RENDER - RabbitEars NextGen Data Evaluator Report - v0.2.1

Physical Layer Pipes - 2 PLPs (L1 BSID: Not Set)

PLP IDSFIModulationCode RateLayerTI ModeLLSLockRequired SNRBitrate
00qam169/15corehtiYesYesAWGN: 7.32-7.58 dB
Rayleigh: 9.94-10.28 dB		N/A
10qam25611/15corehtiYesYesAWGN: 18.76-19.08 dB
Rayleigh: 21.94-22.40 dB		N/A
L1 Detail Information Not Available
Link Mapping Table Data Not Available

Service Summary (SLT BSID: 3102)

Service NameIDChannelProtocol / CategorySLS Destination
T2 Internet Required50014.10ROUTE / Linear A/V Service239.255.4.10:5000
PBTV Internet Required50024.11ROUTE / Linear A/V Service239.255.4.11:5000
KIRO Encrypted50037.1ROUTE / Linear A/V Service239.255.7.1:5001
ESG5004ROUTE / ESG Service239.255.51.1:5100
KUNS500551.1MMT / Linear A/V Service239.255.51.1:5001
DDAAS Hidden5006ROUTE / App-Based Service239.255.51.100:6000
KOMO50074.1ROUTE / Linear A/V Service239.255.4.1:5001
GMLOOP50084.20ROUTE / App-Based Service239.255.4.20:5000
KBTC-VC Internet Required500928.11ROUTE / Linear A/V Service239.255.28.11:5000
ROXi50104.21ROUTE / App-Based Service239.255.4.21:5000
Capability Descriptor Table (CDT) - 3 Certificate(s)
AttributeValue
OCSP RefreshP7DT0H
Certificate Count3

Certificate Details

Certificate 1 - KUNS-TV Signalling Signing CDT 0001 (Valid Until: Sep 2 2026)
FieldValue
Subject/C=US/ST=Washington/L=Seattle/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=KUNS-TV Signalling Signing CDT 0001
Issuer/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number220752B7704A72E207F729C3B248C631BC3FBCCF
Valid FromSep 2 16:55:58 2025 GMT
Valid UntilSep 2 16:55:58 2026 GMT
Signature Algorithmsha256WithRSAEncryption
Public KeyRSA (3072 bits)
SHA-1 Fingerprint15:B0:C4:5E:5A:F0:B1:B6:65:32:9D:CC:E8:F3:AE:64:7C:07:F8:FA
SHA-256 Fingerprint34:4F:12:D6:B5:6E:1C:E8:1E:75:A9:DD:8B:C1:78:E5:FE:D5:A9:2C:9A:3C:9A:C6:43:A0:95:37:C8:60:01:
Certificate AuthorityNo
Self-SignedNo
Certificate 2 - KUNS-TV Signalling Signing SMT 0001 (Valid Until: Sep 2 2026)
FieldValue
Subject/C=US/ST=Washington/L=Seattle/O=Sinclair Broadcast Group, Inc./OU=Sinclair Broadcast Group, Inc/CN=KUNS-TV Signalling Signing SMT 0001
Issuer/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Serial Number260B16F22F7E5101290DAA02BD1AD020750FAECC
Valid FromSep 2 16:56:00 2025 GMT
Valid UntilSep 2 16:56:00 2026 GMT
Signature Algorithmsha256WithRSAEncryption
Public KeyRSA (3072 bits)
SHA-1 FingerprintC4:EA:BD:C8:DE:9A:6D:21:89:62:E2:6A:8D:87:80:AD:18:BA:0A:03
SHA-256 FingerprintCF:9B:10:3D:0F:BD:55:EA:26:54:4B:9B:C9:14:A3:09:D1:E9:E1:BB:5A:C4:E2:E9:E6:A4:0E:9C:20:C9:97:
Certificate AuthorityNo
Self-SignedNo
Certificate 3 - ATSC 3.0 Signing CA-2 (Valid Until: Sep 8 2030)
FieldValue
Subject/C=US/O=ATSC 3.0 Security Authority LLC/OU=Signing CA-DC1/CN=ATSC 3.0 Signing CA-2
Issuer/C=US/O=Pearl TV/OU=Root CA-1/CN=ATSC3 Root-CA
Serial Number1D81C0A269A03D9AAF128428593DB6B8
Valid FromSep 8 00:00:00 2021 GMT
Valid UntilSep 8 23:59:59 2030 GMT
Signature Algorithmsha512WithRSAEncryption
Public KeyRSA (3072 bits)
SHA-1 Fingerprint06:63:9A:0C:E9:C0:E7:2C:44:05:1C:8A:91:B6:68:FB:25:C4:38:75
SHA-256 Fingerprint23:42:5B:1C:CA:CB:F3:31:7C:8B:03:59:DA:E0:A3:98:C4:84:05:DB:1B:6B:92:15:58:69:F7:89:30:9A:65:
Certificate AuthorityYes
Self-SignedNo
Raw XML
<?xml version="1.0" encoding="UTF-8"?>
<CertificationData xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/CDT/1.0/CDT-1.0-20180706.xsd">
<ToBeSignedData OCSPRefresh="P7DT0H"><Certificates>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</Certificates><Certificates>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</Certificates><Certificates>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</Certificates><CurrentCert>hNgZ84eLhnCktXMj39W9uhE4BFs=</CurrentCert></ToBeSignedData>
<CMSSignedData>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</CMSSignedData>
<OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse><OCSPResponse>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</OCSPResponse>
</CertificationData>
Service List Table (SLT) Instance 1 - Raw XML
<?xml version="1.0" encoding="UTF-8"?>
<SLT bsid="3102" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SLT/1.0/ SLT-1.0-20211209.xsd">
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:T2:KOMO" majorChannelNo="4" minorChannelNo="10" serviceCategory="1" serviceId="5001" shortServiceName="T2" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.4.10" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="tag:sinclairplatform.com,2020:PBTV:KOMO" majorChannelNo="4" minorChannelNo="11" serviceCategory="1" serviceId="5002" shortServiceName="PBTV" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.4.11" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service drmSystemID="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" globalServiceID="https://doi.org/10.5239/25B9-59FC" majorChannelNo="7" minorChannelNo="1" protected="true" serviceCategory="1" serviceId="5003" shortServiceName="KIRO" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.7.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service serviceCategory="4" serviceId="5004" shortServiceName="ESG" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.51.1" slsDestinationUdpPort="5100" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:KUNS:3103" majorChannelNo="51" minorChannelNo="1" serviceCategory="1" serviceId="5005" shortServiceName="KUNS" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.51.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="2" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:broadspanwireless.com,2023:3102:KUNS-TV:3103" hidden="true" hideInGuide="true" serviceCategory="3" serviceId="5006" shortServiceName="DDAAS" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.51.100" slsDestinationUdpPort="6000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:KOMO:3123" majorChannelNo="4" minorChannelNo="1" serviceCategory="1" serviceId="5007" shortServiceName="KOMO" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.4.1" slsDestinationUdpPort="5001" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service configuration="Broadcast" globalServiceID="tag:sinclairplatform.com,2020:Gameloop:KOMO" majorChannelNo="4" minorChannelNo="20" serviceCategory="3" serviceId="5008" shortServiceName="GMLOOP" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.4.20" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service broadbandAccessRequired="true" configuration="Broadband" globalServiceID="https://doi.org/10.5239/3E28-EDFE" majorChannelNo="28" minorChannelNo="11" serviceCategory="1" serviceId="5009" shortServiceName="KBTC-VC" sltSvcSeqNum="0">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.28.11" slsDestinationUdpPort="5000" slsMajorProtocolVersion="0" slsMinorProtocolVersion="0" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
    <Service globalServiceID="tag:sinclairplatform.com,2020:Roxi:komo" majorChannelNo="4" minorChannelNo="21" serviceCategory="3" serviceId="5010" shortServiceName="ROXi" sltSvcSeqNum="1">
        <BroadcastSvcSignaling slsDestinationIpAddress="239.255.4.21" slsDestinationUdpPort="5000" slsProtocol="1" slsSourceIpAddress="172.16.200.1"/>
    </Service>
</SLT>

