-4 - next-generation audio codec)
    •

  • Language: en
    •

  • Presentations: 1 (separate audio mixes, e.g., main, commentary, descriptive)
    •

  • Sample Rate: 48000 Hz
    •



Caption Asset Descriptor (CAD)




  • Caption Track 1:


    • Role: main (primary captions)
      •

    • Aspect Ratio: 16:9
      •

    • Profile: text (text-based captions)
      •

    •







Service 5007: DDAAS Hidden








Protocol: ROUTE

Category: App-Based Service


Source: 172.16.200.1

Destination: 239.255.14.100:6000


Hidden: Service & Guide

App: No




Service Details (from SLT)





  • Global Service ID: tag:broadspanwireless.com,2023:3008:KJZZ-TV:3009
    •

  • Category: 3 (App-Based Service)
    •

  • SLS Destination: 239.255.14.100:6000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: . (ROUTE)
    •

  • Hidden: Yes
    •

  • Hide in Guide: Yes
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5007"></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item></metadataEnvelope>




Service 5009: GMLOOP (2.20)








Protocol: ROUTE

Category: App-Based Service


Source: 172.16.200.1

Destination: 239.255.2.20:5000


Hidden: No

App: GameLoop




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:Gameloop:KUTV
    •

  • Category: 3 (App-Based Service)
    •

  • SLS Destination: 239.255.2.20:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: . (ROUTE)
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5009"></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>


HTML Entry-point Description (HELD) Instance 1

Raw XML
<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tag:sinclairplatform.com,2020:Gameloop:KUTV" bbandEntryPageUrl="https://nextgen.gameloop.tv/run3tv-common/index.html"></HTMLEntryPackage>
</HELD>




Service 5010: PBTV (2.11) Internet Required








Protocol: ROUTE

Category: Linear A/V Service


Source: 172.16.200.1

Destination: 239.255.2.11:5000


Video: 1920x1080p (59.94 fps)

Codec: hev1.2.4.L123.B0


Audio: 2 ch @ 384 kbps

Codec: ac-4.02.01.00


Hidden: No

App: No




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:PBTV:KUTV
    •

  • Category: 1 (Linear A/V Service)
    •

  • SLS Destination: 239.255.2.11:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: 0.0 (ROUTE)
    •

  • Broadband Required: Yes
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<?xml version="1.0" encoding="utf-8"?><BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5010"><DeliveryMethod><UnicastAppService><BasePattern>a0-24-</BasePattern><BasePattern>d0-Data3_5-</BasePattern><BasePattern>video-Video1_1-</BasePattern><BasePattern>video-Video1_2-</BasePattern><BasePattern>video-Video1_3-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="5"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="173"></item></metadataEnvelope>


Media Presentation Description (MPD) Instance 1 (Published: 2025-05-01T17:12:05Z)

Type: dynamic

Min Buffer Time: PT10S

Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015



Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)


Representation ID: Video1_3


  • Bandwidth: 1000000 (1000 kbps)
    •

  • Codecs: hev1.2.4.L93.B0
    •

  • Resolution: 960x540 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=419068671141120, d=480480, r=29


Representation ID: Video1_2


  • Bandwidth: 4000000 (4.0 Mbps)
    •

  • Codecs: hev1.2.4.L120.B0
    •

  • Resolution: 1280x720 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=419068671141120, d=480480, r=29


Representation ID: Video1_1


  • Bandwidth: 8000000 (8.0 Mbps)
    •

  • Codecs: hev1.2.4.L123.B0
    •

  • Resolution: 1920x1080 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=419068671141120, d=480480, r=29


Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)


Representation ID: 24


  • Bandwidth: 384000 (384 kbps)
    •

  • Codecs: ac-4.02.01.00
    •

  • Audio Sample Rate: 48000 Hz
    •

  • Audio Channels: 2
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=419068671141120, d=480480, r=29


Adaptation Set (Content: text, Mime: application/mp4)


Representation ID: Data3_5


  • Bandwidth: 50000 (50 kbps)
    •

  • Codecs: stpp.ttml.im1t
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=419068671141120, d=480480, r=29


Raw XML
<?xml version="1.0" encoding="UTF-8"?><MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-05-01T17:12:05Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://kutv-sbgtv.atsc.stream/pickleball/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="540" minWidth="960" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="419068671141120"/>            </SegmentTimeline>         </SegmentTemplate>                                 <Representation bandwidth="1000000" codecs="hev1.2.4.L93.B0" frameRate="60000/1001" height="540" id="Video1_3" sar="1:1" scanType="progressive" width="960"/><Representation bandwidth="4000000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_2" sar="1:1" scanType="progressive" width="1280"/><Representation bandwidth="8000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="419068671141120"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.00" id="24"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="419068671141120"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_5"/></AdaptationSet>   </Period></MPD>




Other Global LLS Tables


Unlinked User Defined Service Table (UDST)


BroadSpan Service: DDAAS


BroadSpan Service:




  • Reservation Name: RTK
    •

  • Service ID in UDST: 5008
    •

  • Destination: 239.255.14.103:6123
    •

  • Order ID: 2025-03-21-RTK-Route-3
    •



Raw XML
<?xml version="1.0" encoding="UTF-8"?>
<UDST version="0.1">
    <UDS>
        <broadSpanServices>
            <broadSpanService name="DDAAS"/>
            <broadSpanService>
                <rsrv apiKey="" callbackUrl="" destIP="239.255.14.103" destPort="6123" mktid="" name="RTK" orderId="2025-03-21-RTK-Route-3" srvid="5008"/>
            </broadSpanService>
        </broadSpanServices>
        <broadSpanServices/>
    </UDS>
</UDST>



System Time Details - Actual Timestamp in L1Detail




AttributeValue



currentUtcOffset37


utcLocalOffset-PT6H


dsStatusfalse




Raw XML
<?xml version="1.0" encoding="utf-8"?>
<SystemTime xmlns="http://www.atsc.org/XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/ SYSTIME-1.0-20211208.xsd" currentUtcOffset="37" utcLocalOffset="-PT6H" dsStatus="false"/>



Input Info




AttributeValue



Input TypePCAP File


File Name36607-0-20250501-131204-p0p1-ipv4.pcap


Total Packets Processed46290


Capture Duration21.4 seconds


File Last Modified2025-05-01 13:12:04 EDT


Analysis Run Time2025-11-22 06:00:25 EST




ATSC 3.0 Data Usage Analysis





IP:Port (ID)Usage ↓ServiceTypeTotal DataBitrate



  239.255.2.1:5001 (TSI 100)

 17.74%
  KUTV
  Video
  13.82 MB
  5.16 Mbps




  239.255.4.1:5001 (TSI 100)

 17.60%
  KTVX
  Video
  13.71 MB
  5.12 Mbps




  239.255.14.1:5001 (PID 100)

 17.55%
  KJZZ
  Video
  13.67 MB
  5.10 Mbps




  239.255.30.1:5001 (TSI 100)

 17.45%
  KUCW
  Video
  13.59 MB
  5.07 Mbps




  239.255.14.1:5001 (PID 200)

 1.65%
  KJZZ
  Audio
  1.28 MB
  479.2 Kbps




  239.255.2.1:5001 (TSI 1006)

 1.64%
  KUTV
  ROUTE Media
  1.28 MB
  477.9 Kbps




  239.255.14.1:5001 (PID 28321)

 1.56%
  KJZZ
  Data/Captions
  1.22 MB
  453.7 Kbps




  239.255.2.1:5001 (TSI 200)

 1.56%
  KUTV
  Audio
  1.21 MB
  453.1 Kbps




  239.255.2.1:5001 (TSI 0)

 0.63%
  KUTV
  Service Signaling
  490.1 KB
  183.0 Kbps




  239.255.30.1:5001 (TSI 0)

 0.54%
  KUCW
  Service Signaling
  422.6 KB
  157.8 Kbps




  239.255.4.1:5001 (TSI 0)

 0.52%
  KTVX
  Service Signaling
  403.0 KB
  150.5 Kbps




  239.255.30.1:5001 (TSI 200)

 0.36%
  KUCW
  Audio
  283.8 KB
  106.0 Kbps




  239.255.4.1:5001 (TSI 200)

 0.36%
  KTVX
  Audio
  281.8 KB
  105.2 Kbps




  239.255.14.1:5001 (PID 201)

 0.26%
  KJZZ
  Audio
  200.6 KB
  74.9 Kbps




  239.255.14.1:5100 (TSI 0)

 0.22%
  ESG
  Service Signaling
  171.2 KB
  63.9 Kbps




  239.255.30.1:5001 (TSI 201)

 0.20%
  KUCW
  Audio
  155.5 KB
  58.0 Kbps




  239.255.4.1:5001 (TSI 201)

 0.20%
  KTVX
  Audio
  155.3 KB
  58.0 Kbps




  239.255.2.1:5001 (TSI 201)

 0.19%
  KUTV
  Audio
  147.3 KB
  55.0 Kbps




  239.255.14.1:5001 (PID 0)

 0.17%
  KJZZ
  Service Signaling
  130.7 KB
  48.8 Kbps




  239.255.14.1:5100 (TSI 60)

 0.17%
  ESG
  ROUTE Media
  128.8 KB
  48.1 Kbps




  239.255.14.1:5100 (TSI 50)

 0.16%
  ESG
  ROUTE Media
  127.8 KB
  47.7 Kbps




  239.255.14.1:5100 (TSI 80)

 0.16%
  ESG
  ROUTE Media
  126.7 KB
  47.3 Kbps




  239.255.2.11:5000 (TSI 0)

 0.15%
  PBTV
  Service Signaling
  115.4 KB
  43.1 Kbps




  239.255.2.10:5001 (TSI 0)

 0.13%
  T2
  Service Signaling
  101.0 KB
  37.7 Kbps




  239.255.14.103:6123

 0.13%
  Unknown Service
  Other UDP
  98.8 KB
  36.9 Kbps




  224.0.23.60:4937 (LLS)

 0.12%
  LLS Signaling
  LLS Signaling
  96.1 KB
  35.9 Kbps




  239.255.2.1:5001 (TSI 1004)

 0.10%
  KUTV
  ROUTE Media
  77.0 KB
  28.7 Kbps




  239.255.4.1:5001 (TSI 300)

 0.10%
  KTVX
  Captions
  74.4 KB
  27.8 Kbps




  239.255.30.1:5001 (TSI 300)

 0.09%
  KUCW
  Captions
  71.2 KB
  26.6 Kbps




  239.255.2.20:5000 (TSI 0)

 0.09%
  GMLOOP
  Service Signaling
  68.9 KB
  25.7 Kbps




  239.255.14.100:6000 (TSI 0)

 0.07%
  DDAAS
  Service Signaling
  58.0 KB
  21.6 Kbps




  239.255.2.1:5001 (TSI 300)

 0.06%
  KUTV
  Captions
  46.8 KB
  17.5 Kbps




  239.255.14.1:5001 (PID 300)

 0.05%
  KJZZ
  stpp
  40.7 KB
  15.2 Kbps






Total: 77.89 MB | Signaling: 2.64% | Media: 79.21% | Other: 0.13%