Service 5001: T2 (4.10) Internet Required

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.4.10:5000
Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0
Audio: 2 ch @ 192 kbps
Codec: ac-4.02.01.00
Hidden: No
App: No
Service Details (from SLT)
  • Global Service ID: tag:sinclairplatform.com,2020:T2:KOMO
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.4.10:5000
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
  • Broadband Required: Yes
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5001"><DeliveryMethod><UnicastAppService><BasePattern>a0-22-</BasePattern><BasePattern>d0-Data3_3-</BasePattern><BasePattern>video-Video1_1-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="17"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="13"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-10-14T22:43:33Z)
Type: dynamic
Min Buffer Time: PT10S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1
  • Bandwidth: 7000000 (7.0 Mbps)
  • Codecs: hev1.2.4.L123.B0
  • Resolution: 1920x1080 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Timescale: 240000
    • S: t=422515619766240, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 22
  • Bandwidth: 192000 (192 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Timescale: 240000
    • S: t=422515619770244, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_3
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Timescale: 240000
    • S: t=422515619766240, d=480480, r=29

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-10-14T22:43:33Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://komo-sbgtv.atsc.stream/t2/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422515619766240"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="7000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422515619770244"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="192000" codecs="ac-4.02.01.00" id="22"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422515619766240"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_3"/></AdaptationSet>   </Period></MPD>

Service 5002: PBTV (4.11) Internet Required

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.4.11:5000
Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0
Audio: 2 ch @ 384 kbps
Codec: ac-4.02.01.00
Hidden: No
App: No
Service Details (from SLT)
  • Global Service ID: tag:sinclairplatform.com,2020:PBTV:KOMO
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.4.11:5000
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
  • Broadband Required: Yes
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5002"><DeliveryMethod><UnicastAppService><BasePattern>a0-24-</BasePattern><BasePattern>d0-Data3_5-</BasePattern><BasePattern>video-Video1_1-</BasePattern><BasePattern>video-Video1_2-</BasePattern><BasePattern>video-Video1_3-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="10"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="158"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-10-14T22:43:33Z)
Type: dynamic
Min Buffer Time: PT10S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_3
  • Bandwidth: 1000000 (1000 kbps)
  • Codecs: hev1.2.4.L93.B0
  • Resolution: 960x540 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Timescale: 240000
    • S: t=422515619766240, d=480480, r=29
Representation ID: Video1_2
  • Bandwidth: 4000000 (4.0 Mbps)
  • Codecs: hev1.2.4.L120.B0
  • Resolution: 1280x720 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Timescale: 240000
    • S: t=422515619766240, d=480480, r=29
Representation ID: Video1_1
  • Bandwidth: 8000000 (8.0 Mbps)
  • Codecs: hev1.2.4.L123.B0
  • Resolution: 1920x1080 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Timescale: 240000
    • S: t=422515619766240, d=480480, r=29

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: 24
  • Bandwidth: 384000 (384 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Timescale: 240000
    • S: t=422515619770244, d=480480, r=29

Adaptation Set (Content: text, Mime: application/mp4)

Representation ID: Data3_5
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Timescale: 240000
    • S: t=422515619766240, d=480480, r=29

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-10-14T22:43:33Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://komo-sbgtv.atsc.stream/pickleball/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="540" minWidth="960" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422515619766240"/>            </SegmentTimeline>         </SegmentTemplate>                                 <Representation bandwidth="1000000" codecs="hev1.2.4.L93.B0" frameRate="60000/1001" height="540" id="Video1_3" sar="1:1" scanType="progressive" width="960"/><Representation bandwidth="4000000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_2" sar="1:1" scanType="progressive" width="1280"/><Representation bandwidth="8000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422515619770244"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="384000" codecs="ac-4.02.01.00" id="24"/></AdaptationSet><AdaptationSet contentType="text" id="2" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate initialization="d0-$RepresentationID$-init.mp4" media="d0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422515619766240"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data3_5"/></AdaptationSet>   </Period></MPD>

Service 5003: KIRO (7.1) Encrypted

Protocol: ROUTE
Category: Linear A/V Service
Source: 172.16.200.1
Destination: 239.255.7.1:5001
Video: 1920x1080p (59.94 fps)
Codec: hev1.2.4.L123.B0
Audio: 6 ch @ 96 kbps +1 additional audio stream
Codec: ac-4.02.01.01
Hidden: No
App: Run3TV
Service Details (from SLT)
  • Global Service ID: https://doi.org/10.5239/25B9-59FC
  • Category: 1 (Linear A/V Service)
  • SLS Destination: 239.255.7.1:5001
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
  • Protected: Yes
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5003"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: :

TSIRepresentation IDContent TypeContent Ratings
100Video1_1videoN/A
200a02_2audioN/A
201a13_3audioN/A
300d4_4subtitlesN/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="8000000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="96000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="56"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="23"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="172"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>
Media Presentation Description (MPD) Instance 1 (Published: 2025-10-14T22:43:33Z)
Type: dynamic
Min Buffer Time: PT2S
Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015

Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)

Representation ID: Video1_1
  • Bandwidth: 8000000 (8.0 Mbps)
  • Codecs: hev1.2.4.L123.B0
  • Resolution: 1920x1080 (16:9)
  • Frame Rate: 60000/1001 (59.94 fps)
  • Scan Type: progressive
  • Sample Aspect Ratio: 1:1
  • Segment Template:
    • Initialization: video-init.mp4
    • Media URL: video-$Number$.mp4v
    • Timescale: 240000, Duration: 480480, Start: 1
  • DRM Protection:

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)

Representation ID: a02_2
  • Bandwidth: 96000 (96 kbps)
  • Codecs: ac-4.02.01.01
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 6
  • Segment Template:
    • Initialization: a0-$RepresentationID$-init.mp4
    • Media URL: a0-$RepresentationID$-$Number$.m4s
    • Timescale: 240000, Duration: 480480, Start: 1
  • DRM Protection:

Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)

Representation ID: a13_3
  • Bandwidth: 48000 (48 kbps)
  • Codecs: ac-4.02.01.00
  • Audio Sample Rate: 48000 Hz
  • Audio Channels: 2
  • Segment Template:
    • Initialization: a1-$RepresentationID$-init.mp4
    • Media URL: a1-$RepresentationID$-$Number$.m4s
    • Timescale: 240000, Duration: 480480, Start: 1
  • DRM Protection:

Adaptation Set (Content: text, Mime: application/mp4, Lang: und)

Representation ID: d4_4
  • Bandwidth: 50000 (50 kbps)
  • Codecs: stpp.ttml.im1t
  • Segment Template:
    • Initialization: $RepresentationID$-init.mp4
    • Media URL: $RepresentationID$-$Number$.m4s
    • Timescale: 240000, Duration: 480480, Start: 1

Raw XML

<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT6S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-10-14T22:43:33Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="ee23171e-0a22-5ed6-91e1-4f4c39daee7d" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="ee23171e-0a22-5ed6-91e1-4f4c39daee7d" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>AAAASnBzc2gAAAAA7e+LqXnWSs6jyCfc1R0h7QAAACoiDGtpcm9fZzJfcDJfMUjj3JWbBmoUYXRzY19ncm91cDJfcHJvZmlsZTIAAAJocHNzaAAAAADt74upedZKzqPIJ9zVHSHtAAACSCIMa2lyb19nMl9wMl8xSOPclZsGWAJqFGF0c2NfZ3JvdXAyX3Byb2ZpbGUyclgKEP7gAsN/EFDkj25Kv3Xfh9QSEO4jFx4KIl7WkeFPTDna7n0aIM/CZe8RZJZGoZ1W8kjugsVSAsU0aXai1IaUoEP5EIrOIhCCqLcFXCugxcoCepexs3HSclgKEMtonnMvM1NbiAzYoZigpGUSEO4jFx4KIl7WkeFPTDna7n0aIMJMsjKYEFBYcQi9JZKfvf47bBi9rDvYwBv+18qHNmuqIhBjKog3a5YDre8DWJ1FtQQwclgKEOCAdqv9plL8l0C2R1YSllkSEGoaHT/dQFRGnTo69+CUZxAaIPNlRMcc0v4iMSCD16Ixp3womw7IFdSqz1aStPiVKlQxIhDxLMrxOoxJC5mOFu9ZeRciclgKEAqxnRcP+VBvjQwDq2QUA5QSEGoaHT/dQFRGnTo69+CUZxAaIDbOLiQL97pu1YvOBWCQ0+vcsWo+mhbecXF6EnUe6CK8IhDNaHowN+aSwuqYa0/HKwFMclgKEPZU0e3uVV1vg0z/fbUICDgSEPxkn9MYF1DDiunwTKPbP8saIA8lR05QMktDD5uMbCN7+qCA2Izv739XgF+QXMaWVNvZIhBAhcEOWPpZQP/OVtV1OCfbclgKEHg5LB43JVKIjuApVhHyY3wSEPxkn9MYF1DDiunwTKPbP8saIAEw5aB6TYpSaWZUKraLE8ACnK9POxKluS52agZMgQIrIhDlE0GX4Zw5Uobsw/NKruqg</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kiro_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="8000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="ee23171e-0a22-5ed6-91e1-4f4c39daee7d" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="ee23171e-0a22-5ed6-91e1-4f4c39daee7d" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kiro_g2_p2_1</dashif:Laurl>         </ContentProtection>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="6"/>               <Representation audioSamplingRate="48000" bandwidth="96000" codecs="ac-4.02.01.01" id="a02_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1" xmlns:cenc="urn:mpeg:cenc:2013">         <ContentProtection cenc:default_KID="ee23171e-0a22-5ed6-91e1-4f4c39daee7d" schemeIdUri="urn:mpeg:dash:mp4protection:2011" value="cenc"/>         <ContentProtection cenc:default_KID="ee23171e-0a22-5ed6-91e1-4f4c39daee7d" schemeIdUri="urn:uuid:edef8ba9-79d6-4ace-a3c8-27dcd51d21ed" value="Widevine">            <cenc:pssh>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</cenc:pssh>            <dashif:Laurl licenseType="groupLicense-1.0">file://atsc_group2_profile2.lic</dashif:Laurl>            <dashif:Laurl licenseType="license-1.0">https://drm-license.a3sa.yottacloud.tv/v1/wv/license?content_id=kiro_g2_p2_1</dashif:Laurl>         </ContentProtection>         <SegmentTemplate duration="480480" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" lang="und" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>
HTML Entry-point Description (HELD) Instance 1

Raw XML

<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tv:nextgentv.cmg.com" bbandEntryPageUrl="https://nextgentv.cmg.com/run3tv-common/index.html" ></HTMLEntryPackage>
</HELD>

Service 5004: ESG

Protocol: ROUTE
Category: ESG Service
Source: 172.16.200.1
Destination: 239.255.51.1:5100
Hidden: No
App: No
Service Details (from SLT)
  • Global Service ID:
  • Category: 4 (ESG Service)
  • SLS Destination: 239.255.51.1:5100
  • SLS Source: 172.16.200.1
  • SLS Protocol Version: 0.0 (ROUTE)
User Service Description (ROUTE) Instance 1
Content TypeVersionUser AgentFilter Codes

Raw XML

<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5004"></UserServiceDescription></BundleDescriptionROUTE>
S-TSID (Stream Description) Instance 1

ROUTE Stream: 239.255.51.1:5100

TSIRepresentation IDContent TypeContent Ratings
50N/A
60N/A
80N/A

Raw XML

<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS sIpAddr="172.16.200.1" dIpAddr="239.255.51.1" dPort="5100"><LS tsi="50"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="1633" Content-Location="sgdd_1633" Content-Length="42314" Transfer-Length="4206" Content-Type="application/vnd.oma.bcast.sgdd+xml" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="60"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="3112" Content-Location="sgdu_content_3112" Content-Length="287050" Transfer-Length="25844" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File><fdt:File TOI="4143" Content-Location="sgdu_service_schedule_4143" Content-Length="57583" Transfer-Length="4934" Content-Type="application/vnd.oma.bcast.sgdu" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="80"><SrcFlow><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="0"><fdt:File TOI="5703" Content-Location="s28711_h3_ba.png" Content-Length="9147" Transfer-Length="8389" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5704" Content-Location="s51306_ll_h15_ac.png" Content-Length="6025" Transfer-Length="5795" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5705" Content-Location="s28708_ll_h15_ac.png" Content-Length="16622" Transfer-Length="16457" Content-Encoding="gzip"></fdt:File><fdt:File TOI="5706" Content-Location="s32356_ll_h15_ac.png" Content-Length="12457" Transfer-Length="12112" Content-Encoding="gzip"></fdt:File></FDT-Instance></EFDT><Payload codePoint="1" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>
Service Signaling (Metadata Envelope) 1
Content TypeVersion

Raw XML

<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="9"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="574"></item></metadataEnvelope>
Electronic Service Guide (ESG) - 4 Service(s), 312 Program(s) (from 320 fragments)
Service : KBTC-VC (28.11)
FieldValue
IDurn:digicap:svc:5009:1760456956698
Statushttps://doi.org
DescriptionKBTC-VC
Raw XML (0 fragments)


Service : KOMO (4.1)



FieldValue
IDurn:digicap:svc:5007:1760456956698
Statustag:sinclairpla
DescriptionKOMO
Raw XML (0 fragments)


Service : KUNS (51.1)



FieldValue
IDurn:digicap:svc:5005:1760456956698
Statustag:sinclairpla
DescriptionKUNS
Raw XML (0 fragments)


Service : KIRO (7.1)



FieldValue
IDurn:digicap:svc:5003:1760456956698
Statushttps://doi.org
DescriptionKIRO
Raw XML (0 fragments)






Service 5005: KUNS (51.1)








Protocol: MMT

Category: Linear A/V Service


Source: 172.16.200.1

Destination: 239.255.51.1:5001


Video:

Codec: hev1.2.X.L123.X


Audio: 6 ch

Codec: ac-4.02.01.00


Hidden: No

App: Run3TV




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:KUNS:3103
    •

  • Category: 1 (Linear A/V Service)
    •

  • SLS Destination: 239.255.51.1:5001
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: 0.0 (MMT)
    •





User Service Bundle Description (USBD) Instance 1



IDContent TypeVersion



5005UserServiceDescription1.0


Raw XML
<?xml version="1.0" encoding="utf-8"?><BundleDescriptionMMT xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/MMTUSD/1.0/" xmlns:sa="tag:atsc.org,2016:XMLSchemas/ATSC3/SA/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/MMTUSD/1.0/ MMTUSD-1.0-20210401.xsd"><UserServiceDescription serviceId="5005"><Channel serviceIcon="service_icon"><ServiceDescription serviceDescrText="KUNS" serviceDescrLang=""></ServiceDescription><ServiceDescription serviceDescrText="TBD" serviceDescrLang="en"></ServiceDescription></Channel><MPUComponent mmtPackageId="mmt"></MPUComponent><ComponentInfo componentType="1" componentRole="0" componentProtectedFlag="false" componentId="videoasset01"></ComponentInfo><ComponentInfo componentType="0" componentRole="0" componentProtectedFlag="false" componentId="audioasset02"></ComponentInfo><ComponentInfo componentType="2" componentRole="0" componentProtectedFlag="false" componentId="subtitleasset03"></ComponentInfo></UserServiceDescription></BundleDescriptionMMT>


User Service Description (USD) -



FieldValue
Service ID5005
MMT Package IDmmt
Components:
Component IDTypeRoleDescription
videoasset0110Main Video
audioasset0200Main Audio
subtitleasset0320Main Data/Captions
Raw XML
<?xml version="1.0" encoding="UTF-8"?><UserServiceDescription serviceId="5005">
  <Channel serviceIcon="service_icon">
    <ServiceDescription serviceDescrText="KUNS" serviceDescrLang=""/>
    <ServiceDescription serviceDescrText="TBD" serviceDescrLang="en"/>
  </Channel>
  <MPUComponent mmtPackageId="mmt"/>
  <ComponentInfo componentType="1" componentRole="0" componentProtectedFlag="false" componentId="videoasset01"/>
  <ComponentInfo componentType="0" componentRole="0" componentProtectedFlag="false" componentId="audioasset02"/>
  <ComponentInfo componentType="2" componentRole="0" componentProtectedFlag="false" componentId="subtitleasset03"/>
</UserServiceDescription>


MMT Signaling (MP Table - Binary)

Binary MMT Package Table


Asset IDAsset TypeCodecPacket ID



videoasset01hev1HEVC/H.265100


audioasset02ac-4AC-4 Audio200


subtitleasset03stppTTML Subtitles300




HTML Entry-point Description (HELD) Instance 1

Raw XML
<?xml version="1.0" encoding="UTF-8"?><HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d3o3enj75dempy.cloudfront.net/run3tv-common/index.html"   appContextId="tag:sinclairplatform.com,2020:KUNS:3103" />
</HELD>


MMT Stream Descriptors Instance 1



Video Stream Properties Descriptor (VSPD)




  • Codec: hev1.2.2.L123.B (HEVC/H.265)
    •

  • HEVC Profile: Main 10 (supports 10-bit color depth for HDR content)
    •

  • HEVC Level: 4.1 (defines maximum resolution, frame rate, and bitrate capabilities)
    •

  • Tier: Main (Main tier: standard bitrates, High tier: allows higher bitrates)
    •

  • Scan Type: Progressive (full frames, better quality)
    •



Audio Stream Properties Descriptor (ASPD)




  • Codec: ac-4 (Dolby AC-4 - next-generation audio codec)
    •

  • Language: es
    •

  • Presentations: 1 (separate audio mixes, e.g., main, commentary, descriptive)
    •

  • Sample Rate: 48000 Hz
    •



Caption Asset Descriptor (CAD)




  • Caption Track 1:


    • Role: main (primary captions)
      •

    • Aspect Ratio: 16:9
      •

    • Profile: text (text-based captions)
      •

    •







Service 5006: DDAAS Hidden








Protocol: ROUTE

Category: App-Based Service


Source: 172.16.200.1

Destination: 239.255.51.100:6000


Hidden: Service & Guide

App: No




Service Details (from SLT)





  • Global Service ID: tag:broadspanwireless.com,2023:3102:KUNS-TV:3103
    •

  • Category: 3 (App-Based Service)
    •

  • SLS Destination: 239.255.51.100:6000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: . (ROUTE)
    •

  • Hidden: Yes
    •

  • Hide in Guide: Yes
    •





Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<?xml version="1.0" encoding="utf-8"?><metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"></metadataEnvelope>




Service 5007: KOMO (4.1)








Protocol: ROUTE

Category: Linear A/V Service


Source: 172.16.200.1

Destination: 239.255.4.1:5001


Video: 1280x720p (59.94 fps)

Codec: hev1.2.4.L120.B0


Audio: 16 ch @ 448 kbps +1 additional audio stream

Codec: ac-4.02.01.02


Hidden: No

App: Run3TV




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:KOMO:3123
    •

  • Category: 1 (Linear A/V Service)
    •

  • SLS Destination: 239.255.4.1:5001
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: 0.0 (ROUTE)
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5007"><DeliveryMethod><BroadcastAppService><BasePattern>a0-a02_2-</BasePattern><BasePattern>a1-a13_3-</BasePattern><BasePattern>d4_4-</BasePattern><BasePattern>video-</BasePattern></BroadcastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>


S-TSID (Stream Description) Instance 1

ROUTE Stream: :


TSIRepresentation IDContent TypeContent Ratings



100Video1_1videoN/A


200a02_2audioN/A


201a13_3audioN/A


300d4_4subtitlesN/A


Raw XML
<S-TSID xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/" xmlns:afdt="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:fdt="urn:ietf:params:xml:ns:fdt" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/S-TSID/1.0/ S-TSID-1.0-20210411.xsd tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ATSC-FDT/1.0/ ATSC-FDT-1.0-20210428.xsd urn:3GPP:metadata:2007:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2007-Extensions.xsd urn:3GPP:metadata:2012:MBMS:FLUTE:FDT 3GPP/FLUTE-FDT-3GPP-2012-Extensions.xsd"><RS><LS tsi="100"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="8000000" afdt:fileTemplate="video-$TOI$.mp4v"><fdt:File TOI="1" Content-Location="video-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="video" repId="Video1_1"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="200"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="448000" afdt:fileTemplate="a0-a02_2-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a0-a02_2-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a02_2"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="201"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="48000" afdt:fileTemplate="a1-a13_3-$TOI$.m4s"><fdt:File TOI="1" Content-Location="a1-a13_3-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="audio" repId="a13_3"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS><LS tsi="300"><SrcFlow rt="true"><EFDT><FDT-Instance Expires="4294967295" afdt:efdtVersion="1" afdt:maxTransportSize="50000" afdt:fileTemplate="d4_4-$TOI$.m4s"><fdt:File TOI="1" Content-Location="d4_4-init.mp4"></fdt:File></FDT-Instance></EFDT><ContentInfo><MediaInfo contentType="subtitles" repId="d4_4"></MediaInfo></ContentInfo><Payload codePoint="8" formatId="1" frag="0" order="true"></Payload></SrcFlow></LS></RS></S-TSID>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="11"></item><item metadataURI="stsid.sls" contentType="application/route-s-tsid+xml" version="13"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="22"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="3"></item></metadataEnvelope>


Media Presentation Description (MPD) Instance 1 (Published: 2025-10-14T21:59:16Z)

Type: dynamic

Min Buffer Time: PT2S

Profiles: urn:mpeg:dash:profile:isoff-broadcast:2015



Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)


Representation ID: Video1_1


  • Bandwidth: 8000000 (8.0 Mbps)
    •

  • Codecs: hev1.2.4.L120.B0
    •

  • Resolution: 1280x720 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:


    • Initialization: video-init.mp4
      •

    • Media URL: video-$Number$.mp4v
      •

    • Timescale: 240000, Duration: 480480, Start: 1
      •



Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)


Representation ID: a02_2


  • Bandwidth: 448000 (448 kbps)
    •

  • Codecs: ac-4.02.01.02
    •

  • Audio Sample Rate: 48000 Hz
    •

  • Audio Channels: 16
    •

  • Segment Template:


    • Initialization: a0-$RepresentationID$-init.mp4
      •

    • Media URL: a0-$RepresentationID$-$Number$.m4s
      •

    • Timescale: 240000, Duration: 480480, Start: 1
      •



Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)


Representation ID: a13_3


  • Bandwidth: 48000 (48 kbps)
    •

  • Codecs: ac-4.02.01.00
    •

  • Audio Sample Rate: 48000 Hz
    •

  • Audio Channels: 2
    •

  • Segment Template:


    • Initialization: a1-$RepresentationID$-init.mp4
      •

    • Media URL: a1-$RepresentationID$-$Number$.m4s
      •

    • Timescale: 240000, Duration: 480480, Start: 1
      •



Adaptation Set (Content: text, Mime: application/mp4)


Representation ID: d4_4


  • Bandwidth: 50000 (50 kbps)
    •

  • Codecs: stpp.ttml.im1t
    •

  • Segment Template:


    • Initialization: $RepresentationID$-init.mp4
      •

    • Media URL: $RepresentationID$-$Number$.m4s
      •

    • Timescale: 240000, Duration: 480480, Start: 1
      •



Raw XML
<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT2S" minimumUpdatePeriod="PT1H6M44S" profiles="urn:mpeg:dash:profile:isoff-broadcast:2015" publishTime="2025-10-14T21:59:16Z" timeShiftBufferDepth="PT12S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="720" maxWidth="1280" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="720" minWidth="1280" par="16:9" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="video-init.mp4" media="video-$Number$.mp4v" startNumber="1" timescale="240000"/>               <Representation bandwidth="8000000" codecs="hev1.2.4.L120.B0" frameRate="60000/1001" height="720" id="Video1_1" sar="1:1" scanType="progressive" width="1280"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate duration="480480" initialization="a0-$RepresentationID$-init.mp4" media="a0-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="16"/>               <Representation audioSamplingRate="48000" bandwidth="448000" codecs="ac-4.02.01.02" id="a02_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1">         <SegmentTemplate duration="480480" initialization="a1-$RepresentationID$-init.mp4" media="a1-$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="48000" codecs="ac-4.02.01.00" id="a13_3"/></AdaptationSet><AdaptationSet contentType="text" id="3" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1">         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <Accessibility schemeIdUri="urn:mpeg:dash:role:2011" value="caption"/>         <SegmentTemplate duration="480480" initialization="$RepresentationID$-init.mp4" media="$RepresentationID$-$Number$.m4s" startNumber="1" timescale="240000"/>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="d4_4"/></AdaptationSet>   </Period></MPD>


HTML Entry-point Description (HELD) Instance 1

Raw XML
<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://d12znlta0k8cwu.cloudfront.net/run3tv-common/index.html" appContextId="tag:sinclairplatform.com,2020:KOMO:3123" />
</HELD>




Service 5008: GMLOOP (4.20)








Protocol: ROUTE

Category: App-Based Service


Source: 172.16.200.1

Destination: 239.255.4.20:5000


Hidden: No

App: GameLoop




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:Gameloop:KOMO
    •

  • Category: 3 (App-Based Service)
    •

  • SLS Destination: 239.255.4.20:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: . (ROUTE)
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5008"></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="1"></item></metadataEnvelope>


HTML Entry-point Description (HELD) Instance 1

Raw XML
<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage appContextId="tag:sinclairplatform.com,2020:Gameloop:KOMO" bbandEntryPageUrl="https://nextgen.gameloop.tv/run3tv-common/index.html"></HTMLEntryPackage>
</HELD>




Service 5009: KBTC-VC (28.11) Internet Required








Protocol: ROUTE

Category: Linear A/V Service


Source: 172.16.200.1

Destination: 239.255.28.11:5000


Video: 1920x1080p (59.94 fps)

Codec: hev1.2.4.L123.B0


Audio: 2 ch @ 128 kbps +2 additional audio streams

Codec: ac-4.02.01.00


Hidden: No

App: No




Service Details (from SLT)





  • Global Service ID: https://doi.org/10.5239/3E28-EDFE
    •

  • Category: 1 (Linear A/V Service)
    •

  • SLS Destination: 239.255.28.11:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: 0.0 (ROUTE)
    •

  • Broadband Required: Yes
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5009"><DeliveryMethod><UnicastAppService><BasePattern>audio-0-Audio2_2-</BasePattern><BasePattern>audio-1-Audio3_3-</BasePattern><BasePattern>audio-2-Audio4_4-</BasePattern><BasePattern>data-0-Data5_5-</BasePattern><BasePattern>video-Video1_1-</BasePattern></UnicastAppService></DeliveryMethod></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="4"></item><item metadataURI="mpd.mpd" contentType="application/dash+xml" version="19"></item></metadataEnvelope>


Media Presentation Description (MPD) Instance 1 (Published: 2025-10-14T22:43:32Z)

Type: dynamic

Min Buffer Time: PT10S

Profiles: urn:mpeg:dash:profile:isoff-live:2011



Adaptation Set (Content: video, Mime: video/mp4, PAR: 16:9)


Representation ID: Video1_1


  • Bandwidth: 7000000 (7.0 Mbps)
    •

  • Codecs: hev1.2.4.L123.B0
    •

  • Resolution: 1920x1080 (16:9)
    •

  • Frame Rate: 60000/1001 (59.94 fps)
    •

  • Scan Type: progressive
    •

  • Sample Aspect Ratio: 1:1
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422515620727200, d=480480, r=29


Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)


Representation ID: Audio2_2


  • Bandwidth: 128000 (128 kbps)
    •

  • Codecs: ac-4.02.01.00
    •

  • Audio Sample Rate: 48000 Hz
    •

  • Audio Channels: 2
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422515620727200, d=480480, r=29


Adaptation Set (Content: audio, Mime: audio/mp4, Lang: spa)


Representation ID: Audio3_3


  • Bandwidth: 128000 (128 kbps)
    •

  • Codecs: ac-4.02.01.00
    •

  • Audio Sample Rate: 48000 Hz
    •

  • Audio Channels: 2
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422515620727200, d=480480, r=29


Adaptation Set (Content: audio, Mime: audio/mp4, Lang: eng)


Representation ID: Audio4_4


  • Bandwidth: 128000 (128 kbps)
    •

  • Codecs: ac-4.02.01.00
    •

  • Audio Sample Rate: 48000 Hz
    •

  • Audio Channels: 2
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422515620727200, d=480480, r=29


Adaptation Set (Content: text, Mime: application/mp4, Lang: und)


Representation ID: Data5_5


  • Bandwidth: 50000 (50 kbps)
    •

  • Codecs: stpp.ttml.im1t
    •

  • Segment Template:
    • Timescale: 240000
      •

    • S: t=422515620727200, d=480480, r=29


Raw XML
<MPD availabilityStartTime="1970-01-01T00:00:00Z" maxSegmentDuration="PT2.002S" minBufferTime="PT10S" minimumUpdatePeriod="PT2S" profiles="urn:mpeg:dash:profile:isoff-live:2011" publishTime="2025-10-14T22:43:32Z" timeShiftBufferDepth="PT2M0S" type="dynamic" xmlns="urn:mpeg:dash:schema:mpd:2011" xmlns:cenc="urn:mpeg:cenc:2013" xmlns:dashif="https://dashif.org/" xmlns:scte214="urn:scte:dash:scte214-extensions" xmlns:scte35="http://www.scte.org/schemas/35/2016" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemalocation="urn:mpeg:dash:schema:mpd:2011 DASH-MPD.xsd http://dashif.org/guidelines/ContentProtection laurl.xsd">   <Period id="P0" start="PT0S">      <BaseURL>https://kbtc.atsc.stream/pbs/</BaseURL><AdaptationSet contentType="video" id="0" maxFrameRate="60000/1001" maxHeight="1080" maxWidth="1920" mimeType="video/mp4" minFrameRate="60000/1001" minHeight="1080" minWidth="1920" par="16:9" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-Y',{5 'TV-Y'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="video-$RepresentationID$-init.mp4" media="video-$RepresentationID$-$Time$.mp4v" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422515620727200"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="7000000" codecs="hev1.2.4.L123.B0" frameRate="60000/1001" height="1080" id="Video1_1" sar="1:1" scanType="progressive" width="1920"/></AdaptationSet><AdaptationSet contentType="audio" id="1" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-Y',{5 'TV-Y'}"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="main"/>         <SegmentTemplate initialization="audio-0-$RepresentationID$-init.mp4" media="audio-0-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422515620727200"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="128000" codecs="ac-4.02.01.00" id="Audio2_2"/></AdaptationSet><AdaptationSet contentType="audio" id="2" lang="spa" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-Y',{5 'TV-Y'}"/>         <SegmentTemplate initialization="audio-1-$RepresentationID$-init.mp4" media="audio-1-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422515620727200"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="128000" codecs="ac-4.02.01.00" id="Audio3_3"/></AdaptationSet><AdaptationSet contentType="audio" id="3" lang="eng" mimeType="audio/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-Y',{5 'TV-Y'}"/>         <SegmentTemplate initialization="audio-2-$RepresentationID$-init.mp4" media="audio-2-$RepresentationID$-$Time$.mp4a" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422515620727200"/>            </SegmentTimeline>         </SegmentTemplate>         <AudioChannelConfiguration schemeIdUri="urn:mpeg:mpegB:cicp:ChannelConfiguration" value="2"/>               <Representation audioSamplingRate="48000" bandwidth="128000" codecs="ac-4.02.01.00" id="Audio4_4"/></AdaptationSet><AdaptationSet contentType="text" id="4" lang="und" mimeType="application/mp4" segmentAlignment="true" startWithSAP="1"><Rating schemeIdUri="http://dashif.org/guidelines/dash-atsc-RRTrating:1" value="1,'TV-Y',{5 'TV-Y'}"/>         <SupplementalProperty schemeIdUri="http://dashif.org/guidelines/dash-atsc-closedcaption" value="ar:16-9;er:0;profile:0;3d:0"/>         <Role schemeIdUri="urn:mpeg:dash:role:2011" value="subtitle"/>         <SegmentTemplate initialization="data-0-$RepresentationID$-init.mp4" media="data-0-$RepresentationID$-$Time$.mp4s" timescale="240000">            <SegmentTimeline>               <S d="480480" r="29" t="422515620727200"/>            </SegmentTimeline>         </SegmentTemplate>               <Representation bandwidth="50000" codecs="stpp.ttml.im1t" id="Data5_5"/></AdaptationSet>   </Period></MPD>




Service 5010: ROXi (4.21)








Protocol: ROUTE

Category: App-Based Service


Source: 172.16.200.1

Destination: 239.255.4.21:5000


Hidden: No

App: ROXi




Service Details (from SLT)





  • Global Service ID: tag:sinclairplatform.com,2020:Roxi:komo
    •

  • Category: 3 (App-Based Service)
    •

  • SLS Destination: 239.255.4.21:5000
    •

  • SLS Source: 172.16.200.1
    •

  • SLS Protocol Version: . (ROUTE)
    •





User Service Description (ROUTE) Instance 1



Content TypeVersionUser AgentFilter Codes



Raw XML
<BundleDescriptionROUTE xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/ROUTEUSD/1.0/ ROUTEUSD-1.0-20170920.xsd"><UserServiceDescription serviceId="5010"></UserServiceDescription></BundleDescriptionROUTE>


Service Signaling (Metadata Envelope) 1



Content TypeVersion



Raw XML
<metadataEnvelope xmlns="urn:3gpp:metadata:2005:MBMS:envelope"><item metadataURI="usbd.rusd" contentType="application/route-usd+xml" version="1"></item><item metadataURI="held.held" contentType="application/atsc-held+xml" version="2"></item></metadataEnvelope>


HTML Entry-point Description (HELD) Instance 1

Raw XML
<HELD xmlns="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/AppSignaling/HELD/1.0/ HELD-1.0-20210312.xsd"><HTMLEntryPackage bbandEntryPageUrl="https://cdn.prod.tvapp.roxi.tv/releases/prod-atsc/index.html#/atsc,faststream,showId=46eb1cf29052,prod" appContextId="tag:sinclairplatform.com,2020:Roxi:komo" />
</HELD>




Other Global LLS Tables


System Time Details - Actual Timestamp in L1Detail




AttributeValue



currentUtcOffset37


utcLocalOffset-PT7H


dsStatustrue


dsDayOfMonth2


dsHour0




Raw XML
<?xml version="1.0" encoding="utf-8"?>
<SystemTime xmlns="http://www.atsc.org/XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="tag:atsc.org,2016:XMLSchemas/ATSC3/Delivery/SYSTIME/1.0/ SYSTIME-1.0-20211208.xsd" currentUtcOffset="37" utcLocalOffset="-PT7H" dsStatus="true" dsDayOfMonth="2" dsHour="0"/>



Input Info




AttributeValue



Input TypeDebug File


File Name4624-0-20251014-154300-p0p1-dbg.dbg


Total Packets Processed32547


File Last Modified2025-10-14 18:55:45 EDT


Analysis Run Time2025-11-22 06:00:39 EST




ATSC 3.0 Data Usage Analysis





IP:Port (ID)Usage ↓ServiceTypeTotal DataBitrate



  239.255.7.1:5001 (TSI 100)

 27.34%
  KIRO
  Video
  15.21 MB
  N/A




  239.255.4.1:5001 (TSI 100)

 27.26%
  KOMO
  Video
  15.17 MB
  N/A




  239.255.51.1:5001 (PID 100)

 17.38%
  KUNS
  Video
  9.67 MB
  N/A




  239.255.51.1:5001 (PID 63061)

 2.34%
  KUNS
  Data/Captions
  1.30 MB
  N/A




  239.255.51.1:5001 (PID 200)

 1.62%
  KUNS
  Audio
  903.9 KB
  N/A




  239.255.4.1:5001 (TSI 200)

 1.54%
  KOMO
  Audio
  854.8 KB
  N/A




  239.255.7.1:5001 (TSI 0)

 1.01%
  KIRO
  Service Signaling
  562.3 KB
  N/A




  224.0.23.60:4937 (LLS)

 0.97%
  LLS Signaling
  LLS Signaling
  540.2 KB
  N/A




  239.255.4.1:5001 (TSI 0)

 0.73%
  KOMO
  Service Signaling
  403.8 KB
  N/A




  239.255.51.1:5100 (TSI 80)

 0.49%
  ESG
  ROUTE Media
  270.6 KB
  N/A




  239.255.7.1:5001 (TSI 200)

 0.36%
  KIRO
  Audio
  201.9 KB
  N/A




  239.255.51.1:5100 (TSI 0)

 0.30%
  ESG
  Service Signaling
  164.8 KB
  N/A




  239.255.51.1:5001 (PID 0)

 0.23%
  KUNS
  Service Signaling
  127.5 KB
  N/A




  239.255.28.11:5000 (TSI 0)

 0.22%
  KBTC-VC
  Service Signaling
  120.1 KB
  N/A




  239.255.7.1:5001 (TSI 201)

 0.20%
  KIRO
  Audio
  111.0 KB
  N/A




  239.255.4.1:5001 (TSI 201)

 0.18%
  KOMO
  Audio
  101.7 KB
  N/A




  239.255.4.11:5000 (TSI 0)

 0.18%
  PBTV
  Service Signaling
  100.5 KB
  N/A




  239.255.4.10:5000 (TSI 0)

 0.16%
  T2
  Service Signaling
  90.6 KB
  N/A




  239.255.51.1:5100 (TSI 50)

 0.16%
  ESG
  ROUTE Media
  89.8 KB
  N/A




  239.255.51.1:5100 (TSI 60)

 0.16%
  ESG
  ROUTE Media
  89.6 KB
  N/A




  239.255.4.20:5000 (TSI 0)

 0.09%
  GMLOOP
  Service Signaling
  49.2 KB
  N/A




  239.255.4.21:5000 (TSI 0)

 0.09%
  ROXi
  Service Signaling
  48.4 KB
  N/A




  239.255.51.1:5001 (PID 300)

 0.08%
  KUNS
  stpp
  43.0 KB
  N/A




  239.255.7.1:5001 (TSI 300)

 0.07%
  KIRO
  Captions
  38.4 KB
  N/A




  239.255.51.100:6000 (TSI 0)

 0.04%
  DDAAS
  Service Signaling
  22.6 KB
  N/A




  239.255.4.1:5001 (TSI 300)

 0.02%
  KOMO
  Captions
  10.6 KB
  N/A






Total: 55.64 MB | Signaling: 4.01% | Media: 79.20% | Other: 0.00%
